Karat 20632T-S User manual

BEFORE YOU BEGIN
-1-
!please carefully read this installation instruction in order to
ensure proper care and assembly of this accessory.
!Please keep this installation instruction for future
reference.
Prior to drilling into walls, check there are no hidden
electrical wires, cables or water supply pipes with the
aid of ar, electronic detector. If you use power tools do
not forget:
1. Wear eye protection.
2. Unplug equipment after use.
1.
2.
!
!
TOOLS AND ACCESSORIES
Leveling Instrument Tape
Screw Driver
Drill Hammer
Anchor x 2
2
Screw x 2
2
ROUGHING-IN
Unit: mm
:
Reference Value
Our company reserves the right to change marked dimensions without prior notice.
MULTI-FUNCTION PAPER HOLDER
20632T-S
20160902

-2-
INSTALLATION
1. Put the product into the drilled wall. Mark 2 holes on the
wall. Drll holes .
1.
3. Insert anchors into wall. Put the tissue box in place and
tighten the screws.
3.
2. Drill 35~40mm holes on the wall with 6mm drill bit.
2. 6mm 35~40mm
4. Put tissues into the paper holder . 4.

-3-
1. Clean the product daily with cotton cloth.
Do not use abrasive materials.
2. Do not use strong chemical detergents such as strong acid,
strong alkali or phosphoric acid.
3. Avoid scratching product surface with sharp objects.
1.
2.
3.
CARING FOR YOUR PRODUCTS
Our company provides one years warranty for its drain. Our
company will at its election, repair, replace or make
appropriate adjustment where our company inspection
discloses any such defects occurring in normal usage within
warranty.
The warranty, including products, is limited clearly. Our
company is not responsible for other damages appeared after
the warranty. Also, the warranty dose not cover problems
arising from labor charges, incorrect use and installation.
Shanghai Kohler International Trade Co., Ltd.
Address: Room 324, 2 Xinlin Rd, Waigaoqiao Free
Trade Zone, Shanghai
Tel: [phone]
Postcode: 200131

1265681
Plastic anchor
6ÖX35mm
MULTI-FUNCTION PAPER HOLDER
20632T-S
1299542
Slide bar
1299543
Panel
1299541
Bracket assy
1299540
Escutcheon
1265673
Screw
4X35mmÖ
