Instruction Manual
TWS Bluetooth Earphones
P507076

A. Multifunctional Button
- Answer or end a call
- Reject a call
- Play or Pause
- Volume Up or Down
- Track Forward or Backward
B. Bluetooth Indicator
C. Microphone
D. USB Charging Port
E. Charging Case Button
L. Left (Slave)
R. Right (Master)
EN
A
D
C
L R
E
B
A. Multifunctional Button
- Answer or end a call
- Reject a call
- Play or Pause
- Volume Up or Down
- Track Forward or Backward
B. Bluetooth Indicator
C. Microphone
D. USB Charging Port
E. Charging Case Button
L. Left (Slave)
R. Right (Master)
EN

Safety Instructions
•Please read, follow and keep these
instructions.
•Heed all warnings on the product and in the
instructions for use.
•Stop using this product immediately if it
causes discomfort or pain. When using this
product, it is recommended that you limit the
volume to help avoid causing harm to your
ears and danger resulting from being unable
to hear what is going on around you.
•Keep the device out of extreme heat and
humidity.
•Do not use the device near water, such as
sinks, bathtubs, swimming pools, washing
machines, tubs of water, etc.
•Observe all signs and instructions that require
an electrical device or radio product to be
switched off in the designated areas, such as
petrol / refueling stations, hospitals, blasting
areas, potentially explosive atmospheres and
aircraft.
EN Earphones

•Using headphones while driving can distract
you and increase the likelihood of an accident.
If driving conditions demand it (such as bad
weather, high traffic density, presence of
children in the car, difficult road conditions),
pull off the road and park before making or
answering calls.
•Battery life may differ depending on personal
habits.
•This appliance should be used in moderate
climates.

Warning
• To prevent potential hearing damage, do not
listen at high volume levels for long periods.
• Do not turn the volume up too high; doctors
warn against prolonged exposure
to high volumes.
• Stop using the product or lower the volume
if you feel your ears ringing.
• Prolonged listening at high volume could
lead to hearing damage.
• Danger of explosion if battery is incorrectly
replaced. Replaced only with the same or
equivalent type.
• The batteries (battery pack or batteries
installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
• No naked flame sources, such as lighted
candles, should not be placed on the
apparatus.
• For ages 12 up. This is not a toy.
• IPX4 water proof is for earphone only, but
not for charging case.

Specificatio
Bluetooth Version: V 5.0 Battery for Earbuds: 45mAh x2, 3.7V
Bluetooth Chipset: BK3266 Charging Time: About 1.5 hours
Driver Unit
Water Proof:
6mm x 2
IPX4 (for earphone
only)
Battery for Charging
Case:
400mAh, 3.7V (3 times
recharge for charging
case)
Working Distance
Range:
10M Charging Time: About 2.5 hours
Frequency Range: 2.4000 - 2.4835GHz
Frequency Response: 20Hz - 20KHz Working Time: Up to 3 hours
Impedance: 32Ohm ± 15% at
1KHz (DC)
Standby Time: About 200 hours
Maximum Radio
Transmit Power:
< 10mW
Using the TWS Bluetooth Earphones
This guideline is provided to help you get started quickly with your wireless stereo earphones; please
read it carefully and save it for future reference.
What’s in the box
1. Bluetooth earphones
2. Charging Case
3. Instruction manual
4. XS / S / M / L Ear tips
5. USB charging cable
Power Supply
• We recommend that you fully charge the battery before using for the first time
• Put the earbuds into charging case for charging.
• Allow about 1.5 hours for a full charge of earbuds.
• Charging case blink white LED when charging, LED will be off when fully charged.
• Plug the Micro USB end of the supplied USB cable into the USB micro port charger connector of
charging case.
• Allow about 2.5 hours for a full charge of charging case. Charging case pulsing white LED when
charging, LED will be solid when fully charged.

Power On
Mode 1:
Open the charging case, the earbuds
will auto power on.
Power Off
Mode 1:
Put earbuds into charging case and close
the lid, the earbuds will auto power off.
Mode 2:
Press and hold L&R buttons for 3s while
the earbuds are out of the charging case.
Mode 2:
Press and hold L&R buttons for 3s while
the earbuds are out of the charging case.
Mode 3:
Pairing beyond 5 mins, earbud will power off.
Mode 4:
Earbuds pairing with device; No connection beyond 5 mins,
TWS will auto power off.
L&R buttons
L&R buttons
Power On
Mode 1:
Open the charging case, the earbuds will
auto power on.
Mode 2:
Press and hold L&R buttons for 3s while the
earbuds are out of the charging case.
Power Off
Mode 1:
Put earbuds into charging case and close
the lid, the earbuds will auto power off.
Mode 2:
Press and hold L&R buttons for 3s while the
earbuds are out of the charging case.
Mode 3:
L & R Pairing with each other beyond 5 mins, earbuds will power off.
Mode 4:
Earbuds paring with device, no connection beyond 5 mins, TWS will auto power off.

Bluetooth Connection
1. Activate the Bluetooth feature function on your native device to begin set-up.
2. The “Search new device” screen will be displayed.
3. Place both devices no more than 3 feet away from each other.
4. Open the charging case, the earbuds will auto power on and pair with each other. After earbuds
pairing with each other successfully (There’s a warning tune “connected”, the LED of master side (R)
starts blinking red/blue light alternately.
5. As soon as the system detects the new device in your dialog box, select the icon that reads “Kappa
P507076”, there’s a warning tune “You device is connected” when connect successfully.
6. For second use, it will connect previous device automatically
Music
Functions L R
Play Short press (each side is OK)
Pause Short press (each side is OK)
Volume + - - - Double Click
Volume - Double Click - - -
Previous Track Press and hold for 2s - - -
Next Track - - - Press and hold for 2s
Voice On Triple Click (each side is OK)
Voice Off Triple Click (each side is OK)
Phone Call
Functions L R
Answer Call Short press (each side is OK)
Reject Call Press and hold for 2s (L/R each side is OK)
End Call Short press (each side is OK)
Switch between
earbuds / device Press and hold for 2s (L/R each side is OK)
Mute On - - - Double Click
Mute Off - - - Double Click

LED Lights Indication
Earbuds LED
Mode 1 Power On LED solid blue 2s
Mode 2 Power Off LED blink solid red once
Mode 3 Pairing Mode LED lights blink red/blue
Mode 4 Connect Mode LED lights slow-blink blue
Mode 5 Reset Mode LED blink blue 3 times, then LED solid red once
Charging Case LED
Mode 1 Charging Case Charging Earbuds LED pulsing white
Mode 2 Earbuds fully charged LED goes off
Mode 3 Charging the charging case LED lights slow-blink white
Mode 4 Charging case fully charged LED solid white
Charging Case Battery Indication
Short press charging case button
75% - 100% battery White LED flash 4 time
50% - 75% battery White LED flash 3 time
25% - 50% battery White LED flash twic
Below 25% battery White LED off
FAQ
1. Single side connect with earbuds, need to switch to both sides.
2. Under shutdown status, press and hold both buttons for 10S(L/R, both sides), LED flash blue 3
times, LED Flash red once, earbuds will power off.
3. Put earbuds into charging case, press and hold charging case button for 6S to reset earbuds. L/R
LED flash blue th ee times, LED flash ed once and power off.

Declaration of Conformity
TCC hereby declares that the radio equipment type P507076 is in compliance with
Directive 7014/5 J/EU. The full text of the EU declaration of conformity is available at
the following internet address upon request. http://www.tccgIobal.com/en/contact
TCC Global N.V.
Zuidplein 84, 1077 XV Amsterdam, The Netherlands
Disposal of your old product
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
Attention should be drawn to the environment aspects of battery disposal.
Processing of electric and electronic equipment at the end of their service life is
applicable to all in member counties of the European Union and other European
countries operating a selective waste collection system. This symbol, affixed to th
product or its packaging, indicates that the product must not be processed with
household waste. It must be brought to an electric and electronic waste collection point
for recycling and disposal. By ensuring the appropriate disposal of this product you also
help in preventing potentially negative consequences for the environment and human
health. The recycling of materials helps preserve our natural resources. For further
information regarding the recycling of this product, please contact your municipality,
local waste disposal centre of the shop where the product was purchased.
This symbol means that the product contains a built-in rechargeable battery covered by
European Directive 2013/56/EU which cannot be disposed of with normal household
waste. We strongly advise you to take your product to an official c lection point to
have a professional remove the rechargeable battery.
Inform yourself about the local separate collection system for electrical and electronic
products and rechargeable batteries. Follow local rules and never dispose of the
product or rechargeable batteries with the normal household waste. Correct disposal of
old products and rechargeable batteries helps prevent negative consequences for the
environment and human health.

A. Multifunctional Button
- Answer or end a call
- Reject a call
- Play or Pause
- Volume Up or Down
- Track Forward or Backward
B. Bluetooth Indicator
C. Microphone
D. USB Charging Port
E. Charging Case Button
L. Left (Slave)
R. Right (Master)
EN
A
D
C
L R
E
B
A. 多功能按鈕
-接聽或結束通話
-拒絕來電
-播放或暫停
-調高或調低音量
-上一首或下一首音樂
B. 藍牙指示燈
C. 擴音器
D. 供充電的USB埠
E. 充電盒按鈕
L. 左(Slave)
R. 右(Master)
CN

安全說明
•請閱讀、遵循並保留以下說明。
•注意產品和使用說明中的所有警
告。
•如果引起不適或疼痛，請立即停止
使用本產品。使用本產品時，建議
限制音量，以免聽力受損及避免因
無法感知周圍情況而發生的危險。
•遠離極高溫和潮濕的環境。
•請勿在水附近使用本產品，例如水
槽、浴缸、游泳池、洗衣機、水桶
等。
•請遵守所有在指定區域（例如：加
油站、醫院、爆破區域、潛在爆炸
環境和飛機）關閉電子設備或無線
電產品的標誌和說明。
CN 耳機

• 駕駛時使用耳機會分散您的注意
力，並增加發生事故的機會。如
果駕駛時需要使用本產品（例
如：惡劣天氣、多車路段、車上
有小孩、路況困難），請在撥打
或接聽電話前駛離路段並停車。
• 電池壽命或因個人使用習慣而
異。
• 本產品應在溫和氣候下使用。

警告
• 為避免對聽力可能造成的損害，請
勿長時間以高音量聆聽。
• 請勿將音量調得太高；醫生警告不
要長時間以高音量聆聽。
• 如果出現耳鳴，請停止使用
• 本產品或調低音量。
• 長時間高音量收聽可能會導致聽
力受損。
• 錯誤更換電池或有爆炸的危險。只
可更換相同或等效的電池。
• 電池（電池組或已安裝的電池）不
得暴露在過熱的環境中，例如日
光、火或類似環境。
• 請勿在本產品上放置明火，例如點
燃的蠟燭。
• 供12歲以上人士使用。本產品不是
玩具。
• 只有耳機具有IPX4防水規格。充電
盒並不防水。

產品規格
藍牙版本 V 5.0 耳機電池： 45mAh x2, 3.7V
藍牙晶片： BK3266 充電時間： 約1.5小時
驅動單體
防水：
6mm x 2
IPX4 (耳機) 充電盒電池： 400mAh, 3.7V (可
充電3次)
可使用範圍： 10M 充電時間： 約2.5小時
頻率範圍： 2.4000 - 2.4835GHz
頻率回應範圍： 20Hz - 20KHz 使用時間： 可達3小時
阻抗： 32Ohm ± 15% at
1KHz (DC)
待機時間： 約200小時
最大
輸出功率
< 10mW
使用TWS藍牙耳機
本指南可幫助您快速開始使用TWS耳機。請仔細閱讀並妥善保存以備日後參考查閱。
配件
1. 藍牙耳機
2. 充電盒
3. 使用說明書
4. XS/S/M/L耳膠
5. USB充電線
供電
• 我們建議，在首次使用前，將電池充滿電。
• 將耳機放進充電盒充電。
• 耳機完整充電週期大約為1.5小時。
• 充電時，充電盒的LED白燈會閃爍，充滿電後LED燈會熄滅。
• 將隨附的USB線的Micro USB一端插入充電盒的Micro USB端口。
• 耳機完整充電週期大約為2.5小時。充電時，充電盒的LED白燈會閃爍，充滿電後
LED燈會亮起。

Power On
Mode 1:
Open the charging case, the earbuds
will auto power on.
Power Off
Mode 1:
Put earbuds into charging case and close
the lid, the earbuds will auto power off.
Mode 2:
Press and hold L&R buttons for 3s while
the earbuds are out of the charging case.
Mode 2:
Press and hold L&R buttons for 3s while
the earbuds are out of the charging case.
Mode 3:
Pairing beyond 5 mins, earbud will power off.
Mode 4:
Earbuds pairing with device; No connection beyond 5 mins,
TWS will auto power off.
L及R按鈕
L及R按鈕
打開電源
模式1：
打開充電盒，耳機電源會自動打開。
模式2：
從充電盒中取出耳機，按住L及R按
鈕3秒鐘。
關閉電源
模式1：
將耳機放入充電盒並合上蓋子，耳機
電源會自動關閉。
模式2：
耳機不在充電盒時，按住L及R按
鈕3秒。
模式3：
左右耳機配對超過5分鐘後，耳機電源會關閉。
模式4：
耳機與設備配對； 5分鐘後若沒有連接， TWS 電源會自動關閉。

藍牙無線連接
1. 開啟您的裝置上的藍牙功能，開始設置。
2. 屏幕會顯示「搜索新設備」。
3. 兩個設備的距離不要超過3呎。
4. 打開充電盒，耳機電源會自動打開，並配對裝置。耳機成功配對後（會出現
「Connected」（「已連接」）提示音，主機側（R）的LED燈會開始紅/藍交替閃爍。
5. 系統檢測到新設備後，在對話框中選擇顯示為「Kappa P507076」的圖示，連接成功
後，會出現「Your device is connected」 （「您的設備已連接」）提示音。
6. 第二次使用時，耳機會自動連接用過的設備。
音樂
功能 L R
播放 短按一下（兩邊都可以）
暫停 短按一下（兩邊都可以）
調高音量 - - - 快速按兩下
調低音量 快速按兩下 - - -
上一首音樂 按住2秒 - - -
下一首音樂 - - - 按住2秒
開啟擴音 快速按三下（兩邊都可以）
關閉擴音 快速按三下（兩邊都可以）
通話
功能 L R
接聽來電 短按一下（兩邊都可以）
拒絕來電 按住2秒（左右兩邊都可以）
結束通話 短按一下（兩邊都可以）
耳機/裝置
切換 按住2秒（左右兩邊都可以）
開啟靜音 - - - 快速按兩下
關閉靜音 - - - 快速按兩下

LED指示燈
耳機LED燈
模式1： 打開電源 LED藍燈亮起2秒
模式2： 關閉電源 LED紅燈常亮1次
模式3： 配對模式 LED紅藍燈交替閃爍
模式4： 連接模式 LED藍燈緩慢閃爍
模式5： 重設模式 LED藍燈閃爍3次，紅燈常亮1次
充電盒LED
模式1： 耳機正透過充電盒充電 LED白燈閃爍
模式2： 耳機已充滿電 LED燈熄滅
模式3： 充電盒正在充電 LED白燈緩慢閃爍
模式4： 充電盒已充滿電 LED白燈常亮
充電盒電池指示燈
短按充電盒按鈕一下
75% - 100%電量 LED白燈閃爍4次
50% - 75%電量 LED白燈閃爍3次
25% - 50%電量 LED白燈閃爍2次
25% 以下電量 LED白燈熄滅
常見問題
1. 單邊連接耳機，需要切換到兩邊連接。
2. 在關機狀態下，按住兩個按鈕10秒（左/右兩邊），LED藍燈閃爍3次，然後紅燈閃爍1
次，耳機將關閉電源。
3. 將耳機放入充電盒，按住充電盒按鈕6秒，以重設耳機。左/右 LED藍燈閃爍3次，紅燈
閃爍1次，然後關閉電源。

符合標準聲明
TCC在此聲明，無線電設備P507076符合指令 7014/5 J/EU要求。歐盟符
合性聲明全文可於以下網址獲得。 http://www.tccgIobal.com/en/
contact
TCC Global N.V.
Zuidplein 84, 1077 XV Amsterdam, The Netherlands
處理廢棄產品
您的產品採用高品質的材料和組件設計和製造，可以回收再用。
電池處理應考慮環境因素。
電機電子設備使用期限屆滿時的處理準則適用於歐盟和所有進行垃圾分
類處理的歐洲國家。
產品或產品包裝上貼有此標誌，表示不得將該產品當作家居廢物處理，而
必須帶到電機電子廢物收集點回收處理。適當處理該產品，能協助我們防
止產品對環境和人類健康構成負面影響。回收產品素材有助於保護我們的
自然資源。有關回收此產品的更多信息，請聯繫您所在城市的市政部門，或
產品銷售點當地的廢物處理中心。
此標誌表示產品包含歐盟指令2013/56 / EU涵蓋的內置可充電電池，不能
與普通家居廢物一起處理。我們強烈建議您將產品帶到官方回收點，讓專
業人士卸下充電電池。
請熟讀當地有關電機電子產品和可充電電池的垃圾分類處理準則。請遵守
當地法規，切勿將產品或可充電電池與普通的家庭垃圾共同處理。正確處
理舊產品和可充電電池能防止產品對環境和人類健康構成負面影響。

A. Multifunctional Button
- Answer or end a call
- Reject a call
- Play or Pause
- Volume Up or Down
- Track Forward or Backward
B. Bluetooth Indicator
C. Microphone
D. USB Charging Port
E. Charging Case Button
L. Left (Slave)
R. Right (Master)
EN
A
D
C
L R
E
B
A. Multifunkční tlačítko
- Přijmout nebo ukončit hovor
- Odmítnout hovor
- Hrát nebo pozastavit
- Zvýšení nebo snížení hlasitosti
- Skladba vpřed nebo vzad
B. Bluetooth kontrolka
C. Mikrofon
D. Nabíjecí port USB
E. Tlačítko nabíjecího pouzdra
L. Levý (podřízený)
R. Pravý (hlavní)
CZ
