CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
CORDLESS 1/3 sheet sander
INSTRUCTION MANUAL
220142
LITHIUM ION
18V
WARRANTY*
5 YEAR

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
1
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and all
instructions.Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury. Save all warnings and
instructions for future reference. The term “power tool” in
the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators,ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
220142

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
2
The rating plate on your tool may show symbols. These represent important information about the product or
instructions on its use.
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
Additional Safety Instructions 1/3 Sheet
Sander Warning!
1) Hold power tool by insulated gripping surfaces,
because the sanding pad may contact its own cord.
Cutting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an
electric shock.
2) Disposing of dust. Be extremely careful of dust
disposal, materials in ne particle form may be
explosive. Do not throw sanding dust on an open re.
Spontaneous combustion, may in time, result from a
mixture of oil or water with dust particles.
3) Always wear eye protection and a dust mask for
dusty applications and when sanding overhead.
Sanding particles can be absorbed by your eyes and
inhaled easily and may cause health complications.
4) Use special precautions when sanding chemically
pressure treated timber, paint that may be lead
based, or any other materials that may contain
carcinogens. A suitable breathing respirator and
protective clothing must be worn by all persons entering
the work area. Work should be sealed by plastic
sheeting and persons not protected should be kept out
until work area is thoroughly cleaned.
SYMBOLS
Direct current, DC Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check
with your Local Authority or retailer for
recycling advice.
Refer to instruction manual/booklet
Wear ear protection General warning
Wear eye protection Regulator compliance mark
Wear respiratory protection
220142
5) Do not ‘wet sand’ with this sander. Liquids entering
the motor housing are an electrical shock hazard.
6) Do not use sandpaper intended for larger sanding
pads. Larger sandpaper will extend beyond the sanding
pad causing snagging, tearing of the paper or kick-back.
Extra paper extending beyond the sanding pad can also
cause serious lacerations.
WARNING!
The dust produced when using this tool may
be harmful to health (e.g. when working oak or
beech wood, stones, paint, which could contain
lead or other harmful chemicals). Do not inhale the dust. Use
a dust absorption system and wear a suitable dust protection
mask. Remove deposited dust thoroughly, e.g. with a vacuum
cleaner. Do not use machines on any material containing
asbestos. This machine is suitable only for dry sanding.
Remove the battery pack before starting any work on the
machine.
Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contain chemicals
known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks, cement and other masonry
products, and;
• Arsenic and chromium from chemically-treated timber.
Your risk from these exposures varies, depending on
how often you do this type of work.
To reduce your exposure to these chemicals: work in a well
ventilated area and work with approved safety equipment,
such as dust masks that are specially designed to lter out
microscopic particles.

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
3
Voltage 18V d.c.
No Load Speed 13,000/min
Eccentric Diameter 2.0mm
Pad Size 184 x 93mm
Paper Fitment Clamp or Hook & Loop
SPECIFICATIONS
KNOW YOUR PRODUCT 220142
1 x 80G Sand Paper
1 x Dust Collection Bag
1 x Punch Plate
ACCESSORIES
1 - ON/OFF SWITCH
2 - SANDING PAD 3 - SAND PAPER SPRING
CLAMP HANDLE
4 - DUST COLLECTION BAG
(ANY 18V CHARGE-ALL
BATTERY WILL FIT)
BATTERY
INSERTS HERE
1. ALIGN BATTERY RIBS WITH TOOL 2. SLIDE INTO TOOL 3. STOP WHEN YOU HEAR IT CLICK IN PLACE
1 2 3
*CLICK*
HOW TO INSERT BATTERY ON TOOL

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
4
1
3
2
4
1 2
FITTING ACCESSORIES – HOOK AND LOOP SAND PAPER
FITTING ACCESSORIES – USING WIRE CLAMPS
1. SAND PAPER ALIGNMENT
1. UNLOCK CLAMPS
3. FOLD PAPER
2. ALIGN PAPER
4. SECURE PAPER
2. REMOVING SAND PAPER
Align the edges and holes of the sanding paper
with sanding pad and press down.
Unlock the wire spring clamps on both sides of
the sander.
Fold the sandpaper over the ends of the sanding
pad.
If the replacement sandpaper has holes, align
the holes with the sanding pad, if not refer to the
punch plate instructions.
Place sandpaper under the spring clamps at
the front and rear of the sander and secure the
clamps into their locked position.
To remove sanding paper, peel away from the
sanding pad starting from an edge.
220142
Fit the sandpaper to the sander
following the fitment steps above.
Align the punch plate with the
sanding pad.
Press down on the tool to punch
holes in the sandpaper.
1. FIT SAND PAPER 2. ALIGN PUNCH PLATE 3. PRESS INTO SANDPAPER
1 2 3
USING THE SAND PAPER PUNCH PLATE

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
5
FITTING ACCESSORIES – DUST COLLECTION BAG
Push Firmly
1. ATTACHING COLLECTION BAG
Align the dust outlet on the sander with the dust
collection bag inlet and push until firmly attached.
2. REMOVING COLLECTION BAG
To remove, pull the dust collection inlet away from
the sander.
220142
Pull Away
to Remove
SWITCHING ON AND OFF
1. START SANDER
2. STOP SANDER
To start the sander press the on/off switch into
the on position “I”.
To stop operation, press the on/off switch into
the off position “0”.
1 2

CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
6
SANDING
1. ENSURE SAFETY 2. SECURE WORKPIECE
Always wear safety glasses when working with
the sander. Make sure to secure your hair and any
baggy clothes. Make sure you wear ear muffs, a
mask or a respiratory mask.
Secure material to be sanded where possible.
Make sure your workpiece is securely fastened to
the surface to ensure no movement when sanding.
3. SECURE SAND PAPER
NOTE:
Do not apply heavy pressure or tilt the sanding base as this will prematurely wear the sand paper and
may damage the sander and sanding pad. Ensure you check the surface you are sanding often as the
sander is capable of removing a significant amount of material. In the final stages of sanding, sand with
the grain for a finer finish.
Ensure sand paper is secure to the sanding pad
and with a firm grip start the tool.
1
3
2
220142
Gently lower the tool flat onto the surface and
make smooth back and forth OR side to side
motions.
4. SMOOTH MOVEMENTS
4

MAINTENANCE
CORDLESS 1/3 sheet sander INSTRUCTION MANUAL
This power tool normally requires no maintenance; from time to time the ventilation slots on the motor
casing should be cleaned out. If the unit should become defective, repair should be performed by an
authorized service agent for electric tools.
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust,
oil, grease, etc.
Warning!
Do not at any time let brake fluids, gasoline, petroleum based products, penetrating oils, etc., come in contact with
plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury.
220142
Australia & Global
www.katanapowertools.com.au
[email protected]
[phone]
Made to Katana
specifications and
quality standards
in China.
NOT INTENDED
FOR TRADE USE
* All Katana power tools come with a 5 year (3+2 year) replacement warranty from date of purchase.
3 year standard warranty with the option to register your product online at www.katanapowertools.com.au/
register to receive an additional 2 years free of charge.
Products must be registered within 30 days from date of purchase to qualify for warranty extension.
Katana products and services come with guarantees that cannot be excluded under the Australian Consumer
Law. For major failures with the service, you are entitled: -to cancel your service contract with us; and -to a refund for the unused portion,
or to compensation for its reduced value. You are also entitled to choose a refund or replacement for major failures with goods. If a failure
with the goods or a service does not amount to a major failure, you are entitled to have the failure rectified in a reasonable time. If this is not
done you are entitled to a refund for the goods and to cancel the contract for the service and obtain a refund of any unused portion. You
are also entitled to be compensated for any other reasonably foreseeable loss or damage from a failure in the goods or service’. Warranty is
given by Kincrome Australia Pty Ltd of 3 Lakeview Drive, Caribbean Park, Scoresby, Victoria (Tel [phone]) .
KATANA Warranty is in addition to any other rights you have under the Australian Consumer Law or other applicable laws. For further details
and terms please check our product guide, visit www.kanatapowertool.com.au or call us. Every effort is made to ensure advertised stock is
available, but due to factors beyond the control of Kincrome Australia Pty. Ltd, not all products advertised in this catalogue may be available
at all stores. Kincrome Australia Pty. Ltd. reserves the right to correct printing errors. All sizes shown are approximate only. Accessories
shown do not come with the product unless otherwise specified. Due to printing process, colours in this catalogue may vary slightly to
actual item. E. & O. E. © Copyright 2021. Reproduction in whole or in part is prohibited without consent.
WARRANTY*
5 YEAR
