K&S BASIC KSB 30A User manual

Please, read this manual
carefully before use!
OWNER’S MANUAL
GASOLINE GENERATOR
KSB 30A
KSB 70C
EN

INTRODUCTION
SAFETY INFORMATION 1
Thank you for your purchase of K&S Basic®products. This manual contains a brief description of safety, use
and debugging. More information can be found on the official manufacturer’s website in the support section:
konner-sohnen.com/manuals
You can also go to the support section and download the full version of the manual by scanning the QR code, or on
the website of the official importer of K&S Basic® products: www.konner-sohnen.com
Manufacturer reserves the right to make alterations into the generators, which may not be reflected in this manual.
Pictures and photos of the product may vary from its actual appearance. At the end of this manual, You may find
contact information which you are free to use in case of any issues occurrence.
All data, specified in this operation manual is the most up to date for the moment of its publishing. The current list of
service centers you can find at the website of official importer: www.konner-sohnen.com
Do not use the generator in rooms with poor ventilation or in conditions of excessive humidity. Do not place the
generator in water or on moist soil. Do not expose the generator to rain, snow, as well as to direct sunlight for a long
time. Place the generator on a at, hard surface, away from ammable liquids/gases (at a minimum distance of 1
m). Install the generator at a distance of not less than 1 m from the front control panel and not less than 50 cm on
each side, including the upper part of the generator. Keep unauthorized persons, children, and animals away from
work area. Wear safety shoes and gloves.
We care about the environment, therefore, we consider it expedient to savepaper andWe care about the environment, therefore, we consider it expedient to savepaper and
leave in print a short description of the most important sections.leave in print a short description of the most important sections.
Failure to follow the recommendations marked with this sign may
lead to serious injury or death of the operator or third parties.
ATTENTION – DANGER!
Useful information while operating the machine.
IMPORTANT!
Be sure to read the full version of the manual before
getting started!
Safety symbols and description of inscriptions can be found in the full electronic version.Safety symbols and description of inscriptions can be found in the full electronic version.
As exhaust gases contain poisonous carbon dioxide (CO2) and car-
bon monoxide (CO) gases which are dangerous for life, it is strictly
forbidden to install the generator in residential buildings, prem-
ises connected to residential buildings by a common ventilation
system, other rooms from which exhaust gases may enter living
premises.
ATTENTION – DANGER!
When installing the generator, pay attention to the capacity of
electrical appliances and their starting current, which may be sev-
eral times higher than the rated current. The generator cannot
run in overload conditions when starting consumers with an in-
rush current higher than the generator’s maximum output.
ATTENTION – DANGER!
Pay attention to the number of phases of the generator and the
electrical system. A three-phase generator is only suitable for
three-phase power consumers. Never connect a three-phase gen-
erator to a three-phase home network if there are no three-phase
power consumers
ATTENTION – DANGER!
konner-sohnen.com |1

PRECAUTIONS WHEN WORKING WITH
GASOLINE GENERATOR 1.2
Do not start the generator operation upon presence of electric load! Disconnect the load before you stop the engine.
Only unleaded gasoline is recommended for the generator. It is forbidden to use kerosene or other
fuel types. Before running the generator, it is necessary to define the place and means of its emergency stop. Do not
refuel the running generator.
Fuel contaminates the land and groundwater. Do not
allow the leaking gasoline from the tank!
ATTENTION – DANGER!
Using device for other purposes deprives the right for free warranty.
IMPORTANT!
Be careful. Do not operate the generator, if you are tired, under
the influence of drugs or alcohol. Inattention may cause a serious
injury.
ATTENTION – DANGER!
ELECTRICAL SAFETY 1.1
The generator produces electricity that may lead to an electric shock while neglecting compliance regulations. All
connecting the generator to the network must be made by certied electrician in accordance with all electrical rules
and regulations. Connect the generator to the protective ground before operation. Wires with damaged or spoiled
insulation should be replaced. You should also replace worn, damaged or rusty contacts.
The device generates electricity. Follow safety precautions to
avoid electric shock.
ATTENTION – DANGER!
The generator should be used as an IT or TN system based on the
application. Earthing and additional protective measures such as
insulation monitoring or protection against accidental contact
(residual current device) must be provided based on the applica-
tion and the system used.
IMPORTANT!
It is forbidden to connect to the generator devices which can
generate current pulses and direct energy towards the generator
(voltage stabilizers, devices with electronic brakes, on-grid and
hybrid inverters, etc.).
IMPORTANT!
The generator and power consumers form a closed system, with elements aecting each other. This system is physi-
cally dierent from the public network since it is signicantly aected by factors such as unbalanced phase load and
non-linear current consumption by power consumers that can cause damage to the generator and power consumers
connected to it.
konner-sohnen.com |2

GENERAL VIEW AND COMPOSITION
OF THE GASOLINE POWERED GENERATOR 3
1. Fuel cap
2. Control panel
3. Oil dipstick
4. Oil drain cap
5. Hand starter
6. Fuel valve
7. Air filter
8. Air choke lever
9. Fuel level indicator
10. Damper
11. Alternator
12. Spark plug
12
10
11
2
1
3
4
5
6
7
8
9
SPECIFICATIONS 2
Model KSB 30A KSB 70C
Voltage, V 230 230
Maximum power, kW 2,8 5,5
Rated power, kW 2,5 5,0
Frequency, Hz 50 50
Current max, A 12,17 23,91
Outlets 2*16А 1*16А, 1*32А
Fuel tank capacity, l 12 25
Voltmeter + +
Noise level Lpa(7m)/Lwa, dB 71/96 72/97
Output 12 V, A 12/8,3 12/8,3
Engine model KSB 220 KSB 440
Engine type gasoline powered four-stroke gasoline powered four-stroke
Power output, hp 7 15
Crankcase capacity, cm30,6 1,1
Engine capacity, cm3210 420
Voltage regulator AVR AVR
Engine start manual manual
Power factor, cosφ 1 (230V) 1 (230V)
Dimensions (LxWxH), mm 605x440x435 690x525x550
Net weight, kg 36,2 66,6
Protection class IP23M IP23M
Max. altitude above sea level, m 1000 1000
Relative humidity <95% <95%
Rated voltage tolerance – max. 5%
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited by
circuit breakers.
The optimum operating conditions are ambient temperature of 17–25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specifications. In case of deviations from the above ambient values, the
performance of the generator can be different.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80% of the
rated power.
konner-sohnen.com |3

COMMISSIONING 4
To commission the generator, follow the maintenance recommendations for the first month or twenty hours of
operation (whichever comes first) contained in the “Maintenance” section.
For commissioning models with elektrostart please charge the battery. Please use additional battery charger (not
included) to charge the battery or let the generator work at least one hour at 50% load at the first start.
The manufacturer reserves the right to make changes in the prod-
uct design, conguration and construction. Illustrations in this
manual are for reference only and may dier from actual compo-
nents and inscriptions on the products.
IMPORTANT!
1. Voltmeter or LED display
2. Safety switch
3. Outlets
4 . Engine start button (ON/OFF)
5. 12V/8A DC outlet
6. Ground connector
1. Fill the crankcase with engine oil. The recommended amount of oil for each model is indicated in the specification
chart.
2. Check oil level with an oil dipstick. It should be between the MIN and MAX marks on the oil dipstick.
3. Check fuel level.
4. Check the air filter for correct installation
In the first 20 operating hours of the generator, the following requirements should be met:
1. During commissioning, do not connect power consumers, the power of which exceeds 50% of the nominal
(operating) power of the device.
2. After the first 20 operating hours, be sure to change the oil. It is better to drain oil while the engine is still hot after
operation to ensure quick and complete oil draining.
3. Check and clean the air filter, fuel filter and spark plug.
CHECK THE FUEL LEVELCHECK THE FUEL LEVEL
1. Wear protective gloves to avoid getting gasoline on your skin.
2. Unscrew the fuel cap and check the fuel level in the tank.
3. Fill the fuel tank to the fuel filter level.
4. Tighten the fuel cap securely.
CHECK THE OIL LEVELCHECK THE OIL LEVEL
Recommended fuel: Unleaded gasoline.
Fuel tank volume: see specifications table.
Recommended engine oil: SAE 10W-30, SAE 10W-40.
Recommended engine oil grade: API Service SE type or higher.
Motor oil quantity: see specifications table.
1. Wear protective gloves to avoid getting oil on your skin.
2. Unscrew the oil dipstick and wipe it out with a clean cloth.
3. Insert the dipstick without screwing it in.
4. Check the oil level by a mark on the oil dipstick.
5. Add oil if its level is below the mark on the oil dipstick.
6. Tighten the oil dipstick.
Only unleaded gasoline is recommended for the generator. The
use of leaded gasoline will cause severe damage to internal engine
parts.
IMPORTANT!
fill to here
STARTING TO WORK 5
12 3
654
konner-sohnen.com |4

Works, specified in “Technical maintenance” section, are to be regularily performed. If the the generator user has
no possibility to perform regular maintenance independently, it is necessary to address the official service center to
registrate an order for such works performance.
You can find a list of service center addresses in your warranty card.
MAINTENANCE 6
STOPPING THE ENGINESTOPPING THE ENGINE
1. Disconnect all power consumers from the generator, set the safety switch to the OFF position.
2. Allow the generator to operate at idle for 3 minutes so that the alternator cools down.
3. In case of manual start, set the engine switch to OFF.
4. In case of electric start, set the key to OFF.
5. Move the fuel valve to the “CLOSE” position.
DISCONNECT ALL THE DEVICES BEFORE STOPPING THE GENERATOR!
Do not stop the generator, if there are connected devices. This may
lead generator down!
WARNING - DANGER!
1. Move the fuel valve to the “OPEN” position.
2. Set the air choke to the closed position.
3. To start the generator manually, grasp the starter handle and slowly pull it until resistance is felt. Pull the starter
cord to the full length with a sharp movement.
4. Set the air choke to the “OPEN” position.
ENGINE STARTENGINE START
Do not connect two or more devices simultaneously. The start-up
of many devices requires high power. Devices should be connected
in turn according to their power rating. Do not connect any power
consumers within the first 3 minutes after the generator start.
WARNING - DANGER!
Before starting the engine make sure that the total power of tools or power consumers corresponds to the
rated power of the generator. Do not exceed the rated power of the generator. Do not connect any devices
before the engine start! In the power supply mode, the generator should operate no longer
than 30 minutes in the range from rated to maximum power.
Before connecting any devices to the generator, make sure that they are in good condition. If the device that was
connected suddenly stopped or failed, immediately disconnect the power using a safety switch, disconnect the
device and check it out.
Fuel valve Air choke
closed
OPEN
open CLOSE
Closed
Open Hand starter
If the generator has not been used for a long time, recharge the
battery with a charger (not included).
IMPORTANT!
Standby generators should not run continuously (e.g. by adding
fuel to the tank or connecting a large fuel tank) or longer than
recommended: 4-6 hours for gasoline generators (depending on
load).
ATTENTION – DANGER!
This material is for informational purposes only and does not constitute a manual for installing the equip-
ment or connecting it to the mains, but we strongly recommend that you read the instructions below.
Equipment connection must always be carried out by a certied electrician responsible for the installation
and electrical connection of the equipment according to local laws and regulations. The manufacturer
assumes no liability for improper connection of the equipment or for any material or physical damage that
may result from improper installation, connection or operation of the equipment.
fill to here
konner-sohnen.com |5

In case of any damages, occurred due to non-performance of reg-
ular maintenance works, the manufacturer bears no responsibility
for such damages.
IMPORTANT!
SUCH DAMAGES ARE ALSO:SUCH DAMAGES ARE ALSO:
- Damages occurred as a result of using non original spare parts.
- Corrosion damages and other results of improper equipment storage.
- Damages occures as a result of maintanance performance by inexperienced and unauthorized specialists.
FIRST OF ALL THIS APPLIES TO:FIRST OF ALL THIS APPLIES TO:
- Use of lubricants, gasoline and motor oils, forbidden by the manufacturer.
- Device technical alterations.
- Equipment operations against its intended use.
- Indirect damages, caused by operating faulty equipment.
MANUAL COMPLIANCE
Technical maintanance, operation and K&S Basic™ generator storage
are to be performed according to this manual recommendations.
Manufacturer bears no responsibility for damages and losses,
caused by incompliance to safety requirements and technical
maintanance rules.
IMPORTANT!
- If the generator is often working at high temperature or at high load, the oil should be replaced every 25 operating
hours.
- If the engine is often running in dusty or other harsh conditions, please clean the air filter every 10 hours.
- If you missed the maintenance time, perform it as soon as possible to save the generator engine.
TECHNICAL MAINTENANCE WORKS
Node Service type
Before starting
First month or
after 20 working
hours
Each 3 months or
after 50
working hrs
Each 6 months or
after 100
working hrs
Each year or after
300 working hrs
Motor oil
Checking
level
Changing
Air lter Checking/ Cleaning
Changing
Sparking
plug
Cleaning
Changing
Fuel tank
Checking
level
Cleaning
Fuel lter Cleaning
Motor oil has a serious impact on performance
characteristics and is a major attribute, defining its service
life. Use oils designed for four-stroke cycle vehicle engines,
since such oils contain cleaning additives, which comply or
even exceed SE standards according to API classification (or
equivalent).
RECOMMENDED OILS 7
000CC
10W-30, 10W-40
4040303020201010-10-10-20-20
konner-sohnen.com |6

fill to here
TO DRAIN OIL, PROCEED AS FOLLOWS:TO DRAIN OIL, PROCEED AS FOLLOWS:
1. Place the generator on a flat surface and warm up the engine for several minutes.
Stop the engine and turn the fuel tank cap to the “OFF” position.
2. Loosen the screws and remove the motor cover.
3. Place an oil drain tray under the engine.
4. Unscrew the oil drain cap with a hexagon key.
5. Wait for the oil to drain. Tilt the generator for a better result.
6. Add motor oil to a high level.
7. Wipe the oil drain cap with a clean, dry cloth and wipe off any oil spills, if any.
Make sure that no dirt, dust, etc. are caught in the crankcase.
8. Replace the oil filler cap.
9. Replace the vent cover and tighten the screws.
Avoid draining the engine oil immediately after stopping the
engine. The oil is hot and should be handled with care to avoid
burns.
ATTENTION - DANGER!
Do not tilt the generator while adding oil to the engine. This can
lead to overfilling and damage to the engine.
ATTENTION - DANGER!
Electrode
0,7-0,8 mm
Spark plug is an importaint element providing the correct engine
operation. It has to be intact, without soot deposits and to have a
correct gap.
SPARK PLUG TECHNICAL MAINTENANCE 8
Spark plug
SPARK PLUG INSPECTION:SPARK PLUG INSPECTION:
1. Remove the cap from the spark plug.
2. Remove the spark plug by means of a corresponding spanner.
3. Examine the spark plug.
If it is shattered – it is necessary to replace it. Recommended replacement
spark plugs – F7TC.
4. Measure the gap. It has to be within range 0.7 – 0.8 mm.
5. Place the spark plug in its place by means of a spark plug spanner.
6. Replace the spark plug cap.
It is necessary to check the air filter from time to time and clean any contaminations. Regular air filter maintenance is
necessary to maintain sufficient carburetor air inflow.
AIR FILTER TECHNICAL MAINTENANCE 9
REPLACING OR ADDING MOTOR OIL:REPLACING OR ADDING MOTOR OIL:
Upon oil level decrease it is necessary to add the required quantity in order
to provide the correct generator operation. It is necessary to check the oil levels
according to technical maintanance schedule.
In general, the engine is recommended to run with motor oils of SAE10W-30, SAE10W-40 viscosity level. Motor oils
with other viscosity levels, may be used only if the average air temperature in your region does not exceed the limits
of the temperature range, specified in the table. Oil viscosity according to SAE standards or service category, are
specified on the API capacity sticker.
konner-sohnen.com |7

CLEANING THE FILTER:CLEANING THE FILTER:
1. Open the air filter cover.
2. Remove the sponge filtering element.
3. Remove all dirt deposits inside the hollow case of the air filter.
4. Thoroughly wash the filtering element in warm water.
5. Dry the sponge filter.
6. Dry filtering element is to be moistened by machine oil and excess oil
is to be squeezed out.
GENERATOR STORAGE 10
The generator must be stored in a dry, well-ventilated area that is free from dust. Keep away from children and
animals.
Generator should always remain ready for operation. Therefore
in case of device malfunctions, they are to be repaired before dis-
mounting the generator for storage.
IMPORTANT!
GENERATOR LONG-TERM STORAGEGENERATOR LONG-TERM STORAGE
If the generator will not be used for a long time, it is recommended to:
- Drain the fuel into the tank.
- Drain the motor oil.
- Pull the manual starter until a slight resistance is felt so that the inlet and drain valves get closed.
- Clean the generator from dirt and dust.
When starting the generator after long-term storage, proceed as above in the reverse order.
GENERATOR TRANSPORTATION 11
GENERATOR AND BATTERY UTILISATION 12
WARRANTY SERVICE TERMS 13
For easy generator transportation use packaging, which generator was sold in. Secure the box with the generator to
avoid tipping it on the side of the carriage. Before moving the generator drain the fuel and disconnect the terminals
of the battery (if this model has a battery).
To move the generator from one place to another lift it by holding the frame (if generator has construction with open
frame). If generator has an silent cover, use transportation handles. Be careful, do not expose your feet under the
generator.
To prevent damage to the environment separate generator and battery from ordinary waste and recycle them in the
safest way passing a special place for disposal.
Potential faults and troubleshooting methods, as well as average device capacities canPotential faults and troubleshooting methods, as well as average device capacities can
be found in thefull version of the manual.be found in thefull version of the manual.
The international manufacturer warranty is 1 year. The warranty period starts from the date of purchase. In cases when warranty
period is longer than 1 year according to local legislation please contact your local dealer. The Seller which sells the product is
responsible for granting the warranty. Please contact the Seller for warranty. Within the warranty period, if the product fails because
of defects in the production process, it will be exchanged on the same product or repaired.
All faults caused by the manufacturer during the warranty period will be eliminated free of charge. Warranty repair is carried out
only if you have a fully completed warranty card, the Buyer’s signature of acceptance of the warranty terms, as well as a document
supporting the purchase (cash receipt, sales slip or invoice). In the absence thereof, as well as in the event of errors or corrections
not authenticated by the seller’s seal or illegible inscriptions in the warranty card or tear-o coupon, no warranty repair is carried
out, no objections to quality are accepted and the warranty card is withdrawn by the service center as invalid. The device is accepted
for repair clean and full. konner-sohnen.com |8

CONTACTS
Deutschland:
DIMAX International GmbH
Flinger Broich 203 -FortunaPark-
40235 Düsseldorf, Deutschland
www.koenner-soehnen.com
Ihre BestellungenIhre Bestellungen
[email protected]
Kundendienst, technische FragenKundendienst, technische Fragen
und Unterstützungund Unterstützung
[email protected]
Garantie, Reparatur und ServiceGarantie, Reparatur und Service
[email protected]
SonstigesSonstiges
[email protected]
Polska:
DIMAX International
Poland Sp.z o.o.
Polska, Warczawska, 306B
05-082 Stare Babice,
[email protected]
Україна:
ТОВ «Техно Трейд КС»,
вул. Електротехнічна 47,
02222, м. Київ, Україна
[email protected]
