K-array Kayman KY102W User manual

KY102 Ver. 1.4
KY102
USER GUIDE
English
Kayman

KY102 Ver. 1.4
2
TABLE OF CONTENTS
SYMBOLS ................................................................................ 3
1. INTRODUCTION ..................................................................... 4
2. KEY FEATURES ...................................................................... 4
3. APPLICATIONS....................................................................... 4
4. SAFETY INFORMATION............................................................ 5
5. UNPACKING ......................................................................... 6
6. PHYSICAL ............................................................................. 6
6.1 MOUNTING SCREW HOLES FOR ACCESSORIES ............................................. 7
7. WIRING ................................................................................ 8
7.1 IMPEDANCE SWITCH ............................................................................ 8
7.2 COVERAGE SWITCH ............................................................................. 9
8. RIGGING..............................................................................10
8.1 SUSPENDING FROM THE FLY-BAR ...........................................................10
8.2 HANGING ON THE WALL ..................................................................... 11
8.3 STANDING ON THE BASE ..................................................................... 11
8.4 STANDING ON A KMT SUBWOOFER......................................................... 12
8.5 GROUND LAYING ............................................................................... 12
9. SERVICE ............................................................................. 13
10. TECHNICAL SPECIFICATIONS .................................................. 14

KY102 Ver. 1.4
3
SYMBOLS
This symbol alerts the user to the presence of recommendations about
product’s use and maintenance.
This symbol alerts the user to the presence of recommendations about the
product’s use and maintenance.
K-array declares that this device is in compliance with applicable CE
standards and regulations. Before putting the device into operation, please
observe the respective country-specific regulations!
Waste Electrical and Electronic Equipment (WEEE)
Please dispose of this product at the end of its operational lifetime by bringing
it to your local collection point or recycling center for such equipment.
This device complies with the Restriction of Hazardous Substances Directive.
Warning: DANGEROUS VOLTAGE.
Terminals marked with this symbol carry a risk of electric shock, therefore
external wiring connected to these terminals requires installation by a
qualified professional or the use of ready-made leads or cords.

KY102 Ver. 1.4
4
1. INTRODUCTION
2. KEY FEATURES
3. APPLICATIONS
The K-array KY102 is a passive speaker system comprised of eight 4” neodymium magnet transducers
housed in an elegant and sturdy stainless steel frame. The vertical dispersion pattern can be switched
for wide or narrow coverage, allowing for a great variety of applications. The eight closely-spaced
cone drivers boast true line array characteristics, such as phase coherence, low distortion and focused
listening in both the near field and at a distance from the speaker.
A variety of rigging accessories allows for many linking and hanging options for the KY102 in vertical
and horizontal line array configurations to satisfy many different venue requirements during temporary
events as well as permanent installations.
For easier use and integration with other speakers or amplifiers, the KY102 is equipped with two different
values of impedance (8Ω– 32Ω). The KY102 is able to reproduce the whole vocal frequency range with
high intelligibility. Integrating one of K-array’s powered subwoofers (KMT18, KMT21, KMT218), configured
with specific presets for the KY102, assures excellent coverage of the entire musical frequency range.
All KY102 components are designed by the K-array R&D Department and custom-made under the
K-array Quality Control System.
• Unique performance-to-size ratio
• Vertical, horizontal and 3D line array applications
• Multiple 4” long excursion, full-range cone drivers
• Wide horizontal coverage
• Electronically protected
• Selectable 8 ohm or 32 ohm impedance
• Selectable vertical pattern (spot - flood)
• Weather proof, suitable for outdoor installations - IP54
• Theatre, club, house of worship
• Front fill and under-balcony fill
• Portable and installed AV systems
• Stage and AV studio monitoring

KY102 Ver. 1.4
5
4. SAFETY INFORMATION
Warning: failure to follow these safety instructions could result in injury
or damage to the device or other property.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions.
• Keep this instructions.
• Heed all warnings.
• Follow all instructions and keep all warnings.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or
sold with the apparatus.
• When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
• Avoiding hearing damage. Professional loudspeakers are capable of producing extremely high sound
levels and should be used carefully. Never stand close to loudspeakers driven at high volume. Set
the volume to a safe level. You can adapt over time to a higher volume of sound that over time
may sound normal but can be damaging to your hearing. Hearing loss worsens after exposure to a
sound level of 90 dB or over for an extended period of time. If you experience ringing in your ears
or muffled speech, stop listening and have your hearing checked. The louder the volume, the less
time is required before your hearing could be affected.
• Choking Hazards. This device contains small parts, which may present a choking hazard to small
children. Keep the device and its accessories away from small children.
• Do not make repairs yourself. Never attempt to disassemble, repair or modify the system yourself.
Disassembling the unit may cause damage that is not covered under the warranty. The device contains
no user-serviceable parts. Repairs should only be performed by factory trained service personnel.
• Sound distortion. Do not operate speakers for an extended period of time with sound distortion. This
is an indication of malfunction, which in turn can generate heat and result in a fire.
• Carrying, handling and installing the device. The device contains sensitive components. Do not drop,
disassemble, open, crush, bend, deform, puncture, shred, incinerate, paint, or insert foreign objects
into it. If your device has been dropped or damaged unplug the power cable immediately.
• Set up. Set up your device on a stable retaining horizontal surface. If combined or mechanically
connected with other products, always verify the stability of the resulted system. Install the unit only
in a location that can structurally support the weight of the unit and far away from people who can
interfere with the stability of the system. Assure that the wind does not interfere with the system’s
stability, taking extra securities like chains, weights, ropes or any other certified anchoring systems.
Doing otherwise may result in the unit falling down, causing personal injury or property damage
or even death. The system should only be suspended by qualified personnel following safe rigging
practices. Secure fixings to the building structure are vital. To clarify any doubt you may have, seek
help from architects, structural engineers or other specialists.

KY102 Ver. 1.4
6
5. UNPACKING
Each K-array speaker is built to the highest standard and thoroughly inspected before leaving the
factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new amplifier.
If you find any damage, immediately notify the shipping company. Only the consignee may institute a
claim procedure regarding the system’s electronic equipment.
6. PHYSICAL
Weight
14.9 kg (32.8 lbs)

KY102 Ver. 1.4
7
6.1 MOUNTING SCREW HOLES FOR ACCESSORIES
K-JOINT2 K-WALL2

KY102 Ver. 1.4
8
7. WIRING
KY102 internal wiring is designed to pick up audio power signal from pins 1+ / 1- of a Speakon NL4
connector. Pins 1+ and 1-, such as pins 2+ and 2-, are directly wired from one socket to the other, so the
two sockets are equivalent and can be used to connect the speaker to the amplifier or to connect the
speaker to another KY102 driven in parallel by the same amplifier channel.
NOTE:
• The K-array KA84 amplifier can drive up to two KY102 @ 8Ω
per channel or up to four KY102 @ 32Ωin bridge mode.
• The K-array KMT218 and KMT21 powered subwoofers can drive
up to two KY102 @ 8Ω.
7.1 IMPEDANCE SWITCH
KY102 features a switch which allows users to select the impedance of the speaker (8Ω/32Ω).
The value to be selected depends mainly on the amplifier you use to drive the unit. To find the correct
impedance value to be set on the unit, we recommend that you check the Output Configuration Page
on your K-array KA amplifier or KMT active subwoofer you use to drive the unit. Please refer to your
amplifier or KMT’s User Guide for further details.
IMPEDANCE SWITCH COVERAGE SWITCH

KY102 Ver. 1.4
9
KY102 features a switch which allows users to select the vertical coverage of the speaker.
Flood coverage sets a wide vertical diffusion angle of 30°. Flood coverage is suggested for single
speakers in diffused short throw applications to obtain maximum diffusion with a minimum footprint.
Spot coverage sets a narrower vertical diffusion angle of 7° and is recommended for long throw or
monitoring application.
When more units are combined in a line array configuration, make sure to set the coverage to Spot.
SPOT Coverage - 7°
FLOOD Coverage - 30°
7.2 COVERAGE SWITCH

KY102 Ver. 1.4
10
8. RIGGING
K-array offers a variety of dedicated accessories to mount and interconnect the KY102 speakers for a
wide range of applications.
In this section we introduce you to the main accessories available for this product. More information can
be found in the accessories’ user guides.
8.1 SUSPENDING FROM THE FLY-BAR
KY102 units can be suspended using the K-FLY2 fly bar accessory and the K-JOINT2 hardware accessory
used to connect together two units or to connect a unit to the fly bar. Please refer to the K-FLY2 User
Guide to check all the available configurations and for safety information and operation details.
2 KY102 suspended from the K-FLY2
Consult the dedicated product manuals for safety information
and operation details.

KY102 Ver. 1.4
11
8.2 HANGING ON THE WALL
The K-WALL2 accessory is used to mount a KY102 speaker on a wall or a stand.
8.3 STANDING ON THE BASE
The K-BASE2 accessory assists in standing up to 2 units. For proper installation and operation, connect
the units to the base with K-FOOT2 and K-JOINT2 accessories. Where possible, screw the feet of the
K-BASE2 to the ground.

KY102 Ver. 1.4
12
8.4 STANDING ON A KMT SUBWOOFER
Up to two KY102 can be mounted on a KMT subwoofer by using the K-FOOT2 and K-JOINT2 accessories.
Acoustically speaking, two KY102s perfectly match with a KMT218 subwoofer. An excellent example of
the use of this combination is the K-array portable system KR802.
KMT218 + 2 x KY102
8.5 GROUND LAYING
KY-STAGE allows users to safely lay the speakers on the ground with three different angles: 0°, 30° and
45°. Ideal applications are monitoring and front-fill.

KY102 Ver. 1.4
13
9. SERVICE
To obtain service:
1) Contact the official K-array distributor in your country. Your local distributor will direct you to the
appropriate service center.
2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference.
Ask for Customer Service and be prepared to describe the problem clearly and completely.
3) If the problem cannot be resolved over the phone, you may be required to send the unit in for
service. In this instance, you will be provided with an RA (Return Authorization) number which should
be included on all shipping documents and correspondence regarding the repair. Shipping charges are
the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty. Service must
be performed by an authorized K-array service center.
Cleaning:
Use only a soft, dry cloth to clean the product. Do not use any solvents, chemicals, or cleaning
solutions containing alcohol, ammonia, or abrasives. Do not use any sprays near the product or
allow liquids to spill into any openings.

KY102 Ver. 1.4
14
10. TECHNICAL SPECIFICATIONS
Notes for data
1. With dedicated preset;
2. Measured @8 mt then scaled @1 mt;
3. Measured with musical signal
New materials and design are introduced into existing products without previous notice.
Present systems may differ in some respects from those presented in this catalogue.
ACOUSTICS
Power handling 1200 W
Max power 1800 W
Frequency range 110 Hz – 20 kHz (- 3dB) (1)
Impedance 8 Ω/ 32 Ω(selectable)
SPL 1W/1mt 102 dB (2)
Maximum SPL 132 dB (cont.) – 138 dB (peak) (3)
COVERAGE
Horizontal 90°
Vertical 7° / 30° (selectable)
CROSSOVER
Type External crossover required
Frequency High pass @ 90 Hz, 24 dB/oct suggested
minimum
TRANSDUCERS
Full range 8 x 4” Neodymium magnet cone drivers
with 1.5” voice coil
SELECTION SWITCHES
Impedance 8 Ω/ 32 Ω
Coverage Spot / Flood
POWER AUDIO INPUT/OUTPUT
Connector 2 x 4-pin Speakon
Wiring 1+ 1- (signal IN & LINK); 2+ 2- (through)
RECOMMENDED AMPLIFIERS
Type KA84, KMT
CERTIFICATION
IP 54
PHYSICAL
Dimensions 11.6 x 100.0 x 13.4 cm
(4.6” x 39.4” x 5.3”)
Weight 14.9 kg (32.8 lbs)
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may
appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
