Kariba Xtreme Nomad User manual

Kariba - Xtreme Nomad – Duel Gas
Adventure Water Heater Systems
(For Outdoor Use Only)
GERNERAL INFORMATION
_____________________________________________________________________________________________________________________
Kariba – Xtreme Nomad Adventure Water Heater System
This unique gas appliance is the ultimate choice for water heating systems available to extreme
expeditioners. The Xtreme Nomad is small and light in weight, featuring robust designed with duel
gas options. Twin high pressure gas burners are fitted to deliver a smooth controlled rising of water
temperature ranging from 5 to 60 degrees centigrade. All auxiliary connections are “Plug & Play”, and
the appliance can be operated upright as standard, hung from a tree or a roof rack of a vehicle, or
fitted onto a camper door for example. This appliance is supplied standard with all hoses, shower
head and connectors, complete with an optional 4.2L p/m pump fitted, including a 12V DC power lead.

2.
Duel Gas – Twin Burner: Manual Control Operation
The Kariba-Xtreme Nomad is designed and manufactured to be independently used as an outdoor
shower and ablution facility. This mobile water heater can be used just about anywhere or be
fitted onto an off-road camper/trailer/4 4 vehicle. This appliance is built tough to withstand the
endurance demanded of off-road adventures, and is packaged in a strong “High Lid” Ammo Bo
for protection during transport in rugged terrain. NO fancy components or unnecessary parts
are fitted to the appliance such as “Prevention Featured Components” incorporated in household
gas operated water heaters that can cease to operate in remote places where NO help available.
The unique feature is the twin high pressure burners that can be operated independently. These
burners are powered by EN417 screw on butane propane mi gas canisters, or alternatively by LP
Gas from a gas bottle. Travelers are assured of a continuous supply of gas, by stocking gas
canisters for emergency use, and not restricted by the various technical standards of filling gas
bottles in foreign countries. Gas consumption during average use is 250 grams per hour, but
can increase to a ma imum of 400 grams per hour if used to its ma imum capacity. This water
heater works when you need it to, but simple user friendly rules apply for operating this system.
The Kariba-Xtreme Nomad is safe for use by adults, including minors under supervision when
used in accordance with the instructions. As this appliance is powered by gas, responsible
operation is recommended.
How the Kariba-Xtreme Nomad works:
Refer to setting up the system as shown on the “Set-up Drawing” on page 3. This water heater
has been designed to be user friendly with all the au iliary equipment made for simple user
friendly “Plug & Play” application in order to operate it. When making use of this appliance, in
the first instance attach the supplied equipment to the control panel. Then screw the EN417 gas
canister/s (not supplied) into the burner/s gas inlet and/or the LP Gas hose (supplied) which
must also be attached to the gas bottle. The 12V DC power cord must be pluged into a vehicle
cigarette lighter socket of a motor vehicle alternatively to another 12V DC power supply. No
pump operation is required if cold water from a tap is sourced, but when water from a
container/tank is sourced, the power to the internal pump must be switched on to deliver water
flow from the siphon hose which can be connected to the cold water inlet located on the left side
of the appliance. Cold water flows through the heat e changer, and which raises the water
temperature to the showerhead when the gas flame is ignited. By pressing the electronic
“Push Button” flame ignition located on the center of the control panel, this delivers sparks
sent from the ignition generator to the gas burners to ignite the gas burner flame. The twin gas
control valves determine the flame height for power delivered to the heat e changer. To ignite
the flame, in the first instant water must be flowing through the heat e changer to the
showerhead Open the gas control knob to burner No. 1 by tuning it two to three full turn.
Press the flame ignition a few times to insure the flame is lit, then open the gas control knob to
burner No. 1 by tuning it two more full turns. The energy of the flame passes through the heat
e changer which rapidly increasing the water temperature. To control the water temperature,
adjust the gas control by turning it open or closed. To increase the temperature even more,
open the second gas burner control No 2 until the desired temperature is reached. A constant
water temperature will be delivered until the appliance is shut down. To shut down the
operation, simply close both the gas control valves to the “Closed” position, and switch of the
12V DC pump or close the water at the tap if used. For safety sake, the manufacturer
recommends closing the gas bottle valve when it is not being made use of, and or screw out the
gas canisters for safe storage. This will insure a safe environment at the camp site.
T CHNICAL PARAM T RS
Appliance size : Water Heater = 280 L 210 W 300 H (mm).
Approx. weight : 8.5 Kg. appliance only (Pump version) – Complete package 11 Kg. appro .
Gas & Pressure : For use with EN417 Canisters & LP Gas at Gas Bottle Vapor Pressure.
Gas consumption : Appro . Ma imum 250 /400 Grams Per / Hour.
Temperature Range : Raises water temperature adjustable to 60 Deg. Centigrade.
Flame Ignition : Electronic Press Button flame ignition – 1 AA 1.5V Battery.
12V DC Pump : 4.2L Parma 1. pressurized self siphoning pump.
Power Consumption : 1.5 A/H - Connects to a vehicle/power supply cigarette lighter socket.
Package Includes : High Lid Ammo Bo , Shower Head, Hoses, Power connectors & Instructions.
Options : Can be ordered with or without 12V DC pump fitted.

3.
Kariba-Xtreme Nomad WATER HEATER – supplied with or without pump fitted
For Outdoor use only – Protect this appliance against severe weather elements.

4.
G N RAL INFORMATION
THE KARIBA-XTREME NOMAD WAS DESIGNED AND DEVELOPED WITH FOCUSED THOUGHT ON
POWER REQUIREMENTS IN REMOTE PLACES, ATTENTION TO RELIABILITY DETAIL AND QUALITY
PERFORMANCE AT ALL TIMES. THIS MODEL FEATURES THE MOST VERSITILE AND PRACTICAL
CONSEPT IN WATER HEATERS FOR EXTREME ADVENTURES. TO INSURE CONSISTANCY IN THE
MANUFACTURING PROCESSES, THE HIGHEST POSSIBLE PRODUCTION STANDARD ARE APPLIED. THIS
INCLUDES THE SPECIALIZED EXPERIENCE AND TECHKNOWLIGY GAINED BY OUR TEAM AND
ASSOCIATES OVER THE PAST TWELVE YEARS IN THE MANUFACTURE OF GAS POWERED APPLIANCES.
KARIBA PRODUCTS HAVE THE UTMOST REGARD FOR THE SAFETY OF OUR CUSTOMERS, AND
THEREFORE FOCUS ON SUPPLYING CLEAR SAFETY PRECAUSIONS NOTED ON OUR PRODUCTS AND
PAGAGE LABELS, INLCUDING OUR OPERATING INSTRUCTIONS & HINTS AND ADVICE SUPPLIED TO
CUSTOMERS OF OUR GAS APPLIANCES.
Kariba-Xtreme Nomad - Appliance Standard Package & Contents:
1. 40L High Lid Ammo Bo also used as a water well.
2. Weather resistant powder coated/stainless body with graphic decals & notices.
3. Copper finned heat e changer with twin “High Pressure” burners.
4. Tilting front panel for inspection/maintenance including gas option installation.
5. Appliance supplied with/without 12V DC 4.2 L pump including switch gear.
6. Shower head including all hoses and connectors.
7. “AA” 1.5V Battery for Control Panel flame ignitions system.
8. LP Gas Hose including swivel gas bottle/ EN417 gas canister connectors.
9. Instruction Manual & maintenance booklet.
10. Quality Assurance Certificate.
Warranty:
Warranties are confined to within the borders of the Republic of South Africa. Customers
are requested to refer to the list of contents as noted above which are included in the
Quality Assurance Certificate which also notes the terms and conditions that apply to the
appliance supplied. Should any item/s be missing or damage be affected to the contents
of this appliance, these facts are to be reported to Kariba Safari Equipment CC Tel: 0027 21
511 9405 within 24 hours of the purchase by the customer. The manufacturer recommends
that operators of the appliance read this Instruction Manual booklet to become familiarized
with the workings of this gas appliance before connecting it to a gas container/s, and to
retain the instruction booklet for future reference. After having read the instruction
manual, customers are requested to test the appliance in order to confirm that it is working
satisfactorily. In the unlikely event of a malfunction, details are to be reported to the
Kariba offices within 24 hours of purchase/receipt. Failure to observe these instructions can
result in an invalid claim.
Aftercare Services:
An information/assistance service is provided during office hours in South Africa. Calls can
be made to our aftercare help line on 0027 21 511 9405 during office hours 09.00 to
16.00 Monday through Thursday and 15.00 on Fridays.
Alternatively, you may visit our website www.karibaproducts.co.za and choose our
Contact page for details, or email our help desk at:
karibaequipme[email protected]

5.
Kariba - Xtreme Nomad – Duel Gas
Powder Coated - White & Antique Gray (Standard)

6.
Kariba - Xtreme Nomad – Duel Gas
430 Brushed Stainless Steel finish
