Metallkraft TBS Series User manual

TBS Series
Operating Instructions
TBS 650-12 T
TBS-SERIES
Shearing Machine
TBS 1050-10 T

2TBS-Series | Version 1.01
Imprint
Product Identification
Shearing Machine Article number
TBS 650-12 T 3776165
TBS 1250 E 3776111
Manufacturer
Stuermer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Hotline: [phone] - 0
Fax: [phone] - 55
E-Mail: [email protected]
Internet: www.metallkraft.de
Indications regarding the operating instructions
Original Instructions
Edition: 12.05.2014
Version: 1.01
Language: English
Autor: AV/MS
Indications regarding the copyright
Copyright © 2014 Stuermer Maschinen GmbH, Hall-
stadt,Germany.
The contents of these operating instructions is the sole
property of the company Stürmer Maschinen GmbH.
Passing on as well as copying of this document, the use
and distribution of its content are prohibited if not explic-
itly permitted. Contraventions are liable to compensa-
tion.
Subject to technical modifications and error.
Content
Imprint .....................................................................2
1 Introduction .............................................................3
1.1 Copyright ............................................................ 3
1.2 Customer Service ............................................... 3
1.3 Limitation of Liability ........................................... 3
2 Safety........................................................................3
2.1 Symbol Explanation............................................ 3
2.2 Specified Usage ................................................. 4
2.3 Personal protective equipment........................... 4
2.4 Safety signs on the machine .............................. 5
3 Technical Data.........................................................5
3.1 Type plate........................................................... 5
4 Transport, Packaging, Storage ..............................5
4.1 Delivery and Transport ....................................... 5
4.2 Packaging........................................................... 6
4.3 Storage ............................................................... 6
5 Description of the machine ....................................6
6 Installation and Operation ......................................6
6.1 Installation........................................................... 6
6.2 Operating............................................................ 7
7 Maintenance and Care ............................................7
7.1 Care by cleaning ................................................ 7
7.2 Maintenance and repair ..................................... 7
7.3 Lubrication Checking ........................................ 8
8 Troubleshooting ......................................................8
9 Disposal, recycling of used devices......................8
9.1 Decommissioning ............................................... 8
9.2 Disposal of lubricants......................................... 8
10 Liability for defects (warranty).............................8
11 Spare parts.............................................................9
11.1 Order of spare parts........................................ 9
11.2 Spare parts drawing...................................... 10
12 EC Declaration of Conformity ............................11

Introduction
TBS-Series | Version 1.01 3
1Introduction
You have made a good choice by purchasing the
Shearing Machine made by METALLKRAFT.
Thoroughly read the operating instructions before commission-
ing the machine.
It informs you about the proper commissioning, the in-
tended use as well as the safe and efficient operation
and maintenance of your machine.
The operating instructions are part of the machine. Al-
ways keep it at the place of use of the machine. Further-
more, the local accident prevention regulations and the
general safety notes are applicable for the field of appli-
cation of the machine.
The illustrations in these operating instructions serve the
general comprehension and may deviate from the ac-
tual type.
1.1 Copyright
The contents of these instructions are copyright. Their
application is admissible in the frame of the machine
utilisation. An application beyond the described appli-
cation is not allowed without written approval of the
manufacturer.
1.2 Customer Service
Please call our Customer Service for technical support.
Germany:
Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Str. 26
D-96103 Hallstadt
Service:
Hotline: [phone]-100
Fax: [phone]-111
E-Mail: [e-mail]
Internet: www.metallkraft.de
Spare part orders:
Fax: [phone]-119
E-Mail: [e-mail]
We are always interested in valuable experience and
knowledge gained from using the application, which-
then could be shared and be valuable to develop our-
products even further.
1.3 Limitation of Liability
All information and notes in these operating instructions
were summarised taking the applicable standards and
rules, the state-of-the-art and our long-term knowledge
and experiences into consideration.
In the following cases the manufacturer is not liable for
damages:
- Non-observance of the operating instructions,
- Inappropriate use,
- Use of untrained staff,
- Unauthorised modifications,
- Technical changes,
- Use of not allowed spare parts.
The actual scope of delivery may deviate from the ex-
planations and presentations described here in case of
special models, when using additional ordering options
or due to latest technical modifications.
The obligations agreed in the delivery contract, the gen-
eral terms and conditions as well as the delivery condi-
tions of the manufacturer and the legal regulations at the
time of the conclusion of the contract are applicable.
2 Safety
This paragraph will give you an overview of all important
safety packages for the protection of the people using it
well as for a safe and undisturbed operation. Other task-
based safety notes are included in the individual chap-
ters.
2.1 Symbol Explanation
Safety Instructions
The safety notes in these operating instructions are
highlighted by symbols. The safety notes are introduced
by signal words which express the concern of the risk.
WARNING!
This combination of symbol and signal words indi-
cates an imminently dangerous situation which may
lead to death or severe injuries if they are not
avoided.

4TBS-Series | Version 1.01
Safety
Tips and recommendations
It is necessary to observe the safety notes quoted in
these operating instructions in order to reduce the risks
for personal injuries and damages to property.
2.2 Specified Usage
The Shearing Machine is exclusively allowed to cut
metal, paper, plates, plastics and other suitable materi-
als. Only qualified person who are familar with this ma-
chine are allowed to use it. To intended use of the ma-
chine belongs the adherence of all details in this
instructions, too. Any use beyond the proper use or any
other use is regarded as misuse.
Unauthorized reconstructions or modifications on the
Shearing Machines are forbidden and the EC Declara-
tion of Conformity of the Shearing Machines can be-
come void. The company Stürmer Maschinen GmbH is
not liable for any constructive and technical modifica-
tions on the Shearing Machines.
During improper use of the Shearing Machines as well
as disregarding of safety instructions or user‘s guide ex-
clude the liability of the manufacturer for consequential
resultant damages to persons or items and effect the
termination of the warranty claim!
2.3 Personal protective equipment
The personal protective equipment serves to protect
persons against impairments of safety and health while
working. The staff has to wear personal protective
equipment while performing different works on and with
the appliance which are indicated in the individual para-
graphs of these instructions.
The personal protective equipment is explained in the
following paragraph:
CAUTION!
This combination of symbol and signal words indi-
cates a possibly dangerous situation which may
lead to minor or light injuries if they are not avoided.
NOTE!
This combination of symbol and signal words indi-
cates a possibly dangerous situation which may
lead to property and environmental damages if they
are not avoided.
Tips and recommendations
This symbol highlights useful tips and recommenda-
tions as well as information for an efficient and trou-
ble-free operation.
WARNING!
Danger in case of insufficient qualification
of the staff!
Incorrect use of the machine can cause dangerous
situations.
- Operate the machine only in range of performance,
which is mentioned in the technical specifications.
- Never bypass or overrule the safety system.
- Operate the machine only in very best technical
condition.
Headgear
The industrial helmet protect the head against fall-
ing-objects and against banging on static items.
Hearing protection
The hearing protection protect the ears against
hearing disorder by noise.
Protective goggles
The protective goggles protect the eyes against fly-
ing parts and liquid spillings.
Protective gloves
The protective gloves protect the hands against
sharp components as well as against friction, abra-
sions or deep injuries.
Safety boots
The safety boots protect the feet against crushes,
falling parts and slipping over on slippery under-
ground.
Protective clothes
The protective clothes are tight clothes of little ten-
sile strength.

Technical Data
TBS-Series | Version 1.01 5
2.4 Safety signs on the machine
At the Shearing Machine are several danger and safety
signs attached (Fig. 1), which must be observed and fol-
lowed.
Fig. 1: Safety Signs - 1 Safety Instructions |
2 Warning Sign crushing hazard |
The safety markings which are applied on the machine
must not be removed. Damaged or missing safety mark-
ings may lead to errors, personal and material dam-
ages. Immediately replace them. The machine must be
put out of operation from the moment when the signs are
unable to be recognized and understood at first glance,
until new signs are attached.
3 Technical Data
3.1 Type plate
Fig. 2: Type plate of TBS 1050-10 T
4 Transport, Packaging, Storage
4.1 Delivery and Transport
Delivery
Check if there are any visible transportation damages
after delivery of the machine. If the machine shows any
damages, immediately inform the carrier or the distribu-
tor.
Transport
For delivery the machine is permanently mounted on a
pallet so that it can be transported with a forklift or a
pallet truck.
1
2
TBS 650-12 T TBS 1050-10 T
Max. working
width
650 mm 1050 mm
Max. sheet
thickness
1,25 mm 1,0 mm
Range of rear
end stop
0 - 500 mm 0 - 500 mm
Weight 100 kg 160 kg
Dimensions
LxWxH [mm]
970x470x540 1370x480x580
ATTENTION!
Take care that the handling and lifting equipment
can accommodate the load during transport and lift-
ing.

6TBS-Series | Version 1.01
Description of the machine
4.2 Packaging
All used packaging materials and packaging aids of the
appliance are recyclable and generally need to be
transported to the material recycling.
Crush the packaging material made of cardboard and
supply it to the waste paper collection.
The films are made of polyethylene (PE) and the uphol-
stery parts are made of polystyrene (PS). These materi-
als have to be delivered to a recycling station or a
proper waste management company.
4.3 Storage
The machine must be stored thoroughly cleaned in a dry,
clean and frost-free environment. It must not be placed
in the same room together with chemicals.
5 Description of the machine
The illustrations in these operating instructions serve the
general comprehension and may deviate from the actual type.
Fig. 3: Description TBS 1050-10 T
1 Hand lever
2 Holding down clamp
3 Work bench
4 Back end stop
5 Clamping lever
6 Shaft
7 End stop of bending angle
6 Installation and Operation
6.1 Installation
To achieve a good functioning of the folding machine
and a long service life, the location should meet the fol-
lowing criteria:
- The ground must be level, stable and free of vibra-
tions.
- The working area must be dry and well ventilated.
- Machines causing dust and chips should not be
operated in the vicinityof the Shearing Machine.
- There must be enough space for the operating
personnel, for the transport of material as well as
for adjusting and maintenance.
- The working area must have good lighting.
In the condition as delivered the Shearing Machine is
with exception of some of the mounting parts pre-as-
sembled. The scope of delivery includes in addition still
several accessories.
Step 1: Mounting the hand lever (1, Fig.3) on the con-
nector.
Step 2: Put the back end stop (4, Fig.3) on the support
at the rear and fix it by the clamping lever.
Step 3: Fix the end stop of bending angle (7, Fig.3) at
the scale by the clamping lever.
Use protective gloves!
Use protective boots!
Wear protective clothes!
WARNING!
Risk of crushing!
In case of improper work on the Shearing Machine
the risk of injury of the upper extremities is high.
NOTE!
After installation remove the grease from the blank
metal parts which has been applied for protection.
- Use normal solvents for this.
- Do not use water, nitro solvents, or similar!

Maintenance and Care
TBS-Series | Version 1.01 7
6.2 Operating
Step 1: Put the workpiece on worktable, place the scale
into correct position and set the end stops to the
desired positions.
Step 2: Press the workpiece against the end stops and
fix it with the holding down clamp. Therefore
move the bending lever a bit downwards.
Step 3: Move the bending lever completely downwards
to perform the cutting.
7Maintenance and Care
7.1 Care by cleaning
Clean the machine in regular intervals using a soft and
moistened cloth.
Treat blank metallic working surfaces with anti-rust
spray.
7.2 Maintenance and repair
Lubricate all moving parts and bearings once per
month.
Maintenance and repair works must only be performed
by specialists. If the machine does not work properly,
please contact a specialised dealer or our customer
service. Please find the contact data on chapter 1.2
Customer service.
WARNING!
Danger in case of insufficient qualification of the staff!
Insufficiently qualified persons cannot estimate the
risks while using the machine and expose yourself
and others to the danger of severe injuries.
- Have all works only performed by qualified per-
sons.
- Keep insufficiently qualified persons out of the
working area.
CAUTION!
Risk of crushing!
In case of improper works on the machine there is a
risk of injury on the upper limbs.
WARNING!
There is danger for the operator and for other per-
sons if they do not comply with the following rules.
- The operator must not work if he is under the influ-
ence of alcohol, drugs or medication.
- The operator must not work if he is overworked or
suffers from fatigue and difficulties in concentrat-
ing.
- Operators must be familiar with the structure and
function of this machine.
- The folding machine may only be operated by one
skilled person. Other persons must not enter the
working area during operation.
Use protective gloves!
Use protective boots!
Wear protective clothes!
Tips and recommendations
In order that the machine is always in good operat-
ing status, it is necessary to regularly perform care
and maintenance works.
WARNING!
Danger in case of insufficient qualification
of the staff!
Insufficiently qualified persons cannot estimate the
risks while performing repair work at the appliance
and expose themselves and others to the danger of
severe injuries.
- Have all maintenance works only performed by
qualified persons.
NOTE!
After maintenance, repair and cleaning works,
check if all claddings and protective equipment are
properly reassembled to the machine and that there
are no more tools inside or in the working area of of
the appliance..
ATTENTION!
Never use solvents or cleaning solutions to clean
plastic parts or lacquered surfaces. The surface may
be dissolved and consequential damage may occur.
use water containing mild cleaning detergents.

8TBS-Series | Version 1.01
Troubleshooting
7.3 Lubrication Checking
8 Troubleshooting
9 Disposal, recycling of used devices
ImFor environmental benefits it is necessary to ensure
that all components of the machine are only disposed of
by the provided and allowed means.
9.1 Decommissioning
Immediately decommission used machines in order to
avoid later misuse and endangering of the environment
or of persons.
- Dispose of all environmentally hazardous operating
materials of the used device.
- If required, disassemble the machine into easy-to-han-
dle and usable components and parts.
- Supply the machine components and operating mate-
rials to the provided disposal routes.
9.2 Disposal of lubricants
The manufacturer of the lubricant makes the disposal in-
structions for the used lubricants available. If applica-
ble, ask for the product-specific data sheets.
10 Liability for defects (warranty)
The legal regulations apply for our customers who are the con-
sumers. The customer has to give us the opportunity to con-
vince ourselves of the defect and to bring the product at our re-
quest and cost to one of our shops for examination. The
following points apply for our commercial customers:
(1) The customer has to check the delivered goods immedi-
ately upon delivery in particular on defects. He has to inform us
immediately about any determined apparent defects. He also
immediately has to inform the carrier about any transportation
damages and missing packages. If it is not possible to immedi-
ately detect the defects even though the goods are thoroughly
checked, he has to inform us immediately upon detection of the
defects in writing. In this case our customer immediately has to
stop the processing, machining and use of the ordered goods.
The customer has to give us the opportunity to convince our-
selves of the defect and to bring the product at our request and
cost to one of our shops for examination. After execution of an
agreed acceptance, the notice of defects which were identifia-
ble during acceptance shall be excluded. For commercial cus-
tomers, the legal term of liability for defects of 2 years is being
omitted.
(2) The term of liability for defects amounts to one year from the
passing of risk unless otherwise stated in the contract or law. If
the manufacturer of the delivered product grants a longer term
of liability for defects, we assign our rights hereof to the pur-
chaser/buyer already with the purchase of the product. We will
provide you a current list of the individual terms and conditions
of liability for defects of the manufacturers at any time upon
your request.
(3) In case of warranty we will provide rework or replacement in
consultation with the manufacturer at our choice. Necessary
expenses, in particular transportation, travel, labour and mate-
rial costs which are occurring since the purchased product
was transported to another place than the place of fulfilment,
do not imperatively have to be paid by us, unless it is pre-
scribed by the law. If reworks or replacements regarding a
defect demonstrably fail twice or would the repair of the defect
require a disproportionately high effort and the rework is there-
fore refused, the customer may request a reduction of the
reimbursement or an annulment of the contract. We point out to
our customers that there is no case of liability for defect in par-
ticular in case of defects which had been caused at the
premises of the customer due to misuse or improper use and
for defects which had been caused because the products
were exposed to damaging external influences (in particular
extreme temperatures, humidity, exceptional physical or elec-
trical stress, voltage fluctuations, lightning strikes, static elec-
tricity, fire) at the premises of the customer.
(4) If it results in the frame of an examination of the product due
to a notice of defects that the notice of defects was unjustified,
we are entitled to invoice a customary charge for the examina-
tion of the product as well as the transportation costs
(5) Our warranty does neither cover natural wear and tear,
improper use and storage, faulty installation nor damages
which are occurring after the passage of risk due to faulty or
negligent usage, excessive stress, improper operating equip-
ment or due to any other influences which are not provided
according to the contract.
(6) The claim for liability of defects due to an error is excluded
for any repair works performed by the purchaser/buyer or third
parties without our approval or improper repairs by a service
partner that is not authorised by the manufacturer.
Interval of lubrication Activity
Before operation Lubricate blade and bear-
ing of lever
Before operation Lubricate gears
Weekly Lubricate holding down
clamping
Weekly Lubricate bearing of the
cam
Monthly Lubricate rear end stop
Fault Remedy
Formation of fins at
the cutting edge
1. Cutting gap is too big,
new setting of the cutting
gap.
2. Blade dulled, change
blade
Cutted workpiece
doesn´t show the
dimensions of the
setting.
New setting of end stop.

Spare parts
TBS-Series | Version 1.01 9
(7) In cases of positive breach of contract, delay, impossibility,
unauthorised action as well as any other legal basis (except for
precontractual violations) we are only liable in case of intent or
gross negligence. In cases where culpable damage is caused
to live or health or bodily damage is caused, in cases of culpa-
ble negligence of cardinal contractual obligations (main con-
tractual obligations) or in the case of wilful deception as well as
in the event of a claim according to § 437 figure 2 Civil Law we
are liable to the statutory extent, whereby our liability for the
violation of cardinal obligations is limited to the amount of typi-
cally foreseeable damages. The term of cardinal obligations is
either used to denote a concretely described integral obliga-
tion jeopardising the attainment of the contractual purpose or
abstractly elucidated as a duty which must be fulfilled in order
that the contract can be duly and properly and on whose fulfil-
ment the customer may ordinarily rely. If we are in delay our
customer has either the right to demand damages or the right
to withdraw from the contract.
(8) In case of data losses we are only liable if our customer has
demonstrably saved the data stocks in regular intervals at least
once a day. The liability for data losses is limited to the restora-
tion cost if a backup copy is available, unless the data losses
were caused by us intentionally or grossly negligent. Other-
wise a liability is excluded except in cases of intent or gross
negligence.
(9) The scope of our liability according to the German Product
Liability Act remains unaffected.
11 Spare parts
11.1 Order of spare parts
The spare parts may be purchased with the authorised
dealer or directly with the manufacturer. Please find the
corresponding contact data in Chapter 1.2 Customer
service.
Indicate the following basic information for spare part
orders:
- Type of device
- Article number
- Part number
- Quantity
- Year of manufacturing
- Required mode of dispatch (mail, freight, sea, air,
express)
- Address of dispatch
Spare part orders which do not include the above indi-
cations may not be taken into consideration. If the indi-
cations regarding the mode of dispatch are missing, the
product is dispatched at the discretion of the supplier.
You will find indications regarding the device type, arti-
cle number and year of manufacturing on the type plate
which is fixed on the device.
Example
If it is necessary to order the bending lever for the
shearing machine TBS 1050-10 T.
- Type of machine: Shearing Machine TBS 1050-10 T
- Article number: 377 6111
- Part number: 52
The order No. is: 0-377 6111-52
The order No. consists of the article number, the part
number and one digit in front of the article number.
- Place the digit 0 in front of the article number.
- Also place the digit 0 in front of the part numbers 1
through 9.
Article numbers of your appliance:
Shearing Machine TBS 650-12 T: 377 6165
Shearing Machine TBS 1050-10 T: 377 6111
DANGER!
Danger of injury by the use of wrong spare
parts!
Dangers may result for the user and damages as
well as malfunctions may be caused by using wrong
or damaged spare parts.
- Only use original spare parts of the manufacturer or
spare parts admitted by the manufacturer.
- Always contact the manufacturer in case of uncer-
tainties.
NOTE!
The manufacturer's warranty will become nul and
void if non admitted spare parts are being used.

10 TBS-Series | Version 1.01
Spare parts
11.2 Spare parts drawing
In case of service, the following drawing shall help to identify the necessary spare parts. Send a copy of parts drawing
with the marked components to your authorised dealer when ordering spare parts.
Fig. 4: Spare parts drawing

EC Declaration of Conformity
TBS-Series | Version 1.01 11
According to Machinery Directive 2006/42/EC Annex II 1.A
Manufacturer / distributor: Stürmer Maschinen GmbH
Dr.-Robert-Pfleger-Starße 26
D-96103 Hallstadt
hereby declares that the following product
Product Group: Metallkraft®Metallbearbeitungsmaschinen
Machine typ: Shearing Machine
Description of the machine: TBS 650-12 T
TBS 1050-10 T
Serial number: ____________________
Year of manufacture: 20____
corresponds to all the relevant provisions of the abovementioned Directive and other Directives applied (below) - in-
cluding their amendments current at the time of the declaration.
Relevant EU Directives 2006/95/EG Low Voltage Directive
The following harmonized standards have been applied:
DIN EN ISO 12100:2010 Safety of machinery. General principles for design.
Risk assessment and risk reduction (ISO 12100:2010)
Responsible for documentation: Engineering Department, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt
Hallstadt, 2012/01/20
______________________
Kilian Stürmer
CEO, Director
12 EC Declaration of Conformity

www.metallkraft.de
