Jvc Ux-g6 User manual

Safety precautions ----------------------------------- 1-2

Important for laser products ----------------------- 1-3

Preventing static electricity ------------------------- 1-4

Attention at repair reception ----------------------- 1-5

Instructions (UX-G6) --------------------------------- 1-6 - 15

AX-UXG6 ----------------------------------------------- 2-1

XT-UXG6 ----------------------------------------------- 2-11

TD-UXG6 ----------------------------------------------- 2-31

SP-UXG6 ----------------------------------------------- 2-46

Standard schematic diagrams -------------------- 2-47

Printed circuit boards -------------------------------- 2-56 - 60

Parts List ------------------------------------------------ 3-1 - 31

Contents

MICRO COMPONENT SYSTEM

SERVICE MANUAL

UX-G6/FS-G6

No.20808

Feb. 2000

Unit composition

Contents Model Name

STEREO AMPLIFIER AX-UXG6

CD / TUNER XT-UXG6

CASSETTE DECK TD-UXG6

SPEAKER SYSTEM SP-UXG6

MIC RO COMPONENT SYSTEM UX-G6R

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

1BIT P•E•M D•D•CONVERTER

PHONES

COMPACT

DIGITALAUDIO

REC PAUSE

DOLBY B NR

AUTO

REVERSE

REC

DOWN

SET

ENTER

AUTOPRESET

PLAY MODE

FM MODE

CANCEL

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

DISPLAY

/CHARA.

ACTIVE

BASS EX.

PTY/EON

VOLUME

FM/AM

–

CDTAPE

Area Suffix (UX-G6)

UB ............. Hong Kong

UP ..................... Korea

U............... Other Areas

UX-G6/FS-G6

< ATTENTION >

When this model is repaired, a part of unit of “UX-G6/FS-G6”is necessary.

(Please refer to page 1-5)

Area Suffix (FS-G6)

J ......... U.S.A./ Canada

We will separately issue the

parts list of J version.

1-2

Safety Precautions

1.This design of this product contains special hardware and many circuits and components specially

for safety purposes. For continued protection, no changes should be made to the original design

unless authorized in writing by the manufacturer. Replacement parts must be identical to those

used in the original circuits. Services should be performed by qualified personnel only.

2. Alterations of the design or circuitry of the product should not be made. Any design alterations of

the product should not be made. Any design alterations or additions will void the manufacturer`s

warranty and will further relieve the manufacture of responsibility for personal injury or property

damage resulting therefrom.

3. Many electrical and mechanical parts in the products have special safety-related characteristics.

These characteristics are often not evident from visual inspection nor can the protection afforded

by them necessarily be obtained by using replacement components rated for higher voltage,

wattage, etc. Replacement parts which have these special safety characteristics are identified in

the Parts List of Service Manual. Electrical components having such features are identified by

shading on the schematics and by ( ) on the Parts List in the Service Manual. The use of a

substitute replacement which does not have the same safety characteristics as the recommended

replacement parts shown in the Parts List of Service Manual may create shock, fire, or other

hazards.

4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the

like to be separated from live parts, high temperature parts, moving parts and/or sharp edges

for the prevention of electric shock and fire hazard. When service is required, the original lead

routing and dress should be observed, and it should be confirmed that they have been returned

to normal, after re-assembling.

5. Leakage currnet check (Electrical shock hazard testing)

After re-assembling the product, always perform an isolation check on the exposed metal parts

of the product (antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control

shafts, etc.) to be sure the product is safe to operate without danger of electrical shock.

Do not use a line isolation transformer during this check.

Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure

the leakage current from each exposed metal parts of the cabinet , particularly any exposed

metal part having a return path to the chassis, to a known good earth ground. Any leakage

current must not exceed 0.5mA AC (r.m.s.)

Alternate check method

Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms

per volt or more sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by

a 0.15 F AC-type capacitor between an exposed

metal part and a known good earth ground.

Measure the AC voltage across the resistor with the

AC voltmeter.

Move the resistor connection to eachexposed metal

part, particularly any exposed metal part having a

return path to the chassis, and meausre the AC

voltage across the resistor. Now, reverse the plug in

the AC outlet and repeat each measurement. voltage

measured Any must not exceed 0.75 V AC (r.m.s.).

This corresponds to 0.5 mA AC (r.m.s.).

Warning

1.This equipment has been designed and manufactured to meet international safety standards.

2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.

3. Repairs must be made in accordance with the relevant safety standards.

4. It is essential that safety critical components are replaced by approved parts.

5. If mains voltage selector is provided, check setting for local voltage.

Good earth ground

Place this

probe on

each exposed

metal part.

AC VOLTMETER

(Having 1000

ohms/volts,

or more sensitivity)

1500 10W

0.15 F AC TYPE

CAUTION

Burrs formed during molding may be left over on some parts of the chassis. Therefore,

pay attention to such burrs in the case of preforming repair of this system.

UX-G6/FS-6G

1-3

UX-G6/FS-G6

Important for laser products

1.CLASS 1 LASER PRODUCT

2.DANGER : Invisible laser radiation when open and inter

lock failed or defeated. Avoid direct exposure to beam.

3.CAUTION : There are no serviceable parts inside the

Laser Unit. Do not disassemble the Laser Unit. Replace

the complete Laser Unit if it malfunctions.

4.CAUTION : The compact disc player uses invisible

laserradiation and is equipped with safety switches

whichprevent emission of radiation when the drawer is

open and the safety interlocks have failed or are de

feated. It is dangerous to defeat the safety switches.

5.CAUTION : If safety switches malfunction, the laser is able

to function.

6.CAUTION : Use of controls, adjustments or performance of

procedures other than those specified herein may result in

hazardous radiation exposure.

VARNING : Osynlig laserstrålning är denna del är öppnad

och spårren är urkopplad. Betrakta ej strålen.

VARO : Avattaessa ja suojalukitus ohitettaessa olet

alttiina näkymättömälle lasersäteilylle.Älä katso

säteeseen.

ADVARSEL : Usynlig laserstråling ved åbning , når

sikkerhedsafbrydere er ude af funktion. Undgå

udsættelse for stråling.

ADVARSEL : Usynlig laserstråling ved åpning,når

sikkerhetsbryteren er avslott. unngå utsettelse

for stråling.

REPRODUCTION AND POSITION OF LABELS

WARNING LABEL

DANGER : Invisibie laser radiation

when open and interlock or

defeated.

AVOID DIRECT EXPOSURE TO

BEAM (e)

VARNING : Osynlig laserstrålning är

denna del är öppnad och spårren är

urkopplad. Betrakta ej strålen. (s)

VARO : Avattaessa ja suojalukitus

ohitettaessa olet alttiina

näkymättömälle lasersäteilylle.Älä

katso säteeseen. (f)

ADVARSEL :Usynlig laserstråling

ved åbning , når

sikkerhedsafbrydere er ude af

funktion. Undgå udsættelse for

stråling. (d)

CLASS 1

LASER PRODUCT

CAUTION

Please use enough caution not to

see the beam directly or touch it

in case of an adjustment or operation

check.

1-4

UX-G6/FS-G6

Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged,

can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.1. Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.

Be careful to use proper grounding in the area where repairs are being performed.

1.1.1. Ground the workbench

1. Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over

it before placing the traverse unit (optical pickup) on it.

1.1.2. Ground yourself

1. Use an anti-static wrist strap to release any static electricity built up in your body.

1.1.3. Handling the optical pickup

1. In order to maintain quality during transport and before installation, both sides of the laser diode on the

replacement optical pickup are shorted. After replacement, return the shorted parts to their original condition.

(Refer to the text.)

2. Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power

source can easily destroy the laser diode.

1.2. Handling the traverse unit (optical pickup)

1. Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.

2. Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific

details, refer to the replacement procedure in the text. Remove the anti-static pin when replacing the traverse

unit. Be careful not to take too long a time when attaching it to the connector.

3. Handle the flexible cable carefully as it may break when subjected to strong force.

4. It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it

Conductive material

(conductive sheet) or iron plate

(caption)

Anti-static wrist strap

1-5

UX-G6/FS-G6

When this model is repaired, a part of unit of "UX-G6/FS-G6" is necessary.

A necessary unit is described to rear panel.

Please keep the unit from the customer together when you repair this model.

< ATTENTION >

NOTE:

NEED & XT-UXG6

WHEN SERVICING

REAR SIDE

Unit necessary for repair

XT-UXG6

AX-UXG6

NOTE:

NEED AX-UXG6

WHEN SERVICING

Unit necessary for repair

AX-UXG6

XT-UXG6

REAR SIDE

NOTE:

NEED AX-UXG6

& XT-UXG6

WHEN SERVICING

Unit necessary for repair

AX-UXG6

XT-UXG6

TD-UXG6

REAR SIDE

Attention at repair reception

1-6

UX-G6/FS-G6

Instructions (UX-G6)

COMPACT DISC/TUNER

CASSETTE DECK

For Customer Use:

Enter below the Model No. and Serial

No. which are located either on the rear,

bottom or side of the cabinet. Retain this

information for future reference.

Model No.

Serial No.

LVT0377-005A

[U, UB, US]

UX-G6

Consists of AX-UXG6, XT-UXG6, TD-UXG6,

and SP-UXG6.

MICRO COMPONENT SYSTEM

INSTRUCTIONS

MANUAL DE INSTRUCCIONES

MICRO COMPONENT SYSTEM UX-G6

MOS- FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

1BI T P•E•M D•D•CONVERTER

PHONES

COMPACT

DIGITAL AUDIO

REC PAUSE

DOLBY B NR

AUTO

REVERSE

REC

DOWN

SET

ENTER

AUTOPRESET

PLAY MODE

FM MODE

CANCEL

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

DISPLAY

/CHARA.

ACTIVE

BASSEX.

VOLUME

FM/AM

47¢

–

CDTAPE

STEREO AMPLIFIER

AX-UXG6

XT-UXG6

TD-UXG6

SP-UXG6

SPEAKER SYSTEM

WARNING :SHOCK HAZARD

- DO NOT OPEN

AVIS: RISQUE DE

CHOC ELECTRIQUE

- NE PAS OUVRIR

VICTOR COMPANY OF JAPAN,LIMITED

UNPLUG MAINS (AC) CORD

FROM WALL OUTLET,WHEN

CONNECTING THIS.

NOTE

NEED T-U G6

WHEN SERVICING

CAUTION: SPEAKER IMPEDANCE

6 16Ω

FROM CONNECTOR-A OF T-U G6

RIGHT LEFT

SUB WOOFER OUT

SPEAKERS AC IN

CONNECTOR-A

STEREO AMPLIFIER

MODEL NO. A -U G6

SYSTEN NO.U -G6

AC 115V/230V

50/60Hz 54W

110-120V 220-240V

VOLTAGE SELECTOR

115V 230V

VOLTAGE SELECTOR

[A] [B]

115V 230V

VOLTAGE SELECTOR

0100JTMMDWJSCEN, SP, CH

Mains (AC) Line Instruction (not applicable for Europe, U.S.A., Canada, Australia and U.K.)

Instrucción sobre la línea de la red (CA) (no aplicable para Europa, EE.UU., Canadá, Australia, ni el Reino

Unido)

VICTOR COMPANY OF JAPAN, LIMITED

CAUTION for mains (AC) line

BEFORE PLUGGING IN, do check that your mains

(AC line voltage corresponds with the position of the

voltage selector switch provided on the outside of this

equipment and, if different, reset the voltage selector

switch, to prevent from a damage or risk of fire/

electric shock.

PRECAUCIÓN

para la línea de la red (CA)

ANTES DE ENCHUFAR EL EQUIPO, compruebe si la

tensión de la línea de la red (CA corresponde con la

posición del selector de tensión situado en la parte

exterior del equipo, y si es diferente, reajuste el selector

de tensión para evitar el riesgo de incendios/descargas

eléctricas.

Notes on [B] t pe voltage selector

115 V position of the selector covers from 110 V to

120 V in service, and 230 V position covers from 220

V to 240 V in service.

Notas sobre el selector de tensión tipo [B]

La posición de 115v del selector cubre desde 110 V

hasta 120 V en funcionamiento, y la posición de 230 V

cubra desde 220 V hasta 240 V en funcionamiento.

Warnings, Cautions and Others

Avisos, recauciones y otras notas

– G-1 –

Caution –– switch!

Disconnect the mains plug to shut the power off completely (the

STANDBY/ON lamp goes off).

The switch in any position does not disconnect the mains

line.

•When the unit is on standby, the STANDBY/ON lamp lights

red.

•When the unit is turned on, the STANDBY/ON lamp lights

green.

The power can be remote controlled.

Precaución –– Interru tor !

Desconecteel enchufe de la redpara desconectar la alimentación

por completo (la lámpara STANDBY/ON se apaga).

Elinterruptor no desconectarácompletamentela alimentación

principal, cualquiera que sea su posición.

•Cuando la unidad estáen espera, la lámpara STANDBY/ON

se enciende en rojo.

•Cuando conecta la unidad, la lámpara STANDBY/ON se

enciende en verde.

La alimentacion puede ser controlada a distancia.

The STANDBY/ON lam

Lám ara STANDBY/ON

1BIT P•E•MD•D•CONVERTER

PHONES

COMPACT

DIGITAL AUDIO

MIC RO COMPONENT SYSTEM UX-G6

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

MOS - FET

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

PRECAUCIÓN

Para reducir riesgos de choques eléctricos, incendio, etc.:

1. No extraiga los tornillos, los cubiertas ni la caja.

2. No exponga este aparato a la lluvia o a la humedad.

–G-2 –

1-7

UX-G6/FS-G6

Caution: Pro er Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:

1 Front: No obstructions and open spacing.

2 Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.

3 Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand

with a height of 10 cm or more.

Precaución: el a arato debe estar bien ventilado

Para evitar posibles riesgos de descargas eléctricas e incendios y prevenir cualquier posible daño, coloque el

aparato del modo siguiente:

1 Parte delantera: No ponga nada delante, deje el espacio libre.

2 Laterales/ parte superior/ parte trasera: No se debería colocar nada en las áreas y las distancias que se

detallan a continuación.

3 Parte inferior: Coloque el aparato sobre una superficie recta. Debe haber buena circulación de aire; para

ello, coloque el aparato sobre una base a una altura mínima de 10 cm.

–G-3 –

1 cm

15 cm

15 cm 15 cm

10 cm

1 cm 15 cm 15 cm

AX-UXG6

TD-UXG6

XT-UXG6

XM-G6

AX-UXG6

TD-UXG6

XT-UXG6

XM-G6

Front view Side view

Vista frontal Vista lateral

REPRODUCTION OF LABELS / REPRODUCCIÓN DE ETIQUETAS /

IMPORTANT FOR LASER PRODUCTS

IMPORTANTE PARA PRODUCTOS LÁSER

1 CLASSIFICATION LABEL, PLACED ON EXTERIOR

SURFACE 1

1 ETIQUETA DE CLASIFICACION, PROVISTA SOBRE LA

SUPERFICIE EXTERIOR

2 WARNING LABEL, PLACED INSIDE THE UNIT

2 ETIQUETA DE ADVERTENCIA, PEGADA EN EL

INTERIOR DE LA UNIDAD

CLASS 1

LASER PRODUCT

1. CLASS 1 LASER PRODUCT

2. DANGER: Invisible laser radiation when open and interlock failed

or defeated. Avoid direct exposure to beam.

3. CAUTION: Do not open the top cover. There are no user

serviceable parts inside the Unit; leave all servicing to qualified

service personnel.

1. PRODUCTO LÁSER CLASE 1

2. PELIGRO: En el interior hay radiación láser invisible. Evite el

contacto directo con el haz.

3. PRECAUCIÓN: No abra la tapa superior. En el interior de la

unidad no existen piezas reparables por el usuario; deje todo

servicio técnico en manos de personal calificado.

–G-4 –

DANGER: Invisible laser

radiation when open and

interlock failed or defeated.

AVOID DIRECT EXPOSURE

TO BEAM. (e)

ADVARSEL: Usynlig laser-

stråling ved åbning, når

sikkerhedsafbrydere er ude

af funktion. Undgåudsæt-

telse for stråling (d)

VARNING: Osynlig laser-

strålning när denna del är

öppnad och spärren är

urkopplad. Betrakta ej

strålen. (s)

VARO: Avattaessa ja suo-

jalukitus ohitettaessa olet

alttiina näkymättömälle

lasersäteilylle. Äläkatso

säteeseen. (f)

English

Power sources

• When unplugging from the wall outlet, always pull the

plug, not the AC power cord.

DO NOT handle the AC power cord with wet

hands.

Moisture condensation

Moisture may condense on the lens inside the units in the

following cases:

• After starting heating in the room

• In a damp room

• If the units are brought directly from a cold to a warm

place

Should this occur, the system may malfunction. In this case,

leave the units turned on for a few hours until the moisture

evaporates, unplug the AC power cord, and then plug it in

again.

Others

• Should any metallic object or liquid fall into a unit, unplug

the units and consult your dealer before operating any

further.

• If you are not going to operate the units for an extended

period of time, unplug the AC power cord from the wall

outlet.

DO NOT disassemble the units since there are

no user serviceable parts inside.

If anything goes wrong, unplug the AC power cord and

consult your dealer.

About This Manual

This manual is organized as follows:

• The manual mainly explains operations using the buttons

and controls on the units. You can also use the buttons

on the remote control if they have the same or similar

names (or marks as those on the units.

If operation using the remote control is different from

that using each unit, it is then explained.

• Basic and common information that is the same for many

functions is grouped in one place, and is not repeated in

each procedure. For instance, we do not repeat the

information about turning on/off the system, setting the

volume, changing the sound effects, and others, which

are explained in the section “Basic Settings” and

“Common Operations” on pages 10 to 13.

• The following marks are used in this manual:

Gives you warnings and cautions to

prevent from a damage or risk of fire/

electric shock.

Also gives you information which is not

good for obtaining the best possible

performance from the units.

Gives you information and hints you had

better know.

Precautions

Installation

• Install in a place which is level, dry and neither too hot

nor too cold — between 5˚C and 35˚C.

• Install the units in a location with adequate ventilation to

prevent internal heat buildup in the units.

• Leave sufficient distance between the units and the TV.

• Keep the speakers away from the TV to avoid interference

with TV.

DO NOT install the units in a location near heat

sources, or in a place subject to direct sunlight,

excessive dust or vibration.

We would like to thank you for urchasing one of our JVC roducts.

Before o erating this micro com onent system, read this manual carefully

and thoroughly to obtain the best ossible erformance from your system,

and retain this manual for future reference.

Introduction

English

Contents

Introduction .......................................................... 1

About This Manual ............................................................... 1

Precautions ........................................................................... 1

Contents ................................................................. 2

Location of the Buttons and Controls................. 3

Front Panels .......................................................................... 4

Remote Control .................................................................... 5

Getting Started...................................................... 6

Unpacking ............................................................................ 6

Putting the Batteries into the Remote Control ..................... 6

Connecting the System Control Cables and the External

Wire .................................................................................. 6

Connecting MD Recorder XM-G6 ....................................... 7

Connecting Sub Woofer System ........................................... 7

Connecting Antennas............................................................ 7

Connecting Speakers ............................................................ 8

Connecting Other Equipments ............................................. 9

Basic Settings ...................................................... 10

Setting the Clock ................................................................ 10

Setting the Display Illumination (Dimmer ....................... 10

Common Operations .......................................... 11

Adjusting the Voltage Selector ........................................... 11

Turning On the Power and Selecting the Sources .............. 11

Adjusting the Volume ......................................................... 12

Reinforcing the Bass Sound ............................................... 12

Adjusting Bass and Treble Sounds ..................................... 12

Operating the Sliding Panel................................................ 13

Listening to the External Equipment .................................. 13

Listening to FM and AM Broadcasts ................ 14

Setting the AM Tuner Interval Spacing .............................. 14

Tuning in a Station ............................................................. 14

Presetting Stations .............................................................. 15

Pla ing Back a CD.............................................. 16

Playing Back the Entire Disc — Normal Play ................... 16

Searching and Skipping Tracks .......................................... 17

Programing the Playing Order of the Tracks

— Program Play ............................................................. 17

Playing at Random — Random Play .................................. 19

Repeating Tracks — Repeat Play ....................................... 19

Pla ing Back a Tape ........................................... 20

Playing Back a Tape — Basic Operation ........................... 20

Fast-Winding a Tape ........................................................... 21

Searching and Skipping to Each Program

— Music Scan ................................................................ 21

Playing Back Dolby-Recorded Tape .................................. 21

Recording onto a Tape........................................ 22

Manual Recording onto a Tape ........................................... 22

Recording in Auto Reverse ................................................ 23

Synchronized Recording from a CD .................................. 24

Recording from the External Equipment ........................... 24

Using the Timers ................................................. 25

Using Recording Timer ...................................................... 25

Using Daily Timer .............................................................. 26

Using Sleep Timer .............................................................. 28

Timer Priority ..................................................................... 28

Maintenance and Additional Information ........ 29

Handling CDs ..................................................................... 29

Handling Cassette Tapes .................................................... 30

Types of Cassette Tapes...................................................... 30

Troubleshooting .................................................. 31

Specifications....................................................... 32

1-8

UX-G6/FS-G6

English

Location of the Buttons and Controls

XT-UXG6

Compact Disc

/Tuner

AX-UXG6

Stereo Amplifier

TD-UXG6

Cassette Deck

Display window

Front Panels

REC BASS

1234

Become familiar with the buttons and controls on the units.

MI CR O COMPONENT SYSTEM UX-G6

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

PHONES

1BIT P•E•MD•D•CONVERTER

COMPACT

DIGITAL AUDIO

REC PAUSE

DOLBY B NR

AUTO

REVERSE

REC

;

English

Front Panels

AX-UXG6 Stereo Amplifier

1 button and STANDBY/ON lamp (11 *

2MULTI JOG dial

3FM/AM button (14 *

4OPEN/CLOSE button (13 *

5Display window

6VOLUME dial (12

7AUX button (13, 24 *

XT-UXG6 Compact Disc/Tuner

8CD tray

9Remote sensor (5

pPHONES jack (12

q0 (open/close button for CD tray (16 *

w6 (play/pause button (17 *

e7 (stop button (17

TD-UXG6 Cassette Deck

rπ (auto-reverse button and lamp (20, 23

tDOLBY B NR button and lamp (21, 23

yREC PAUSE button (22

uTape operations indicators (20, 22

• Tape direction (2 / 3 and REC indicators

i0 (open/close button for Tape tray (20 *

(playback button (20 *

;7 (stop button (21

aTape tray

To press the buttons suffixed with * mark also

turns on the s stem.

Display window

1Timer mode indicators

• REC (recording timer and DAILY (daily

timer indicators

2CD playback mode indicators

• PROGRAM, RANDOM, (repeat 1 ,

and (repeat all mode indicators

3FM mode indicators

• STEREO and MONO indicators

4BASS indicator

Buttons behind the sliding panel

1DISPLAY/CHARA. button **

24 button (14, 17, 18, 21

3¢ button (14, 17, 18, 21

4SET button (18, 25

5CANCEL button (10, 18, 25

6ENTER button **

7PLAY MODE button (17

8REC MODE button (24

9TITLE/EDIT button **

pCLOCK/TIMER button (10, 25

** Used only with MiniDisc recorder XM-G6

(not supplied .

• DO NOT operate any button and control until

the system setup is completed.

• DO NOT operate the sliding panel by hands,

otherwise it will cause serious damages on the

sliding mechanism (see page 13 .

MOS - FET

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

12345 6 7 8 9 p

MICROCOMPONENTSYSTEMUX-G6

OPEN/CLOSE

AUX

VOLUME

MULTI

FM/AM

STANDBY/ON

JOG

SET

4¢

Continued

English

VOLUME

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

TAPE

FM/AM

DOWN

SET

AUX

;

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASS EX.

Remote Control

When using the remote control, point it at

the remote sensor on the front panel.

Remote Control

1PANEL OPEN/CLOSE button (13

2CLOCK/TIMER button (10, 25

3ACTIVE BASS EX. (extension button (12

4TREBLE button (12

5BASS button (12

6REPEAT button (19

7PLAY MODE button (17

8TITLE/EDIT button *

9UP button (12, 14, 17

pDISPLAY/CHARA. button *

qSET button (18, 25

w< (left cursor button (10, 17, 25

eDOWN button (12, 14, 17

rMD 6 (play/pause button *

tFM/AM button (14

yTAPE

(playback button (20

u7 (stop button (17, 21

i4 button (14, 17, 18, 21

oDIMMER button (10

;(standby/on button (11

aSLEEP button (28

sFM MODE button (15

dAUTO PRESET button (15

fENTER button *

gCANCEL button (10, 18, 25

h> (right cursor button (10, 17, 25

jAUX button (13, 24

kCD 6 (play/pause button (17

l¢ button (14, 17, 18, 21

/VOLUME +/– button (12

* Used only with MiniDisc recorder XM-G6 (not

supplied .

To operate the s stem correctl using the remote

control

Before using these buttons:

For Tuner operations, press FM/AM button on the

remote control first.

For CD operations, press CD 6 (play/pause

button on the remote control first.

For Tape operations, press TAPE 23 (playback

button on the remote control first.

Become familiar with the buttons on the remote control.

Continued

1BIT P•E•MD•D•CONVERTER

PHONES

COMPACT

DIGITAL AUDIO

REC PAUSE

DOLBYB NR

AUTO

REVERSE

REC

MICRO COMPONENT SYSTE M UX-G6

MOS- FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

AUTOPRESET

PLAY MODE

FM MODEBASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6R

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASSEX.

Remote

Sensor

English

Unpacking

After unpacking, check to be sure that you have all the

following items.

The number in the parentheses indicates the quantity of the

pieces supplied.

• AM loop antenna (1

• FM antenna (1

• Remote control (1

• Batteries (2

• Speaker cords (2

• External wire (1

If any is missing, consult your dealer immediately.

Putting the Batteries into the Remote

Control

Insert the batteries — R6P (SUM-3 /AA (15F — into the

remote control, by matching the polarity (+ and – on the

batteries with the + and – markings on the battery

compartment.

When the remote control can no longer operate the units,

replace both batteries at the same time.

• DO NOT use an old battery together with a new

one.

• DO NOT use different types of batteries together.

• DO NOT expose batteries to heat or flame.

• DO NOT leave the batteries in the battery

compartment when you are not going to use the

remote control for an extended period of time.

Otherwise, it will be damaged from battery

leakage.

Connecting the System Control Cables and

the External Wire

UX-G6 micro component system consists of three units,

AX-UXG6 Stereo Amplifier, XT-UXG6 Compact Disc/

Tuner, TD-UXG6 Cassette Deck, and SP-UXG6 Speaker

System.

You can easily connect these units using the system control

cables equipped on the rear panel of the units.

•To prevent malfunction, connect the external wire as

illustrated.

DO NOT change vertical stacking order of the

units as illustrated to avoid heat buildup.

•To connect the cables, press the middle of the connector

body until it clicks into the connector on the rear panel.

•To disconnect, if needed, pull the connector out pushing

both sides of the connector body. Never pull out the cables

themselves.

When connecting the s stem control cables to

the connectors

Make sure to connect the cable to the connector

having the same name such as “FROM

CONNECTOR-A” and “TO CONNECTOR-A.”

Getting Started

To connect To disconnect

R6P(SUM-3)/AA(15F)

AX-UXG6

TD-UXG6

FROM CONNECTOR-A

TO CONNECTOR-A

FROM CONNECTOR-B

TO CONNECTOR-B

External wire

(supplied)

XT-UXG6

VOLTAGESELECTOR

1-9

UX-G6/FS-G6

English

Connecting Antennas

Supplied FM antenna

Attach the FM antenna to the FM 75 Ω COAXIAL

terminal on the rear panel of XT-UXG6.

Extend the FM antenna.

Fasten it up in the position which gives ou the

best reception.

About the supplied FM antenna

The FM antenna supplied with this unit can only be

used as temporary measure. If reception is poor,

you can connect an outdoor FM antenna.

To connect an outdoor FM antenna

Before connecting it, disconnect the supplied FM antenna.

Connecting MD Recorder XM-G6

You can also connect the MD recorder XM-G6 (not

supplied , specifically designed for UX-G6. This unit will

complete UX-G6 micro component system.

When you connect and use this unit, refer to the Instructions

supplied with it for details.

• DO NOT install XM-G6 until you turn off the

system and unplug the AC power code, otherwise

installation should fail to damage the system.

• DO NOT change the vertical stacking order of XM-

G6 as illustrated to avoid heat buildup.

Connecting Sub Woofer System

When using JVC external sub woofer system, connect

audio cable between AX-UXG6’s SUB WOOFER OUT

jack and the input of your sub woofer system.

ANTENNA

LOOP

FM 75

COAXIAL

Outdoor FM antenna

(not supplied)

A 75Ωantenna with coaxial type connector

(DIN 45325) should be used.

ANTENNA

LOOP

FM 75

COAXIAL

SUBWOOFER OUT

AX-UXG6

Sub Woofer System

(not supplied)

Audio cable

(not supplied)

AX-UXG6

VOLTAGESELECTOR

Continued

XM-G6

XT-UXG6

Optical digital cable

(supplied with XM-G6)

FROM CONNECTOR-C

TO CONNECTOR-C

External wire

(supplied with UX-G6)

External wire

(supplied with XM-G6)

AX-UXG6

VOLTAGESELECTOR

English

RIGHT LEFT

SPEAKERS

12, 3

Connecting Speakers

You can connect the speakers using the speaker cords.

Open the speaker terminal.

Insert the end of the speaker cord to the terminal.

Match the polarity of the speaker terminals: Red (+

to red (+ and black (– to black (– .

Close the speaker terminal on the rear of the unit.

When connecting speaker cords

• Make sure to connect the cords correctly following

the right series of above steps.

During operation, wrong connection or a short

circuit make the power turned off to protect the

system.

The clock loses the setting and is reset to “0:00”.

Also the MD recording may fail.

• Use only speakers with the same speaker

impedance as indicated by the speaker terminals

on the rear of the unit.

AM antenna

Vinyl-covered wire

(not supplied)

AM loop antenna (supplied)

Red

Black

Speaker Cord

Left speaker

Right speaker

Continued

Connect the AM loop antenna to the AM LOOP

terminals as illustrated.

Turn the AM loop antenna until ou have the best

reception.

To connect an external AM antenna

When reception is poor, connect a single vinyl-covered

wire to the AM EXT terminal and extend it horizontally.

(The AM loop antenna must remain connected.

For better reception of both FM and AM

• Make sure the antenna conductors do not touch

any other terminals and connecting cables.

• Keep the antennas away from metallic parts of

the units, connecting cables, and the AC power

cord.

LOOP

FM 75

COAXIAL

ANTENNA

EXT

English

(AC wall outlet)

To ANALOG IN

To DIGITAL OUT

To audio output

XT-UXG6

To optical digital input

VOLTAGESELECTOR

Connecting Other Equipments

You can connect the following equipments to the system:

• Audio equipment — used only as an analog playback

device.

• Audio equipment with an optical digital input terminal

— used as a digital recording device.

When you connect and use these equipments, refer also to

the manuals supplied with them.

To connect audio equipment without a digital

output terminal

Connect the audio output jacks on the other equipment and

the ANALOG IN jacks, using an audio cable (not supplied .

Be sure that the plugs of the audio cables and the jacks on

the rear panel of the unit are color coded: White plugs and

jacks are for left audio signals, and red ones for right audio

signals.

• DO NOT connect other equipment while the

power is on.

• DO NOT plug in any equipment until all

connections are complete.

• By using audio cable (not supplied , connect

between the audio output jacks on the other

equipment and the ANALOG IN jacks.

Protective Plug

Before connecting the other equipment,

remove the protective plug from the terminal.

Continued

(AC wall outlet)

To ANALOG IN

XT-UXG6

To audio output

on the other equipment

VOLTAGESELECTOR

To connect audio equipment with an optical digital

input terminal

By using both an optical digital cable (not supplied and an

audio cable (not supplied , connect:

• Between the optical digital input terminal on the other

equipment and the optical digital output terminal on XT-

UXG6.

• Between the audio output jacks on the other equipment

and the ANALOG IN jacks.

NOW, ou can plug in the s stem and other connected

equipment FINALLY!

DO NOT plug in before setting the voltage selector

switch on the rear of the unit and all connection

procedure are complete (check to see page 11).

When connecting the AC power cord into a wall outlet, the

system switches to standby mode with STANDBY/ON lamp

lit red.

English

Basic Settings

Before operating the system any further, set the clock built

in this system first, then some other basic settings.

Setting the Clock

You can set the clock using the remote control whether

the system is turned on or turned off (i.e. standby mode .

Press CLOCK/TIMER button on the remote control.

The hour digit in the display window starts blinking.

Press < / > button on the remote control to adjust

the hour, then press SET button on the remote

control (rotating MULTI JOG dial also available).

•To correct the hour after pressing SET button, press

CANCEL button. The hour digit starts blinking again.

Press < / > button on the remote control to adjust

the minute, then press SET button on the remote

control (rotating MULTI JOG dial also available).

If there is a power failure

The clock loses the setting and is reset to “0:00.”

To adjust the clock again

You need to press CLOCK/TIMER button five

times until the clock setting mode is selected.

Setting the Display Illumination (Dimmer)

You can adjust the brightness of around the display window.

Each time you press DIMMER button, the display window

dims and brightens alternately.

•While the s stem is turned off:

Press DIMMER button, “DISPLAY OFF” appears in the

display window for a while and the system clock

disappears.

Press the button again, “DISPLAY ON” appears in the

display window for a while and only the system clock

become dimmed.

•While the s stem is turned on:

Press DIMMER button, both operating information and

indicators in the display window dims. The light around

MULTI JOG dial also becomes darker than usual.

Press the button again, all the illumination around the

display window recovers as usual.

Dimmer setting in the standb mode

Once the system is turned on, the dimmer setting in

the standby mode does affect neither normal

operations nor display indications.

MIC RO COMPONENT SYST EM UX -G6

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

MULTI JOG

Display window

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

SET

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASS EX.

DIMMER

CLOCK/TIMER

CANCEL

DOWN

SET

</ >

1-10

UX-G6/FS-G6

English

Common Operations

Here are basic and common things that apply to all the

operations of UX-G6 system.

Adjusting the Voltage Selector

Before plugging in the system, set the correct voltage for

your area with the voltage selector on the rear of AX-UXG6

unit.

[A]

[B]

Notes on [B] t pe voltage selector

115 V position of the selector covers from 110 V to

120 V in service, and 230 V position covers from

220 V to 240 V in service.

Turning On the Power and Selecting the

Sources

When you press a play button for example, like FM/AM,

CD 6 (play/pause , or TAPE 23 (playback , the system

automatically turns on and STANDBY/ON lamp lights

green.

One Touch Play

If any CD or a tape, or last tuned station provided, the system

starts playing that source.

To select the external equipment as the source, press MD

6 (play/pause or AUX button so that the system

automatically turns on.

Using button

•To turn on the s stem without pla ing,

press button so that STANDBY/ON lamp lights

green.

•To turn off the s stem (standb mode),

press again button so that STANDBY/ON lamp

lights red.

A little power is always consumed even while the system

is in standby mode.

MIC RO COMPONENT SYSTEM UX-G6

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

FM/AM

MULTI JOG VOLUME

AUX

OPEN/CLOSE

BASS

BASS indicator

STANDBY/ON

VOLUME

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

TAPE

FM/AM

DOWN

SET

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASS EX.

(standby/on)

CD 6(play/pause)

AUX

TAPE `(playback)

PANEL

OPEN/CLOSE

ACTIVE BASS EX.

TREBLE

BASS

FM/AM

VOLUME (+/–)

UP/DOWN

110-120V 220-240V

VOLTAGE SELECTOR

115V 230V

VOLTAGE SELECTOR

English

•To save the power consumption, make use of Dimmer

feature (see page 10 .

•To switch off the power suppl completel , unplug the

AC power cord from the AC outlet. STANDBY/ON lamp

goes off.

When ou unplug the AC power cord

or if a power failure occurs

The clock is reset to “0:00” right away, while the

tuner preset stations will be erased in a few days.

Adjusting the Volume

You can adjust the volume level only while the system is

turned on.

• Rotate VOLUME dial clockwise to increase the volume

level or counterclockwise to decrease it.

• Using VOLUME dial, rotating quickly makes a large

change in the volume level while rotating slowly makes a

step-by-step change.

• When using the remote control, press VOLUME + button

to increase the volume level or press VOLUME – button

to decrease it.

The volume level (from 0 to 50 appears in the display

window as follows:

For private listening

Connect a pair of headphones to the PHONES jack.

No sound comes out of the speakers. Be sure to turn

down the volume level before connecting or putting

headphones.

DO NOT turn off the system with the volume level set

to an extremely high level; otherwise, the sudden blast

of sound can damage your hearing, speakers and/or

headphones when you turn on the system or start

playing any source.

REMEMBER you cannot adjust the volume level while

the system is turned off.

Continued

Reinforcing the Bass Sound

The richness and fullness of the bass sound is maintained

regardless of how low you set the volume level.

You can use this effect only while listening sources.

•To get the effect, press ACTIVE BASS EX. button on

the remote control, and its indicator lights in the display

window.

•To cancel the effect, press the button again so that the

indicator goes off.

Adjusting Bass and Treble Sounds

You can adjust bass and treble sound effects with the remote

control, conforming to your preference and acoustic

surroundings.

You can use this effect only while listening sources.

To adjust the bass

Press BASS button.

The current level settings shortly appears as follows:

To exit from the level setting, press the button again.

Press UP/DOWN button to adjust the level.

• Press UP button to increase the bass tone level.

• Press DOWN button to decrease the bass tone level.

The bass level can be adjusted in seven steps from –3

through 0 to +3 (step “0” makes no effect .

To cancel the effect, adjust the level to “0.”

To adjust the treble

Press TREBLE button.

The current level settings shortly appears as follows:

To exit from the level setting, press the button again.

Press UP/DOWN button to adjust the level.

• Press UP button to increase the treble tone level.

• Press DOWN button to decrease the treble tone level.

The treble level can be adjusted in seven steps from –3

through 0 to +3 (step “0” makes no effect .

To cancel the effect, adjust the level to “0.”

1BIT P•E•MD•D•CONVERTER

PHONES

COMPACT

DIGITAL AUDIO

REC PAUSE

DOLBYB NR

AUTO

REVERSE

REC

MICRO COMPONENT SY STEM UX-G6

MOS- FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

PHONES jack

English

Operating the Sliding Panel

You can use the sliding panel to enable advanced operations

features provided for UX-G6 micro component system.

• Press OPEN/CLOSE button on the front panel (or PANEL

OPEN/CLOSE button on the remote control .

The sliding panel opens to uncover the inner buttons

behind the panel for further operations.

• Press OPEN/CLOSE button again.

The sliding panel automatically closes to hide the 10 inner

buttons.

Each time you press the button, the sliding panel opens and

closes repeatedly.

The buttons behind the sliding panel provided to control

various program settings such as playback, recording, and

presetting mode of each source. For details, refer to chapters

concerning to the particular unit.

When turning off the s stem

After pressing button, the system closes sliding

panel as well as other CD tray and Tape tray

automatically if they are still opened.

MOS - FET

MICROCOMPONENTSYSTEMUX-G6

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

Inner Buttons

OPEN/CLOSE

Continued

Listening to the External Equipment

You can listen to an external equipment such as MD recorder,

VCR, and other auxiliaries.

First make sure that the external equipment is properly

connected to the system (see page 7 and 9 . For operation

of the equipment, refer to its Instructions.

Press AUX button to select an external source.

• To play an audio equipment without optical digital

output, select AUX so that the following information

appears in the display window.

Start pla ing back the external equipment.

Adjust the volume level to the desired listening

level.

Appl other sound effects, if ou wish.

English

You can tune in FM and AM stations manually,

automatically, and use the preset station feature.

Setting the AM Tuner Interval Spacing

Some countries space AM stations 9 kHz apart, and some

countries use 10 kHz spacing.

When shipped, the built-in AM tuner is set to 9 kHz spacing.

•To set the frequenc spacing — on the front panel onl

Press FM/AM button first.

While pressing and holding 7 (stop button on XT-UXG6,

press FM/AM button on AX-UXG6 repeatedly to select

“AM–9kHz” or “AM–10kHz” appeared alternately in the

display window.

Tuning in a Station

Press FM/AM button.

The system automatically turns on and tunes in the last

tuned station (either FM or AM . The following

information appears in the display window.

• Each time you press the button, the band alternates

between FM and AM.

• If a program on FM band is broadcast in stereo,

STEREO indicator lights.

Select a station using one of the following three

methods.

•Manual Tuning

Opening the sliding panel, press 4 / ¢ (lower/

higher frequencies button repeatedly to change the

frequencies step by step until you find the desired

station.

•Auto Tuning

Opening the sliding panel, press and hold 4 / ¢

(lower/higher frequencies button for a second or more

to start searching a station and stop automatically until

the station of sufficient signal strength is tuned in.

•Preset Station Tuning

Rotate MULTI JOG dial clockwise to increase the

preset number or counterclockwise to decrease it

until the desired station is easily found.

Using the remote control:

UP/DOWN button on the remote control also has

the same function as MULTI JOG dial on the front

panel.

Listening to FM and AM Broadcasts

VOLUME

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

TAPE

FM/AM

DOWN

SET

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASS EX.

FM/AM

UP/DOWN

FM MODE

AUTO PRESE

SET

CANCEL

4/ ¢

PANEL

OPEN/CLOSE

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

SET

4¢SET CANCEL

Buttons behind the sliding panel

MIC RO COMPONENT SY STE M UX- G6

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

MULTI JOG

STEREO/MONO

indicator

FM/AM

OPEN/CLOSE

Preset number

1-11

UX-G6/FS-G6

English

The tuned station in step 1 is now stored in the

preset channel selected in step 3.

Storing a new station on an used channel

erases the previousl stored one.

To preset stations automatically — Auto Preset

You can automatically preset 30 FM, 15 AM stations. Preset

numbers will be allocated as stations are found, starting from

the lowest frequency and moving up to the higher frequency.

On the remote control onl :

Press FM/AM button to select a desired band.

Press and hold AUTO PRESET button on the

remote control for more than two seconds.

The system automatically starts searching for stations

with the strong signals continuously, and they are stored

successively into memory as follows:

When ou unplug the AC power cord

or if a power failure occurs

The preset stations will be erased in a few days.

If this happens, preset the stations again.

To change the FM reception mode

• When an FM stereo broadcast is hard to receive or noisy,

press FM MODE button on the remote control so that

MONO indicator lights in the display window. Reception

improves.

•To restore the stereo effect, press FM MODE button

again so that STEREO indicator lights in the display

window.

In this stereo mode, you can hear stereo sounds when a

program is broadcast in stereo.

Continued

Preset Station

You are possibly not allowed to use the feature until

the station presetting completes.

In some cases, test frequencies have been already

memorized for the system since the factory examined

the preset station features before shipment. This is

not a malfunction.

Presetting Stations

You can preset up to 30 FM and 15 AM stations into memory

by following two methods: manual/automatic presettings.

• There is a time limit in doing the following steps. If the

setting is canceled before you finish, start from step 1

again.

To preset stations manually — Manual Preset

Press 4 / ¢ (lower/higher frequencies) button

to tune in the desired station manuall .

Press SET button.

“SET” appears in the display window for a while (not

blinking .

• Note that “SET” message disappears, presetting

procedure is cancelled.

Rotate MULTI JOG dial or press repeatedl UP/

DOWN button to select the preset channel numbered

from 1 to 30 on FM, or 1 to 15 on AM.

• Note that the selected channel “02” disappears,

presetting procedure is cancelled.

Press SET button again.

“STORED” appears in the display window for a

while.

English

• DO NOT try to open or close the CD tray by

hands as it will be damaged.

• DO NOT place any foreign matters.

• DO NOT prevent the tray from opening and

closing, because it may results damages on the

unit.

Press 0 (open/close) button again.

The disc tray closes while the information appears

one after another as follows.

• When closing the tray without a CD placed, “CD NO

DISC” appears.

When pressing 66

6 (pla /pause) button directl ,

the s stem starts pla back a CD immediatel .

You can use Normal, Program, Random, or Repeat Play.

• When using the buttons behind the sliding panel, press

OPEN/CLOSE button on the AX-UXG6 to open the

sliding panel first.

• When using the remote control, press CD 6 (play/

pause button first and 7 (stop button successively.

PlayingBacktheEntireDisc—NormalPlay

Press 0 (open/close) button on CD unit.

The system automatically turns on and the disc tray

comes out.

Place a disc correctl on the circle of the disc tra ,

with its label side up.

Good No Good

• When using a CD single (8 cm , place it on the

inner circle of the disc tray.

Playing Back a CD

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

SET

4¢

Buttons behind the sliding panel

4¢

SET CANCEL PLAY MODE

MIC RO COMPONENT

MOS - FET

MULTI

FM/AM

STANDBY/ON

JOG

MULTI JOG Playback mode

indicators

RTER

7(stop)

(play/pause)

0(open/close)

Total track number

Total playback time

VOLUME

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

TAPE

FM/AM

SET

AUX

TITTLE/EDIT

REPEAT

TREBLE

UP/DOWN

PLAY MODE

REPEAT

DOWN

SET

CANCEL

CD 6(play/pause)

4/ ¢

7(stop)

</ >

English

To go to another track

Before or during playback, press 4 / ¢ button

repeatedly:

Press ¢ button:

Skips to the beginning of the next and succeeding

tracks.

Press 4 button:

Goes back to the beginning of the current and

previous tracks.

Rotating MULTI JOG dial clockwise also changes the tracks

forwards quickly, while rotating it counterclockwise the

tracks reverses quickly.

< / > button on the remote control is also available

to skipping operations.

Programing the Playing Order of the Tracks

—Program Play

You can arrange the order in which the tracks play before

you start playback. You can program up to 32 tracks.

Place a CD.

• If the current playing source is not the CD, press

6 (play/pause button on the CD unit, then 7

(stop button before going to the next step.

Press PLAY MODE button repeatedl until “CD

PROGRAM” appears in the displa window.

• Each time you press the button, playback mode

indicators also change as follows:

Rotate MULTI JOG dial to select a track number to

be programed (< / > buttons also available).

Track number

Program number

PROGRAM

Canceled

(Normal play)

RANDOM

Continued

Press 6 (pla /pause) button on the CD unit.

Each track of the CD starts playing one after another,

and stops when the final track has finished playing.

•To stop pla ing back for a moment, press 6

(play/pause button on the CD unit.

The playback time starts blinking in the display

window.

•To resume pla back, press 6 (play/pause

button again.

Playback continues from the point where it was

stopped for a while.

Press 7 (stop) button to stop pla ing back the CD.

Following information for the CD appears in the display

window.

Total track number

Total playback time

Press 0 (open/close) button on the CD unit to

remove the CD.

• Pressing 0 (open/close button during playback

directly, the CD unit stops playback and opens CD

tray.

Searching and Skipping Tracks

While playing back a CD, you can do the following

operations.

To search and skip to a particular point in a track

During playback, press and hold 4 / ¢ button to meet

the desired passages in a track:

Press and hold or ¢ button:

Fast forwards in the track.

Press and hold or 4 button:

Fast reverses in the track.

UP/DOWN button on the remote control is also

available to searching operations.

English

Press SET button to program the track number.

Track number

Program number

Here the track number 2 on the CD is stored into a

program number 1, and shortly after that the total

playback time of programed tracks appears in the display

window as follows:

Total playback time

Repeat steps 3 to 4 to program other tracks ou

want up to 32 tracks.

•If ou tr to program a 33rd step

“MEMORY FULL” will appear in the display

window, and your entry is ignored.

•The total pla back time of programed tracks

exceeds 99’59”

“– – : – –” will appear in the display window.

Press 6 (pla /pause) button on the CD unit.

The programed tracks are played back in the order you

have set.

• Other CD operations are the same as Normal play.

Press 7 (stop) button to quit the Program pla .

• When Program play finished, CD unit automatically

stops.

To check the program contents

Before playing back the CD, you can check the program

contents by using 4 / ¢ button.

Press ¢ button:

Shows the programed tracks in the programed

order.

Press 4 button:

Shows them in the reverse order.

To modify the program

Before playing back the CD, you can erase the last

programed track by pressing CANCEL button. Each time

you press the button, the last programed track is erased from

the end of program.

•To add new tracks to the program before you start

playing-back, simply select a track number again you

want to add (repeat steps 3 to 4 .

Continued

To erase all the programed data

After playing back the CD, you can erase all the programed

track data by pressing 7 (stop button. New program can

be entered again.

To exit from the Program play mode

Before or during playback, you can exit from Program play

mode as follows:

• Before playback, press PLAY MODE button twice.

• During playback, press 7 (stop button then PLAY MODE

button twice.

Playback mode indicator goes off and the system resumes

Normal play mode.

Pressing 00

0 (open/close) button to open the CD

tra also quits and erases the program pla .

1-12

UX-G6/FS-G6

English

Repeating Tracks —Repeat Play

You can have the entire disc, the programed tracks, or the

individual track repeat as many times as you like.

Place a CD.

If the current playing source is not the CD, press 6

(play/pause button on the CD unit, then 7 (stop button

before going to the next step.

Press REPEAT button on the remote control

repeatedl to set the repeat mode.

• Each time you press the button, repeat mode indicators

light in the display window, and Repeat playback

mode changes as follows:

: Repeats one track on the CD or in a

program.

: Repeats all the tracks on the CD or a

program.

Press 7 (stop) button to quit Repeat pla .

To exit from Repeat play mode

Pressing REPEAT button repeatedly until repeat mode

indicators ( and goes off in the display window.

Combining pla modes:

• When combining Program play and Repeat play,

you can repeat whole the programed tracks or

one track among them ( and .

• When combining Random play and Repeat play,

you can just repeat whole the shuffled tracks

(only .

Playing at Random —Random Play

The tracks of the loaded CD will play in no special order

(at random when you select this mode.

Place a CD.

If the current playing source is not the CD, press 6

(play/pause button on the CD unit, then 7 (stop button

before going to the next step.

Press PLAY MODE button repeatedl until “CD

RANDOM” appears in the displa window.

• Each time you press the button, playback mode

indicator also changes as follows:

Press 6 (pla /pause) button on the CD unit.

The track numbers are shuffled in the display window

for a few seconds, and start playing back at random.

Random play ends when all the tracks are played back

once.

• Other CD operations are the same as Normal play.

Press 7 (stop) button to quit Random pla .

To exit from Random play mode

Before playing back the CD, you can exit from Random

play mode as follows:

• Before playback, press PLAY MODE button once.

• During playback, press 7 (stop button then press

PLAY MODE button once.

Play mode indicator goes off and the system resumes the

normal play mode.

Pressing 0 (open/close) button to open the CD

tra also quits and erases the random pla .

Canceled

(

Normal pla

Continued

PROGRAM

Canceled

(Normal play)

RANDOM

English

• DO NOT try to open or close the tape tray by

hands as it will be damaged.

• DO NOT place any foreign matters.

• DO NOT prevent the tray from opening and

closing, because it may results damages on the

unit.

Press 0 (open/close) button again to close the tra .

Press ` (pla back) button on the unit or TAPE

` (pla back) button on the remote control.

The tape playback starts and the tape direction indicator

blinks slowly in orange to show the tape running

direction.

• Each time you press ` (playback on the cassette

deck unit or TAPE ` (playback button on the remote

control, you can change the tape sides to be played

back currently.

3 : pla s the forward side.

2 : pla s the reverse side.

Pla back comes to an end (Auto Reverse)

The cassette deck unit automatically changes the tape

direction to the reverse side, and continue playback

both sides. Each time to press the button, Auto

Reverse feature is set to on/off alternately.

You can listen to Normal (Type I , High position (TypeII ,

and Metal (Type IV type tapes without further settings.

• When using the inner buttons, press OPEN/CLOSE button

on AX-UXG6 unit to open the sliding panel first.

• When using the remote control, press TAPE 23

(playback button first and 7 (stop button successively.

DO NOT use tapes longer than 120 minutes.

The characteristic deterioration may occur and these

tapes easily jam in the tape transport mechanism.

Playing Back a Tape —Basic Operation

Press 0 (open/close) button on the cassette deck

unit.

The system automatically turns on and the tape tray

comes out.

Place a tape on the tra with the side ou want to

listen to facing up (forward side).

Tape fits in the caved-in area so that an exposed edge

of the tape faces toward the inside of the unit.

Playing Back a Tape

REC PAUSE

DOLBY B NR

AUTO

REVERSE

REC

DOLBY B NR

π(auto reverse) 0(open/close)

`(playback) 7(stop)

Tape operation indicators

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

SET

4¢

Buttons behind the sliding panel

4¢

REC

Tape direction indicator

VOLUME

CANCEL

DISPLAY

/CHARA.

TAPE

FM/AM

DOWN

SET

AUX

4/ ¢

7(stop)

TAPE `(playback)

English

To skip forward to the next music

Press the button same as the tape direction indicator as

follows:

3 ] Press ¢ button.

2 ] Press 4 button.

During Music Scan progressed, the tape direction

indicator starts blinking rhythmically.

Repeating Music Scan feature made eas

searching a desired program on a tape one after

another.

The beginning of the desired program ma not be

located properl

If blanks between music are too short, the blanks

contain too much noise or the program itself

contains very low-level or silent part.

Playing Back Dolby-Recorded Tape

You can play back the tape recorded with Dolby B NR

system. The Dolby NR system allows to reduce hiss noise

in playback.

Press DOLBY B NR button on the cassette deck before

playback. Each time you press the button, the Dolby NR

lamp on the unit lights up orange or turns off.

A tape recorded using Dolb NR

Should be played back using the Dolby NR of the

same type as that used in recording. The audio quality

will be affected if a different type is used in playback.

Dolby Noise Reduction manufactured under license from

Dolby Laboratories Licensing Corporation. “Dolby” and

double-D symbol are registered trademarks of Dolby

Laboratories Licensing Corporation.

Press 7 (stop) button to stop pla back the tape.

Press 0 (open/close) button directl to stop and

remove the tape.

While the s stem is turned off (standb mode)

Pressing ` (playback or TAPE ` (playback

button automatically switches the system turned on

and starts playback if a tape is already loaded.

Fast-Winding a Tape

While stopping the tape, press 4 / ¢ button to fast-

wind the tape.

To fast-forward, if the current tape direction is:

3 ] Press ¢ button.

2 ] Press 4 button.

To fast-rewind, if the current tape direction is:

3 ] Press 4 button.

2 ] Press ¢ button.

During fast-winding, the tape direction indicator starts

blinking quickly.

When the tape comes to an end

The deck unit automatically stops.

Searching and Skipping to Each Program

—Music Scan

While pla ing the tape, you can search and skip to the

beginning of the current and next program on a tape.

Music scan searches for blank portions that usually

separate programs recorded onto the tape, then

automatically plays the program beginning after

that blank portion.

To skip backward to the current music

Press the button opposite to the tape direction indicator

as follows:

3 ] Press 4 button.

2 ] Press ¢ button.

REC REC

forward reverse

REC REC

forward reverse

Continued

English

Place a recordable tape with the side ou want to

record facing up.

Press 0 (open/close button on the cassette deck unit to

open the tape tray; place a tape on it; and press 0 (open/

close button again to close it.

• You cannot record onto the tape without a protect tab.

When using that tape, cover the hole for desired side

with adhesive tape.

Press REC PAUSE button on the cassette deck unit.

Recording onto a Tape

REC PAUSE

DOLBY B NR

AUTO

REVERSE

REC

REC PAUSE DOLBY B NR

π(auto reverse) 0(open/close)

`(playback) 7(stop)

Tape operations indicators

REC

REC indicator

Two types of cassette tapes can be recorded onto, including

normal (Type I , and High position (Type II tapes. These

types are identified automatically by the cassette deck unit

and the recording level is also corrected automatically.

Neither volume level nor sound effects during playback does

affect to the recording.

IMPORTANT:

• It ma be unlawful to record or pla back cop righted

material without the consent of the cop right owner.

Manual Recording onto a Tape

Select one of the recording sources — FM/AM

broadcasts, CD, or other external equipment.

• To record FM/AM broadcasts, receive a station with

Tuner unit.

• To record a CD or its tracks programed, set the play-

pause mode for CD unit.

• To record from an external equipment connected to

ANALOG IN jacks, prepare it as required.

Make sure to select a source first, otherwise ou

cannot use recording function.

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

SET

SET REC MODE

Buttons behind the sliding panel

4¢

VOLUME

ENTER

CANCEL

DISPLAY

/CHARA.

TAPE

FM/AM

DOWN

SET

AUX

TITTLE/EDIT

(stop)

TAPE `(playback)

(play/pause)

FM/AM

AUX

1-13

UX-G6/FS-G6

English

Dolb B NR

Press DOLBY B NR button before recording to

reduce frequency response noise.

When the tape is played back later, also press the

button with its lamp lit.

Recording in Auto Reverse

Select one of the recording sources — FM/AM

broadcasts, CD, or other external equipments.

Make sure the tape side for recording meets the

tape direction indicator 3 (forward).

• Each time to press ` (playback button or TAPE `

(playback button on the remote control, you can

change the tape direction to be recorded onto.

3 : Good, records onto the forward side.

2 : No good, records onto the reverse side.

• The recording in the auto reverse mode stops

automatically after completing recording onto the

2 (reverse direction side.

Be sure to start recording from the 3 (forward

direction side.

• When the auto reverse mode is set to off, recording

stops after having recorded onto one side of the

tape.

Press π (auto reverse) button on the cassette deck

unit to set the reverse mode on.

The auto reverse lamp lights orange on the front panel.

Press REC PAUSE button on the cassette deck unit.

Repeat the steps 4 to 5 of “Manual Recording onto

a Tape” mentioned in the left column.

REC indicator lights red to show the recording pause

mode, and “TAPE REC” appears in the display window

as follows,

To change the recording source

You cannot change the selected source during the

recording pause mode. To exit from the recording

pause mode, press 7 (stop button on the cassette deck

unit.

To make the blank tape

Press AUX button to start recording without

connecting nor playing back the external equipment.

Press Tape ` (pla back) button for FM/AM

broadcasts or 6 (pla /pause) button on the CD unit

to start recording.

Tape direction indicator starts blinking slowly in the

display window.

•To stop recording for a moment, press REC PAUSE

button on the cassette deck unit. Tape direction

indicator stops blinking in the display window.

•To resume recording, press ` (playback button

again. Recording continues from the point where it

was stopped for a while.

Press 7 (stop) button on the cassette deck unit for

FM/AM broadcasts recording, or 7 (stop) button on

the CD unit for the CD recording.

Recording stops and REC indicator goes off in the

display window.

On CD recording, cassette deck unit will stop

after leaving a non-recorded portion of 4 seconds.

If you want to quit recording immediately, press 77

(stop button on the cassette deck unit.

Press 0 (open/close) button on the cassette deck

unit to remove the tape.

• Pressing 0 (open/close button directly during

recording , the cassette deck unit stops recording and

opens the tape tray.

REC

Tape direction indicator

REC

forward

reverse

Continued

English

Synchronized Recording from a CD

CD application on UX-G6 system can be recorded with a

simple, one-touch operation.

Place a recordable tape and a source CD into each

tra .

• To record using Dolby B NR, press the DOLBY B

NR button before recording so that its lamp near the

button lights orange.

Press 6 (pla /pause) button on the CD unit, then

7 (stop) button to set the s stem to CD operation

mode.

Press REC MODE button behind the sliding panel.

The display window shows information as follows:

Press SET button.

Display window shows as follows:

then

UX-G6 starts playback on the CD unit as well as

recording on the cassette deck unit simultaneously.

You can get an entire copy of the source CD.

To select a particular track or program, use REC

PAUSE button on the cassette deck unit. During SYNC

REC mode, you cannot operate CD unit except 7 (stop

button.

•To make recording pause temporaril , press REC

PAUSE button on the cassette deck unit.

•To resume recording, press ` (playback button

on the cassette deck unit.

Using Program pla for CD recording

To edit CD’s tracks to be recorded, it is useful to set

the desired tracks to be played back into a program

in advance.

When CD playback finished, the CD unit first, then

the cassette deck stops recording automatically.

Cassette deck unit will stop after leaving a non-

recorded portion of 4 seconds.

If you want to quit recording immediately, press

7 (stop button on the cassette deck unit.

Press 0 (open/close) button on each unit to remove

the CD and the tape.

Recording from the External Equipment

You can record audio sources played-back on the external

equipment onto a tape manually.

First of all, make sure to connect the external equipment

properly (see also page 9 .

Recording an external audio source manually

Press AUX button to show “AUX” in the displa

window.

The external audio source is selected.

Repeat the steps 2 and 3 on page 22 to prepare a

tape to record.

Information appears as follows:

Press ` (pla back) button on the cassette deck unit

or TAPE ` (pla back) button on the remote control

to start recording.

Tape direction indicator starts blinking slowly in the

display window.

Start pla ing back the external equipment.

•To stop recording for a moment, press REC PAUSE

button on the cassette deck unit. Tape direction

indicator stops blinking in the display window.

•To resume recording, press ` (playback button

again.

•To end the recording, press 7 (stop button on the

cassette deck unit.

Recording stops and REC indicator goes off in the

display window.

REC

Tape direction indicator

English

• Each time you press the button, the timer mode

changes as follows:

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the hour of the timer-

on time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the minute of the

timer-on time, then press SET button.

Rotate MULTI JOG dial (< / > button on the

remote control also available) to select the hour of

the timer-off time, then press SET button.

On UX-G6 system, three timer features are available —

Recording Timer, Daily Timer, and Sleep Timer.

Before using these timers, you need to set the clock built in

the system (see page 10 .

Using Recording Timer

With Recording Timer, you can make a tape of a radio

broadcast automatically.

• You can set Recording Timer whether the system is turned

on or off.

• To correct a mis-entry any time during the setting process,

press CANCEL button.

How Recording Timer actually works

The system automatically turns on, tunes into the specified

station, turns off the volume, and starts recording when the

timer-on time comes.

Then, when the timer-off time comes, the system

automatically turns off (standby .

The timer settings remain stored in memory until you reset

them or unplug the AC power cord.

Press CLOCK/TIMER button repeatedl until

“REC TIMER” and its timer-on time appear in the

displa window.

You can select the timer-on/off time, a tuner preset

channel to record, and recording media.

• If MD recorder XM-G6 (not supplied connected, you

can select MD as recording media (see page 7 .

Using the Timers

ENTER

AUTO PRESET

PLAY MODE

FM MODE

CANCEL

DISPLAY

/CHARA.

BASS

SLEEP

PANEL

OPEN/CLOSE

REMOTE CONTROL RM-SUXG6E

TAPE

FM/AM

DOWN

SET

AUX

TITTLE/EDIT

REPEAT

TREBLE

DIMMER

CLOCK/TIMER

ACTIVE

BASS EX.

SET

CANCEL

CLOCK/TIMER

SLEEP

</ >

(standby/on)

PANEL

OPEN/CLOSE

DAILY TIMER

REC TIMER

Clock

(canceled) DAILY TIMER

ON 0:00

REC TIMER

ON 0:00

DISPLAY

/CHARA. PLAY

MODE REC

MODE TITLE

/EDIT CLOCK

/TIMERCANCEL ENTER

SET

CANCEL CLOCK/TIMER

Buttons behind the sliding panel

4¢

MICRO COMPONENT SYSTEM UX-G6

MOS - FET

OPEN/CLOSE

AUX

VOLUMEMULTI

FM/AM

STANDBY/ON

JOG

MULTI JOG

OPEN/CLOSE

REC

STANDBY/ON

Timer indicators

English

Press SET button to call the previous settings for

next timer recording.

The REC timer indicator lights, and the setting items

appear one after another in the display window.

• To erase the recording timer, press CANCEL button

in this step.

Using Daily Timer

With Daily Timer, you can wake up on your favorite music

or radio program.

• You can set the daily timer whether the system is turned

on or off.

How Daily Timer actually works

The system automatically turns on, and starts playing the

specified source when the timer-on time comes. Then, when

the timer-off time comes, the system automatically turns

off (standby .

The timer settings remain stored in memory until you reset

them or disconnect the AC power cord.

Press CLOCK/TIMER button repeatedl until

“DAILY TIMER” and its timer-on time appear.

• Each time you press the button, the timer mode

changes as follows:

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the hour of the timer-

on time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the minute of the

timer-on time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the hour of the timer-

off time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the minute of the

timer-off time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select either “TUNER FM”

or “TUNER AM,” then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select a preset channel, then

press SET button.

“TAPE REC” follows in the display window as selected

recording media, unless any MD recorder connected.

• If XM-G6 MD recorder connected, you can select

either a tape or an MD as recording media.

Press SET button to select recording media, and turn

off the s stem.

After completing the settings...

The REC timer indicator lights and the setting items appear one

after another in the display window. Thus the Recording Timer is

ready for unattended recording.

After a timer recording is complete...

Set the volume to an appropriate listening level.

If ou press a certain button while Recording

Timer is operating

Recording will stop.

To use the same Recording Timer settings

repeatedly

Once you have set the recording timer, it remains stored

in memory until you change it.

To activate the recording timer with the previous settings,

follow the procedure below:

Press CLOCK/TIMER button repeatedl until

“REC TIMER” appears in the displa window.

DAILY TIMER

REC TIMER

Clock

(canceled) DAILY TIMER

ON 0:00

REC TIMER

ON 0:00

REC

REC timer indicator

Continued

1-14

UX-G6/FS-G6

English

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the minute of the

timer-off time, then press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to select the source, then press

SET button.

TUNER FM: Tunes into a preset FM station. Go to

step 7.

TUNER AM: Tunes into a preset AM station. Go to

step 7.

CD: Plays a CD. Prepare a CD, then go to

step 7.

(MD : Plays a MD, only when XM-G6 MD

recorder connected. Then go to step 7.

TAPE: Plays a tape. Prepare a tape, then go to

step 8.

AUX*: Selects “AUX” as the source. Make the

external equipment ready for playback.

(AUX DIGITAL :

Selects an external digital audio

equipment as the source if connected.

* To use the external equipment with the Daily Timer,

it also has the timer function.

If ou have selected FM/AM as the source in the

above step, select a preset channel.

1 Rotate MULTI JOG dial (< / > button on the remote

control also available to select a preset channel.

2 Press SET button.

If ou have selected CD as the source in the above

step, select a track.

1 Rotate MULTI JOG dial (< / > button on the remote

control also available to select a track.

2 Press SET button.

Rotate MULTI JOG dial (< / > button on the remote

control also available) to adjust the volume level, then

press SET button.

• You can adjust the volume within the range of “0” to

“50.” If you select “– –,” the volume is set to the

previous level when the unit is turned off.

After completing the settings...

The daily timer indicator lights, and the setting items appear one

after another in the display window.

Turns off the unit (standby if you have set the daily timer with

the unit turned on.

If ou press a certain button while Dail Timer is

operating

The unit will not turn off automatically.

To use the same Daily Timer settings repeatedly

Once you have set Daily Timer, it remains stored in memory

until you change it.

To activate the daily timer with the previous settings, follow

the procedure below:

Press CLOCK/TIMER button repeatedl until

“DAILY TIMER” appears in the displa window.

Press SET button to activate Dail timer.

The daily timer indicator lights, and the setting items

appear one after another in the display window.

• To deactivate the daily timer, press CANCEL button

in this step.

REC

DAILY timer indicator

Continued

TUNER

(AUX

DIGITAL)AUX

TUNER

AM (MD)

TAPE

English

Timer Priority

Since each timer can be set separately, you may wonder

what happens if the setting for these timers overlaps.

Here are the priorities for each timer.

• Recording Timer has priorit over Dail Timer and

Sleep Timer.

If Daily Timer is set to come on while Recording Timer

is operating, Daily Timer will not come on at all.

If Recording Timer is set to come on while Sleep Timer

is operating, Sleep Timer will be canceled several seconds

before Recording Timer comes on.

• Sleep Timer has priorit over Dail Timer.

If Daily Timer is set to come on while Sleep Timer is

operating, Daily Timer will not come on at all.

Therefore, the equation is like this (high > low :

Recording Timer > Sleep Timer > Dail Timer

Using Sleep Timer

With Sleep Timer, you can fall asleep to your favorite music

or radio program.

How Sleep Timer actually works

The system automatically turns off after the selected time

length passes while playing any source.

On the remote control onl :

Press SLEEP button on the remote control

repeatedl to select the sleep timer.

• Each time you press the button, the time length

changes as follows:

Wait for about 5 seconds after selecting the time

length.

When the sleep timer setting is completed, the display

window dims and just shows the remaining time until

the shut-off time minute by minute like “SLEEP 30”

then “SLEEP 29”.

•To change the shut-off time, press SLEEP button

repeatedly until the desired time length appears.

•To cancel the setting, press SLEEP button repeatedly

until the sleep timer indication disappears.

6:00 7:00

6:30 7:30

Canceled.

Recording Timer

Sleep Timer

6:00 7:006:30 7:30

Does not work.

Sleep Timer

Daily Timer

6:00 7:307:00

6:30

Does not work.

Recording Timer

Daily Timer

(Canceled)

20 30 60 90 120

English

General Notes

In general, you will have the best performance by keeping

your CDs, cassette tapes and the mechanism clean.

• Store CDs and cassette tapes in their cases, and keep

them in cabinets or on shelves.

• Keep the CD disc tray, and the cassette tapes tray

closed when not in use.

Handling CDs

• Only CDs bearing this mark can be

used with this system. However,

continued use of irregular shape

CDs (e.g. heart shape, octagonal

can damage the system.

• Remove the CD from its case by

holding it at the edge while

pressing the center hole lightly.

• Do not touch the shiny surface of

the disc, or bend the CD.

• Put the CD back in its case after

use to prevent warping.

• Be careful not to scratch the

surface of the CD when placing it

back in its case.

• Avoid exposure to direct sunlight,

temperature extremes, and

moisture.

• To clean the CD

Wipe the CD with a soft cloth in a

straight line from center to edge.

DO NOT use any solvent — such as conventional

record cleaner, spray, thinner, or benzine — to

clean the CD.

Maintenance and Additional Information

English

Types of Cassette Tapes

This cassette deck unit incorporates an Automatic Tape

Detection function. This mechanism uses the tape-type

detection holes to distinguishes which type of tape was

inserted, and sets the bias and equalizer to the optimum

settings for that tape automatically.

The following types of tapes may be used with this cassette

deck unit.

Normal tape

TYPE I

BIAS: NORMAL

EQ: 120µs

High position (CrO

) tape

TYPE II

BIAS: HIGH

EQ: 70µs

Metal tape (only for playback)

TYPE IV

BIAS: METAL

EQ: 70µs

• Certain early period Metal and High position

(CrO2 tapes may not have tape-type detection

slots. The cassette deck unit cannot obtain the

correct characteristics for these tapes.

• Ferrochromite (FeCr TYPE III tapes cannot be

used with this cassette deck unit.

Normal (No detection slots) Tab

(to prevent accidental erasure)

High position

detection slots

Metal detection slots

Handling Cassette Tapes

Cautions regarding handling

• Do not touch the surface of the tape or pull the tape out

of the cassette.

• Tape spooled loosely around the hubs is likely to jam in

the pinch rollers and capstans. Before loading the tape

into the cassette tray, take up the slack in the tape as shown

below.

Tape storage

• Place tapes in their cases for storage.

• Avoid storing tapes on top of TVs or speakers, in sunlight

or places of high temperature, or in humid or dusty areas.

To prevent accidental erasure

• Cassette tapes have tabs to prevent accidental erasure.

• If you remove the tabs after making a recording, the

cassette deck cannot be set to record when that tape is

loaded. Remove the tabs so that valuable

recordings will not be accidentally erased.

Recording (erasure is not possible when the tabs are

removed.

• To make another recording on a tape whose tabs have

been removed, cover the tab holes with adhesive tape.

DO NOT cover the tape-t pe detection slots.

For front side (A)

For reverse side (B)

Tape-type detection slot

Adhesive tape

1-15

UX-G6/FS-G6

English

Troubleshooting

If you are having a problem with your system, check this list for a possible solution before calling for service.

If you cannot solve the problem from the hints given here, or the units has been physically damaged, call a qualified

person, such as your dealer, for service.

Sym tom

No sound is heard.

Poor radio reception.

Unable to record onto a tape.

The CD skips.

Unable to operate using the remote

control.

Loaded CD and tape cannot be

ejected.

The CD does not play.

Operations are disabled.

Possible Cause

• Connections are incorrect, or

loose.

• Headphones are connected.

• Volume level is set to “– –”.

• The antenna is not connected

correctly.

• The AM loop antenna is too close

to the units.

• The FM antenna is not properly

extended and positioned.

• You are using a tape without a

protect tab.

• Tape-type detection slots are

covered by foreign matters.

• The CD is dirty or scratched.

• The path between the remote

control and the remote sensor on

the front panel is blocked.

• The batteries have lost their

charge.

• The main AC power cord is not

plugged in.

• The system is under the recording

operations.

• The CD is upside down.

• The built-in microprocessor has

malfunctioned due to external

electrical interference.

Action

• Check all connections and make

corrections (see pages 6 – 9 .

• Disconnect the headphones (see

page 12 .

• Adjust the volume again (see

page 12 .

• Reconnect the antenna securely.

• Change the position and direction

of the AM loop antenna.

• Extend FM antenna to the best

reception position (see page 7 .

• Cover the hole with adhesive tape

(see page 30 .

• Remove the foreign matters.

• Clean or replace the CD (see page

29 .

• Remove the obstruction.

• Replace the batteries (see page 6 .

• Plug in the AC power plug.

• Stop the recording if required (see

pages 23 .

• Put in the CD with the label side

up.

• Unplug the system then plug it

back in.

English

Specifications

Stereo Amplifier AX-UXG6

Output power

48 W (24 W + 24 W) at 6 Ω (Max.)

Load impedance: 6 Ω (6 Ω to 16 Ω allowance

Audio output level/Impedance (at 1 kHz :

Sub Woofer 800 mV/440 Ω

Power requirement: [A] AC 110 V – 120 V/220 V

– 240 V ,

[B] AC 115 V/230 V

(adjustable with the voltage

selector , 50 Hz/60 Hz

Power consumption: [A] 59 W (at operation

[B] 54 W (at operation

2.0 W (on standby: with

Dimmer

Dimensions (approx. : 182 mm x 81 mm x 313 mm

(W/H/D

Mass (approx. : 3.8 kg

Compact Disc/Tuner XT-UXG6

Audio input sensitivity/Impedance (at 1 kHz :

AUX: 400 mV/47 kΩ

[CD section]

Digital output: OPTICAL DIGITAL OUT

Wow and flutter: Immeasurable

[Tuner section]

FM tuning range: 87.50 MHz – 108.00 MHz

AM tuning range: 531 kHz – 1,710 kHz (at 9 kHz

channel spacing

530 kHz – 1,710 kHz (at 10 kHz

channel spacing

Dimensions (approx. : 181 mm x 81 mm x 313 mm

(W/H/D

Mass (approx. : 1.9 kg

Cassette Deck TD-UXG6

Frequency response :

Normal 30 Hz – 15,000 Hz

High position 30 Hz – 16,000 Hz

Wow and flutter: 0.1 % WRMS

Dimensions (approx. : 181 mm x 81 mm x 304 mm

(W/H/D

Mass (approx. : 1.9 kg

Speaker System SP-UXG6

Type: 2-way Bass-Reflex Type

Speaker unit: Woofer 11.5 cm Cone x 1

Tweeter 3.0 cm Balanced

Dome x 1

Impedance: 6 Ω

Frequency range: 40 Hz – 20,000 Hz

Sound Pressure Level: 85.5 dB/W•m

Dimensions (approx. : 157 mm x 295 mm x 232 mm

(W/H/D

Mass (approx. : 3.3 kg each

Supplied Accessories

See page 6.

Design and specifications are subject to change

without notice.

US and foreign patents licensed from Dolby

Laboratories Licensing Corporation.

1-16

UX-G6/FS-G6

<< M E M O >>

2-1

UX-G6/FS-G6

AX-UXG6

2-2

UX-G6/FS-G6

Disassembly method

(AX-UXG6)

Removing the top cover (See Fig.1)

1. Remove the two screws A and the four screws B

attaching the top cover.

2. Remove the top cover from behind in the direc-

tion of the arrow while pulling the sides outward.

Removing the front panel assembly

(See Fig.2 to 5)

1. Pull out the lower part of the front panel assembly

manually as shown in Fig.2 and 3.

2. Remove the two screws C with collars attaching

the front panel assembly.

3. Remove the front panel assembly downward

along the front sub panel rails as shown in Fig.4

and 5.

ATTENTION: Do not lose the two collars of the

part a when removing the front

panel assembly.

4. Disconnect the card wire extending from the

upper part of the front panel assembly.

(When reattaching the front panel assembly, fit

the parts "a" on both sides of the front panel

assembly to the grooves of the front sub panel

rails and move the assembly upward along the

rails.)

Fig. 1

Fig. 2

A 2

Front panel assembly

Fig. 3

Fig. 4Fig. 5

CFront panel assembly

Front panel assembly

Front sub panel

Slide bracket

Parts a

Front panel assembly

Rail

2-3

UX-G6/FS-G6

Removing the front sub panel assembly

(See Fig.6 to 8)

• Prior to performing the following procedure,

remove the top cover and the front panel assem-

bly.

1. Disconnect the card wire from connector CN704

on the back of the front sub panel assembly.

2. Remove the two screws D on the bottom of the

body.

3. Release the joint "b" on the bottom and the two

joints "c" on both sides of the body, and remove

the front sub panel assembly toward the front.

Removing the rear panel and the voltage

selector (See Fig.9)

• Prior to performing the following procedure,

remove the top cover.

1. Remove the cord stopper on the rear panel while

moving it in the direction of the arrow.

2. Remove the two screws E attaching the voltage

selector on the rear panel.

(The voltage selector can be removed without

removing the rear panel.)

3. Remove the five screws F attaching the rear

panel and release the two joints "d" on both sides

while moving the rear panel upward.

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Front sub panel assembly

CN704

Joint b

Joint 2

Joint d Joint d

Rear panel Cord stopper

Front sub panel assembly

2-4

UX-G6/FS-G6

Removing the regulator board

(See Fig.10)

• Prior to performing the following procedure,

remove the top cover.

1. Disconnect the card wire from connector CN908

on the main board.

2. Disconnect the harness from connector CN906

on the main board.

3. Remove the two screws G attaching the regula-

tor board.

Removing the transformer assembly

(See Fig.11)

• Prior to performing the following procedure,

remove the top cover.

1. Disconnect the harness from connector CN904,

CN905 and CN903 on the main board.

2. Remove the four screws H attaching the trans-

former assembly.

3. Remove the cord stopper and the voltage selec-

tor as shown in Fig.9.

(If necessary, unsolder the soldered point and cut

off the belt fixing the harness.)

Fig. 10

Fig. 11

Regulator board

Main board

CN908

CN906

CN905

CN903

CN904

Cord stopper

Voltage selector

Power transformer

Other manuals for UX-G6

This manual suits for next models

Table of contents

Popular Stereo System manuals by other brands

JBL

JBL 3678-HF Setup instructions

Panasonic

Panasonic SA-NC9GCP Service manual

Aiwa

Aiwa XR-H1100 Service manual

Kenwood

Kenwood HM-DV6MD instruction manual

GPX

GPX HC221B v1165-01 user guide

Philips

Philips MCD288/98 quick start guide

Philips

Philips MCM309R/37 Service manual

Vivanco

Vivanco Music Station user manual

Teac

Teac MC-DX220iDAB Service manual

Aiwa

Aiwa NSX-AJ500 Service manual

Lasonic

Lasonic E-6914 Operation manual

Kenwood

Kenwood HM-437WM instruction manual

Aiwa

Aiwa AWSP15TWL user manual

Yamaha

Yamaha MCR-330 Service manual

Daktronics

Daktronics Sportsound SSR-200 quick start guide

LG CM2520 owner's manual

Philips

Philips FWD182 user manual

Teac

Teac HMX900iP user manual

JVC UX-G6 User manual

Popular Stereo System manuals by other brands
