INSTRUCTION SHEET
6" RANDOM ORBITAL SANDER
QUESTION...
1•847•780•6120
!
SPECIFICATIONS
Free Speed: ..........................12000 RPM
Pad Size:..............................6" (150 mm)
Orbit Diameter: .................... 3/16" (5 mm)
Spindle Thread: .......................... 5/16"- 24
Air Inlet: ................................. 1/4" NPT
Hose Size: ........................3/8" (10 mm) I.D.
Air Pressure: ......................90 P.S.I. (6.2 Bar)
Air Consumption:. . . . . . . . . . . . . . . . . . . 2 CFM (57 L/Min)
IMPORTANT SAFETY INSTRUCTIONS
WARNING
For your own safety, read and understand all warnings and
operating instructions before using any tool or equipment.
WARNING
Improper operation or maintenance of this product could
result in serious injury and property damage. When using
air tools, basic safety precautions should always be
followed to reduce the risk of personal injury.
WARNING
Some dust created by operation of power tool contains
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm. To reduce your
exposure to these chemicals, work in a well ventilated
area and work with approved safety equipment. Always
wear OSHA/NIOSH approved, properly fitting face mask or
respirator when using such tools.
WARNING
Failure to follow these rules may result in serious personal
injury. Remember that being careless for even a fraction of
a second can result in severe personal injury.
WARNING
• Work in a clean, well ventilated area free of
combustible materials.
• Avoid prolonged use: repetitive motion or exposure to
vibration may be harmful to your hands or arms. Use
gloves to provide extra cushion, take frequent rest
periods, and limit daily time of use. If numbness, tingling,
pain or whitening of the skin occurs, stop using the tool
and consult a physician.
• Always wear safety glasses and ear protection during
operation. Always wear approved safety glasses with
shields. Always wear approved hearing protection.
• Do not operate power tools in explosive atmospheres,
such as in the presence of combustible liquid, gases or
dust. Power tools create sparks which may ignite the dust
or fumes
• Do not exceed maximum air pressure of 90 PSI or as
stated on nameplate.
• Use compressed air only.
• Read all manuals included with this product carefully.
• Disconnect the air supply before making any
adjustments, changing accessories or storing the tool.
Always disconnect the air supply before performing any
inspection, maintenance or tool cleaning.
• Do not wear loose fitting clothing or apparel which
contains loose straps or ties, etc. Which could become
entangled in moving parts of the tool and results in
serious personal injury.
• Do not wear jewelry, watches, identifications,
bracelets, necklace, etc. When operating any tool,
they may become caught in moving parts and result in
serious injury.
• Do not depress trigger when connecting the air
supply hose.
• Use only accessories recommended by the manufacturer
for this tool.
• Do not use damaged or worn attachments.
• Do not leave the tool unattended when it is connected to
an air supply.
• Secure and support the work piece to a stable platform.
• Do not force the tool. Use the correct tool for your
application. Using the correct tool which is specifically
designed for a select job will provide better tool
performance and make the job easier.
• Never trigger the tool when not applied to a work
object Attachments must be securely attached. Loose
attachments can cause serious injury.
• Do not put hands near or under moving parts.
You will need this manual for safety instructions, operating procedures, and warranty.
Put it and the original sales invoice in a safe, dry place for future reference.
Visit us on the web at www.southerntechllc.com
Southern Technologies, LLC
3816 Hawthron CT,
Waukegan, IL 60087
Model No. AS63160
16-1005

• The operator must maintain a secure body position and
have a firm grip and footing when using this tool.
• This tool is not electrically insulated. Never use the
tool if there is any chance of it coming into contact with
live electricity.
CAUTION
Think safety! Safety is a combination of operator common
sense and alertness at all times when tool is being used.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
AIR SUPPLY SETUP AND CONNECTION
Refer to Figure 1
• Figure 1 shows the recommended air supply hook-up.
• The use of air line lubricators and air line filters is
recommended to prevent water in the line that can
damage the tool. Drain the air tank daily. Clean the
air inlet filter screen on at least a weekly schedule
to remove accumulated dirt or other matter that can
restrict air flow.
• The tool’s air inlet used for connecting an air supply has
a standard 1/4” NPT American thread.
• If an air line lubricator is not used, before operating the
tool add a few drops of Pneumatic Tool Oil into the tool
inlet. Repeat each hour of constant use.
CAUTION
This air tool requires lubrication BEFORE initial use and
before and after each additional use.
OPERATION
CAUTION
Never mount a grinding wheel on a sander. A grinding
wheel that bursts can cause very serious injury or death
when not properly guarded.
• Ensure the sanding pad is fixed securely to the tool.
Use the supplied wrench to hold the shaft nut in place
while turning the sanding pad clockwise to tighten and
counterclockwise to loosen.
• Select the correct 6" abrasive disc for the job. Use 6"
self adhesive abrasive disc.
• Connect to suitable air supply as recommended.
CAUTION
Risk of unsafe operation. Firmly grasp air hose with hand
when installing or disconnecting to prevent hose whip.
• Touch the sander lightly to the work and allow
the abrasive disc to cut. Take care when sanding
around sharp edges and surfaces to avoid the disc
snagging, the disc may be brought to an abrupt stop
or considerably slowed, causing the tool to kick in
the hands.
• Do not continue to use abrasive discs that are worn or
clogged. Do not use undersized or oversized abrasive
discs. The disc should be no more than 1/4" larger in
diameter than the sanding pad, and not smaller than the
sanding pad.
Key# Part# Description
1 AS631601 Housing
2 AS631602 Spring Pin (3*40L)
3 AS631603 Air Inlet
4 AS631604 Throttle Lever
5 AS631605 Shaft
6 AS631606 Bushing
7 AS631607 O-Ring (21.5*1.5)
8 AS631608 O-Ring 2 (10.7*1.5)
9 AS631609 O-Ring (10.5*1)
10 AS631610 Regulator
11 AS631611 Silencer
12 AS631612 Adapter
13 AS631613 Spring Pin (2*18L)
14 AS631614 Rear End Plate
15 AS631615 Rotor
16 AS631616 Rotor Blade(5)
17 AS631617 Screw (M5*12L)
18 AS631618 Cylinder
19 AS631619 Front End Plate
20 AS631620 Swivel Exhaust
21 AS631621 O-Ring (3.68*1.78)
22 AS631622 Retaining Ring (STW-14)
23 AS631623 Spring
24 AS631624 Retainer Ring
Key# Part# Description
25 AS631625 Nut (M5*0.8)
26 AS631626 Ball Bearing (6000zz)
27 AS631627 Spring Pin (3*28)
28 AS631628 O-Ring (5*2)
29 AS631629 Lock Ring
30 AS631630 Grip Hat
31 AS631631 Shroud
32 AS631632 Ball Bearing (6001zz)
33 AS631633 Washer
34 AS631634 Shaft
35 AS631635 Snap Ring
36 AS631636 Key
37 AS631637 Balancer Shaft
38 AS631638 Washer (3*13)
39 AS631639 Spanner
40 AS631640 O-Ring (39.4*3.1)
41 AS631641 O-Ring (8.8*1.7)
42 AS631642 O-Ring (2*1)
43 AS631643 O-Ring (13.5*1.5)
44 AS631644 Ball Bearing (6001)
45 AS631645 Ball Bearing (6001P)
46 AS631646 Pad (6")
47 AS631647 Stopper
48 AS631648 Washer
Figure 1
Tailpiece
Adaptor
Adaptor
Main Air
Hose
Whip Hose
Coupler
Coupler
Oiler Filter
DRAIN
DAILY
Regulator
PIPES AND
FITTINGS
Stop Valve
Tailpiece
Adaptor
OIL HERE
DAILY Tailpiece
Adaptor
