Kanardia Nesis III User manual

Nesis III — Installation Manual
Kanardia d.o.o.
January 2019
© Kanardia d.o.o.

Nesis III — Installation Manual
Contact Information
Publisher and producer:
Kanardia d.o.o.
Lopata 24a
SI-3000
Slovenia
Tel: [phone]
Email: [e-mail]
A lot of useful and recent information can be also found on the Internet. See
http://www.kanardia.eu for more details.
Copyright
This document is published under the Creative Commons, Attribution-Share-
Alike 3.0 Unported licence. Full license is available on http://creativecommons.
org/licenses/by-sa/3.0/legalcode web page and a bit more human read-
able summary is given on
http://creativecommons.org/licenses/by-sa/3.0/. In short, the license
gives you right to copy, reproduce and modify this document if:
 you cite Kanardia d.o.o. as the author of the original work,
 you distribute the resulting work only under the same or similar license
to this one.
Credits
This document was written using TeX Live (L
A
T
E
X) based document creation
system using Kile running on Linux operating system. Most of the figures were
drawn using Open Office Draw, Inkscape and QCad applications. Photos and
scanned material was processed using Gimp. All document sources are freely
available on request under the licence mentioned above and can be obtained
by email. Please send requests to [e-mail].
Revision History
The following table shows the revision history of this document.
3 © Kanardia 2018

Nesis III — Installation Manual
Rev. Date Description
1.0 Jan 2019 Complete manual rework.
4 © Kanardia 2018

Nesis III — Installation Manual CONTENTS
Contents
1 Introduction 9
1.1 Icons Used Trough the Manual . . . . . . . . . . . . . . . . . . 9
1.2 Warnings .............................. 9
1.3 MinimalSystem .......................... 10
2 Display Installation 10
2.1 Placement Consideration . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Main Display Dimensions . . . . . . . . . . . . . . . . . . . . . 11
2.3 TheCutout............................. 11
2.4 Mounting Procedure . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4.1 Fixation with Supplied M3 nut and Lock Washer . . . . 15
2.4.2 Fixation with Self-Clinching Nut . . . . . . . . . . . . . 15
2.4.3 Fixation with Threaded Rivet Nut Insert . . . . . . . . 16
2.4.4 Fixation with Spacer Stud and Epoxy . . . . . . . . . . 17
3 Power Installation 18
3.1 CircuitBreaker........................... 19
3.2 Aircraft Master Relay . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 BackupBattery........................... 19
4 GNSS Antenna Installation 21
4.1 GNSS Signal Check . . . . . . . . . . . . . . . . . . . . . . . . 23
5 Outside Air Temperature Sensor 24
5.1 Installation ............................. 24
5.2 Connection ............................. 26
6 Audio and Video 27
6.1 AudioConnection ......................... 27
6.1.1 Trig TY91/TY92 . . . . . . . . . . . . . . . . . . . . . . 27
6.1.2 FunkeATR833 ....................... 28
6.1.3 DittelKRT2 ........................ 29
6.2 VideoConnection.......................... 30
5 © Kanardia 2018

Nesis III — Installation Manual CONTENTS
7 USB 30
7.1 USBMemoryStick......................... 31
7.2 WiFiModule ............................ 31
7.3 USB Cable As Charger . . . . . . . . . . . . . . . . . . . . . . . 31
7.4 USB Cable As Tethering . . . . . . . . . . . . . . . . . . . . . . 32
8 CAN 32
8.1 ConnectorandPlug ........................ 33
8.2 CANTopology ........................... 33
8.2.1 T-Junction ......................... 34
8.2.2 Terminator Plug . . . . . . . . . . . . . . . . . . . . . . 35
9 Service Port 35
9.1 Terminal Communication . . . . . . . . . . . . . . . . . . . . . 35
9.2 Port 1 – Auxiliary RS-232 . . . . . . . . . . . . . . . . . . . . . 36
9.3 Autopilot Disengage . . . . . . . . . . . . . . . . . . . . . . . . 37
9.4 AlarmSwitch............................ 37
10 RS-232 Ports 38
10.1Pinout................................ 39
10.2Configuration............................ 39
10.3 Connection Details . . . . . . . . . . . . . . . . . . . . . . . . . 41
10.3.1 TQKRT2Radio ...................... 41
10.3.2 Funke ATR 833 Radio . . . . . . . . . . . . . . . . . . . 42
10.3.3 Trig TY91/TY92 Radio . . . . . . . . . . . . . . . . . . 42
10.3.4 Funke TRT800H Transponder . . . . . . . . . . . . . . . 43
10.3.5 Trig TT21/TT22 Transponder . . . . . . . . . . . . . . 44
10.3.6 TQ KTX2 Transponder . . . . . . . . . . . . . . . . . . 44
10.3.7 PowerFlarm ........................ 45
10.3.8 TRX1500.......................... 47
10.3.9 AIR Traffic AT1 . . . . . . . . . . . . . . . . . . . . . . 49
10.3.10FlarmEagle......................... 52
6 © Kanardia 2018

Nesis III — Installation Manual CONTENTS
11 Service Settings 53
11.1Layout................................ 53
11.2Parameters ............................. 55
11.2.1 Parameter Editing . . . . . . . . . . . . . . . . . . . . . 56
11.3FlapSettings ............................ 57
11.4TrimSensitivity........................... 58
11.5VideoInput............................. 58
11.6SerialPorts ............................. 59
11.7COSensor.............................. 59
11.8Backup ............................... 59
11.9Restore ............................... 60
12 AHRS-Leveling 60
12.1 Yaw Misalignment . . . . . . . . . . . . . . . . . . . . . . . . . 61
12.2 Roll and Pitch Adjustment . . . . . . . . . . . . . . . . . . . . 62
12.3InitialPitch............................. 62
13 Engine 62
13.1EngineModel............................ 63
13.2SwitchFunction .......................... 63
13.3Channels .............................. 64
13.3.1 Channel Editing . . . . . . . . . . . . . . . . . . . . . . 65
13.3.2 Min/Max .......................... 67
13.3.3 Offset ............................ 68
13.3.4 Tank............................. 68
14 Tank 68
14.1FuelLevelSensors ......................... 69
14.1.1 LinearShape ........................ 69
14.1.2 UserShape ......................... 70
14.1.3 Predefined Shapes . . . . . . . . . . . . . . . . . . . . . 72
14.2 Simulated Fuel Tank . . . . . . . . . . . . . . . . . . . . . . . . 73
15 Offset 74
7 © Kanardia 2018

Nesis III — Installation Manual CONTENTS
16 Autopilot 75
17 Special 75
18 CAN Devices 76
18.1 Indu Layout Change . . . . . . . . . . . . . . . . . . . . . . . . 76
18.2 Enable/Disable Magnetic Heading . . . . . . . . . . . . . . . . 76
19 Joyu 77
19.1 Device/Action Pairs . . . . . . . . . . . . . . . . . . . . . . . . 77
19.2Configuration............................ 78
8 © Kanardia 2018

Nesis III — Installation Manual 1. Introduction
1 Introduction
First of all we would like to thank you for purchasing our product. Nesis is a
complex instrument and we strongly recommend reading the manuals before
installation. You may be also interested in reading:
 Nesis Installation Manual (this manual),
 Nesis User’s Manual,
 DAQU Installation Manual,
 MAGU Manual,
 Autopilot Installation Manual,
 our web page www.kanardia.eu.
This manual assumes that you are familiar with the Nesis user interface sys-
tem.
1.1 Icons Used Trough the Manual
A few icons appear on the side of the manual, which have special meanings:
This icon denotes information that needs to be taken with special
attention. An injury or even death is possible if instructions are
not obeyed.
Failing to follow the instructions may lead to the equipment dam-
age.
This icon denotes background information about the subject.
This icon denotes a tip.
1.2 Warnings
The following warnings and limitations apply during installation.
 Software based fuel flow and software based fuel level can be very danger-
ous and misleading. They affect also range and endurance calculation.
Never trust any of these values. Make sure that you have some reliable
way to check the actual fuel level during the flight.
9 © Kanardia 2018

Nesis III — Installation Manual 1.3 Minimal System
 Before installing the instrument, you shall carefully read and understand
this manual and any other supplementing manual.
 The manual is not a substitute for an approved aircraft specific main-
tenance manual, installation or design drawing. Attempting to install
Nesis and corresponding equipment by reference to this manual only
(without planning or designing an installation specific to aircraft) may
compromise the safety and is not recommended.
1.3 Minimal System
Nesis minimal system consists of two components: Nesis III display and
DAQU (engine management box). They are sold together as a kit.
This manual starts with the installation instructions for the minimal system
and then adds separate sections for optional components.
Some components have their own installation manuals.
2 Display Installation
This section covers the installation of the Nesis display.
2.1 Placement Consideration
There are several consideration which affect the display position on the in-
strument panel.
 The display must be in direct view field of the pilot without any ob-
structions.
 The display supports landscape orientation only. Portrait orientation is
not possible.
 The display has a modest power consumption. It is cooled trough top
and bottom openings in the housing. Please make sure that cooling air
will be able to circulate trough the housing openings.
 Avoid to place the display next to the heater vents or into any kind of
direct stream of hot air.
10 © Kanardia 2018
