Kaino GM-8825 User manual

Digital Piano
OWNER'S MANUAL
GM-8825
GM-8825

PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
*Please keep these precautions in a safe place for future reference.
｣
* Do not open the instrument or attempt to
disassemble the internal parts or modify them in any
way. The instrument contains no user-serviceable
parts. If it should appear to be malfunctioning,
discontinue use immediately and have it inspected by
qualified service personnel.
* Do not expose the instrument to rain, use near water
or in damp or wet conditions, or place containers on it
containing liquids that might spill into any opening.
* If the power cord or plug becomes frayed or
damaged, or if there is a sudden loss of sound during
use of the instrument, or if any unusual smells or
smoke appear to be caused by it, immediately turn off
the power, disconnect the power plug from the outlet, and
have the instrument inspected by qualified service
personnel.
Do not use a voltage other than the indicated power
supply voltage. Use of a voltage other than indicated may
cause fire or electrical shock.
*
* Before cleaning the instrument, always remove the
power plug from the outlet. Never insert or remove an
power plug with wet hands.
* Check the power plug periodically and remove any dirt
or dust, which may have accumulated on it.
WARNING
Always follow the basic precaution listed below to avoid the possibility of serious injury or even death from
electronic shock, short-circuiting, fire or other hazards. These precautions include, but are not limited to,
the followings:
CAUTION
Always follow the basic precaution listed below to avoid the possibility of physical injury or damage to the
instrument or other property. These precautions include, but are not limited to, the followings:
｣
* Do not place the power cord near heat sources such
as heaters or radiators, and do not excessively bend or
otherwise damage the cord, place heavy objects on it,
or place it in a position where anyone could walk on,
trip on, or roll anything over it.
* Do not connect the instrument to an electrical outlet
using a multiple-connector. Doing so can result in
lower sound quality, or possibly cause overheating in
the outlet.
* Unplug the power cords when not using the
instrument, or during electrical storms.
* When removing the power plug from the instrument
or an outlet, always hold the plug itself but not the cord.
* Do not expose the instrument to excessive dust or
vibrations, or extreme cold or heat, (such as direct
sunlight, near a heater, or in a car during the day) to
prevent the possibility of panel disfiguration or
damage to the internal components.
* Before moving the instrument, remove all connected
power cords and other cables.
* When cleaning the instrument, use a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths. Do not place
vinyl, plastic or rubber objects on the instrument, since
* Before connecting the instrument to other electronic
components, turn off the power for all components.
Before turning the power on or off for all components, set
all volume levels to minimum. Also, be sure to set the
volume of all components at their minimum levels and
gradually raise the volume controls while playing the
instrument to set the desired listening level.
* Do not use the instrument near other electrical products
such as televisions, radios, or speakers, since this might
cause interference which can affect proper operation of
other products.
* Do not place the instrument in an unstable position
where it might accidentally fall over.
* Do not rest your weight on, or place heavy objects on
the instrument, and do not use excessive force on the
buttons, switches and connectors.
* Do not operate the instrument for a long period of time
at a high or uncomfortable volume level, since this can
cause permanent hearing loss. If you experience and
hearing loss or ringing in the ears, consult a physician.
WE CANNOT BE HELD RESPONSIBLE FOR DAMAGE
BY IMPROPER USE OR MODIFICATIONS TO THE
INSTRUMENT, OR DATA THAT IS LOST OR
DESTROYED.
this might discolour the panel or keyboard.

Contents
MIDI function 18
18
18
19
19
Setting up 1
Playing demo songs 3
Playing sounds 4
Auto accompaniment 7
3 steps piano teaching system 16
16
16
17
17
17
Appendix 20
20
21
22
23
27
28
Status Register 11
Recording system 12
What is MIDI..............................................
What you can do with MIDI........................
Connecting to a personal computer...........
Connecting to other MIDI device................
Step 1 Master the timing............................
Step 2 Master the melody..........................
Step 3 Play your song ...............................
Learn to play the left hand.........................
Learn to play the accompaniment..............
Specifications............................................
Sound list...................................................
Styles list.....................................................
Percussions list.........................................
Important Message Section......................
Installation.................................................
Recording System ...................................
Four different ways to record ................
Data can be recorded to the user song..
Accompaniment recording .......................
Melody recording......................................
Accompaniment and melody recording....
Multi-track recording.................................
Play the recording songs...........................
Delete track...............................................
12
13
13
14
14
15
15
15
1
2
2
2
2
3
4
5
5
5
6
6
6
11
11
11
11
7
8
8
8
8
9
9
9
9
10
10
10
Power connection .....................................
Audio equipment connections ..................
Line Out jacks .......................................
Phones jacks .........................................
Display indications ...................................
Playing demo songs..................................
Sound selection.........................................
Dual...........................................................
Split...........................................................
Touch Sensitive.........................................
Transpose.................................................
Vibration & Effect.................................
.......................................................Pedals.
Status Register .......................................
Data stored by the Status register........
Registering the panel settings..............
Recall the registered panel settings......
Playing single-fingering chord..............
Single-fingering....................................
Playing fingering chord.........................
The tone C fingering ............................
Styles selection .......................................
Start Accompaniment ..............................
Variation and Fill-In...................................
Stop Accompaniment................................
...............................................
Tempo setting...........................................
Auto metronome.......................................
Chord fingerings.......................................
Fade In/Out

01
Follow the instructions below according to the power source you intend to use.
This section will help you set up the piano and prepare to play. Be sure to go through this section carefully
before turning the power on.
Power Connections
If you DID NOT read the precautions section, please go back and read carefully before processing!
Minimize the volume of the digital piano.
1
2
3
4
Make sure that the [POWER] button
Connect the power cords to the digital piano and
plug it into an active outlet.
Then turn POWER ON.
When turning the POWER OFF, simply reverse the procedure.
.is set to OFF WARNING
Do not use a voltage other than
the indicated power supply
voltage. Use of a voltage other
than indicated may cause fire or
electrical shock.
Unplug the power cord when not
using the instrument, or during
electrical storms.
Setting up
You are the proud owner of a fine digital piano. This digital piano combines the
most advanced tone generation technology with digital electronics and
features to give you stunning sound quality with maximum musical enjoyment.
New hammer keyboard gives you a real traditional acoustic piano feeling. In
order to make the most of your piano's features and extensive performance
potential, we urge you to read the manual thoroughly while trying out the
various features described. Keep the manual in a safe place for the future
reference.
Congratulations!

Audio equipment connections
Line Out jacks
Phones jack
Connect the piano to external
equipment only after turning off
the power for all devices. To
prevent damage to the
speakers,
set the volume of the external
devices at the minimum setting
beforeconnectingthem.Failure
to do so may result in electric
CAUTION
02
A standard pair of stereo headphones can
be plugged in here for private or late-night
playing. The internal stereo speaker system
will be automatically shut off when a head
phone is plugged into the PHONES jack.
DO NOT listen with the headphone at high
volume for long periods of time. Doing so
may cause hearing loss.
The Line out jacks deliver the output of the digital piano for
connection to a piano amplifier, stereo sound system, a mixing
console, or tape recorder.
Accomp Vol RHYTHM PADs
BASS PHASE
CHORD KEYBOARD
2Chord 3Menu/Messege DisplayFunction indication
14Record Information
5Teaching System information Tempo
6Tracks Volume
7
Display indications
When the power is on, the LCD display on the centre of the digital piano will display as below. Different
information about the digital piano will be displayed when you are playing or operating the piano.
Amplifier
LINE OUT
Setting up
Phones jack

SOUND 1
SOUND 2
STYLE
SONG
1 2 3
456
78 9
0
Playing a demo song.
1Press the power button to the "ON" position.
2Press the [Demo/Record] button to play the main demo song.
Playing demo songs
In this section, you will learn how to play the demo songs, the digital piano has a large database of demo songs.
Once you have set up your digital piano, try listening the pre-programmed demonstration songs.
The digital piano provides a totally 89 demo songs. You can also use the 3 step piano teaching system to learn
these demo songs, for more information about piano teaching system, please turn to the "3 step piano teaching
system" chapter.
4
Use the Master volume dial to adjust the volume, simply press the [Demo/Record] button to stop the song.
Enjoy the demo song.
03
Master VolMaster Vol
RECORD
TRACK1
TRACK1 TRACK2 TRACK3 TRACK4
TRACK2 TRACK3 TRACK4
ACCOMP
PLAY DELETE
DEMO STEP3
STEP2
STEP1
RECORD
TEACH
RECORD
ACCOMP
PLAY DELETE
DEMO STEP3
STEP2
STEP1
3Start a demo song
Press the [SONG] and use the [+] button, the [-] button or the number buttons to select a demo song. Or, press
any key on the note keyboard and hold it till press the [Demo/Record] button to start a demo song. Each key on
the note keyboard stands for one demo song.

1Press the [SOUND 1] button.
If you want to select the sound which from 100 to 127,
press the [SOUND 1] button twice.
2Select the sound.
Use the [+] button, the [-] button, the number buttons
through [0] - [9] to select the sound, the result will be
showed on the display.
Playing Sounds
The digital piano provides lots of musical instruments. Try out the different voices referring to the sound list at
the end of this manual.
Example-Select sound NO.68
1Press the [SOUND 1] button.
Sound selection
3Play a note and adjust the volume.
Master Vol
04
SOUND 1
SOUND 2
STYLE
SONG
SOUND1
SOUND2
STYLE
SONG
1 2 3
456
78 9
0
2P Or, uress the number button [6] and then [8], the desired voice has been reached. se the [+]
button, the [-] button to select the number 68.
3Play the piano and adjust the volume.

05
1Press the [SOUND1] button to select the first voice.
When dual is on, a note played on the keyboard will sound in two voices, voices can be selected by button
[SOUND1] and button [SOUND2]. Sound 1 is the first voice of the layer and the second is called Sound 2.
Playing Sounds
Dual (Playing two voices simultaneously)
4Play the sound.
3Press the [SOUND2] button to select the second voice.
Use the [+] button, the [-] button or the number buttons [1] - [9] to select the
SOUND 2.
The sounds available for selection here (Sound 2) are the same as those
available for Sound 1.
2Press the [DUAL] button.
Split
2
To select the split function.
Press the [KEYBOARD MODE] button.
Split point: Middle C
Sound 2Sound 1
1
Press the [SOUND1] button and select the voice for the left hand.
Select the sound for the left hand.
3Select the sound for the right hand and play the
notes.
NOTE
When the keyboard is split into two parts, the Split Point is on the middle C. The left keyboard note pitch is one octave
up; the right keyboard pitch is one octave down.
06
When you choose the split function, the keyboard will be split into two parts: the right hand part and the left
hand part.
EFFECT
DUAL
TOUCH
FINGER NORMAL
S-FINGER
SPLIT
KEYBOARD MODE
5Use the Balance button to adjust the volume of the second voice.
BALANCE
The keyboard of the digital piano is equipped with a touch response feature that lets you dynamically and
expressively control the level of the voices with your playing strength -- just as the real acoustic instrument.
Touch Sensitive

Playing Sounds
The transpose function allows the overall pitch of the digital piano to be transposed up or down by a maximum
of one octave in semitone increments. The transpose range is from -12 to +12.
Transpose
1Press the [TRANSPOSE] buttons.
Press the upper button to set the transposition up and press the lower
button to set the transposition down.
2Play the notes.
1Press the [TOUCH] button.
The touch sensitive function will be off.
2Play a note.
Vibration and Effect
In most of the string instruments, vibration is one of the skills used often. You can use the vibration function to
make your performance more emotional when you are playing a string instrument. The digital piano also
equipped an effect function according to different instruments, using it can help you to create music with more
varieties.
1Press the [VIB.] buttons or press the [EFFECT] button.
2Play a note.
TRANSPOSE
EFFECT
EFFECT
DUAL
DUAL
TOUCH
TOUCH
06
NOTE: The default setting of the touch sensitive is on when the piano turned on.
NOTE: Press both buttons at the same time to cancel any transpose.
VIB.
However, some instruments don't have touch response, such as organs. You can turn off the touch
sensitivefunction while you are playing an organ.
There are three pedals under the piano.
Sostenuto Pedal(left): when this pedal is trod down,sounding notes before pedal-down will sustain after key
release,those notes played after pedal-down will not sustain.
Soft Pedal(middle): when this pedal is trod down,the notes played will sound softly than normal.
SustainPedal(right): when this pedal is trod down,all notes played will sustain after key release.
1
2
3
Pedals

There are 4 different ways to start the accompaniments:
Start Accompaniment
4Press the [SYNC] button, then press [Intro/Ending] button to set intro mode. Then press any note of the 34
keys from the left on the note keyboard. The accompaniment will begin from the Intro part with your
performance.
1Press the [START/STOP] button to start accompaniment immediately.
3Press the [SYNC] button, then press any note of the 34 keys from the left. The accompaniment will begin
with your performance.
2Press the [Intro/Ending] button to start the accompaniment immediately from the Intro part, the electronic
piano will play a prelude.
Auto accompaniment
The auto accompaniment function puts a full backing band at your fingers. Using it, all you have to do is play
the chords with your left hand as you perform, and the selected accompaniment style matching your music will
automatically play along, instantly following the chords you play. With auto accompaniment, even a
soloperformer can enjoy playing with the backing of an entire band or orchestra.
The digital piano features lots of styles or auto accompaniment patterns in a variety of different musical genres.
Try selecting some of the different styles and play with the auto accompaniment.
07
SYNC A - FILLIN1
B - FILLIN2 START/STOP INTRO/ENDING FADE IN/OUT
1Press the [STYLE] button.
2Select the styles.
Use the [+] button, the [-] button or the
number buttons [1]-[0] to select the
styles.
Styles selection
SOUND1
SOUND2
STYLE
SONG
1 2 3
456
78 9
0

SYNC A - FILLIN1 B - FILLIN2 START/STOP INTRO/ENDING FADE IN/OUT
Auto accompaniment
08
Stop Accompaniment
1Press the [START/STOP] button to stop the accompaniment.
There are 2 different ways to stop the accompaniments:
2Press the [INTRO/ENDING] button.
This is used for the ending of the song. When the ending is finished, the auto accompaniment stops
automatically. The length of the ending differs from different selected style.
Variation Fill-Inand
There are two main sections,main1 and main2. After power on, light of [A-FILLIN1] is on to indicate that main1
section is ready to be started. Press [B-FILLIN2] button, the light of [B-FILLIN2] is turned on to indicate that
the ready section has been changed to main2.
The fill-in section let you add dynamic variations and breaks in the rhythm of the accompaniment, to make your
performance sound even more professional.
Simply press the [A-FILLIN1], [B-FILLIN2] buttons as you play, and the selected fill-in section will play
automatically, spicing up to the auto accompaniment.
When fill-in1 section is finished, it leads smoothly Into main1 section.
When fill-in2 section is finished, it leads smoothly Into main2 section.
There are various types of Auto Accompaniment sections that allow you vary the arrangement of the
accompaniment to match the song you are playing. There are: Intro, Fill-in and Ending. By switching among
them as you play, you can easily produce the dynamic elements of a professional-sounding arrangement in
your performance.
Fade In/Out
[FADE IN/OUT] is used to stat/stop accompaniment gradually by volume. The on- light of [FADE
IN/OUT]means fade in/out is active.
Set [FADE IN/OUT] on before playing accompaniment to gradually start accompaniment until normal volume.
SYNC A - FILLIN1 B - FILLIN2 START/STOP INTRO/ENDING FADE IN/OUT

Auto accompaniment
The way in which your left hand plays the chord is referred
to as "fingering". There are two types of fingering:
Chord Fingerings
Single fingering
Fingering
Press the [KEYBOARD MODE] buttons to select
the fingering mode.
FINGER
S-FINGER
SPLIT
Each style of the digital piano has been programmed with a
default or standard tempo, however, it can be changed by
the [TEMPO+] and [TEMPO-] buttons. You can change the
tempo to any value from 40 to 240 beats per minute.
Tempo setting
TEMPO
Press [METRO] Button to set the metronome effect. Three
types of metronome effects can be set automatically
according to the present style, including 2/4, 3/4 and 4/4.
You can also use the Tempo buttons to change the tempo
of metronome. If accompaniment started, metronome will
be invalid automatically.
Auto Metronome
METRONOME
2/4
3/4
4/4
09
Using single-finger mode to play chord is simple to produce beautifully orchestrated accompaniment using
major, minor and minor-seventh chords by pressing a minimum number of keys on the Auto Accompaniment
section of the keyboard. The following abbreviated chord fingering are used:
Play singer-finger chord
Set [FADE IN/OUT] on when playing accompaniment to gradually stop accompaniment until volume
decreased to zero.

Auto accompaniment
Singer Fingering
Major: Just press the basic key
Minor: Press the basic key and any black key on its left side.
Seventh: Press the basic key and any white on its left side.
Minor seventh: Press the basic key and one white key, and one black on its left side.
This is the default accompaniment mode. When use finger mode to play, the player presses auto chord
keyboard according to the chord relation, the keyboard will accompany well.
Playing finger chord
The tone C fingering
10
F Fm F7 Fm7 B Bm B7 Bm7
m/D C C
G Gm G7 Gm7
C
#b
/D Cm
#b
7
7/D
#b
m7
m7/D
#b
DDDD
A Am A7 Am7
#b
/E
#b
m/E m
#b
7/E 7m7/E m7
#b
C Cm C7 Cm7 FFFF
#b
/G
#b
m
m/G
#b
7
7/G
#b
m7
m7/G
D Dm D7 Dm7
GGGG
#b
/A
#b
m
m/A 7/A 7
#b
m7/A m7
#b
EEm E7 Em7
AAAA
#b
/B
#b
mm/B
#b
7/B 7m7m7/B
#b
C
Cm
C7 Cm7
CM7
Caug
Csus4 C(9) C7(13) CmM7 Cm7 5 Cdim7
C6
Cm(9)
Cm6 Cdim
C7( C7( Cm7(9) Cm7(11)
#
9) 11)
#
Cm(
#
5)
The rest may be deduced by analogy

Status Register
Since the digital piano is such a sophisticated instrument with such a variety of controls and functions -- voice,
styles, auto accompaniment, and effect settings, just to name a few -- the Status Register function is one of the
most convenient and powerful of the instrument. It allows you save virtually panel settings to a Register
Memory setting, and then instantly recall your custom panel settings by pressing a single button.
Status Register provides up to 4 memory space, which allows you to recall them during your performance.
DATA stored by the Status Register
Set up the panel controls as required.
While holding the [SET] button, press one of the
Status Register button: [1] through [4].
1
2
SOUND 1
SOUND 2
STYLE
TEMPO
Accompaniment volume
Accompaniment section A/B
Touch Sensitive on/off
Effect on/off
Any data that was previously
recorded in the Status Register
location you selected will be
erased and replaced by the new
settings.
NOTE
Press the [SET] button and then press one of the Status Registration button:
[1] to [4] to recall the settings.
Registering the panel settings
Recall the Registered Panel Settings
SET
1234
SET
1234
11
Status Register

Recording System
With the powerful and easy-to-use Recording System, you can record your own keyboard performance and
create your own complete, fully orchestrated compositions.
Tempo
Accompaniment style number
Section changes and their timing
Chord changes and their timing
Accompaniment volume
Data that can be recorded to user song:
Accompaniment Recording
Melody Recording.
Multi-Track Recording.
This records only the auto accompaniment.
This records your keyboard performance without the auto accompaniment.
This records your keyboard performance along with the auto accompaniment.
With this method, you can record up to 5 tracks independently.
Accompaniment and Melody Recording
The digital piano provides four different ways to record:
NOTES:
Using Metronome function can make your recording sessions much more efficient.
Using Status Registration can make your recording sessions much more efficient, since various settings (such as voices, styles, etc.)
can be recalled by a single button press.
Whenever you record, please notify that any previously recorded material in the same track will be erased.
The following notes and cautions are important for you to keep in mind as you record:
.
12
Note ON/OFF (key press and release)
Touch Sensitive ON/OFF
Sound change settings
Effect setting
Recording System

Recording System
1
3
4
5
6
Select style and fingering mode.
While pressing the [RECORD] button press the [STEP3/ACMP] button
Start Recording
Change the accompaniment style when it is needed.
Press the [STEP3/AMCP] button again to stop recording.
Record will start as soon as you start the auto accompaniment.
2Press the [RECORD/TEACH] button to open the record function.
Accompaniment Recording
1
2
3
4
5
Select sound.
While pressing the [RECORD/DEMO] button, press one of the [TRACK] buttons.
Play any notes of the keyboard to start recording.
Change sound when it is needed.
Press the selected track button to stop recording.
The performance will be recorded in the track you selected.
Melody Recording
RECORD
RECORD
TRACK1
TRACK1
TRACK1
TRACK1
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
ACCOMP
ACCOMP
PLAY
PLAY CLEAR
DEMO
DEMO
STEP3
STEP3
STEP2
STEP2
STEP1
STEP1
RECORD
RECORD
TEACH
TEACH
1
1
2
2
3
3
13
CLEAR

3Press the [PLAY] button to start recording.
Or play any notes in the keyboard to start recording directly.
Recording System
Multi-Track Recording
1
2
Use the same operation as one of the recording methods explained above.
While pressing the [RECORD] button, press one of the track buttons you want record.
Accompaniment and Melody Recording
RECORD
RECORD
TRACK1
TRACK1
TRACK1
TRACK1
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
ACCOMP
ACCOMP
PLAY
PLAY
CLEAR
DEMO
DEMO
STEP3
STEP3
STEP2
STEP2
STEP1
STEP1
RECORD
RECORD
TEACH
TEACH
12 3
3
4
Press the [PLAY] button to start recording.
Press the [ACMP] button or one of the any other selected [TRACK] buttons to stop the
recording
Or play any notes in the keyboard to start recording directly.
1Select style and sound.
2While press the [RECORD] button, press the [ACMP] button and one then of the
[Track1]-[Track4] buttons.
RECORD
TRACK1
TRACK1 TRACK2 TRACK3 TRACK4
TRACK2 TRACK3 TRACK4
ACCOMP
PLAY
DEMO STEP3
STEP2
STEP1
RECORD
TEACH
12 3
14
4
CLEAR
CLEAR

1
2
Press the [RECORD] button.
Press the track button: [TRACK 1] to [TRACK 4] button according to the tracks you
want to play back.
Press the [ACMP] button if you want to play the auto accompaniment record.
3Press the [PLAY] button.
1While pressing the [CLEAR] button, press the track button, which you want to delete.
2Press the [ACMP] button while pressing the [CLEAR] button to delete the accom-
paniment record.
For instance, after you record your performance into TRACK 1, while holding the [RECORD] press the
[TRACK 2] button to prepare record, press the [TRACK 1] button to play the track 1, meanwhile you can start
your new record with track 2. Once you finish, press [TRACK 2] to stop, your performance recorded in track 2
has been mixed with track 1.
4Press the [ACMP] button or one of the any other selected [TRACK] buttons to
stop the recording.
Recording System
RECORD
RECORD
TRACK1
TRACK1
TRACK1
TRACK1
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
ACCOMP
ACCOMP
PLAY
PLAY
CLEAR
CLEAR
DEMO
DEMO
STEP3
STEP3
STEP2
STEP2
STEP1
STEP1
RECORD
RECORD
TEACH
TEACH
15
Play the Recording Songs
Delete Track

3 steps Piano Teaching System
The 3-step Piano Teaching System feature takes you through the three distinct steps described below to help
you learn to play all of the demo songs in the digital piano. In this feature, you can learn to play the right or the
left hand, even another accompaniment in the demo song as well..
In this step, pressing any key on the keyboard will play the correct note of the selected song, so you can
concentrate in getting the timing right without worrying about how to play the right note. The melody of the
selected demo song will wait until you press a key before proceeding to the next phrase. The light will flash
above the next key of the melody, so just simply follow the light you will play the correct key of the melody.
1
2
3
4
Press the [SONG] button and select a song to learn.
Press the [TEACH] button to open the teaching function.
Press the [STEP 1] button to start the first step.
Follow the lights and press the corresponding key to play.
Step 1 Master the timing
Accompaniment waits until
you press any key to play the
note.
If you accidentally press more
than one key in succession, ac-
companiment is played for the
corresponding number of notes.
Pressing more than one key at
the same time counts as corres-
ponding notes. Pressing a key
while another key is held down is
counted as a single note.
Step 2 Master the melody
1.Select one demo song you want to learn.
.
2Press the [TEACH] button to set the digital piano in a teaching mode.
In this step, you will learn the right key to play the melody. the melody still waits until you play the correct note,
and so you can learn at your own pace. The accompaniment will not continue unless you play the correct key of
the melody.
NOTES:
16
RECORD
TRACK1
TRACK1 TRACK2 TRACK3 TRACK4
TRACK2 TRACK3 TRACK4
ACCOMP
PLAY CLEAR
DEMO STEP3
STEP2
STEP1
RECORD
TEACH

Step 3 Play your song
After following the step 1 and step 2, you can enjoy playing the melody at a normal speed in this step. The
accompaniment will proceed at a normal speed regardless of whether you play the correct note or not.
1
2
3
4
.Select the song you want to learn.
.
Press the [TEACH] button to set the digital piano in a teaching mode.
Press the [STEP 3] button to start the third step.
Follow the lights and play the corresponding note to play the song.
3 steps Piano Teaching System
Learn to play with left hand
The left hand can also be performed in the 3 steps teaching system, just simply press [TRACK2] before you
start the each step. If you want to learn the left hand by step 3, press [TRACK2] and then press [STEP3]
Learn to play the accompaniment
Some of the demo songs have accompaniment tracks, in those songs, you can learn to play the
accompaniment by right hand or the left hand.
Press [TRACK3] if you want to learn the right hand of the accompaniment, and [TRACK4] for the left hand
of the accompaniment.
If you want to learn the right hand of the accompaniment by step 3, press [TEACH], and then press
[TRACK3], and Press [STEP3].
17
RECORD
RECORD
TRACK1
TRACK1
TRACK1
TRACK1
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
TRACK2
TRACK2
TRACK3
TRACK3
TRACK4
TRACK4
ACCOMP
ACCOMP
PLAY
PLAY
CLEAR
CLEAR
DEMO
DEMO
STEP3
STEP3
STEP2
STEP2
STEP1
STEP1
RECORD
RECORD
TEACH
TEACH
1
1
23
3Press the [STEP2] button to start the second step.
.
4Follow the lights and press the corresponding key to play the melody.
