K-EIKO EJS120PV User manual

INDUSTRIAL POWER TOOLS
Jig Saw
MODEL EJS120PV
WARNING: THE SAFETY INFORMATION
GIVEN INSIDE MUST BE READ AND
UNDERSTOOD BY ANY PERSON
USING, INSTALLING, REPAIRING
OR MAINTAINING THESE
TOOLS.
•Nonskid large soft grip handle
•Easy-to-operate large trigger switch
(equipped with speed control dial)
•Powerful dust blowing allows a clear view of
the ink line
•Compact and lightweight
OPERATOR'S MANUAL
Please retain this information for future reference

1
GENERAL SAFETY RULES
WARNING!
Read all instructions
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
The term “power tool” in all of the warnings listed below
referstoyourmainsoperated(corded)powertoolorbattery
operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1) Work area
a) Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust.
Power tools create sparks which may ignite the
dust of fumes.
c) Keep children and bystanders away while operating
a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection.
Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c) Avoid accidental starting. Ensure the switch is in
the off position before plugging in.
Carrying power tools with your finger on the
switch or plugging in power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance
at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used.
Use of these devices can reduce dust related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tools operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different from
intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool
is maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.

2
SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) Blade No.31.................................................................1
For cutting thick lumber
(2) Splinter guard.............................................................1
(3) Chip cover ................................................................... 1
(4) Hexagonal bar wrench...............................................1
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
(1) Blades, No.1 – No.6, 31*
* No.31 Blade is a standard accessory.
(2) Guide
Optionalaccessoriesaresubjecttochangewithoutnotice.
APPLICATIONS
䡬Cutting various lumber and pocket cutting
䡬Cutting mild steel plate, aluminum plate, and copper
plate
䡬Cutting synthetic resins, such as phenol resin and
vinyl chloride
䡬Cutting thin and soft construction materials
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If
the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
MOUNTING THE BLADE
1. Use the accessory hexagonal bar wrench to loosen
the blade set screws on the blade holder, as shown in
Fig. 1(a).
2. Holding the blade with its cutting edge facing the
front, insert the mounting portion of the blade into
the plunger groove until it touches the bottom of the
groove.
3. As shown in Fig. 1(b), firmly clamp the side screw.
CAUTION
䡬Loosened set screws may cause the blade to be
damaged. Always ensure that the set screws are
securely tightened. Always ensure that the plunger
grooveisclean and clear of sawdust to ensure proper
blade mounting and set screw clamping.
4. Storing the hexagonal bar wrench
(1) Insert in a hole on the side of the main unit with
holding the short side horizontally as shown in
Fig. 2.
Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)
Power input 400W*
Wood: 65mm
Max. cutting depth Mild steel: 6mm
No-load speed 0 – 3000 min–1
Stroke 18mm
Min. cutting radius 25mm
Weight (without cord) 1.5kg
Fig. 1(a)
Fig. 1(b)
Blade set screw Hexagonal bar wrench
Blade set screw
Roller
Blade (blade edge
must face front)
Blade holder

3
(2) Rotate with the hexagonal bar wrench inserted and
secure as shown in Fig. 2.
ADJUSTING THE GUIDE ROLLER
The guide roller, shown in Fig. 3, is employed to prevent
the blade from snapping. Prior to use, adjust guide roller
in accordance with the following procedures:
(1) Loosen the holder set screw with the accessory
hexagonal bar wrench.
(2) Gently slide the guide roller until the roller groove
lightly touches the back of the blade.
NOTE
On delivery from the factory, there is a gap of about
3mm between the roller and blade.
(3) Firmly tighten the holder set screw.
CAUTION
䡬The guide roller can be used only for Blades that
have a straight line on the rear that is longer than
50mm. (Fig. 4A and 4B) When using other types
of blades (Fig. 4C), slide the guide roller in
backwardssothattheguideroller does not contact
the blade.
䡬When cutting thick boards or performing
continuous cutting operations, use the blade
shown in the Fig. 4A, 4B and be sure to set the
guide roller.
CHIP COVER POSITIONING
1. Chip cover
Use the chip cover to reduce flying of cut particles
and to easily operate the saw.
Slide the chip cover while lightly pressing its front
section.
The chip cover can be set at three positions as shown
in Fig. 5.
2. How to choose the position of the ship cover
Set the chip cover to the first step when attaching or
removing the blade.
Set the chip cover to the second step when cutting
wooden materials.
Set the chip cover to the second or third step when
cutting metal materials such as steel.
CAUTION
䡬Keep always the chip cover in the low position when
operating the tool.
䡬Wear protection glasses even if the chip cover is
used.
Fig. 2
Fig. 3
Fig. 4
123
Fig. 5
Chip cover
Main unit
Hexagonal bar wrench
Blade set screw
Holder
Blade holder
Roller

4
ADJUSTING THE BLADE OPERATING SPEED
The blade operating speed can be adjusted within a
range of 0 to 3000 min–1 according to the degree that the
triggerswitch is depressed. Select the speed appropriate
to the material being worked and/or the working
conditions.
To achieve continuous operation, pull the trigger switch
all the way back and depress the stopper. Then, turn the
speed adjustment knob to adjust the blade operating
speed as desired.
NOTE
The speed adjustment knob rotates approximately 1.5
turns. To turn the switch OFF, pull the trigger switch
again to disengage the stopper, and release the trigger
switch.
CUTTING
CAUTION
䡬Whilesawing, the base must be firmly in contactwith
the material surface, and the blade must be held at a
right angle. If the base becomes separated from the
material, it could cause the blade to break.
䡬When cutting while holding the front surface, be
careful of the moving blade and hold the upper part
firmly.
1. Rectilinear cutting
(1) To ensure accurate rectilinear cutting, employ the
optional accessory guide as shown in Fig. 6.
(2) Use the splinter guard to reduce roughness of the
cutting surface of wooden materials. Attach the
splinter guard by inserting it from the front section of
the base until it clicks into place. (Fig. 7)
CAUTION
Set the base in the front position when using the
splinter guard.
2. Cutting a circle or a circular arc
To ensure efficient cutting, employ the optional
accessory guide and nail or wood screw as shown in
Fig. 8.
When mounting the guide, loosen the base bottom
screw, and shift the base as far forward as it will go.
3. Sawing curved lines
When sawing a small circular arc, reduce the feeding
speed of the machine. If the machine is fed too fast, it
could cause the blade to break.
4. Cutting metallic materials
Always use an appropriate cutting agent (spindle oil,
soapy water, etc.). When a liquid cutting agent is not
available, apply grease to the back surface of the
material to be cut.
5. Pocket cutting
(1) In lumber
Aligning the blade direction with the grain of the
wood, cut step by step until a window hole is cut in
the center of the lumber. (Fig. 9)
(2) In other materials
When cutting a window hole in materials other than
lumber, initially bore a hole with a drill or similar tool
from which to start cutting.
Fig. 6
Fig. 7
Fig. 8
Fig. 9
4mm screw (8mm)
Guide
Splinter guard
Base
Guide
4mm screw (8mm)
Nail or wood
screw

5
6. Angular cutting
Set the chip cover to the first step. (Fig. 5)
To adjust the angle of inclination; loosen the base
bottom screw, shift the base position to the side
groove of the semicircular portion, align the scale on
the base semicircular portion (figures engraved on
the scale indicate the angle of inclination) with the
housing edge line, and thoroughly tighten the base
bottom screw. (Fig. 10 and 11)
CAUTION
Set the screw to the opposite side of the inclining
side when using the guide. (Fig. 12)
7. Dust produced in operation
CAUTION
䡬To prevent accidents, turn the switch off and remove
the plug from the power supply when not in use.
䡬For instruction on using the dust collector and
applicable cutting debris, please read the dust
collector instruction manual.
The dust produced in normal operation may affect
the operator’s health. Either of following way is
recommended.
a) Wear a dust mask
b) Use external dust collection equipment
When using the external dust collection equipment,
connect the rubber adapter (accessory of external
dust collection equipment) with end the of hose from
external dust collection equipment.
Then connect the another end of rubber adapter with
the hose attachment part that positioned in rear end
of jig saw. (See Fig. 13)
SELECTION OF BLADES
1. Accessory blades
To ensure maximum operating efficiency and results
it is very important to select the appropriate blade
best suited to the type and thickness of the material
to be cut. One type of blade is provided as standard
accessory. The blade number is engraved in the
vicinity of the mounting portion of each blade. Select
appropriate blades by referring to Table 1.
Fig. 10
Fig. 11
Fig. 12
Guide
4mm
screw
(8mm)
Base
Scale Housingedge
line
Sidegroove
4mm
screw
(8mm)
Fig. 13
Hose
attachment part

6
2. Acceptable commercial blades (Fig. 14)
This machine is designed to accept most blades
available on the open market. As illustrated in
Fig. 14, blade dimension restrictions are as follows:
䡬Thickness: L2 .....Less than 1.6mm
䡬Width : L3 ..... 6.3mm
L4 .....8mm
L5 .....7mm
NOTE
Whencutting thick materials, use K-EIKO genuine blades
which have an inclination as shown in Fig. 4-A or B.
MAINTENANCE AND INSPECTION
1. Inspecting the blade
Continued use of a dull or damaged blade will result
in reduced cutting efficiency and may cause
overloading of the motor. Replace the blade with a
new one as soon as excessive abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure
that they are properly tightened. Should any of the
screws be loose, retighten them immediately. Failure
to do so could result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the
power tool. Exercise due care to ensure the winding
does not become damaged and/or wet with oil or
water.
Table 1 List of Appropriate Blades
Material to be cut Material quality Blade No.
Lumber General lumber
No.1 or No.31 (thick plate) or No.41 (thick
plate) or No.2 (thin plate)
Plywood No.3 or No.6
Iron plate Mild steel plate No.6
Nonferrous metal Aluminum, copper, brass No.6
Phenol resin, melamine resin, etc. No.4 (thick plate) or No.6 (thin plate)
Synthetic resin Vinyl chloride, acryl resin, etc. No.2 or No.4 (thick plate) or No.6
(thin plate)
Foamed styrol, etc. No.2
Pulp Cardboard, corrugated paper No.2
Hardboard No.5 or No.6
Fiberboard No.6
Others Hard rubber No.2
Slate No.5
4. Replacing supply cord
If the supply cord of Tool is damaged, the Tool must
be returned to K-EIKO Authorized Service Center for
the cord to be replaced.
5. Servicing
Consult an authorized Service Agent in the event of
power tool failure.
6. Service parts list
CAUTION
Repair, modification and inspection of K-EIKO Power
Tools must be carried out by an K-EIKO Authorized
Service Center.
This Parts List will be helpful if presented with the
tool to the K-EIKO Authorized Service Center when
requesting repair or other maintenance.
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
MODIFICATIONS
K-EIKO Power Tools are constantly being improved
and modified to incorporate the latest technological
advancements.
Accordingly, some parts may be changed without
prior notice.
NOTE
Due to K-EIKO’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
Fig. 14
Acceptable blades

7
IMPORTANT
Correct connection of the plug
The wires of the main lead are coloured in accordance
with the following code:
Blue : –Neutral
Brown : –Live
As the colours of the wires in the main lead of this tool
may not correspond with the coloured markings
identifyingtheterminals in your plug proceed as follows:
Thewirecolouredbluemustbeconnectedtotheterminal
marked with the letter N or coloured black. The wire
coloured brown must be connected to the terminal
marked with the letter L or coloured red. Neither core
must be connected to the earth terminal.
NOTE
This requirement is provided according to BRITISH
STANDARD 2769: 1984
Therefore, the letter code and colour code may not be
applicable to other markets except The United Kingdom.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
Measured A-weighted sound power level: 95 dB (A).
Measured A-weighted sound pressure level: 84 dB (A).
Uncertainty KpA: 3 dB (A).
Wear ear protection.
The typical weighted root mean square acceleration
value: 10.2 m/s2.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2002/96/EC on
waste electrical and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility.

8
502
1
2
4
5
6
78
9
10
12
13
11
3
14
15
16
17
18
19
20
12
21
22
23
24
25
26
27
28
29
30
501
Item
No. Part Name
1 CHIP COVER
2 GUARD BAR
3 LABEL
4 HOUSING (A), (B) SET
5 SWITCH
6 NOISE SUPPRESSOR
7 TAPPING SCREW (W/FLANGE) D4×20
8 NAME PLATE
9 CORD CLIP
10 TAPPING SCREW (W/FLANGE) D4×16
11 BASE
12 HEX. SOCKET HD. BOLT M4×8
13 PLATE NUT
14 CARBON BRUSH
15 BRUSH HOLDER
16 CORD ARMOR
17 ROLLER HOLDER
18 HEX. SOCKET HD. BOLT M4×16
19 CORD
20 PLUNGER HOLDER
21 PLUNGER
22 CONNECTING PIECE
23 GEAR
24 WASHER
25 HOLDER
26 BALL BEARING 608VVMC2EPS2L
27 ARMATURE
28 BALL BEARING 626VVMC2ERPS2S
29 STATOR
30 TERMINAL
501 HEX. BAR WRENCH 3MM
502 SPLINTER GUARD

9

10

701
Code No. C99160611
Printed in China
EC DECLARATION OF CONFORMITY
We declare under our sole responsibility that this
product is in conformity with standards or
standardized documents EN60745, EN55014 and
EN61000-3 in accordance with Council Directives
73/23/EEC, 89/336/EEC and 98/37/EC.
Manufactured for
KENNEDY TOOLS
Wigston Works, Leicester, England.
ISO 9002 REGISTERED COMPANY
Signed:
Date: 31 January 2007
Name: Martin Cooke
Position: Director, The Kennedy Group Ltd.
QUALITY GUARANTEE & WARRANTY
K–EIKO INDUSTRIAL POWER TOOLS carry one years manufacturers warranty.
K–EIKO INDUSTRIAL POWER TOOLS are designed & manufactured
to the highest standards & specifications
Assuring the quality and performance required by all sectors of industry.
K–EIKO INDUSTRIAL POWER TOOLS are fully guaranteed against
faulty materials & workmanship
Should they be found to be defective, they will either be repaired or replaced free of charge
(fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
Manufactured For:
KENNEDY TOOLS
Wigston Works, Leicester, England.
ISO 9001 REGISTERED COMPANY
AVAILABLE FROM YOUR DISTRIBUTOR
