Kambrook KSB8 User manual

Kambrook - Australia
Building 2, Port Air Industrial Estate
1A Hale Street
Botany NSW 2019
Australia
Customer Service Line 1300 139 798
Customer Service Fax [phone]
www.kambrook.com.au
Due to continual improvement in design or otherwise, the product you
purchase may differ slightly from the illustration in this book. Issue D13
Kambrook - New Zealand
Private Bag 94411
Botany, Manukau
Auckland 2163
New Zealand
Customer Service Line/
Spare Parts 0800 273 845
Customer Service Fax [phone]
www.kambrook.co.nz

Instruction Booklet
Power Drive
Stick Mixer
KSB8

Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 0800 273 845
(New Zealand). Alternatively, visit us on our website at
www.kambrook.com.au or www.kambrook.co.nz

Contents
Kambrook Recommends p4
Safety First
Your Kambrook Power Drive p6
Stick Mixer
Operating Your Kambrook p7
Power Drive Stick Mixer
Care, Cleaning and Storage p13
Food Preparation Guide p14
Recipes p16

4
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Power Drive Stick Mixer
• Carefully read all instructions before
operating the Kambrook Power Drive Stick
Mixer for the first time and save for future
reference.
• Remove and safely discard any packaging
material and promotional labels before using
the blender for the first time.
• To eliminate a choking hazard for young
children, remove and safely discard the
protective cover fitted to the power plug of
this appliance.
• Do not place the Stick Mixer near the edge
of a bench or table during operation. Ensure
the surface is level, clean and free of water,
flour, etc.
• Do not place the Stick Mixer on or near a
hot gas or electric burner, or where it could
touch a heated oven.
• If using the Stick Mixer as the Hand Blender
to blend hot food in a saucepan over heat,
remove the saucepan from the heat source
and ensure the power cord and body of
appliance are also kept away from any heat
source.
• Handle the Stick Mixer and attachments with
care – remember the blade is very sharp and
should be kept out of reach of children.
• Always make sure the Stick Mixer is
completely and properly assembled before
operating.
• Ensure the Stick Mixer is turned off by releasing
the ‘VARIABLE’ or ‘BOOST’ button, the power is
switched off at the power outlet and the cord
is unplugged from the power outlet before
attempting to attach any of the accessories.
• Always ensure the Blending Shaft is securely
fitted onto the blender motor body before
operating.
• Do not use attachments other than those
provided with the Stick Mixer.
• Do not attempt to operate the Stick Mixer by
any method other than those described in
this booklet.
• Do not process hot or boiling liquids
in the chopping bowl – allow liquids
to cool before placing into the
chopper bowl.
• Do not operate the appliance continuously
for more than 1 minute. Allow the motor to
rest for 1 minute between each use.
• Never mix dry, thick or heavy mixtures for
more than 30 seconds. Stop the operation
and stir the ingredients before continuing.
Allow the motor to rest for 1 minute between
each use.
• Always ensure the Stick Mixer is turned off
by releasing the ‘VARIABLE’ or ‘BOOST’
button, the power is switched off at the
power outlet and the cord is unplugged
from the power outlet before attempting

5
to move the appliance, when not in use, if
left unattended and before disassembling,
cleaning or storing.
• If food becomes lodged around the
processing blade or in the blade guard,
release the ‘VARIABLE’ or ‘BOOST’ button,
switch the power off at the power outlet and
unplug the cord. Use a spatula to dislodge
the food. Do not use fingers as the blades
are sharp.
• To protect against electric shock do not
immerse the motor body, cord or power plug
in water or any other liquid.
• Do not remove the Stick Mixer from
ingredients during operation. Ensure the
appliance is switched off and has stopped
turning before removing, to avoid contact
with moving blade.
• Do not leave the Stick Mixer unattended
when in use.
• Do not allow children to use the Stick Mixer
without supervision.
• Do not use the Stick Mixer with wet hands.
• Keep the appliance clean. Follow the cleaning
instructions provided in this book.
Important Safeguards For All
Electrical Appliances
• Carefully read all instructions before operating
the appliance and save for future reference.
• Remove and safely discard all packaging
material and promotional labels before using
the appliance for the first time.
• Fully unwind the power cord before use.
• Do not let the power cord hang over the edge
of a bench or table, touch hot surfaces or
become knotted.
• To protect against electric shock, do not
immerse the power cord, power plug or
appliance in water or any other liquid, unless it
is recommended in the cleaning instructions.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance, by a person
responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• It is recommended to inspect the appliance
regularly. Do not use the appliance if the
power supply cord, plug, connector or
appliance becomes damaged in anyway.
Return the entire appliance to the nearest
authorised Kambrook Service Centre for
examination and/or repair.
• Any maintenance other than cleaning should
be performed at an authorised Kambrook
Service Centre.
• This appliance is for household use only.
Do not use this appliance for other than its
intended use. Do not use in moving vehicles or
boats.
Do not use outdoors. Misuse may cause injury.
• The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable that a
safety switch with a rated residual operating
current not exceeding 30mA be installed in
the electrical circuit supplying the appliance.
See your electrician for professional advice
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in use.
• Before cleaning, always turn the appliance
to the OFF position, switch off at the power
outlet, unplug at the power outlet and remove
the power cord, if detachable, from the
appliance and allow all parts to cool.
• Do not place this appliance on or near a heat
source, such as hot plate, oven or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls, curtains
and other heat or steam sensitive materials
and provide adequate space above and on
all sides for air circulation.

6
Your Kambrook Power Drive Stick Mixer
1. Variable speed control dial
2. ‘VARIABLE’ speed button
3. ‘BOOST’ button
4. Heavy duty 500 watt motor
5. Detachable stainless steel
blending shaft for easy cleaning
6. Surrounding blade guard
7. High performance stainless steel
processing blade
8. Chopper bowl with lid and
chopping blade
9. Transparent jug for blending
and measuring

7
Operating Your Kambrook Power Drive
Stick Mixer
Before First Use
Remove any packaging material
and promotional labels. Wash the
blending shaft in warm soapy water.
Rinse and dry thoroughly. Ensure no
water remains inside the blending
shaft to avoid water running into the
motor when reattached.
Disassemble and wash chopping
blade, chopper bowl and chopper
bowl lid and jug in warm soapy water,
rinse and dry thoroughly. Ensure no
water remains on the chopper bowl
lid to avoid water running into the
motor body when reattached.
NOTE: The detachable blender
shaft is dishwasher safe.
Do not wash any other parts of
the Stick Mixer in the dishwasher.
The Stick Mixer Is a Versatile
Appliance
The Stick Mixer motor body can be
attached to:
• The stainless steel blending shaft
– for use as a hand blender
• The chopper bowl with chopping
blade and lid – for use as a Mini
Chopper or Food Processor
NOTE: Before placing the
blending shaft on the motor
body, make sure the blending
shaft is dried thoroughly after
each washing.
WARNING:All processing
blades are extremely
sharp. Avoid any contact
with hands.

8
Operating Your Kambrook Power Drive
Stick Mixer continued
To Attach the Stainless Steel
Blending Shaft
Hold the shaft with the blades down,
and the indicator symbol on the
top end of the blending shaft with the
corresponding indicator symbol on
the end of the motor body. Screw the
motor body in a clockwise direction
until the indicator symbol on the
motor body is aligned with the
indicator symbol on the blending
shaft (See Fig 1).
Always ensure the blending shaft
is dry, and no water is left inside,
before reattaching.
Fig. 1
To Use the Hand Blender
Ensure the blender is completely
and properly assembled as detailed
above.
1. Place food to be processed into
the jug provided (or a sufficiently
large mixing bowl or saucepan).
The jug provided should be only ½
full or less when blending liquids or
when making a puree of fruit and/
or vegetables (See Fig 2).
2. For food preparation tips and
recipes refer to page 14 and the
recipe section.
Fig. 2
3. Insert the plug into a
230V or 240V power outlet
and turn the power on.
4. By turning the Variable Speed
Control dial on top of the motor
body, select a speed between
MIN and 5.
5. Place the blending shaft as
deeply as possible into the jug,
press and hold the ‘VARIABLE’
button to turn the blender on. The
button must be kept depressed
for the required duration of
operation.
6. If extra turbo power is required
when blending, press the ‘BOOST’
button.
7. Work through the ingredients in
the jug with a gentle raising and
lowering motion.
8. Switch off the motor by releasing
the ‘VARIABLE’ or ‘BOOST’ button.
9. Ensure the motor has completely
stopped before lifting the blender
out of the jug.
10. When processing has finished,
switch off at the power outlet and
remove the power plug.

9
NOTE: When pressing and
holding the ‘VARIABLE’ button
the blender will operate at the
speed selected by the Variable
Speed Control. When using the
‘BOOST’ button the blender will
always operate at maximum
speed operation. The ‘BOOST’
button can be used at any time.
To Detach the Stainless Steel
Blending Shaft
Ensure the Stick Mixer is turned off,
the power is switched off at the
power outlet and the appliance is
unplugged.
Hold the motor body with one hand,
(Fig 3) whilst holding the blending
shaft in the other hand and turn
the blending shaft in a clockwise
direction. Pull the motor body away
from the blending shaft to detach.
Fig. 3
NOTE: The Stick Mixer has a
Variable Speed Control. To
decrease speed turn the dial
anti-clockwise and to increase
speed turn the dial clockwise
(See Fig 4).
The Stick Mixer motor will only
operate while the ‘VARIABLE’ or
‘BOOST’ button remain depressed –
this is a safety feature.
Fig. 4
Recommendations when
Using the Stick Mixer as a
Hand Blender
• The Stick Mixer blends foods and
liquids rapidly, therefore it is easy
to over-process. Remember when
using the blending shaft, to stop
the Stick Mixer and check food
throughout the operation.
• The stainless steel blending
shaft on the Stick Mixer allows
for hot food to be processed
directly in the saucepan. This
makes blending soups and
sauces very easy.
• For safety reasons move the
saucepan away from the heat
before processing.
• Ensure the body of the appliance
and power cord are kept away
from any heat source.
• When pureeing and blending,
cut food into uniform sizes.
This will ensure smooth and
consistent results.
• Warm all liquids to be added to
soups and purees, this will ensure
even blending.
