JVC LT-22HD32J User manual

INSTRUCTIONS
LT-22HD32J
LT-22HD3WJ
LT-24HD32J
LEDTV/DVD Combo
57W0201A_ENG.indd 157W0201A_ENG.indd 1 9/15/11 2:06:27 PM9/15/11 2:06:27 PM

2
Important Warning
CAUTION:
A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM
WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPER-
ATE THE PLAYER CORRECTLY AS INSTRUCTED.
THE FOLLOWING CAUTION LABEL IS LOCATED ON THE REAR PANEL OF THE UNIT.
WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO
THE OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, AND ANNOYING INTERFERENCE, USE
THE RECOMMENDED ACCESSORIES ONLY.
Precautions
Battery notice (valid in EU only)
Look after our environment - contact your local authorities for advice on how to safely dispose of exhausted
batteries.The crossed out wheelie bin symbol indicates that used batteries should not be disposed of with your
normal household waste! A separate collection system for used batteries is in place to allow the correct treatment
and recycling in accordance with current legislation. Please contact your local authority for details on collection
and recycling schemes in your area.
DVB-C notice
The DVB-C reception possibly requires an additional contract with your cable supplier. A Smartcard
for the receipt of encrypted programmes comes with the contract. Programmes that do not come with the contract
will remain encrypted and not be viewed.
You receive DVB-C programmes with a CA module (CAM) of your cable network operator. You insert the CAM
into the CI-Slot (refer to page 10) of this TV set.You insert the Smartcard into the CAM.
You can possibly receive a few unencrypted DVB-C programmes at your home location even without
an additional contract and without a CAM. However, these programmes frequently reveal a poorer
image quality than the DVB-C-HD programmes that are subject to a charge. The image quality that is frequently
poor is a feature of the respective programmes.
Information for the DVB-T function
Any function relative to the digital television (with the DVB logo) is available only within the country or area
where such signals are transmitted.Verify with the salesman if it is possible to receive a DVB-T signal in the
zone where you live.
Remove the CAM for DVB-T reception, if it has been inserted.
A DVB-T antenna must be connected for DVB-T reception.
Even if the television conforms to the DVB-T specifications, the compatibility to future digital DVB-T
transmissions is not guaranteed.
Some digital television functions may not be available in some countries.
The DVB-T system present in this device is FTA (Free to air).
•
•
•
•
•
•
•
•
•
CLASS 1
LASER PRODUCT
Dear Customer, [European Union]
This apparatus is in conformance with the valid European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of JVC KENWOOD Corporation is:
JVC Technical Services Europe GmbH Postfach 10 05 04
61145 Friedberg
Germany
57W0201A_ENG.indd 257W0201A_ENG.indd 2 9/15/11 2:06:31 PM9/15/11 2:06:31 PM

3
Features
Precautions........................................................... 2
Features................................................................ 3
Contents ............................................................... 3
Important safety information.................................. 4
Important Instruction ............................................. 5
Location of controls............................................... 7
Remote Control..................................................... 8
Antenna connection............................................ 10
Auto setup........................................................... 11
Selecting the input source................................... 11
On-screen Language Selection .......................... 12
Changing the order of stored channels ............... 12
Station search..................................................... 12
Update Scan....................................................... 12
Manual Station search ........................................ 13
Basic Operation .................................................. 13
Teletext ............................................................... 14
Stereo reception in analogue cable TV
channel mode ..................................................... 14
Remarks on DVB-T system ................................. 15
Password Setup (Parental lock) .......................... 16
EPG (Electronic Program Guide) ........................ 16
Picture size and resolution .................................. 17
Picture format...................................................... 18
Other convenience functions .............................. 19
Media Operation ................................................. 22
Media Browser.................................................... 22
Playback files...................................................... 23
Playable File Types ............................................. 24
Disc..................................................................... 25
Playing a disc...................................................... 27
Zooming (DVD)................................................... 28
Locating desired scene (DVD/Audio CD)............ 28
Changing Soundtrack Language (DVD).............. 28
Subtitles (DVD) ................................................... 28
Changing angles (DVD) ...................................... 29
Title selection (DVD) ........................................... 29
DVD menu (DVD)................................................ 29
Disc status .......................................................... 29
Using HOME MENU ........................................... 29
Play mode........................................................... 30
Audio Settings menu........................................... 31
Video Adjust menu.............................................. 31
Customizing The Function Settings..................... 31
Parental Control .................................................. 33
Language Code List............................................ 34
Country/Area code list ........................................ 34
PC connection .................................................... 35
Connecting an HDMI or a DVI device to
the HDMI input.................................................... 35
Connection to other equipment........................... 35
Troubleshooting table.......................................... 37
License information............................................. 38
Specifications ..................................................... 39
TV
16:9 LCD screen
LED-Backlight-Technology
On-Screen Language Display in 18
languages
DVB-C-HDTV-Tuner
DV B -T-Tuner
Cable-analogue-Tuner
Electronic Progr. Guide (EPG) for DVB
•
•
•
•
•
•
•
USB-Media player for JPEG and WMA
CI-Slot for CA- module
Auto Power Off after 4 hours with no
operation
DVD Player
Digital output for Dolby Digital and DTS
Playback of DVD, MP3/WMA/JPEG and
Audio-CD
•
•
•
•
•
Contents
Information for Users on Disposal of Old
Equipment and Batteries
[European Union]
These symbols indicate that the electrical and
electronic equipment and the battery with this
symbol should not
be disposed of as
general household
waste at its end-of-life.
Instead, the products
should be handed
over to the applicable
collection points
for the recycling
of electrical and
electronic equipment
as well as batteries
for proper treatment,
recovery and recycling in accordance with your
national legislation and the Directive 2002/96/EC
and 2006/66/EC.
By disposing of these products correctly, you
will help to conserve natural resources and will
help to prevent potential negative effects on the
environment and human health which could
otherwise be caused by inappropriate waste
handling of these products.
For more information about collection points and
recycling of these products, please contact your
local municipal office, your household waste
disposal service or the shop where you purchased
the product.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
[Business users]
If you wish to dispose of this product, please
confirm attached “KESA ELECTRICALS SAFETY
INSTRUCTIONS” to obtain information about the
take-back of the product.
[Other countries outside the European Union]
These symbols are only valid in the European
Union.
If you wish to dispose of these items, please do so
in accordance with applicable national legislation or
other rules in your country for the treatment of old
electrical and electronic equipment and batteries.
Products
Battery
Notice :
The sign Pb below the symbol
for batteries indicates that this
battery contains lead.
57W0201A_ENG.indd 357W0201A_ENG.indd 3 9/15/11 2:06:31 PM9/15/11 2:06:31 PM

4
Important safety information
This unit has been produced according to all current safety regulations.The following safety tips should safeguard
users against careless use and the dangers connected with such use.
Although this appliance has been carefully manufactured and rigorously checked prior to leaving the factory, as
with all electrical appliances it is possible for problems to develop. If you notice smoke, an excessive build-up
of heat or any other unexpected phenomena, you should disconnect the plug from the mains power socket
immediately.
Ensure that the unit is sufficiently ventilated! Never place next to or underneath curtains!
This set should be only be connected to an AC 220~240V / 50Hz mains power supply - do not attempt to
connect it to any other type of supply.
The socket-outlet must be installed near the equipment and easily accessible.
Any repairs must be carried out by qualified service personnel only.
Do not open this unit. A non-expert attempting to repair the unit could be dangerous and potentially cause a fire
hazard.
Keep away from rodents. Rodents (and also cockatiels) enjoy biting into electric flexes.
The animal can cause a short cut (fire hazard!) and receive a fatal electric shock.
Always hold plug when pulling out plug from power mains supply system. Do not pull on flex.The flex can
become overloaded and cause a short cut.
Never wet clean. Only use a damp cloth, the same as when cleaning furniture.
Do not submerge in or under water!
Set up unit so that no one is able to trip over the flex.
This unit is recommended to be installed on shock-free benches in order to avoid any danger from falling.
Take note that toddlers can pull the unit down from the table or cupboard by means of its flex. Children can hurt
themselves when doing this.
Do not use the unit near heat sources.The casing and flex could be damaged by the impact of heat.
Watch out for kiddies copying what adults do! Do not stick any objects through the vents!
The vents must remain open! No newspapers or covers should be put on the unit!
The remote control is not a toy! Toddlers could swallow the batteries. If a battery has been swallowed, please
seek out a doctor immediately.
The screen is made of glass and can break if damage is done to it. Be careful when collecting sharp-edged
glass splitters.
You could be hurt or the unit could be damaged.
If the unit is mounted on the wall, contact the shop where you purchased the unit for advice, and leave the
installation work to experts. Incomplete installation work can cause you injuries.
Taking fall-prevention measures
- If these measures are not taken, the unit can fall and you could be injured.
- Contact the shop where you purchased the unit to obtain full details of the measures.
When a TV stand is used,
- Ensure the unit is fully on the stand and placed in the centre.
- Do not leave the stand doors open.
- You could be hurt as a result of the unit falling or breaking, or your fingers being caught or jammed. Take extra
precautions if you have children.
Avoid placing the unit on any surfaces that may be subject to vibrations or shocks.
To protect the unit during a thunder storm unplug the AC power cord and disconnect the antenna. Caution: Do
not touch the antenna connector.
When you leave your home for a long period of time, unplug the AC power cord for safety reasons.
The unit becomes warm when in operation. Do not place any covers or blankets on the unit in order to prevent
overheating. The ventilation holes are not to be blocked. Do not set up near radiators. Do not place in direct
sunshine. When placing on a shelf leave 10 cm free space around the whole unit. Make some space around TV
(Correct shelf assembly).
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
Liquids spilled into the unit can cause serious damage. Switch the set OFF and disconnect the mains power
supply, then consult a qualified service person before attempting to use the unit again.
Please pay attention to the following instructions in order to avoid receiving a life-threatening electric
shock:
Protect against moisture. Never use in the bath or sauna.
Never use near a bath, shower or swimming pool.
Never use the unit if it has got wet.This can also mean condensation moisture, which occurs in the winter when
the cold unit is brought into a heated flat. Wait before operating the unit especially after it has been transported
in the winter, until the cold unit has adjusted to the room temperature.
Do not place any heavy objects on the flex. Electrical isolation could be damaged.
Never wrap insulating tape around damaged flexes or on damaged plugs. These should be repaired or replaced
by qualified service personnel.
Never use this unit if the cabinet is defective. Do not make provisional repairs if the cabinet is damaged - this
should be replaced by a new cabinet if necessary.
Unplug the unit from the mains power supply prior to the cleaning of the unit.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
57W0201A_ENG.indd 457W0201A_ENG.indd 4 9/15/11 2:06:32 PM9/15/11 2:06:32 PM

5
Important safety information
How to attach the stand
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on.
• Do not support the TV by the screen as sharp objects and too much pressure may cause damage.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1) Place the TV on its front onto a table.
2) Align the stand’s base-plate (supplied) as seen here.
It will fit in only one direction. Make sure the locating pegs project through the locating holes.
3) Carefully hold the base plate in position and secure it with screws (included).
Dismantling the base
For wall mounting, the base plate must be dismantled. To do this, remove screws (M, see page 10) from the back.
Take off the base plate entirely. Fit a VESA 100mm wall mounting kit.
LT-22... LT-24...
Important Instruction
For your own safety read following instruction carefully before attempting to connect this unit to the mains supply.
GREEN
&
YELLOW
(Earth)
(if there is earth cable)
FUSE
BROWN
(Live)
BLUE
(Neutral)
MAINS (AC) OPERATION
The wires in the mains lead are coloured in accordance with the following code :
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green and yellow must be
connected to the terminal which is marked with the letter E, or
by the earth symbol, or coloured green or green and yellow.
The wire which is coloured blue or black must be
connected to the terminal which is marked with the letter
N or coloured Black.
The wire which is coloured brown or red must be
connected to the terminal which is marked with the letter
L or coloured Red.
For continued protection against risk of fire, replace only
with same type and rating of fuse (ASTA approved 5A
250VAC fuse).
IMPORTANT
NOTE:
To detach the base plate, perform these steps in reverse order.•
57W0201A_ENG.indd 557W0201A_ENG.indd 5 9/15/11 2:06:33 PM9/15/11 2:06:33 PM
