Kantech KT-200 User manual

Door Controller
•Two door controller
•Compatible with Proximity, Wiegand, Mag Stripe, Bar Code, Biometric and
other technologies
•Built-in power supply for door lock (24VDC)
•RS-485/RS-232 communication ports
•Supervised inputs (16)
•Optional relay module (REB-8)
•Quick terminal plug-in connectors
KT-200

Item # 23655
DN1533-0405
©2004 Kantech
Product specifications and availability subject to change without notice.
Certain product names mentioned herein may be trade names and/or
registered trademarks of other companies.
Tel: [phone] Fax: [phone]
Toll free: 1-888-KANTECH (1-888-526-8324)
www.kantech.com
Door Controller
Point Monitoring
Each KT-200 can monitor the state of 16 input points such as magnetic
contacts, motion detectors, temperature sensors or any other device with
dry contacts. To ensure line integrity, all zones are terminated with end-of-
line resistors.
Control Relays
Two control relays provided on each KT-200 can be used to activate
alarms or other devices such as lighting control, ventilation, and air
conditioning. These relays can be activated according to schedules, events
reported by the system, or a combination of different logical conditions.
System Configuration
The system configuration is determined by a choice of EPROMs available to
meet different systems and capacity requirements. As the system is
expanded, the KT-200 circuit board remains the same. This feature provides
flexibility and savings in the future.
Memory and Autonomy
All KT-200 controllers keep the access control database in memory. This means
that the KT-200 keeps all information regarding cards, schedules, access codes
and can verify access requests even when it is disconnected from the network
(autonomy varies for EntraPass Global Edition). The memory is also protected by
a lithium battery maintaining data even if the usual battery backup is
disconnected. Date and time are also maintained by this on-board battery.
Technical Specifications
AC power 24 volts AC, 75 VA, class 2
Battery back-up 2 gel type batteries 12V, 7Ah provide operation for 8 hours
Cabinet measurements 39.4cmH x 5cm W x 9.8cm D (15.5 in x 13.63 in x 3.88 in) EMT 1,25cm (1/2 in) and 1,9cm (3/4 in)
knockouts. Is supplied with a lock and two keys.
Weight 6kg (13.8 lbs)
Operating temperatures 2ºC to 40ºC (35ºF to 110ºF) at 90º non-condensing humidity
Processor Z80-6Mhz, with “watchdog” circuit
Reader technologies Proximity, Wiegand, magnetic, bar code, keypads and others
Reader maximum distance 150 meters (500 feet) from KT-200
PIN confirmation At each reader equipped with a keypad
Monitor points 16 monitor points, NO/NC, supervised by end-of-line resistors (included)
Points maximum wiring 600 meters (2000 ft) AWG#22
Door strike powerSupplied by the KT-200: 27 volts DC 250mA maximum
Auxiliary outputs 27 volts DC, 50mA open collector
Control relays 2 relays, 30 VDC/24VAC, 2A max. Possible expansion to 16 relays
Tamper switch Normally closed
Communications ports RS232 and RS485
Communications speeds From 1200 to 19200 bauds
Internal memory Maintained by lithium battery
Network autonomy Distributed data and processing
KT-200 Door Controller for 2 readers (complete)
KT-200BO Metal Box for KT-200 Controller
KT-200-CAMLO Keylock for KT-200 Controller (2 keys)
KT-200CSA Door Controllers for 2 readers (complete) - CSA approved
KT-200F-ACC Accessory kit (fuses, keys, end of line resistors, battery
leads) included in KT-200 and KT-200NB (Rev A to F)
KT-200G-ACC Accessory kit (keys, end of line resistors, battery leads)
included in KT-200 and KT-200NB (Rev G)
KT-200NB Door Controller for 2 readers (complete, no box)
REB-8 Relay expansion board
EP-ENTRA3 EPROM for EntraPass Special, Corporate, and Global
(Windows NCC) Edition (one per KT-200 required)
EP-8002 EPROM for EntraPass Global using DOS NCC
(one per KT-200 required)
TR2475 Transformer (110V/75VA)
REB-8 relay
expansion board
Easily Expandable
The REB-8 relay expansion board
provides an additional 8 general
purpose control relays to the KT-200
door controller. Two REB-8 boards
can be used to expand up to 16
relays and can also be used as a
cost-efficient alternative for basic
elevator control, with up to 16 floors
per cab. Used with the EntraPass
system, the REB-8 is connected
instead of a keypad on door 2 inputs.
Ordering Information:
KT-200
