Kaon KSF-A3200HR User manual

ENGLISH
ENG - 1
Please read the entire manual thoroughly
and retain it for future reference.
User’s Manual
Digital Satellite Receiver
A_ENG_110944

ENGLISH
2 - ENG
• Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment.
• Unplug the receiver from the AC power outlet before cleaning.
• Use only a damp cloth for cleaning the exterior of the receiver.
• Do not use accessories or attachments not recommended by the receiver manufacturer as they may
cause problems to the equipment and will void the warranty.
• Do not place the receiver on an unstable cart, stand, tripod, bracket, or table.
• The receiver may fall, causing serious personal injury and damage to the receiver.
• Do not block or cover the slot opening in the receiver.
• These are provided for ventilation and protection from overheating.
• Never place the receiver near or over a radiator or any heat source.
• Do not place the receiver in an enclosure such as a cabinet without proper ventilation.
• Do not stack the receiver on top of or below other electronic devices.
• The apparatus shall not be exposed to dripping or splashing and with no object filled with liquids, such as
vases, shall be placed on the apparatus.
• Operate the receiver using only the type of power source indicated on the marking label.
• Unplug the receiver power cord by gripping the power plug, not the cord.
• Route power supply cord so that are not likely to be walked on or pinched by items placed upon or
against them. Pay particular attention to the cords that plugs in the convenience receptacles, and the
point where they exit from the unit.
• Use an outlet that contains surge suppression or ground fault protection.
• For added protection during a lightning storm, or when the receiver is left unattached and unused for
long periods of time, unplug it from the wall outlet and disconnect the lines between the receiver and the
antenna. This will provide some protection against electrical damage caused by lightning or power line
surges.
• The mains plug is used as the disconnect device. The disconnect device shall remain readily operable.
Servicing
• Do not attempt to service the receiver yourself, as opening or removing covers may expose you to
dangerous voltage, and will void warranty.
Refer all servicing to authorized service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : To reduce the risk of electrical shock,
do not remove the cover. No user serviceable parts inside.
Refer any servicing to qualified Service personnel.
Warning
General Safety

ENGLISH
ENG - 3
Made by Kaonmedia
1. STANDBY
Switches the receiver to Standby Mode or Operation
Mode
2. VOL
◄ / ►
Press to adjust the volume or select a menu item.
3. CH
▲ / ▼ ( Program ▲ / ▼ )
Channel Up/Down or select item of sub-menu.
4. OK
To select a program, a highlighted line or parameter
value.
5. MENU To see main menu.
6. EXIT Exit from parameter and cancel selected
function.
7. SEG. DISP.
4-digit 7-segment display channel information.
8. USB Port
Connect the USB memory with USB cable.
1. LOOP THROUGH
Loop through Signal O/P to connect to other STB
using co-axial cable.
2. LNB
To connect to a satellite antenna and cable jacks.
3. RS-232
To connect to a personal computer for software
upgrade.
4. HDMI
Use the HDMI cable to connect this jack to the HDMI
jack on your television for the best quality picture.
5. 0/12V
Depending on the user’s antenna switch box, you can
choose either 0V/12V.
6. VIDEO
Video connection port to the TV or other equipment.
7. AUDIO
Audio connection port to the TV or other equipment.
8. TV
TV OUT To connect a TV via a coaxial cable.
9. POWER Supply
90 ~ 250V AC, 50/60Hz.
Front Panel
Note
The design of the Front/Rear Panel may be changed without any notice in advance.
Rear Panel
1
2
2
1
42
7
5
3
6
546
7
8
3 8
9
3

ENGLISH
4 - ENG
Note
1. When inserting batteries, make sure that the polarity (+/-) is correct.
2. The design of the Remote Control Unit may be changed without any notice in advance.
1 MUTE To enable or disable audio.
2 STAND BY To switch between operation and stand by mode.
3 NUMERIC BUTTONS To select the channel by entering channel number OR for entering PIN code.
4 TV/STB To switch between TV and STB mode.
5 TV/RADIO To switch between TV and Radio.
6 EXIT To return the normal viewing mode from a menu.
7MULT VIEW Multi video pop-up window will appear.
8 MENU To display the Main Menu on the screen or return to the previous menu.
9 RECORDED LIST To open the recorded list screen.
10 Left/Right To move left or right on the menu.
To increase or decrease the volume.
Up/Down To move up or down on the menu.
11 OK To confirm your choice.
12 CHANNEL Up/Down To change channel up and down.
13 VOLUME Up/Down To increase or decrease the volume.
14 REW Used for rewinding.
15 FF Used for fast-forwarding.
16 Play Used for playing files.
17 Pause Used for pausing files.
18 Quick Replay To go to the previous screen.
19 Quick Forward To go to the next screen.
20 Record Saves the current channel to the external HDD.
21 Stop Used for stopping record or play.
22 SUB-T(RED) To enable or disable subtitle or change the channel list mode.
23 INFO(BLUE) To display the information box on the screen.
24 SORT(GREEN) To sort channel list.
25 TIMER(YELLOW) To set Timer function.
26 P.STD To change picture standard. (Option)
27 SLEEP To select a present time interval for automatic shut off.
28 RECALL To return to the previous channel.
29 AUDIO To select the sound mode.(Mono, Left, Right, Stereo)
30 P.SIZE To change screen size.
31 TEXT To see the teletext by OSD. (Option)
32 EPG To display the TV/RADIO program guide.
Remote Control
MUTE
NUMERIC BUTTON
TV/STB
EXIT
CH Up/Down
STAND BY
MULT VIEW
RECORDED LIST
OK
TV/RADIO
MENU
Left/Right/Up/Down
VOL Up/Down
REW FF
15
Quick Replay
Record Stop
SUB-T(RED) INFO(BLUE)
SORT(GREEN) TIMER(YELLOW)
P.STD
P.SIZE
EPG
SLEEP
RECALL AUDIO
TEXT
Play
Quick Forward
19
1
3
4
6
8
10
12
14
2
5
7
9
11
13
Pause
17
18
20 21
22 23
24 25
26
30
32
27
28 29
31
16

ENGLISH
ENG - 5
Connection
Menu Application
Press the MENU button on the remote control unit. You will see the Main Menu on the screen.
1. Press the ▲/▼/◄/► buttons to move to sub menu.
2. Press the
OK button to select or confirm menu.
3. Press the
MENU button to return to previous menu.
4. Press the EXIT button to quit the menu.
1. To Connect Satellite Antenna LNB cable (Diseqc 1.0 /Diseqc 1.2)
Connect the Satellite antenna cable to LNB IN.
2. Loop Through
Connect co-axial cable to the Loop Through on the STB to give signal
to other STB.
3. RS-232
To Connect to PC for software upgrades.
4. 0V/12V
To connect to 0/12V switch.
5. To Connect TV/VCR
Connect RCA cable to the receiver.
6. To connect a external hard disk drive (HDD) for PVR
Connect a external USB hard disk drive (HDD) to USB.
Easy Installation
You will see only Easy Installation menu at first when you plug in your
system.
The Easy Installation gives you the convenience of selecting the language
(Menu, Subtitle & Audio), setting the local time & channel search.
1. Language – Menu, Subtitle & Audio
This option allows you to set the desired language for Menu,
Subtitle & Audio.
2. Local Time Setting
You can set your local time according to your location.
Choose either GMT or your local area time to your preference.
♦ To set the GMT
Select the GMT Usage “ On .”
At the GMT Offset, press ◄/► buttons to change the time by
30-minute interval.
Note
To set the Summer Time, select “On”.
♦ To set the Local Time
Select the GMT Usage “ Off ”
To set the Date and Time, press NUMERIC button to select year,
month, day and time.
3. Auto Scan
Select the satellite you want using the ▲/▼ buttons on the satellite
list.
Pressing RED button, you can see channel search window.
Note
If auto DiSEq is offered, it will be automatically adjusted.
Note
The design of the Rear Panel may be
changed without any notice in advance.
Made by Kaonmedia

ENGLISH
6 - ENG
Easy Installation
Press the MENU button.
Press the ▲/▼ buttons to select the desired item on the basic
setting screen.
1. Satellite List
 Edit : Press the RED button, you can edit satellite name and
satellite longitude.
 Add : Press the GREEN button, you can enter add satellite
menu.

Delete : Press the YELLOW button, you can delete satellite.

Antenna Setup : Press the BLUE button to select Antenna Set up.
 Satellite Search : Press TEXT button to select Satellite Search.
2. Antenna Setup
You can select Fixed Antenna or Motor Antenna in connection type.
 Fixed Antenna :You can set the LNB Freq. , DiSEqC1.0 , 22K , 0/12V , Toneburst , LNB Power .
• LNB Freq. : Select the proper LNB frequency referring to your LNB.
• DiSEqC : You can select and use appropriate port for your DiSEqC switch box.
•
22KHz : Depending on the user's antenna switch box or LNB.
You can supply either 22KHz by setting ON or OFF .
When selecting the U-LNB 1 and U-LNB 2, the 22KHz will be dimmed.
(MOTOR DiSEqC 1,2).
• 0V/12V : Depending on the user's antenna switch box. You can choose either 0V/12V.
• Tone Burst : Depending on the user's antenna switch box.
•
LNB Power : Select the LNB Power On or OFF .
 Motor Antenna : You can set the LNB Type , Motor Type , Local Longitude , Local Latitude , Delete All ,
Motor Setting , Limit Setup .
•
LNB Type : You can set the LNB Type .
• Motor Type : Select the DiSEqC1.2 or USALS.
• Local Longitude (USALS) : Press the NUMERIC buttons and enter the Longitude.
When the
OK button is pressed. It can be toggled East/West.
• Latitude (USALS) : Press the NUMERIC button and enter the Latitude.
When the OK is pressed, it can be toggled North/South.
• Delete All : The reset option is available at the Motor Antenna menu.
• Motor Setting/Limit Setup : You can set the east/west limit by current position.
After the Degree, Longitude and Latitude is entered accurately, the
DiSEqC Motor will automatically move to the satellite’s position.
3. Satellite Search
If you want to search the channel, you select Satellite .
You can set FTA Only , Scan Channel , Network Search , Scan Mode items.
Moving the Search item and press OK button to start scanning.
•
Search type : Select the FTA +Scrambled, FTA or Scrambled .
•
Scan Channel : Select the Radio, TV + Radio, or TV Channel .
•
Network Search : You can select Yes or No . When you select Yes , you can find more transponders
using the home network.
•
Scan Mode : Select the Auto Scan or Preset Scan .
4. TP Search
Pressing ◄ or ► buttons, you can switch satellite.
 Edit : Press the RED button. Set frequency, Symbol rate and Polarity at the Edit TP .

Add : Press the GREEN button. Set frequency, Symbol rate and Polarity at the Add TP.
 Delete : Press the YELLOW button, you can delete TP.
 Search : Press BLUE button to select TP Search .

ENGLISH
ENG - 7
Basic Function
Edit Channel
1. Program Information Banner
After the television channels have been programmed, you will see the information box each time
you change the channels.
From these menus, Press the Color buttons to you can edit
FAV(favorite) lists, lock, sort, skip, Rename, Move, or Delete channel.
1. TV/Radio Channel List
You can edit favorite TV and Radio list.
 Favorite Channel
You can edit favorite TV and Radio list.
 Lock Channel
From here you can lock channels in any of the list in order to
prevent (e.g. your children from watching.)
Sort Channel
From here you can sort channels to name order or FTA.
Skip
Channel
You can skip TV or Radio channel from the current list.
Rename
Channel
You can change the name of channel you want.
Move
Channel
You can change the position of the channel you want on the TV/Radio/All channel lists.
Delete
Channel
You can delete TV or Radio channel from the current list.
2. Delete All
You can delete all channel TV and Radio list.
2. Subtitle
When you press the RED button, you can see the subtitle window.
3. Teletext
When you press the TEXT button, you can see the telelext window.
4. Simple Channel List
When you press OK button during receiving service stream, you can get Simple Channel List view.
Using ▲/▼ buttons in Channel List view, you can choose another channel.

Find : Press the RED button. Press ▲/▼/◄/► and colored buttons to select the desired alphabet.
Press YELLOW button and it will show you the channel list according to each alphabet.
This function is to search the available channel in an easier and faster way.

Sort : Press the BLUE button. Press ▲/▼/◄/► button to select the desired channel.
This function is to more easily find or select the channel.
5. Timer
When you press the Yellow button, you can see the Timer window for STB.
6. Multi View
When you press the MULTI VIEW button, multi video pop-up window appears.
7. Recorded List
When you press the RECORDED LIST button, you can see the recorded list screen.
Note
In full screen, press BLUE button can open infomation
banner and infomation box, in the windows shows the
parameter of current channel.

ENGLISH
8 - ENG
If you want to customize the system to suit you better, you can specify
some settings from the submenus in the System Setting menu.
Note
At the System Menu list, press OK button and sub list will appear in a
pop-up window.
1. Menu Language / First Audio / Seconol Audio /
Teletext Language
In this menu You can change default language for menus, first
audio, second audio, subtitle, and teletext when changing services.
2. TV System
 STB with HDMI : You can set TVoutput, Video System(Resolution), Aspect Mode and Video output.
3. Local Time Setting
You can set your local time according to your location.
Choose either GMT or your local area time to your preference.
♦ To set the GMT
Select the GMT Usage “ On .”
At the GMT Offset, press ◄/► buttons to change the time by 30-minute interval.
Note: To set the Summer Time, select “On”.
♦ To set the Local Time
Select the GMT Usage “ Off ”
To set the Date and Time, press NUMERIC button to select year, month, day and time.
4. Timer Setting
You can setting between 8 timer item by pressing ▲or ▼buttons and press OK button.
You can select
Timer Mode (Off / Once/ Daily), Wakeup Channel , Wakeup Date , On Tim e, and
Duration item.
Note: This is not for PVR.
5. Parantal Lock
Enter Parental Lock item, there will pop an dialogue for you to input the password.
Default password is “0000”. This menu have below function.

Menu Lock : You will have to enter the PIN code every time when you enter the Menu.

Channel Lock : You may need PIN code every time you select the lock channel program as
you set in the channel control.

New Password : Input the current PIN code using NUMERIC buttons on the remote control.

Confirm Password : To verify the new PIN code, re-enter a new PIN code in the highlighted confirm
PIN code.
6. OSD Setting
 OSD Timeout : You can select for how long the OSD will be shown. (1~15seconds)
 OSD Transparency : Give the variable transparency on Video and OSD screen. (50%~100%)
7. Rename Favorite
In This menu, you can rename the favorite group’s name.
8. Other
 Multiview : Multi Video allows you to watch several channels in one screen simultaneously.
It can be used to watch one channel from among several channels.

Channel Chang : Select the Freeze or Black screen.
System Setup

ENGLISH
ENG - 9
1.
Information
Displays the system information: MODEL name, S/W, H/W, Loader version.
2.
Factory Reset
Use this option only if you have to start the complete installation procedure from scratch.
If you continue from here, all your previous settings and all channels will be cleared!
The default data will be loaded.
3.
USB Connection
1. Disconnect the power plug.
2. You can upgrade the product software or record by connecting External USB storage devices.
3. Connect the power plug of the receiver to an outlet.
4. Turn on the STB.
Tools
Playing back Files (MP3/Image)
Upgrade by USB
You can listen to MP3 music or see the image files by sliding type through USB connection.
Save MP3 and image files into USB from your PC.
1. Press the
MENU button.
2. Go to Tools in Menu.
3. Select
USB.
4. Press ▲/▼ buttons to select the desired folder (MP3 or Image).
5. RED button sorts all the MP3 files.
6. GREEN button sorts all the image files.
7. YELLOW button sorts all the S/W files.
8. BLUE Button sorts all the other software upgrade option files.
In the file list menu, press the
YELLOW button to sort the S/W file.
Navigate to the desired software & pressing OK software upgrade will
begin.

ENGLISH
10 - ENG
PVR - Recording and Playing back
Recording
Reservation Timer
Time Shift recording
Basic Function
Press the RECORD button to record the current broadcast programme.
When the recording starts the Record icon is displayed.
Note
To stop recording, press the STOP button.
You can set a programme to be recorded at a specific time. Even if
the receiver is in standby mode, it will switch into operation mode and
start recording at a specified time. When the recording comes to the
end, the receiver will switch back into standby mode again. However,
if you press any button on the remote control or on the front panel, the
receiver will not switch into standby mode.
1. Press the
OK button to display reservation timer screen.
2. Press the ▲/▼/◄/►/ OK button to record reservation.
This function is for setting the
Time Shift . If you set to ON, you can
use the Time Shift function.
- If the Time Shift is set while watching satellite broadcasting, press
the
REW button once to rewind the currently playing screen and the
PLAY/PAUSE button to pause.
- If you press the PLAY/PAUSE button, the screen will play back from
the point where it is stopped.
You must connect external hard disk drive (HDD) to this receiver to record or play back programme
by PVR function.
- USB HDD 2.0 support
- Range of Time Shift/Recording (in external HDD)
Disk free size Time shift size Recording size
below 200MB 0 0
200MB~700MB disk free size 0
700MB~10GB 500MB remain
10GB~20GB 1GB remain
20GB~40GB 2GB remain
40GB~80GB 4GB remain
More than 80GB 8GB remain
- Recording capacity: 1.7 GB per hour
Note: It differs depending on broadcasting.

ENGLISH
ENG - 11
Playing back
HDD Format
Fast Forward & Rewind
During Playback of recorded files we can use the Fast Forward &
Rewind function buttons in the RCU with 2X, 4X, 8X 16X & 24X
speed.
Slow Forward & Rewind
During Playback of recorded files we can use the Fast Forward &
Rewind function buttons in the RCU with 2X, 4X & 8X speed.
Quick Search
You can move to the desired location of a recorded file using the
banner.
• During Playback press the BLUE button in RCU to get the banner.
• Press ◄/► on buttons on RCU to navigate to the desired point on
the recorded file .
• Press
OK on the desired point to start playing at that point.
1. To format the HDD, press the ▲/▼ button on the Tools menu to
select
HDD Format and then press the OK button.
You can see the HDD Information (Recording free, Timeshift, Free,
Used, and Total).
2. When the format confirmation pop-up window appears, press the
OK button.
Record Manager
You can edit the recording list such as rename, lock, and delete.
•
Rename (Red button) : To change file names. Characters such as
0~9 and A~Z can be used.
• Delete (Blue button) : To delete a file.
•
Lock (Green button) : To set for entering a password when you
access files. They are then displayed as
“hidden files” in Microsoft Windows, after
the USB cable is connected.

ENGLISH
12 - ENG
Problem Solution
No display LED on the front panel.
No power supply
Power cord plug in correctly.
No Picture Ensure that the STB is switched on.
Check connection and correct.
Check channel and video output and correct
Poor picture quality Check the signal level, if this is low then try adjusting the alignment of your dish.
No Sound Check the volume level of the TV and STB.
Check the mute status of the TV and STB.
Check the connection of audio cord.
Remote Control does not operate Point remote control directly towards the receiver.
Check and replace batteries.
Check that nothing blocks the front panel.
Service is not running or scrambled Check the whether the Common Interface module and smart card is correctly
inserted.
Check that the smart card is appropriate for the selected service.
You have forgotten your secret PIN
code
Refer to Change PIN code of this owner's manual.
Troubleshooting
1. Record Manager
You can edit the recording list such as rename, lock, and delete.
2.
Reservation timer
You can set a programme to be recorded at a specific time.
3.
HDD Information
You can see external HDD information.
4.
HDD Format
You can format the external HDD.
5.
Timeshift
If you set to ON, you can use the Time Shift function.
REC
Game: Tetrix, Othello.
Game
