K-array KMC20V User manual

KMC20 Ver. 1.0
KMC20V-KMC20H
USER GUIDE
English

KMC20 Ver. 1.0
2
TABLE OF CONTENTS
1. INTRODUCTION ..................................................................... 4
2. KEY FEATURES ...................................................................... 4
3. PACKAGE CONTENTS .............................................................. 5
3.1 KMC20V ........................................................................................... 5
3.2 KMC20H .......................................................................................... 5
4. SAFETY INFORMATION............................................................ 6
5. UNPACKING ......................................................................... 7
6. PHYSICAL OVERVIEW.............................................................. 7
7. MICROPHONE SETUP .............................................................. 8
7.1 VERTICAL MOUNTING BASE ................................................................... 8
7.2 HORIZONTAL BASE.............................................................................. 9
7.3 MICROPHONE STAND ..........................................................................10
8. SERVICE ............................................................................. 11
9. TECHNICAL SPECIFICATIONS ................................................... 12
10. CERTIFICATION ................................................................... 13

KMC20 Ver. 1.0
3
This symbol alerts the user to the presence of recommendations about
product’s use and maintenance.
This symbol alerts the user to the presence of recommendations about the
product’s use and maintenance.
K-array declares that this device is in compliance with applicable CE
standards and regulations. Before putting the device into operation, please
observe the respective country-specific regulations!
WEEE
Please dispose of this product at the end of its operational lifetime by bringing
it to your local collection point or recycling center for such equipment.
This device complies with Restriction of Hazardous Substances Directive.
SYMBOLS
WARNING: Dangerous voltages! Risk of electric shock.
Terminals marked with this symbol are HAZARDOUS LIVE and the external
wiring connected to these terminals requires installation by a qualified
professional or the use of ready-made leads or cords.

KMC20 Ver. 1.0
4
1. INTRODUCTION
2. KEY FEATURES
Ever since K-array launched its first slim column speaker in 2007, it has maintained its position of leader
of sleek line arrays. With every subsequent product release, the company has perfected its solutions
composed of closely-spaced, full-range sound sources by incorporating its Pure Array Technology.
This same line array technology is now being applied to the latest addition to the K-array portfolio in
a form other than a speaker. The Capture-KMC20 is the smallest line array microphone in the market
featuring PAT technology composed of 8 x 4mm cardioid capsules aligned in a line array configuration.
Given its line array characteristics, the Capture shows a minimal variation of gain with distance. As a result,
the distance between the orator and the microphone is not crucial and he is able to move towards or away
from the mic freely without strongly affecting the volume or audio quality.
The polar response is cardioid in the horizontal plane, and very narrow in the vertical plan, therefore,
when mounted in vertical, not only does the mic not pick up sound from behind, but it’s also insensitive
to sounds that come from above and below, strongly reducing the amount of ambient sound captured.
Being very wide in the horizontal plane, a single microphone can pick up more people and gives maximum
freedom of movement to the right and left without volume fluctuations.
While when mounted in horizontal, the capture is very wide on the vertical plane and very narrow on the
horizontal plane, resulting in capturing only the person in front of the microphone while standing or sitting.
The microphone’s impressively slender frame is shaped from a 6x6 mm solid square brass bar using a
milling cutter with bits less than 2 mm in radius. It’s meticulously pieced together welding 2 mm- and
4 mm- tall capsules to a 0.6 mm-thick electronic board then two 0.3 mm-thick stainless steel grills are
micro-stretched over the frame. The frame is secured in place by two plates screwed one on top of the
other. Finally, all the components are sandblasted to obtain a homogeneous opaque finish and embellished
with an ultra-black ruthenium galvanic bath.
And given its thickness of 6mm, these incredibly thin microphones are impressively discreet and made
with durable premium materials like brass to be used for a variety of applications in conference halls,
boardrooms, houses of worship and TV studios.
• Ultra-thin
• 8 capsules of 4 mm
• Cylindric-cardioid polar pattern
• Pure Array Technology
• Extended frequency response
• 48V phantom powered
• Vertical and horizontal supports
• Durable, elegant brass frame

KMC20 Ver. 1.0
5
3. PACKAGE CONTENTS
1 x microphone
3.1 K M C 20V
1 x K-BASEMV brass base
for vertical mounting
with included wire and
connector for preamplifier
The Capture microphone is available in two versions: KMC20V (that includes a base for vertical mounting)
and KMC20H (that includes a base for horizontal mounting). If you need to mount the microphone in both
orientations, the additional base is available to purcharse as an accessory.
1 x microphone
3.2 KMC20H
1 x K-BASEMH brass base
for horizontal mounting
1 x preamplifier 1 x M2 key
1 x preamplifier 1 x M2 key
1 x M3 key

KMC20 Ver. 1.0
6
Read these instructions - Keep these instructions - Heed all warnings
4. SAFETY INFORMATION
Warning. Failure to follow these safety instructions could result in injury
or damage to the device or other property.
IMPORTANT SAFETY INSTRUCTIONS
• Follow all instructions and keep all warnings.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus.
• Choking Hazards. This device contains small parts, which may present a choking hazard to small
children. Keep the device and its accessories away from small children.
• Do not make repairs yourself. Never attempt to disassemble, repair or modify the system yourself.
Disassembling the unit may cause damage that is not covered under the warranty. The device
contains no user-serviceable parts. Repairs should only be performed by factory trained service
personnel.
• Carrying, handling and installing the device. The device contains sensitive components. Do not drop,
disassemble, open, crush, bend, deform, puncture, shred, incinerate, paint, or insert foreign objects
into it.
• Water. Water entering the housing of the microphone can cause a short-circuit and damage the
elctronics. Protect the microphone from wetness. Use only a slightly damp cloth to clean the
microphone.

KMC20 Ver. 1.0
7
5. UNPACKING
Each K-array microphone is built to the highest standard and thoroughly inspected before leaving the
factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new microphone.
If you find any damage, immediately notify the shipping company. Only the consignee may institute a
claim procedure regarding the system’s electronic equipment.
6. PHYSICAL OVERVIEW
Weight
KMC20V: 0.352 kg (0.776 lbs)
KMC20H: 0.414 kg (0.913 lbs)
9,3in
236mm
0,2in
6mm
0,2in
6mm
87
30,7
55
56,3
40,6
50

KMC20 Ver. 1.0
8
7. MOUNTING THE MICROPHONE
Insert the microphone into the base and screw in place using the M2 key included in the packaging.
Untighten the upper rig of the base, adjust the inclination of the microphone, then tighten to lock the
microphone in the desired position.
7.1 VERTICAL MOUNTING BASE

KMC20 Ver. 1.0
9
Insert the microphone into the base and screw in place by using the M2 key included in the packaging.
To adjust the orientation of the microphone, untighten the screw placed in the lower part of the base
using the included M3 key. Position the microphone in the desired position, then tighten the screw.
7.2 HORIZONTAL BASE

KMC20 Ver. 1.0
10
7.3 MICROPHONE STAND ACCESSORY
Tighten the extendable stand in the floor base. Insert the microphone in the slot on the top of the
stand and screw it in place using the included screw driver. Adjust the orientation of the stand and the
microphone. Connect the wire from the floor base to the preamplifier. Use an XLR microphone cable to
connect the preamplifier to the mixer and feed it with the 48V phantom power.

KMC20 Ver. 1.0
11
8. CONNECTING THE MICROPHONE
Connect the wire coming out from the base to the included preamplifier. Use a three-pin XLR professional
microphone cable (XLR) to connect the preamplifier to a microphone input which provides 48 V phantom
powering.
Phantom supply voltage must stay between 36 to 52 Vdc, providing at least 7mA of current. Voltage
must be positive on pins 2 and 3 of the XLR connector of the preamplifier.
INCLUDED
Mic
Preamplifer
XLR cable

KMC20 Ver. 1.0
12
9. SERVICE
To obtain service:
1) Contact the official K-array distributor in your country. Your local distributor will direct you to the
appropriate service center.
2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference.
Ask for Customer Service, and be prepared to describe the problem clearly and completely.
3) If the problem cannot be resolved over the phone, you may be required to send the unit in for
service. In this instance, you will be provided with an RA (Return Authorization) number which should
be included on all shipping documents and correspondence regarding the repair. Shipping charges are
the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty. Service must
be performed by an authorized K-array service center.
Cleaning:
Use only a soft, dry cloth to clean the housing. Do not use any solvents, chemicals, or cleaning
solutions containing alcohol, ammonia, or abrasives. Do not use any sprays near the product or
allow liquids to spill into any openings.

KMC20 Ver. 1.0
13
10. TECHNICAL SPECIFICATIONS
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may
appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
General
Type Line array microphone
Capsule 8 x 4mm electret condenser
Frequency Response 65 – 15000 Hz
Sensitivity -37 dBV (1kHz @ 94 dB SPL)
Maximum SPL 105 dB SPL (1 kHz, 10% THD)
Signal to Noise Ratio 55 dB (1 kHz, A-weighted)
Polar pattern Cardioid line array
Handling and Finish
IP Rating IP54
Dimensions (WxHxD) & Weight 6 x 226 x 6 mm (0.24 x 8.90 x 0.24 in)
0.032 kg (0.070 lbs)
Finish Ruthenium Plated Brass
Polar pattern
Vertical Horizontal
-90°+90°
-120°+120°
-150°+150°
+/-180°
deg
0°
-30°
-60°
+30°
+60°
-15
-12
-9
-6
-3
0
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
-90°+90°
-120°+120°
-150°+150°
+/-180°
deg
0°
-30°
-60°
+30°
+60°
-15
-12
-9
-6
-3
0
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz

KMC20 Ver. 1.0
14
11. CERTIFICATION
