JVC TV 13142 User manual

Serial Number
IMPORTANT NOTE TO THE CUSTOMER:
In the space below, enter the serial number for your
television (located on the rear of the television cabinet).
Staple your sales receipt or invoice to the inside cover of this guide.
Keep this user's guide in a convenient place for future reference.
Keep the carton and original pac aging for future use.
For models :
TV-13142
TV-13142W
TV/VCR COMBO
USER’S GUIDE
(Illustration of TV-13142)
POWER
ONTIMER
RECTIMER
REC
STOP/EJECTFFPLAYREW
VOLUME
CHANNEL
SP/EPINPUT
PHONES VIDEO-IN - AUDIO
/
REC/ITR
VIDEO CASSETTE RECORDER
PLAY
STOP
TV
REC PAUSE
FFREW
TRACKING AUTO
SLEEPCALL
INPUT
ENTER
SET –
SET
+
MENU
ZERO RETURN RESET
PROGRAM SP/ EPTIMER
POWER
COUNTER
CANCEL TV/CAP/TEXT
RETURN
0
8
5
2
7
4
1
9
6
3
MUTING
CH
CH
VOL VOL

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magni-
tude to constitute a risk of electric shock to
persons.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCETO RAIN OR
MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTEN-
SION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try correcting the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user's authority to operate this equipment.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

1
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEEDWARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
6. ATTACHMENTS
Do not use attachments not recommended by the unit’s manufacturer as they may cause hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and serious damage to the unit.
Use only with a cart, stand, tripod, bracket, or table recommended by the
manufacturer.
8A. An appliance and cart combination should be moved with care.Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
9. VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, and to ensure reliable
operation of the unit, and to protect it from overheating.These openings must not be blocked or covered.The
openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.This unit
should never be placed near or over a radiator or heat source.This unit should not be placed in a built-in installa-
tions such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have
been adhered to.
10. POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate.If you are not sure
of the type of power supply to your home, consult your appliance dealer or local power company.For units
intended to operate from battery power, or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way.This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug.If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug, if your unit is equipped with a 3-wire
grounding-type plug, a plug having a third (grounding) pin.This plug will only fit into a grounding-type power
outlet.This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet.
Do not defeat the safety purpose of the grounding-type plug.
IMPORTANT SAFEGUARDS
S3126A
PORTABLE CART WARNING
(symbol provided by RETAC)

2
IMPORTANT SAFEGUARDS (CONTINUED)
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
13. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system.This will prevent damage to the unit
due to lightning and power line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits.When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be
fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock.Never spill or spray any type of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and support-
ing structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
18. SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage
or other hazards.Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions.Adjust only those controls
that are covered by the operating instructions, as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the unit to its normal
operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance, this indicates a need for service.
20. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.

3
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
ANTENNA LEAD
IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
ELECTRIC SERVICE
EQUIPMENT GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC-NATIONAL ELECTRICAL CODE POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
S2898A
21. SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22. WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
23. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
24. NOTETO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.

4
FEATURES
ColorTV With Video Cassette Recorder - Unique space saving design combines a 13" color TV and a video cassette
recorder.
High Quality PictureTechnology - This TV/VCR equipped “HQ” incorporates VHS High Quality technology. A built-in detail
enhancer is used to boost the recorded signal and provide maximum picture quality during playback.It is compatible with
other VHS video cassette recorders.
SQPB - Tapes recorded in the S-VHS system can be played back simply on this TV/VCR.
4 Video Heads - Provides optimal picture quality for special effects playback.
Frequency SynthesizedTuner - Electronically locks in and memorizes all available channels for perfect reception with the
touch of a button.
181 ChannelTuner - Receives standard VHF and UHF broadcast channels and up to 113 cable channels.The actual
number of channels received depends upon channel reception in your area or your cable system.
UnifiedTV/VCR Random Access Remote Control - This remote control allows operating various TV and VCR functions
from the comfort of your favorite viewing position.
Closed Caption Decoder With FullText Mode - Displays text captions or full screen text on the screen for hearing
impaired viewers.
8-Programs/ 1-Month ProgrammableTimerWith Everyday/Every Week Capability - The built-in timer allows automatic
absentee recording of up to 8 TV programs within 1 month. It is also possible to record a program which is broadcast at the
same time everyday or every week.
Auto Clock Set - Once yourTV/VCR is pluged into the AC outlet, it automatically sets the correct date and time.
On-Screen TV Display And VCR Programming - When you select a channel or make other changes, the TV will show an
indicator on the screen for a few seconds.Timer recording can be programmed and confirmed on the screen.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control adjustment of
BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Automatic Playback/Rewind-Stop-Eject - When loading a cassette tape without the erase prevention tab, this TV/VCR
will automatically play back the cassette tape at the correct speed.When a tape reaches its end during play-back, recording
(except during ITR and Timer Record) and fast forward, it will automatically stop, rewind, stop and eject the tape.
Programmable ON/OFFTimer - Allows you to automatically turn on or off your TV/VCR at a set time.
ProgrammableTV SleepTimer - Operable from the remote control, theTV can be programmed up to 120 minutes to turn
off automatically.
Full LoadTapeTransport - Permits rapid access between modes.
Automatic Repeat Play System - When Auto Repeat option is turned on, the TV/VCR will automatically play back the same
cassette tape repeatedly.
InstantTimer Recording (ITR) - Simply by pressing the REC and PLAY buttons, theTV/VCR can be programmed for up to
5 hours of recording with an immediate start.
Audio/Video Input/Output Jacks - A VCR or other video device may be hooked up to this TV/VCR for dubbing or playback
purposes.
2 Speed Picture Search - 3 or 5 times normal speed in SP mode (9X or 15X in EP).
2 Speed Record/ Playback - Records and plays two tape speeds (SP, EP).
RealTimeTape Counter With Zero Return -The counter displays the real tape time and the zero return can be used to
return the tape to a preselected position (00:00:00) while the counter can be used to locate programs.
Digital AutoTracking - Automatically adjusts tracking during playback for the best possible picture.
On-Screen 3 Language Display -You can select one of 3 languages, English, Spanish or French for on-screen programming.
V-Chip - The V-Chip function can rate a TV program or a movie content. It allows you to set a restriction level.

5
TABLE OF CONTENTS
It is recommended that you carefully read the descriptions and operating procedures contained in this
User’s Guide prior to operating your newTV/VCR.
PREPARATION
PRECAUTIONS ...................................................................................................................................................... 6
LOCATION OF CONTROLS ................................................................................................................................... 8
REMOTE CONTROL .............................................................................................................................................. 9
ANTENNA CONNECTIONS ................................................................................................................................. 11
CABLE TV CONNECTIONS ................................................................................................................................. 12
SETTING LANGUAGE.......................................................................................................................................... 13
AUTO CLOCK SETTING ...................................................................................................................................... 14
MANUAL CLOCK SETTING ................................................................................................................................. 16
TV OPERATION
TV OPERATION.................................................................................................................................................... 17
TO MEMORIZE CHANNELS ................................................................................................................................ 21
SETTING THE V-CHIP.......................................................................................................................................... 24
PICTURE CONTROL ADJUSTMENTS ................................................................................................................ 28
TO SET THE ON TIMER ....................................................................................................................................... 30
TO SET THE OFF TIMER ..................................................................................................................................... 31
PLAYBACK
LOADING AND UNLOADING A VIDEO CASSETTE............................................................................................ 32
PLAYBACK............................................................................................................................................................ 33
SPECIAL PLAYBACK ........................................................................................................................................... 35
RECORDING
RECORDING A TV PROGRAM............................................................................................................................ 37
INSTANT TIMER RECORDING (ITR) ................................................................................................................... 39
TIMER RECORDING ............................................................................................................................................ 40
OTHER FUNCTIONS FOR THE TIMER RECORDING ........................................................................................ 42
ADDITIONAL INFORMATION
USING THE REAL TIME TAPE COUNTER .......................................................................................................... 44
USING ZERO RETURN........................................................................................................................................ 45
DUPLICATING A VIDEO TAPE ............................................................................................................................. 46
RECEPTION DISTURBANCES ............................................................................................................................ 47
TROUBLESHOOTING GUIDE.............................................................................................................................. 48
VIDEO HEAD CLEANING..................................................................................................................................... 50
SPECIFICATIONS................................................................................................................................................. 51

6
MOISTURE CONDENSATION
DO NOT OPERATE ANY FUNCTIONS ONTHIS UNIT FOR AT LEAST TWO OR
THREE HOURS WHEN MOISTURE INTHE AIR CONDENSES ON IT. LETTHE
UNIT STAND WITH POWER ON (SEE BELOW).
WHAT IS MOISTURE CONDENSATION?
When a cold liquid is poured into a glass, for example, water vapor in the air will
condense on the surface of the glass.This is called moisture condensation.
MOISTURE WILL CONDENSE ONTHE UNIT INTHE FOLLOWING CASES;
• When you move the unit from a cold to a warm place.
• After heating a cold room or under extremely humid conditions.
WHENYOU EXPERIENCETHE ABOVE CONDITIONS,
Plug the power cord into an AC outlet, set the POWER switch to ON and leave the
unit at room temperature until moisture condensation disappears.
Depending on the surrounding conditions, this may take two or three hours.
Head Drum
Video Tape
PRECAUTIONS
If you cause a static discharge when touching the
unit, and the unit fails to function, simply unplug the
unit from the wall outlet, wait a few minutes, and
plug it back in.The unit should return to normal
operation.
Avoid extreme heat.
Avoid extreme cold.
Do not place the unit on or near appliances which
may cause electromagnetic interference (e.g.speak-
ers, etc).Doing so may cause erratic operation of the
unit including picture and/or sound distortion or noise.
Avoid extreme moisture and dust. The ventilation holes prevent overheating.Do not
block or cover these holes.Especially avoid
covering the holes with soft materials such as cloth
or paper.

7
POWER SOURCE
Polarized AC Cord
(One blade is wider than the other.)
To protect the unit from a lightning storm, unplug the
AC power cord from the wall outlet and disconnect
the antenna.
Do not insert fingers or any other objects into the
cassette loading slot. Do not spray cleaner or wax
directly on the unit or use forced air to remove dust.
Keep the unit away from flower vases, sinks, etc.
If liquids should be spilled into the unit, serious
damage will result. If you spill any liquids into the
unit, unplug the AC power cord immediately and
consult qualified service personnel before attempting
to use it again.
When you leave your home for a long time, unplug
the AC power cord.
When you finish operating the unit, always unload
the cassette and turn off the power.
Avoid places subject to strong vibration.Use in a
horizontal (flat) position only.
AC Outlet
Wider Hole
and Blade
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for operation on AC.Insert
the AC cord plug into a standard 120V 60Hz polarized AC outlet.
NOTES:
1. Never connect the AC line cord plug to other than the specified
voltage (120V 60Hz).Use the attached power cord only.
2. If the polarized AC cord does not fit into a non-polarized AC outlet,
do not attempt to file or cut the blade.It is the user’s responsibility
to have an electrician replace the obsolete outlet.
3. If you cause a static discharge when touching the unit, and the unit
fails to function, simply unplug the unit, from the AC outlet, wait a
few minutes, and plug it back in.The unit should return to normal
operation.

8
LOCATION OF CONTROLS
REARFRONT
REC / ITR REW
PHONES
INPUT SP/EP
– CHANNEL
+–
VOLUME
+
REC REC TIMER ON TIMER
VIDEO –IN –AUDIO
PLAY FF
POWER
STOP/EJECT
8 9 15 1610 11 12 13 14 177
23 654
REC/OTR REW
PHONES
INPUT SP/EP
– CHANNEL
+–
VOLUME
+
REC REC TIMER ON TIMER
VIDEO –IN –AUDIO
PLAY FF
POWER
STOP/EJECT
1
ANT
18 19
FRONT:
1. Cassette Loading Slot - To insert or remove a
video tape.
2. REC
/ ITR Button - Press once to start normal
recording. Additional presses activate Instant Timer
Recording.
3. REW (Rewind) Button - In the Stop mode, this
button rapidly winds the tape backwards. In the Play
mode, this button activates reverse search.
4. PLAY Button - Press to play a prerecorded tape.
5. FF (Fast Forward) Button - In the Stop mode, this
button rapidly winds the tape forward. In the Play
mode, this button activates forward search.
6. STOP/EJECT Button - Press once to stop the tape
in any mode. Press again to eject the tape.
7. Headphone Jack - Plug monaural headphones or
an earphone with an 1/8" miniplug into this jack for
private listening.
8. AUDIO/VIDEO IN Jacks - Audio and video signal
cables from an external source can be connected
here.
9. INPUT Selector Button - Switches the program for
viewing between the VCR and an external input
source.
10. SP/EP Selector Button - Sets the tape speed for
recording.
11. CHANNEL + / – Buttons - Press to select a channel
for viewing or recording.
12. VOLUME + / – Buttons - Press to raise or lower the
volume of the sound.
13. REC Indicator - Lights when the TV/VCR is record-
ing.
14. RECTIMER Indicator - This lights when the TIMER
button is pressed.
15. ONTIMER Indicator - This indicator lights up when
the powered up. It also lights up when ONTIMER
program is turned ON while power is OFF.
16. POWER Button - Press to turn the TV/VCR on or off.
17. Remote Sensor - Signals from the Remote Control
are received here.
REAR:
18. VHF/UHF Antenna Jack - Connect the 75 ohm
coaxial cable from the antenna or Cable TV service
to this jack.
19. AC Power Cord - Connect to a 120V, 60Hz outlet.
DESCRIPTION OF CONTROLS
