Kaiser Baas R10+ User manual

R10+ CAR DVR
Your expert witness on board
USER GUIDE

3
English
Languages
English 4

4
English
Community
Tech support:
e: [e-mail]
w: www.kaiserbaas.com/support
p: Australia 1300 302 306
p: New Zealand 0800 302 306
(business hours, AEST)
/kaiserbaas

5
English
Contents
Safety Precautions 6
What’s in the Box 7
Product Diagram 8
Setting up the R10 Car DVR 9
In Car Operation 10
Computer Connection 11
Interface 12
Specifications 16
Frequently Asked Questions 18
Contact Us 19

6
English
Safety Precautions
Before using your R10+ Car DVR, please ensure you have
read and understood all of the information below.
• Only use the provided USB-mini cable to power the
R10+.
• Do not expose the R10+ to water, dust, oil or tempera-
tures above 70˚c.
• Avoid leaving the R10+ in direct sunlight for prolonged
periods of time.
• Please do not attempt to adjust the camera or settings
whilst you are operating your vehicle.
PLEASE OBEY ALL ROAD LAWS IN YOUR REGION WHILST
USING YOUR R10+. CHECK ALL LOCAL LEGISLATION
BEFORE USE.

7
English
What’s in the Box
Please ensure the product package has all the following
contents:
A
A
B
B
D
D
C
C
R10 Car DVR
Windscreen Mount
3m USB Mini Cable
User Guide
Car Charger
80cm USB Mini Cable
Adhesive Pad
E
E
F
G
F
G

8
English
Product Diagram
1Wide Angle Lens
2Mounting Slot
32.7” Display
4POWER Button
5MENU Button
6MODE Button
7UP Button
8OK Button
9DOWN Button
10 Micro SD Slot
HDMI Mini Port (adapter
required for HDMI)
12 AV Out Port
13 Mini USB Port
11
USB
HDMITF
AV-OUT
USB
HDMITF
AV-OUT
1
2
3
10
11
12
13
4 7
5 8
6 9

9
English
Setting up the R10+
General
• Insert a Micro SD card into the allocated slot on the
left side of the R10+. An ideal placement for the R10+ is
behind the rear vision mirror.
• The R10+ will power up and start recording as soon as
it receives power from the connected USB-mini power
cable (i.e turning your car on)
Car set up
• Clean your windscreen, making sure the placement of
the R10+ does not obscure the view of the driver.
• Attach the R10+ to the mount by sliding the R10+
connection from left to right along the mount connec-
tion until latched into place.
• Remove the protective layer from the 3M adhesive on
the mount.
• Stick the adhesive to the inside of the front windscreen
in the desired position. Press for 30 seconds to ensure
that the R10+ is mounted securely.
• Adjust the pivot connection to ensure that the R10+ is
correctly angled.
• Finally connect the R10+ to power using the 3m USB-
mini power cable and the USB car charger, make any
final adjustments to placement as necessary.

10
English
In Car Operation
The R10+ is optimised to use a Class 6 Micro SD card (not
included) with at least 8GB of free space. For best results
please use a Class 6 Micro SD card.
• The internal G-sensor will register any impacts and will
log them as an ‘Event’. These ‘Event’ files will be stored
in the RO file and will not be recorded over by regular
footage. These files need to be manually deleted from
your Micro SD card by connecting your R10+ to your
computer or by formatting the Micro SD card.
• For more information on the R10+ interface please see
page 12

11
English
Computer Connection
• Either connect the R10+ via the USB-mini cable, or insert
the Micro SD card (not included) to your computer via
an SD card adapter.
• Select “Mass Storage” mode to access files.
• R10+ will appear as an external storage device.
• Video files will be kept in a directory within the external
storage under the directory titled VOLUME1/CARDV/
MOVIE (Event files will be moved to the RO file)
• Click on any of the video files for playback.

12
English
Interface
Recording/Viewfinder screen
From this screen you can manually start and stop recording
using the OK button. You can also navigate to the menu
screen by using the MENU button. Cycle through the
Recording and Video Playback modes using the MODE key.
To cycle through these modes you will need to ensure that
the camera is not recording. In Photo mode the UP and
DOWN buttons are used to control the zoom function.
1Mode (movie/photo)
2G-sensor (On/O)
3Loop time (how
long your camera will
film before looping and
creating a new file)
4Exposure
5Sound
6Licence plate
7Date
8Time
9Battery
10 Memory
11 Resolution
12 Recording time
1 2 12
4
5
6
7 8 9
11
10
3

13
English
Playback
In this screen the UP and DOWN buttons are used to
navigate through files and the OK button is used to play
back files. The MODE button is used to navigate back. Once
a video is playing, the UP and DOWN buttons are used to
control the volume and the OK button pauses. The MODE
button stops the video.
Menu
The R10+ menu can be accessed by pushing the MENU
button. The MENU button can then be used to cycle through
the dierent menus. The UP and DOWN buttons are used
to navigate though the sub-menus and the OK and MENU
buttons are used to select and navigate back respectively.
1Video icon
2File name
3Resolution
4Date
5Time
6Battery
1 2
3
4
5
6

14
English
Film menu
Resolution:
Defines the level of
recording detail.
• 1296P (scaled up)
• 1080P
• 720P
• WVGA
• VGA
Loop Recording
Sets the length of recording
loop files.
• O
• 1 Minute
• 3 Minutes
• 5 Minutes
WDR
Toggles wide dynamic
range.
• O
• On

15
English
Exposure
Sets exposure levels.
• +2.0
• +5/3
• +4/3
• +1.0
• +2/3
• +1/3
• +0.0
• -1/3
• -2/3
• -1.0
• -4/3
• -5/3
• -2.0
Motion Detection
Triggers recording when
motion is detected.
• O
• On
Record Audio
Mutes or unmutes
recording.
• O
• On
Date Stamp
Add or remove the date
stamp from footage.
• O
• On

16
English
Parking Guard
When activated, the R10+
will detect an impact or
shock after the car has
been parked, triggering a
30 second recording.
• O
• On
G-Sensor
Determine the sensitivity
of the trigger for the
Parking Guard and Event
Recording.
• O
• Low
• Medium
• High
Camera Settings Menu
In the menu, push the MENU button a second time to
navigate to the camera settings menu.
Date/Time
Set time and date to be
displayed on footage.
Auto power o
Determine duration of
inactivity before the camera
powers down.
• O
• 30 Seconds
• 1 Minute
Beep sound
Toggle settings for sounds
that indicate button use.
• O
• On

17
English
Language
Set language for device.
Frequency
Allows the frequency to be
edited.
• 50 Hz
• 60 Hz
Carplate
Add or remove your
licence plate from the
footage.
• O
• On (Enter licence plate
number)
Format
A quick way to delete
all items on the inserted
Micro SD card. (This will
permanently delete all
footage on the card)
Default setting
This resets all of the
settings on your R10+.
Screen saver
The screen saver function
puts the screen to sleep
whilst recording. Select the
length of time before the
screen saver activates.
• O
• 1 Minute
• 5 Minutes
• 10 Minutes
Version
This displays the camera
version number.

18
English
Specifications
Dimension (L x W x H) 110mm x 47mm x 25mm
Weight 70g
Lens 140˚ Wide Angle Lens
CMOS AR0330
LCD Display 2.7” 16:9
Resolution 1920 x 1080 FHD 30fps
Compresson format H.264
Cigarette adaptor
Input voltage
DC 12/24 V
Main unit Input voltage DC 5 V
Power Current DC5V Recording current 450mA/
Standby 350mA
Power Consumption 2.3W
Battery 180mAh Lithium polymer
Storage Class 6 Recommended
Max 32GB
Operation Temperature -20°C - 65°C
Storage Temperature -20°C - 75°C

19
English
Frequently Asked Questions
Q. The image is blurry.
A. Try repositioning the camera. For best results, try and
aim the camera through a section of the windshield that
is not overly curved or angled, as this can cause a blurring
eect.
Q. My device will not record.
A. Please ensure that you have your R10+ connected to
a power source using the supplied USB-mini power cable
and that you have a Micro SD card inserted that is Class 4
(ideally Class 6) or above and 32GB or below.
Q. My HDMI cable will not fit in the HDMI socket on the
camera.
A. The socket at the top of the R10+ is a mini HDMI port
and requires a mini HDMI adapter (not included) for use with
HDMI cables.
Q. I can’t delete files o of my Micro SD card using the
R10+ settings.
A. It may be that the file that you are trying to delete has
been flagged as an “Event” file by the R10+ G-sensor. These
files can only be deleted by connecting your R10+ to a
computer, or by formatting your Micro SD card.

20
English
Contact Us
Having trouble setting your R10+ Car DVR up?
Please contact us. No question too big or small and we are
more than happy to help.
Please visit:
www.kaiserbaas.com/support
Or email:
[e-mail]
For further information please visit:
www.kaiserbaas.com
Tech support:
e: [e-mail]
w: www.kaiserbaas.com/support
p: Australia 1300 302 306
p: New Zealand 0800 302 306
(business hours, AEST)
