KANSAI SPECIAL WX Series User manual

INSTRUCTION 


Industrial Sewing Machines
First published : August 1991
Second edition : March 1997
No. 970016
WX8800
WX8700
LX5801

INTRODUCTION
INTRODUCTIONINTRODUCTION
INTRODUCTION
Thank you for your purchasing Kansai Special's WX Series.
Read and study this instruction manual carefully before beginning any of the
procedures and save it for later use.
1. This instruction manual describes adjustments and maintenance procedures on this
machine.
2. Before starting the machine check to make sure the pulley cover, safety cover, etc.
are secured.
3. Before adjusting, cleaning, threading the machine or replacing the needle, be sure
to turn off the power.
4. Never start the machine with no oil in the reservoir.
5. Refer to the parts list as well as this instruction manual before maintenance. If
the machine includes a thread trimmer, read and study the instruction manual for
the thread trimmer carefully.
6. The contents described in this instruction manual are subject to change without
notice.

CONTENTS
CONTENTSCONTENTS
CONTENTS
1. NEEDLES & THREADING THE MACHINE
1-1 Needles ･･････････････････････････････････ 1
1-2 Replacing the needle ･･････････････････････ 1
1-3 Threading the machine ･･･････････････････ 1
2. MACHINE SPEED
2-1 Machine speed & direction in which the machine
pulley runs ･･････････････････････････････ 2
2-2 Motor & belt ･････････････････････････････ 2
3. LUBRICATION
3-1 Oil ･･････････････････････････････････････ 3
3-2 Oiling ･･･････････････････････････････････ 3
3-3 Replacing the oil and the oil element ･･･････ 3
4. SEWING MACHINE INSTALLATION
4-1 Cutting the machine table ･････････････････ 4
4-2 Installing the machine ････････････････････ 5
5. TIMING OF THE LOOPER TO THE
NEEDLES
5-1 Angle and height for installing the looper ･･･ 6
5-2 Looper left-to-right movement ･････････････ 6
5-3 Looper setting distance ･･･････････････････ 7
5-4 Needle height ････････････････････････････ 7
5-5 Needle/looper front-to-back relationship ････ 7
5-6 Changing the looper orbit ･････････････････ 8
5-7 Changing the amount of the looper front-to-back
movement ･･･････････････････････････････ 8
6. FRONT AND REAR NEEDLE GUARDS
6-1 Position of the needle guard (rear) ･････････ 9
6-2 Position of the needle guard (front) ･････････ 9
7. SPREADER
7-1 Position of the spreader ･･････････････････ 10
7-2 Position of the spreader guide ････････････ 10
7-3 Timing of the spreader ･･･････････････････ 11
8. FEED DOGS & STITCH LENGTH
8-1 Feed dog height & tilt ････････････････････ 11
8-2 Stitch length ････････････････････････････ 12
8-3 Differential feed ･････････････････････････ 12
9. PRESSER FOOT
9-1 Presser foot pressure ････････････････････ 13
9-2 Position of the presser foot & foot lift ･･････ 13
10. STITCH FORMATION
10-1 Position of the needle thread guides ･･････ 14
10-2 Position of the thread guide on the needle
thread take-up ････････････････････････ 14
10-3 Timing of the needle thread take-up ･････ 14
10-4 Position of the needle thread guard ･･････ 15
10-5 Position of the thread guide of the spreader
thread take-up ････････････････････････ 15
10-6 Position of the thread guide of the looper thread
take-up ･･･････････････････････････････ 15
10-7 Position of the looper thread take-up ･････ 16
11. EMK ELASTIC FEEDER
11-1 To insert the lace/elastic ････････････････ 16
11-2 Lace/elastic guide on the presser foot ･････ 16
11-3 Adjusting the front of the presser foot ････ 16
11-4 To install the tape guide ････････････････ 17
11-5 Feeding amount of the lace/elastic ･･･････ 17
11-6 Pressure of the elastic feed small roller ･･ 17
11-7 Checking the performance of the elastic
feeder ････････････････････････････････ 17
11-8 Oiling each part ････････････････････････ 18
12. EMK FRONT KNIFE DEVICE
12-1 Adjusting and oiling the lower knife holder
･18
12-2 Replacing the lower knife ･･･････････････ 18
12-3 Replacing the upper knife ･･･････････････ 18
12-4 Overlap of the upper and lower knives ･･･ 19
12-5 To sharpen the knife ･･･････････････････ 19
13. REPLACING THE TIMING BELT
13-1 Marks on the timing belts ･･･････････････ 19
13-2 To remove the timing belt ･･･････････････ 19
13-3 To place the timing belt ･････････････････ 20
14. CLEANING THE MACHINE ･･･････････ 20

1
< Note >
Before replacing the needle, be sure to turn off the machine.
A clutch motor continues running for a while after the machine is turned off.
Therefore keep on pressing the pedal until the machine stops.
【1】NEEDLES & THREADING THE MACHINE
1
11
1-
--
-1 Needles
1 Needles1 Needles
1 Needles
UY128GAS of Schmetz or Organ
Select the proper needle for the fabric and thread.
< Needles and needle size >
Schmetz UY128GAS Nm65 Nm70 Nm75 Nm80 Nm90
Organ UY128GAS # 09 # 10 # 11 # 12 # 14
1
11
1-
--
-2 Replacing the n
2 Replacing the n2 Replacing the n
2 Replacing the needle
eedleeedle
eedle
To replace the needle, check the needle carefully to see
that the scarf is turned to the rear of the machine (see the
illustration). Then install the needle correctly.
1
11
1-
--
-3 Threading the machine
3 Threading the machine3 Threading the machine
3 Threading the machine
Thread the machine correctly by referring to the illustration below.
Threading the machine incorrectly may cause skip stitching, thread breakage and/or
uneven stitch formation.
A, B, C ... Needle threads
D............. Top cover thread
E ............ Looper thread
For stretchable threads
such as woolly thread

2
Thread tension should be changed according to various kinds of conditions such as the
thread to be used and/or the feeding amount (see Chapter 10 for "Stitch formation").
【2】MACHINE SPEED
2
22
2-
--
-1 Machine speed & direction in which the machine pulley runs
1 Machine speed & direction in which the machine pulley runs1 Machine speed & direction in which the machine pulley runs
1 Machine speed & direction in which the machine pulley runs
Refer to the table below for maximum and standard
speeds of the Series. To extend machine life, run the
machine approximately 15~20% below the maximum
speed for the first 200 hours of operation (approx. 1
month). Then run the machine at the standard speed.
The machine pulley turns clockwise as the handwheel
does as seen from the machine pulley.
2
22
2-
--
-2 Motor & belt
2 Motor & belt2 Motor & belt
2 Motor & belt
Motor : 3-phase, 2-pole, 400W clutch motor
Belt : M type V belt
Select the proper motor pulley according to the
machine speed (refer to the motor pulley outer
diameter on the table below). Adjust where to
position the motor by pressing the finger onto the
middle of the belt so that 1~2cm deflection can be
obtained (see the illustration on the right).
< Machine speed >
TYPE MAXIMUM SPEED STANDARD SPEED
WX8803 6000SPM 5500SPM
WX8803EMK 5000SPM 4500SPM
LX5801 6500SPM 6000SPM
< Motor pulley selection table >
Machine speed (SPM)Motor pulley
outer diameter
(mm) 50Hz 60Hz
80 3300 3900
90 3700 4400
100 4100 4900
110 4500 5400
120 5000 5900
130 5300 6400
140 5800 (6900)
150 6200

3
< Note >
When the oil filter cap is removed, the oil collected on the element drips. Be careful.
【3】LUBRICATION
3
33
3-
--
-1 Oil
1 Oil1 Oil
1 Oil
Use Kansai Special’s genuine oil.
(Part No. 28-613 : 1000cc)
3
33
3-
--
-2 Oiling
2 Oiling2 Oiling
2 Oiling
■
To fill the machine with oil
Remove rubber plug A from the oil hole.
Fill the machine with oil until the oil level is at the
top line (see H in the illustration) on oil gauge C.
After the first lubrication, add oil so that the oil
level will be between H and L.
■
To check for proper oil flow
After filling the machine with oil, run the machine
to check the oil is splashing to oil flow sight window
B.
3
33
3-
--
-3
33
3 Replacing the oil and the oil element
Replacing the oil and the oil elementReplacing the oil and the oil element
Replacing the oil and the oil element
To extend machine life, be sure to replace the oil
after the first 250 hours of operation.
To replace the oil, follow the procedures below.
1. Remove the V belt from the motor pulley and
then remove the machine from the table.
2. Remove screw D and then drain the oil.
Be careful not to stain V belt with the oil.
3. After draining the oil, be sure to tighten screw
D.
4. Fill the machine with oil by referring to 3-2
shown above.
If element E is contaminated, proper oiling may not
be performed. Clean the filter element every six
months. If just a little or no oil flows out from the
nozzle with the proper amount of oil in the machine,
check the element. To do so, remove oil filter cap F.
Replace the element if necessary.

4
【4】SEWING MACHINE INSTALLATION
4
44
4-
--
-1 Cutting the machine table
1 Cutting the machine table1 Cutting the machine table
1 Cutting the machine table
■
Cut the diagonally shaped area for the EMK type.
■
Hole A shown below is for installing the electric presser foot lift.

5
4
44
4-
--
-2 Installing the machine
2 Installing the machine2 Installing the machine
2 Installing the machine
Install the machine correctly by referring to the illustration below.
Secure the bolts in place with the nuts tightened against the underside of the machine
table. Fit the rubber cushions onto the bolts.
Then mount the machine properly onto the rubber cushions.
Install the chute for the EMK type (see below).

6
【5】TIMING OF THE LOOPER TO THE NEEDLES
5
55
5-
--
-1 Angle and height for installing the looper
1 Angle and height for installing the looper1 Angle and height for installing the looper
1 Angle and height for installing the looper
To obtain the proper angle and height, insert the looper fully into looper holder A and
then tighten screw B. WX Series Angle : 3° Distance at 25mm from the point of the
looper between the bottom of the looper blade and the extension line from the point of the
looper : Approximately 1.3mm. LX Series Angle : 3.5° Distance at 20mm from the point
of the looper between the bottom of the looper blade and the extension line from the point
of the looper : Approximately 1.2mm.
5
55
5-
--
-2 Looper left
2 Looper left2 Looper left
2 Looper left-
--
-to
toto
to-
--
-right movement
right movementright movement
right movement
The point of the looper should pass the center of the left needle and 0.5~1mm above the
top of its needle's eye when the looper moves to the left or right on the front or back side of
the needles (see the illustration below). Refer to 5-4 for the height of the needle.
To adjust the timing of the looper to the needles,
1. Remove the machine cover.
2. Loosen screws A on the timing pulley (upper).
3. Shift the timing pulley (upper) by turning the handwheel while holding the timing
pulley (upper) by hand.

7
< Note >
After the above adjustment, check to make sure each needle
drops into the center of each needle hole .
5
55
5-
--
-3 Looper setting distance
3 Looper setting distance3 Looper setting distance
3 Looper setting distance
Set the looper so that the distance from the point of the
looper to the center of the needle bar is 6mm when the
looper is at its farthest position to the right. For 1-needle
machines, this distance is 4mm. The table below shows
setting distance A from the point of the looper to the
center of the right needle when the needle is at the bottom
of its stroke and the looper is at its farthest position to the
right.
Setting distance A varies according to the needle space.
To make this
adjustment,
loosen screw C
(see 5-1) on the
looper holder.
5
55
5-
--
-4 Needle height
4 Needle height4 Needle height
4 Needle height
The point of the looper should be 0.5~1mm above the top
of the left needle's eye on the back side of the needle when
the point of the looper has reached the center of the left
needle with the machine pulley turning in the operating
direction (see 5-2).
To adjust the height of the needle,
1. Set the needle bar at the top of its stroke.
2. Remove the plug on the head cover.
3. Loosen screw A.
4. Move the needle bar up or down.
5
55
5-
--
-5 Needle/looper front
5 Needle/looper front5 Needle/looper front
5 Needle/looper front-
--
-to
toto
to-
--
-back relationship
back relationshipback relationship
back relationship
The point of the looper is 0.5~1mm above the top of the
left needle's eye on the back side of the needle when it has
reached the center of the left needle. With the point of
the looper at this position, set the clearance between the
left needle and the point of the looper at approximately
0.2mm.
Then the looper should barely touch the right needle
(approximately 0.2mm). On 3-needle machines, the
clearance between the point of the looper and the middle
needle should be 0mm. To make the above adjustment,
1. Loosen screw C (see 5-1).
2. Move the looper holder front or back.
NEEDLE SPACE
(INCH) LOOPER SETTING DISTANCE A
3.2mm (1/8) 4.4mm
4.0mm (5/32) 4mm
4.8mm (3/16) 3.6mm
5.6mm (7/32) 3.2mm
6.4mm (1/4) 2.8mm
1 Needle 4mm
< Note >
When moving the looper holder front or back, be careful not
to change the looper setting distance.

8
5
55
5-
--
-6 Changing the looper orbit
6 Changing the looper orbit6 Changing the looper orbit
6 Changing the looper orbit
When the looper moves around the needles, the point of
the looper on 2-needle and 3-needle machines barely
touches the right needle and the clearance between the
point of the looper and the left needle is approximately
0.2mm.
To change the looper's orbit,
1. Loosen screw B on eccentric A.
2. Shift the timing mark by moving eccentric A front
or back.
The timing mark is factory-set for standard.
Do not change the orbit extremely.
■
The timing mark is at the standard position.
The 3 o'clock end of the orbit is at a slightly up
position.
■To advance the timing of the looper to the needle
Shift the timing mark to X. Skip stitching may occur when the looper moves to the right.
A thread chain is not produced smoothly.
■To delay the timing of the looper to the needle Shift the timing mark to Y.
Skip stitching may occur when the looper moves to the left.
The needle extremely touches the back of the looper, causing needle breakage.
5
55
5-
--
-7 Changing the amount of the looper font
7 Changing the amount of the looper font7 Changing the amount of the looper font
7 Changing the amount of the looper font-
--
-to
toto
to-
--
-back movement
back movementback movement
back movement
The clearance between the point of the left needle and
the back side of the looper when the looper moves to
the right from the extreme left end of its travel should
be 0.05 -0.1mm. The clearance between the point of
the right needle and the back side of the looper should
be 0.2~0.3mm. The amount of the looper front-to-back
movement is factory-set properly for needle counts
9~11.
If you use needle counts 12~14, adjust the amount as
required (see below).
1. Remove rear bed cover A.
2. Loosen the nut on the looper front-to-back rod pin.
To decrease the amount, move the rod pin to X.
To increase the amount, move the rod pin to Y.
The amount range is from 2.3 to 3.1mm.
The amount is factory-set at 2.7 to 2.8mm.
Adjust according to the needle count.
If the amount is excessively decreased, the needle will
rub against the back of the looper, causing needle
breakage. If the amount is excessively increased, the
clearance between the needle and the back of the
looper will increase and then skip stitching may occur
when the looper moves to the left.
< Note >
To sew under good conditions, adjust the looper orbit after
changing the amount of the looper front-to-back
movement by moving the timing mark slightly to X or Y.

9
【6】FRONT AND REAR NEEDLE GUARDS
6
66
6-
--
-1 Position of the needle guard (rear)
1 Position of the needle guard (rear)1 Position of the needle guard (rear)
1 Position of the needle guard (rear)
Align line (a) on needle guard (rear) A with the center of
the right needle hole when the needle guard (rear) is at
the bottom of the stroke. When point of the looper passes
the back side of the needles, the needle guard (rear)
should push the right needle slightly toward the front and
the clearance between the point of the looper and the left
needle should be approximately 0.2mm.
Set the clearance between the right needle and the point
of the looper at 0~0.05mm when the point of the looper
has reached the center of the right needle from the
extreme right end of its travel. When the point of the
looper has reached the center of the left needle, make sure
the left needle does not touch the looper by pressing the
left needle backward. Then turn the needle guard (rear)
with screw B to set the clearance between the needle
guard (rear) and the needle at 0.1~0.15mm. Adjust the
needle guard (rear) front to back with screw C.
6
66
6-
--
-2 Position of the needle guard (front)
2 Position of the needle guard (front)2 Position of the needle guard (front)
2 Position of the needle guard (front)
Set the clearance between the needles and needle guard
(front) A when the point of the looper has reached the
center of the right and left needles at 0~0.05mm.
To make this adjustment, loosen screw B.

10
【7】SPREADER
7
77
7-
--
-1 Position of the spreader
1 Position of the spreader1 Position of the spreader
1 Position of the spreader
■Height
The distance between the top surface of the needle plate
and the bottom surface of the spreader should be
9~11mm.
■Left-to-right position:
When the spreader is at the extreme left end of its travel,
the distance between the center of the left needle and the
point of the thread carrying notch should be 4.5~5.5mm.
When the spreader passes the left needle, the distance between the point of the thread
carrying notch and the left needle should be 0.5~0.8mm. To make the above adjustment,
loosen screws A and B.
■Adjust the amount of the spreader movement according to the number of spreader
threads and/or the fabric weight to make this adjustment, remove the arm top cover,
loosen nut C and then move the adjusting lever pin in direction (a) or (b). To decrease
the amount, move the pin in the direction of (a). To increase the amount, move the pin
in the direction of (b).
7
77
7-
--
-2 Position of the spreader thread guide
2 Position of the spreader thread guide2 Position of the spreader thread guide
2 Position of the spreader thread guide
The clearance between spreader thread guide B and
spreader A should be 0.5-0.8mm.
When the spreader is at the extreme right end of its travel,
point (a) of the spreader thread carrying notch should be
aligned with the center line of the slot of spreader thread
guide B. When the needle bar is at the bottom of its
stroke, the clearance between the spreader thread guide
and spreader thread guide C should be 1mm and the
eyelet of spreader thread guide C should be approximately
0.5mm left to the center line of the slot of spreader thread
guide B.
To make the above adjustment, loosen two screws D and
screw E and move each thread guide up or down, left or
right, or front or back as required.

11
7
77
7-
--
-3 Timing of the spreader
3 Timing of the spreader3 Timing of the spreader
3 Timing of the spreader
The timing of the spreader is factory-set by referring to
the previous procedure (see 7-2).
Adjust according to the thread to be used or other
conditions.
To make this adjustment,
1. Remove the top arm cover.
2. Loosen two screws for looper eccentric A on the
upper shaft.
3. Shift alignment mark C front or back while
referring to alignment mark B.
To advance the timing of the spreader to the needle, shift mark C in the direction of D.
To delay the timing of the spreader to the needle, shift mark C in the direction of E.
【8】FEED DOGS & STITCH LENGTH
8
88
8-
--
-1 Feed dog height & tilt
1 Feed dog height & tilt1 Feed dog height & tilt
1 Feed dog height & tilt
■Height
When the feed dogs are at the top of their stroke, the
feed dog teeth should be parallel with and 1.0~1.2mm
above the top surface of the needle plate.
To make this adjustment, loosen screw A and move the
main and differential feed dogs up or down.
■Tilt
Remove the cover from the rear side of the bed.
Loosen screw D from hole C with a 2.5mm hex.
Wrench.
When the feed dogs are at their top of their stroke, the
feed dogs should be parallel with the top surface of the
needle plate. Adjust by turning eccentric pin E with a
screwdriver.
< Note >
When turning the eccentric pin, tighten screw D with the
pin slightly touching feed bar B while checking that the
shaft is not shifted to the left.

12
8
88
8-
--
-2 Stitch length
2 Stitch length2 Stitch length
2 Stitch length
The stitch length is adjustable from 1.4 to 3.6mm as
follows
Stitch
length(mm) No. of stitches (within 1") No. of stitches (within 30mm)
3.6 7.0 8.0
2.4 10.5 12.5
1.4 18.0 21.0
■To adjust the stitch length
1. Press push button A lightly until its end touches the
inside part and clicks.
2. Turn the handwheel by hand while pressing the push
button lightly until the push button goes further into
the depth.
3. Then press down the push button strongly again.
Adjust the stitch length as required by turning the
handwheel.
4. Align the required stitch length with alignment mark
B. Then release the push button.
8
88
8-
--
-3 Differential feed
3 Differential feed3 Differential feed
3 Differential feed
■
Normal differential feed (to gather the fabric)
To make this adjustment, loosen nut A, move lever B up or
down and tighten nut A at the required position.
To obtain a feed ratio of 1:1, align lever B with reading C.
To obtain the normal differential feed, raise lever B above
reading C. To obtain a feed ratio of 1:2, set lever B at 2.
■Reverse differential feed (to stretch seam the fabric)
To obtain the reverse differential feed, lower lever B below
reading C. To obtain a feed ratio of 1:0.7, set lever B at
0.7. To adjust the differential feed ratio during sewing
Connect a chain, etc. to the lever. Set the upper and
lower limits with two stoppers (D). To adjust the
differential feed ratio during sewing, move lever B up or
down within this range and then set lever B at the
required position. The differential feed ratio varies
according to the stitch length. See the table below.
< Differential feed ratio >
Stitch length
(mm) Max. normal diff. feed Max. reverse diff. feed
3.6 1:1.2 1:0.7
2.5 1:1.6 1:0.7
2.0 1:1.8 1:0.7
1.4 1:2.0 1:0.7
< Note >
To adjust the stitch length, be sure to turn off the power
first.
< Note >
To use the machine with the normal differential feed, check to make sure the
feed dogs do not touch the needle plate.

13
【9】PRESSER FOOT
9
99
9-
--
-1 Presser foot pressure
1 Presser foot pressure1 Presser foot pressure
1 Presser foot pressure
The presser foot pressure should be as light as
possible, yet be sufficient to feed the fabric and
produce uniform stitches.
To increase the presser foot pressure, turn the
adjusting knob clockwise.
9
99
9-
--
-2 Position of the presser foot & foot lift
2 Position of the presser foot & foot lift2 Position of the presser foot & foot lift
2 Position of the presser foot & foot lift
Fit the presser foot onto the presser bar so that the
needle can drop correctly to the center of the presser
foot needle drop hole.
■Position of the presser foot
Loosen screw A.
Adjust by moving the presser foot left or right while
checking to make sure the needle drops correctly to
the center of the presser foot needle drop hole.
■Foot lift
For machines with the spreader, the presser foot
should be 6mm above the top surface of the needle
plate. Check to make sure presser foot does not
touch the spreader with the presser foot in the above
position. For machines without the spreader, the
presser foot should be 8mm above the top surface of
the needle plate. Set stopper B at the required
position. Fasten the presser foot lift lever with nut
C so that the lever cannot be lowered.

14
【10】STITCH FORMATION
10
1010
10-
--
-1 Position of the needle thread guides
1 Position of the needle thread guides1 Position of the needle thread guides
1 Position of the needle thread guides
The distance from the center of the eyelet of the
needle thread guide to that of the set screw should
be approximately 17.5mm (see the illustration).
Adjust the height of the thread guides by loosening
screws A and moving each thread guide up or down
(refer to the distances shown in the illustration).
If the stitch formation cannot be changed extremely
by adjusting the height of the thread guides because
of the thread to be used, unravel the thread after
test sewing and adjust the height of the thread
guides while checking the tension of the needle
thread.
10
1010
10-
--
-2 Position of the thread guide on the
2 Position of the thread guide on the2 Position of the thread guide on the
2 Position of the thread guide on the needle
needleneedle
needle thread take
thread takethread take
thread take-
--
-up
upup
up
When the needle bar is at the bottom of its stroke,
needle thread take-up bracket A should be level and
the distance from the center of the shaft to the
thread guide of needle thread take-up B should be
75mm.
To make this adjustment, loosen screws C and D.
To tighten the needle thread, move needle thread
take-up to Y.
To loosen the needle thread, move needle thread
take-up to X.
10
1010
10-
--
-3 Timing of the needle thread take
3 Timing of the needle thread take3 Timing of the needle thread take
3 Timing of the needle thread take-
--
-up
upup
up
The timing of the needle thread take-up in relation
to the up-and-down movement of the needles can be
adjusted. This timing is factory-set to synchronize
with the up-and-down movement of the needle bar.
< Note >
The rod ball is factory-set at 5.5mm from the rear end
of the shaft. To make the needle thread loop small,
move the rod ball to the front.
To make the needle thread loop large, move the rod
ball to the back. Remove the rubber top plug.
Loosen the screw of (A) with a 5mm wrench.
Then move the rod ball to the front or back.

15
10
1010
10-
--
-4 Position of the needle thread guard
4 Position of the needle thread guard4 Position of the needle thread guard
4 Position of the needle thread guard
When the needle bar is at the bottom of its stroke,
the center of the eyelet of thread guide A should be
level with the top surface of needle thread guard B.
In addition, A should be parallel with B.
To adjust the height of needle thread guard B,
loosen screw C and move needle thread guard B up
or down.
To tighten the needle thread, move up B.
To loosen the needle thread, move down B.
■For cotton threads (non-stretchable threads)
Bring the needle thread guard 2.0mm below the
standard, or remove it. Loosen screw C and move
down the needle thread guard.
■For woolly threads (stretchable threads)
Raise the needle thread guard as high as possible.
10
1010
10-
--
-5 Posi
5 Posi5 Posi
5 Position of the thread guide of the spreader thread take
tion of the thread guide of the spreader thread taketion of the thread guide of the spreader thread take
tion of the thread guide of the spreader thread take-
--
-up
upup
up
When the needle bar is at the top of its stroke,
thread any one of parts A, B and C on the spreader
thread take-up with the spreader thread.
■For woolly threads: Thread B or C.
■For cotton threads or spun threads
Thread A and adjust the spreader thread take-up
according to the thread or fabric to be used.
Adjust by moving up or down the spreader thread
take-up with screws D.
10
1010
10-
--
-6 Position of the thread guide of the looper thread take
6 Position of the thread guide of the looper thread take6 Position of the thread guide of the looper thread take
6 Position of the thread guide of the looper thread take-
--
-up
upup
up
The eyelets on thread guides B and C should be
aligned with mark X on thread guide A.
To increase the amount of the looper thread
supplied by the looper thread take-up, loosen screws
of thread guides B and C and move the thread
guides to the front. To decrease it, move the thread
guides to the back. Adjust according to the thread
and stitch length to be used.
For woolly threads, move thread guides B and C to
the front. Do not thread the tension disk.

16
10
1010
10-
--
-7 Position of the looper thread take
7 Position of the looper thread take7 Position of the looper thread take
7 Position of the looper thread take-
--
-up
upup
up
Thread guide D should be at the center of the groove of
looper thread take-up A. When the point of the left
needle has reached 0.5~1mm above the bottom surface of
the looper blade while the looper is moving from the
extreme left end of its travel, the looper thread should be
removed from position C on the looper thread take-up.
To make this adjustment, loosen screw B and adjust the
looper thread take-up. To adjust the height of thread
guide D, loosen screw E and then align the bottom of the
slot of thread guide D with the top surface of the bracket.
【11】EMK ELASTIC FEEDER
11
1111
11-
--
-1 To insert the lace/elastic
1 To insert the lace/elastic1 To insert the lace/elastic
1 To insert the lace/elastic
Insert the lace/elastic correctly by referring to the
illustration. The rollers are opened by pressing rubber
adjusting lever A.
11
1111
11-
--
-2 Lace/elastic guide on the presser foot
2 Lace/elastic guide on the presser foot2 Lace/elastic guide on the presser foot
2 Lace/elastic guide on the presser foot
Loosen screw A. Adjust the position of the tape guide
according to the needle space and/or width of the tape.
Adjust the position of upper knife guide B according to the
hem width cut by the knife. Install upper knife guide B
by tightening screw C while checking upper knife guide B
does not touch the knife.
11
1111
11-
--
-3 Adjusting the front of the presser foot
3 Adjusting the front of the presser foot3 Adjusting the front of the presser foot
3 Adjusting the front of the presser foot
Adjust the front of the presser foot according to the type of
fabric and/or elastic to be used.
To sew heavy weight elastic onto the fabric, raise the front
of the presser foot. This reduces resistance and feeds the
fabric smoothly. Loosen nut D and turn screw E as
required.

17
11
1111
11-
--
-4 To install the tape guide
4 To install the tape guide4 To install the tape guide
4 To install the tape guide
Install tape guide shaft A as close to the needle as possible,
but the machine must sew the fabric smoothly.
To adjust the tape guide, loosen screw B and turn eccentric
collar C clockwise or counterclockwise.
The eccentric collar serves as a stopper, so install the
eccentric collar properly so that it does not touch the needle
holder and spreader thread guide, etc.
11
1111
11-
--
-5 Feeding amount of the lace/elastic
5 Feeding amount of the lace/elastic5 Feeding amount of the lace/elastic
5 Feeding amount of the lace/elastic
To adjust the feeding amount of the lace / elastic, loosen
wing nut A and turn adjusting screw C while checking the
readings on lever B. To increase the amount, turn screw C
clockwise. To decrease the amount, turn screw C
counterclockwise. Adjustable from 0.9 to 2.3mm. Adjust
according to the fabric and/or elastic to be used. Adjust the
pressure of the elastic feed small roller (see 11-6)
simultaneously.
To increase the amount a little more, loosen two eccentric
set screws from hole D. Turn the handwheel all the way to
MAX with the wrench inserted until the handwheel stops
and then tighten the set screws. This increases the
adjustable range from 1.4 to 3.6mm.
11
1111
11-
--
-6 Pressure of the elastic feed s
6 Pressure of the elastic feed s6 Pressure of the elastic feed s
6 Pressure of the elastic feed small roller
mall rollermall roller
mall roller
To adjust the pressure of small roller A, loosen adjusting
nut B as required. To increase the pressure, turn
clockwise.
To decrease the pressure, turn counterclockwise.
Adjust the pressure according to the elastic to be used.
11
1111
11-
--
-7 Checking
7 Checking7 Checking
7 Checking the performance of the elastic feeder
the performance of the elastic feederthe performance of the elastic feeder
the performance of the elastic feeder
If the elastic feeder does not work well, it will not feed elastic uniformly, causing various
kinds of trouble such as burned elastic, jammed elastic, needle breakage, uneven sewing.
Check the following.
1. Adjust small roller A so that it can turn easily.
If it does not, the tape cannot be fed neatly.
2. The roller link and its shaft should move smoothly.
3. The small roller spring pressure should be as light as possible, yet be sufficient to
follow the roller speed.
< Note >
Decrease the pressure for stretchable lace elastic.
Increase the pressure for non-stretchable lace elastic.
