K-array Capture-KMC50 User manual

Capture-KMC50
50-cm-line array microphone
with Pure Array Technology
USER GUIDE

KMC50_uguide_1.0

1
Index
Unpacking 4
Getting Started 5
Single unit 5
Multiple units 5
Assembling 6
Single-unit microphone assembly 6
Multiple-unit microphone assembly 7
Connecting 9
XLR power connector assembly 10
Service 12
Cleaning 12
Mechanical Drawings 12
Capture-KMC50 12
K-FLYM5 flybar 13
KMC50-JOINT 13
K-PREMC01 preamplifier 13
K-PREMC02 preamplifier 14
Technical Specifications 15
Vertical Polar Pattern 15
Horizontal Polar Pattern 15
Capture-KMC50
User Guide

2
K-array declares that this device is in compliance
with applicable CE standards and regulations. Before
putting the device into operation, please observe the
respective country-specific regulations!
WEEE
Please dispose of this product at the end of its
operational lifetime by bringing it to your local collection
point or recycling center for such equipment.
This symbol alerts the user to the presence of
recommendations about the product’s use and
maintenance.
The lighting flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated, dangerous voltage within
the product enclosure that may be of magnitude to
constitute a risk of electrical shock.
Symbols
General heed and warnings
This device complies with Restriction of Hazardous
Substances Directive.
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions - Keep these instructions
Heed all warnings
Installation and commissioning may only be carried out
by qualified and authorized personnel.
Switch-off the mains power supply before carrying out
any connection or maintenance operations.
• Read these instructions.
• Keep this instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• This microphone is intended for professional use.
• Before connecting the microphone to other devices, turn off any power
supply or phantom power.
• In order to operate the microphone, the unit must be connected to a
dedicated preamplifier and a power supply or the P48 phantom power
must be present, according to the actual microphone configuration.
• Use only microphone cables for connecting the microhpone to audio
device.
• Be sure to observe the microphone load impedance recommendation.
• Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• K-array will not shoulder any responsibilities for products modified
without prior authorization.
• K-array cannot be held responsible for damage caused by improper use
of the microphone and its accessories.
Warning. Failure to follow these safety instructions
could result in fire, shock or other injury or damage to
the device or other property.
Capture-KMC50
User Guide

3
Thank you for choosing this K-array product!
To ensure proper operation, please carefully read this owner’s
manual and safety instructions before using the product.
After reading this manual, be sure to keep it for future reference.
Should you have any questions about your new
device please contact K-array customer service at
[e-mail] or contact the official K-array distributor
in your country.
Composed of 16 x 6 mm electret condenser cardioid
capsules aligned in a line array configuration, the KMC50
has been designed for voice and instrument amplification
as well as for capturing environmental sound with the
precision of a perfect directive microphone.
Thanks to the Pure Array Technology, the KMC50 polar
response is cardioid in the horizontal plane and very narrow
in the vertical plan, which allows for a precise and clean
concentration of the signal capture.
Achieving higher directivity with the Capture-KMC50 by
linking up to 4 units to create an impressive continuous
steerable array allows users to explore new microphone
techniques and applications.
Capture-KMC50
User Guide

4
Unpacking
Each K-array product is built to the highest standard and
thoroughly inspected before leaving the factory. Upon arrival,
carefully inspect the shipping carton. If you find any damage,
immediately notify the shipping company. Check that the
following parts are supplied within the package:
Capture-KMC50 Microphone basic kit
A. 1x Capture-KMC50 line array microphone
B. 2x Foam brackets
C. 4x Screws
K-PREMC01 single unit preamplifier kit
D. 1x K-PREMC01 single unit preamplifier
E. 1x KMC50 top cap
F. 1x KMC50 female adapter with cable and MiniXLR connector
K-PREMC02 multiple units preamplifier kit
G. 1x K-PREMC02 multiple units preamplifier
H. 1x KMC50 top cap
I. 1x KMC50 female adapter with cable and MiniXLR connector
Capture-KMC50
User Guide
A B
C
FRONT
LEFT SIDE
D
G
E
H
F
I

5
KMC50-JOINT multiple unit connection hardware
J. 1x KMC50-JOINT accessory
K. 2x M2 screws
K-FLYM5 flybar for suspending and aiming microphone arrays
L. 1x K-FLY5 flybar with cable and MiniXLR connector
M. 1x M2 screw
K-BRK50 bracket compatible with Rycote InVision INV-1
adapter (not provided)
N. 1x K-BRK50 bracket
O. Rycote InVision INV-1 adapter (NOT INCLUDED)
Getting Started
Unpack the Capture-KMC50 microphone and its accessory kits.
A preamplifier kit is required! Select either the K-PREMC01
or the K-PREMC02 preamplifier kit according to the number
of microphone units and the configuration you want to make.
Single unit
1. Assembly the Capture-KMC50 microphone and the female adapter
with cable and MiniXLR connector supplied in the K-PREMC01
preamplifier kit (see Single-unit microphone assembly, page 6).
2. Plug the top cap on the Capture-KMC50 microphone.
3. Connect the MiniXLR connector to the K-PREMC01 single unit
preamplifier.
4. According to the type of application:
• Stand mounting applications: mount the K-BRK50 bracket on the
Capture-KMC50 microphone assembly and set it on the Rycote
InVision INV-1 adapter.
• Surface mounting applications: slip the Capture-KMC50
microphone on the foam brackets: four screws are provided for
fixing the foams to the surface.
5. Plug the microphone to the input device and switch on the Phantom
power (see Connecting, page 9).
Multiple units
1. Assembly the Capture-KMC50 microphones and the KMC50-
JOINT according to the desired array configuration (see Multiple-unit
microphone assembly, page 7).
2. According to the type of application:
• Custom bracketing: plug the female adapter with cable and MiniXLR
connector supplied in the K-PREMC02 preamplifier kit to one end of
the Capture-KMC50 microphone line array.
• Suspended microphone line array: plug the K-FLYM5 flybar to one
end of the Capture-KMC50 microphone line array.
3. Plug the microphone cap on the opposite end of the Capture-KMC50
microphone array.
4. Connect the MiniXLR connector to the K-PREMC02 preamplifier.
5. Connect a reliable 5 V 500 mA power supply to the K-PREMC02
preamplifier (see Connecting, page 9).
6. Plug the K-PREMC02 microphone preamplifier to the input device and
switch on the Phantom power.
K-WIND150 Rycote accessory for maximum isolation from
wind and handling noise.
Capture-KMC50
User Guide
J
M
N
K
L
O

6
Assembling
In order to operate the Capture-KMC50, the microphone and
the proper preamplifier kit – either the K-PREMC01 or the
K-PREMC02 – must be assembled.
Single-unit microphone assembly
The K-PREMC01 preamplifier is designed to drive a single
Capture-KMC50 microphone unit.
The K-PREMC01 single unit preamplifier kit comprises the
top cap and the bottom adapter with cable and MiniXRL
connector. Follows the images below to assemble the
microphone.
The connectors on top and at the bottom of the
microphone are shaped according to the unit
orientation.
Set the microphone cap and the adapter with cable
at the opposite ends of the unit.
Plug the miniXLR connector to the K-PREMC01
preamplifier.
Capture-KMC50
User Guide
FRONT
(straight edge)
PORT
534 mm
[21 in]
PLUG
FRONT
(straight edge)
BACK
(curved edge)
1
2
3
BACK
(curved edge)

7
Multiple-unit microphone assembly
The K-PREMC02 preamplifier is designed to drive up to
4 (four) Capture-KMC50 microphone units in line array
arrangement. The KMC50-JOINT accessory is needed to
joint multiple microphone units.
The optional K-FLYM5 flybar is available for ease the aiming
of the microphone array.
The connectors on top and at the bottom of the
microphones are shaped according to the unit
orientation.
Connect two microphone units to the KMC50-JOINT
accessory and gently tighten the 2x M2 screws.
In order to plug the first unit to the K-FLYM5 flybar, the
Capture-KMC50 microphone shall be oriented upside-down
with the plug connector on top.
Capture-KMC50
User Guide
2
1
FRONT
(straight edge)
PLUG
PORT
M2
PH0
FRONT
(straight edge)
BACK
(curved edge)
BACK
(curved edge)

8
It is possible to connect up to 4 (four) Capture-
KMC50 units using 3x KMC50-JOINT accessories
achieving a maximum of 2-meter-long (6.5 ft)
steerable microphone line array.
Place the cap at the bottom unit and connect the
microphone line array assembly to the K-FLYM5
flybar. Gently tighten the flybar M2 screw to secure
the assembly.
You can possibly angle the joint in order to achieve
the desired microphone array pick-up coverage.
2bis 3
Capture-KMC50
User Guide
unit 1
top
unit 1
top
unit 2
middle top
unit 2
middle
joint 1joint 1
10° max
joint 2joint 2
joint 3
unit 3
middle bottom
unit 3
bottom
1,5 m (5 ft)
microphone line array
(3x Capture-KMC50 units)
2 m (6.5 ft) max extension
microphone line array
(4x Capture-KMC50 units)
unit 4
bottom

9
Connect the MiniXLR to the K-PREMC02
preamplifier.
Connecting
The Capture-KMC50 microphone needs the 48V phantom
power supply.
4
Use only the K-PREMC02 preamplifier for powering
multiple microphone units.
K-array assumes no liability for any damage
caused by a defective power supply.
Always mute the sound reinforcement system
before switching on the power supplies
Use only high quality 5VDC, 500mA power supply
for guarantee pristine audio.
A further 5VDC 500mA power supply unit (not provided)
is needed to guarantee proper microphone operating.
The auxiliary DC power supply can be connected to the
K-PREMC02 preamplifier either via a MicroUSB connector or
using a XLR connector.
When the phantom power
is supplied, the LED on the
K-PREMC01 preamplifier lights up.
When more than one Capture-
KMC50 microphone unit
is employed in line array
configuration, the K-PREMC02
preamplifier must be used AND
a further DC power supply must
be connected to the K-PREMC02
preamplifier.
Capture-KMC50
User Guide
External 5 V, 500 mA
power supply unit
(not provided)
MicroUSB
Phantom
Power ON

10
XLR power connector assembly
Needed materials (not provided by K-array):
• 1x 5VDC 500mA power supply (e.g. Meanwell GE12I05-P1J)
• 1x XLR 3-M connector
• Tools and soldering station
1. Disconnect the power supply from any power
source and wait at least one minute before making
any modifications to the DC connector.
2. Cut away the DC connector.
Capture-KMC50
User Guide
Microphone
input
Auxiliary
power LED
5VDC PSU
5VDC PSU
Phantom
power LED
Auxiliary power
MicroUSB port
Auxiliary power
XLR inlet
Preamplifier
Output
K-PREMC02
powered via the
MicroUSB
K-PREMC02
K-PREMC02
powered via the
XLR connector
5-10 cm
2-4 in
1
2
Phantom
Power ON
Phantom
Power ON

11
3. Cut away the rubber and reveal the internal leads.
4. Identify the positive lead: usually a white line is
drawn on the lead carrying the positive voltage.
5. Solder the leads to the contacts 1 (-) and 2 (+) of the
XLR 3-M connector as show below:
XLR connector Power cable
pin 1 Negative
pin 2 Positive +5VDC
pin 3 not connected
chassis not connected
Capture-KMC50
User Guide
XLR connector
rear side Power cable
3
4

12
502mm
[19.8in]
10mm
[0.4in]
10mm
[0.4in]
30mm
[1.18in]
Service
To obtain service:
1. Please have the serial number(s) of the unit(s) available
for reference.
2. Contact the official K-array distributor in your country:
find the Distributors and Dealers list on K-array website.
Please describe the problem clearly and completely to
the Customer Service.
3. You will be contacted back for online servicing.
4. If the problem cannot be resolved over the phone,
you may be required to send the unit in for service. In
this instance, you will be provided with an RA (Return
Authorization) number which should be included on all
shipping documents and correspondence regarding
the repair. Shipping charges are the responsibility of the
purchaser.
Any attempt to modify or replace components of the device
will invalidate your warranty. Service must be performed by
an authorized K-array service center.
Cleaning
Use only a soft, dry cloth to clean the housing. Do not use
any solvents, chemicals, or cleaning solutions containing
alcohol, ammonia, or abrasives. Do not use any sprays near
the product or allow liquids to spill into any openings.
Mechanical Drawings
Capture-KMC50
Capture-KMC50
User Guide

13
10mm
[0.4in]
498mm
[19.6in]
509mm
[20in]
39mm
[1.5in]
6mm
[0.24in]
60mm
[2.4in]
15mm
[0.6in]
R 5mm
[0.2in]
30mm
[1.2in]
30mm
[1.2in]
22mm
[0.8in]
28mm
[1.1in]
111mm
[4.38in]
19mm
[0.75in]
14mm
[0.53in]
K-FLYM5 flybar
KMC50-JOINT K-PREMC01 preamplifier
Capture-KMC50
User Guide

14
145mm
[5.71in]
88mm
[3.46in]
50mm
[1.97in]
K-PREMC02 preamplifier
Capture-KMC50
User Guide

15
FRONTBACK
TOP
-60°
-30°
-120°
-150°
BOTTOM
60°
30°
120°
150°
2000 Hz
4000 Hz
8000 Hzv
125 Hz
500 Hz
1000 Hz
FRONTBACK
LEFT
-60°
-30°
-120°
-150°
RIGHT
60°
30°
120°
150°
2000 Hz
4000 Hz
8000 Hzv
125 Hz
500 Hz
1000 Hz
Technical Specifications
General
Type Line array microphone
Capsule 16 x 6mm electret condenser
Frequency Response 55 – 20000 Hz
Sensitivity -32 dBV (1kHz @ 94 dB SPL)
Maximum SPL 110 dB SPL (1 kHz, 10% THD)
Signal to Noise Ratio 57 dB (1 kHz, A-weighted)
Connector XLR-M
Polar pattern Cardioid line array
Power supply
Preamplifier Single unit: wired preamplifier
Multiple units: preamplifier box requiring external 5 VDC 500 mA power supply
Phantom Supply Voltage 36 to 52 VDC, (+) pins 2 and 3
Handling and Finish
IP Rating IP54
Dimensions (WxHxD) & Weight 10 x 10 x 510 mm (0.39 x 0.39 x 20 in)
Weight 0.080 kg (0.176 lb)
Finish Ruthenium-plated Aluminum
Vertical Polar Pattern Horizontal Polar Pattern
Capture-KMC50
User Guide

16
This page left intentionally blank
Capture-KMC50
User Guide

17

Designed and Made in Italy
K-ARRAY surl
Via P. Romagnoli 17 | 50038 Scarperia e San Piero - Firenze - Italy
ph [phone] | [e-mail]
www.k-array.com
