KAT VR KAT Walk C PiSystem Adapter User manual



Contact Information 12
First Use Instructions 10
FAQs 12
First and Foremost
Declaration
Safety and Health Cautions
04
05
06
Product Introduction
Product Description
Product Parameters
07
07
Foreword

The owner’s manual contains all the information you need to install the KAT Walk C PiSystem
Adapter. The following symbols are used to indicate crucial information and instructions for
the set-up process:
This symbol is a hint, letting you know what might be helpful at that particular point.
This symbol is important: you must complete one or more of installations or settings as
described in the manual.
This symbol is a safety warning to remind you to be wary of your personal safety while
performing the task, be mindful of this symbol to avert any potential risks.
This symbol is a precaution: it usually provides additional information to help with a
task, as well as information that applies only to certain situations.
04

For the latest information, please feel free to check out our official website:
http://www.kat-vr.com/
It is the trademark of Hangzhou Virtual and Reality Technology Co., Ltd. All
trademarks, product identification and trade names of other companies appearing in this
manual are owned by their respective owners. No parts or content of this manual may be
copied or reproduced without the written permission of the company, and may not be shared
in any form or used for any commercial or profitable purpose.
The contents of this manual are subject to change due to product upgrades or other reasons.
Our company reserves the right to modify the contents of this manual without any notice or
prompt. This manual is intended as a guide only. We do our best to provide accurate informa-
tion in this manual, but we do not guarantee that the contents of the manual are completely
error free. All statements, information, and recommendations in this manual do not constitute
any warranty, express or implied.
05

This adapter is intended for use by people aged 14 to 60 years; if you do not meet the age
requirement, please do not use it.
Please use this adapter according to proper instructions or under the guidance of a profes-
sional to avoid damage. During its use by a minor, a guardian should always be present.
Choking hazard: Do not leave small components that pose a suffocation hazard to children
or pets where they can reach.
Keep the adapter safely away from liquids or containers holding liquids.
Do not insert items into any openings on the adapter.
Do not place the adapter near fire or heat sources, nor try to leave it directly exposed to the
sun.
Be sure to read and follow all product instructions and warnings related to your VR
omni-directional platform and VR headset of choice.
If you violate the above cautions or carry out other violations, it may cause personal
injury or adverse consequences, and KAT VR will not be responsible.
Those who use this adapter are considered to have full capacity of civil conduct and
have complied with the aforementioned matters.
To avoid injury or damage to the product, read and follow all installation and operation
instructions before using the KAT Walk C PiSystem Adapter. If it is improperly used, potential
risks may be triggered.
06

07
KAT Walk C PiSystem Adapter is a specialized adapter developed by KAT VR. It can synchronize
the motion in the VR headset with the actual movement by its user.
Adapter size
Adapter weight
Adapter power
USB ports
Micro USB cable
Mini USB cable
95*70mm
165g
2.5w
4 x USB 2.0 ports
5m
1m
Power cord spec
Work temperature
5V/2.5A
5V/2.5A
USB Ports
Power Port
PS4 Port mini
USB Cable
micro
USB Cable Power cord
2
1

08
21
01
Take out the KAT Walk C PiSystem Adapter
and three cables.
1
1
02
Locate the mini USB cable (PS4 connecting
cable) labeled with the sticker 1 and connect
it to the USB port of the PiSystem Adapter as
sown in the picture.

09
2
2
03
Locate the micro USB cable (controller cable)
labeled with the sticker 2 and connect it to
the USB port of the PiSystem Adapter as
sown in the picture.
04
Then, connect the same micro USB cabel to
the dualshock 4 controller.
06
Locate the power cord labeled with “switch”
sticker and connect it to the power port
shown in the picture.
2
05
Locate the USB cable of the KAT Walk C and
connect it to the PiSystem adapter as shown
in the picture.

2
1
07
complete the connection as shown in the
picture.
10
01
Wait one or two minutes for the KAT Walk C
PiSystem adapter to start.
Controller connected.
Who is using this controller?
Enter Options Menu
02 Before connecting the controller, make sure
that the related equipment is turned on.
Them, stand straight on the KAT Walk C
walking platform. Keep your feet together
and press the PS button on the Dualshock4
controller.
After pressing the button, the screen will
display this picture to indicate a successful
calibration.

11
Before playing PSVR games that require the
use of Dualshock4 controller, make sure that
the controller cable is well organized and
connected to the adapter. You can organize
and connect the controller cable in the same
way you connected the headset.
Before use of the device, please check if any
of the cables is twisted. If needed, manually
straighten them to avoid damage.
Go back to the STEP 6 and repeat the process.
03
If the process has not been succesfully com-
pleted, disconnect the power cord and wait
for five seconds.

E-mail: info@katvr.com
Web: http://www.kat-vr.com/
12
Q
Please press the PS button for adapting and pairing. If there is no response, please replug the
power cord and restart the KAT Walk C PiSystem Adapter.
A
Q
Reconnect the controller cable to KAT Walk C PiSystem Adapter and press the PS button for adapt-
ing. If there is no response, please replug the power cord and restart the KAT Walk C PiSystem-
Adapter.
A
Q
Every time you start PS4, please replug the power cord and restart the KAT Walk C PiSystem
Adapter.
A
There might be some non-scheduled updates for FAQs, please visit:
http://katvr.com/knowledge.html#supportwz for more information.
Company: Hangzhou Virtual and Reality Technology Co., Ltd
Room 901, Building 6, No 1818-2, West WenYi Road, Yuhang Street , Yuhang District,
Hangzhou, Zhejiang Province, China.
Add:
Postal code: 311100
