KSTB2100 User Installation Guide
4
WHAT’S IN THE BOX?
KSTB2100
Set-Top Box (STB)
Kaon Voice
Classic RCU
AA Batteries RCA Analog Composite
Breakout Cable
(Optional)
HDMI Cable Power Adapter

KSTB2100 User Installation Guide
5
SET-TOP BOX AT A GLANCE
Perspective View
Power Button
Used to power the Kaon STB
On or O󰀨.
Status Indicator LED
Indicates power status of STB
(Red = O󰀨, Green = On).
Infrared (IR) Sensor
Used to communicate with the
KURV Remote Control.
1 2
3
1
2
3

KSTB2100 User Installation Guide
6
Rear View
AV Out
SD Analog A/V output, used
to connect to older-style TVs
that do not support HDMI
connections. Ask your installer
for an RCA composite breakout
cable if one was not included.
RJ45
10/100 Ethernet port used to
connect to a home router.
HDMI
Digital A/V output, used to
connect to a TV via HDMI cable.
S/PDIF
Optical Audio output, used to
connect to external Sound bar or
Surround Sound system.
An optical cable with TOSLINK
connectors is required (not
included).
USB
This port has an output power
capability of 5V DC @ 1 amp.
12V/1.5A In
DC Power port, used to connect
via the power adapter.
4
5
6
7
8
9
4 5 6 7 8 9

KSTB2100 User Installation Guide
7
BUTTON FUNCTIONALITY
TV ON
TV/STB ON
Fast Backward
Play/Pause
Fast Forward
TV Guide
Live TV
OK
Up/Down/Left/Right
Return
Home
Google Assistant
Volume Up
Mute
Volume Down
CH UP
Last Channel Watched
CH Down
Menu
Device Input
Remote Set
Number Pad
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
3
6
10
13
14
15
20
22
9
2
4
8
12
19
5
7
16
17
18
21
11

KSTB2100 User Installation Guide
8
