BlueSpot 20511 User manual

9 PCE DOWNLIGHT
INSTALLATION KIT (51 - 75MM)
User Manual
20511

01
Thank you for purchasing a BlueSpot product, you can find further information
on our range at www.BlueSpot.uk.com. Please ensure that you are using the
product correctly and that all guidance and cautions are followed in accordance
with the instructions. Please retain these instructions for future reference.
General Information
Please make sure that you read these instructions carefully in order to avoid injury when
using the downlight installation kit. Follow all health and safety rules and regulations. If in
doubt and available please contact a more knowledgeable source.
DO NOT use if damaged.
• ALWAYS ensure the holesaws have been checked for any damage before use. Any
damage found needs to be repaired or replaced before use to prevent damage to
property or personal injury.
• ALWAYS ensure the drill has been checked for any damage before use. Any damage
found needs to be repaired or replaced before use to prevent damage to property or
personal injury.
• ALWAYS ensure that operators are fully comfortable operating the downlight
installation kit and understand all of the safety precautions before beginning.
• ALWAYS make sure the holesaw has been attached to the drill correctly and there is a
secure connection before beginning.
• ALWAYS ensure the drill is unplugged and not in use when changing the holesaws.
• ALWAYS dress appropriately – clothing should be close fitted and long hair tied back.
Jewellery should be removed and shoes should be worn with a non-slip sole.
• ALWAYS wear the correct eye or face protection when operating the downlight
installation kit.
• ALWAYS wear approved work gloves when operating the downlight installation kit.
• ALWAYS wear approved respiratory protection. This will help protect you from
any dust.
• ALWAYS ensure you work in a well ventilated room.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Keep children and unauthorised persons away from the work area.
• ALWAYS ensure the correct size arbor is used for the holesaw.
Safe use
• BE AWARE that the set contains sharp blades. Keep away from children at all times.
• BE AWARE not to use too much pressure when using the holesaw.
• NEVER leave the downlight installation kit unattended. When you have finished using
the kit it should be stored away in a safe place that is out of reach of children.
• NEVER try to get the downlight installation kit to perform a task that it was not made
for. Do not overload or misuse the tool.
• NEVER operate the tool if you are under the influence of drugs or alcohol as this
is dangerous.
• DO NOT operate the downlight installation kit if you are tired as this is dangerous.
• If the downlight installation kit is damaged do not use.

Please make sure that you read these instructions carefully in order to avoid injury when
using the downlight installation kit. Follow all health and safety rules and regulations. If in
doubt and available please contact a more knowledgeable source.
DO NOT use if damaged.
• ALWAYS ensure the holesaws have been checked for any damage before use. Any
damage found needs to be repaired or replaced before use to prevent damage to
property or personal injury.
• ALWAYS ensure the drill has been checked for any damage before use. Any damage
found needs to be repaired or replaced before use to prevent damage to property or
personal injury.
• ALWAYS ensure that operators are fully comfortable operating the downlight
installation kit and understand all of the safety precautions before beginning.
• ALWAYS make sure the holesaw has been attached to the drill correctly and there is a
secure connection before beginning.
• ALWAYS ensure the drill is unplugged and not in use when changing the holesaws.
• ALWAYS dress appropriately – clothing should be close fitted and long hair tied back.
Jewellery should be removed and shoes should be worn with a non-slip sole.
• ALWAYS wear the correct eye or face protection when operating the downlight
installation kit.
• ALWAYS wear approved work gloves when operating the downlight installation kit.
• ALWAYS wear approved respiratory protection. This will help protect you from
any dust.
• ALWAYS ensure you work in a well ventilated room.
• Maintain tool in good and clean condition for best and safest performance.
• Keep the work area clean, uncluttered and ensure there is adequate lighting.
• Keep children and unauthorised persons away from the work area.
• ALWAYS ensure the correct size arbor is used for the holesaw.
02
Safe Use (continued)
Introduction
The BlueSpot 9 Piece Downlight Installation Kit features six popular sizes of holesaws
specially designed to enable installation of downlights. Includes arbor, hex key and
reinforcing plate.
Package contents - 51, 60, 64, 70, 76 & 86mm. Arbor. Hex key wrench. Reinforcing plate.
Parts Diagram
• BE AWARE that the set contains sharp blades. Keep away from children at all times.
• BE AWARE not to use too much pressure when using the holesaw.
• NEVER leave the downlight installation kit unattended. When you have finished using
the kit it should be stored away in a safe place that is out of reach of children.
• NEVER try to get the downlight installation kit to perform a task that it was not made
for. Do not overload or misuse the tool.
• NEVER operate the tool if you are under the influence of drugs or alcohol as this
is dangerous.
• DO NOT operate the downlight installation kit if you are tired as this is dangerous.
• If the downlight installation kit is damaged do not use.
Arbor Pilot Dril
Bit
Set
Screw
Arbor
Nut
Hole
Saw
Drive Plate
(some saws)

03
Operation
ALWAYS ensure that operators are fully comfortable operating the downlight installation
kit and understand all of the safety precautions before beginning.
ALWAYS ensure the drill is not connected to a power source and is fully switched off
before attaching the holesaw to the drill.
ALWAYS ensure you have checked and are aware of whether there are any wires or pipes
above where you are drilling.
Note – We always recommend testing this first on a test piece of material until you
become comfortable operating the downlight installation kit.
How to attach a holesaw to a drill
1. Choose the holesaw that has the diameter needed for the hole that you would like
to cut.
2. Refer to the parts diagram on page 2 and check the fit of the arbor with the holesaw.
3. Unthread the arbor nut from the arbor.
4.The holesaw in the downlight installation kit has three holes at the back. A drive plate
will have been provided in the set.This will need to be used on the back of the holesaw
to provide a secure connection.
5. Insert the arbor through the centre of the holesaw and drive plate.Then secure in
place using the mandrel nut.
ALWAYS ensure that there is a tight and secure connection between the holesaw and
the arbor.
6. On your drill open the jaws of the drill chuck.
7. Insert the arbor into the drill chuck.
ALWAYS ensure that the drill chuck has been tightened and that there is a secure
connection before operation.
How to use the downlight installation kit
1. Mark the centre of the hole that you would like to cut. Drill a pilot hole completely
through the workpiece.
2. Align the holesaw on the centre of the workpiece with the pilot hole you have just
drilled. The drill should be held at 90°.
3. Pull the trigger on the drill and make contact with the workpiece, pressing straight in.
4. Start slowly and increase the speed of the drill when a circle groove has been made in
the workpiece, pushing the drill in with moderate pressure.
5. When the hole has been cut release the trigger on the drill.
ALWAYS ensure the drill has come to a complete stop before it is removed from the
workpiece.

04
Disposal
Always check and adhere to national regulations when disposing of any tools that are no
longer functional and cannot be repaired.
• Contact your local waste disposal authority for information on how to correctly
Dispose of tools.
Contact
Find out more about the BlueSpot® products at www.BlueSpot.uk.com
Tel: [phone]
Email: [email protected]
Orme Business Centre, Greenacres Road, Oldham, OL4 3NS
Notes
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and
packaging should be sorted, taken to a recycling centre and disposed of in a manner which is
compatible with the environment. When the product becomes completely unserviceable and
requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Environmental Protection
Storage
ALWAYS ensure the downlight installation kit is stored out of reach of children.
Store the tool in a secure, dry place.
Cleaning & Maintenance
Clean the downlight installation kit with a dry cloth if needed.
Operation (continued)
6. When complete remove the holesaw from the drills chuck.
7. Refer to the instructions on the downlight kit for how to install the downlights.
