KaVo MASTERspace User manual

Instructions for use
MASTERspace® - Workplace

Distributed by:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
Phone [phone]
Fax [phone]
Manufacturer:
Kaltenbach & Voigt GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com

Contents
1 User instructions ................................................................................................................ 4
1.1 User guide .................................................................................................................... 4
1.1.1 Abbreviations ..................................................................................................... 4
1.1.2 Symbols ............................................................................................................ 4
1.1.3 Target group ...................................................................................................... 4
1.1.4 Meaning of the pictograms................................................................................... 4
1.2 Service ......................................................................................................................... 5
1.3 Terms and conditions of warranty.................................................................................... 5
1.4 Transportation and storage............................................................................................. 6
1.4.1 Currently valid packaging regulations.................................................................... 6
1.4.2 Damage in transit ............................................................................................... 6
1.4.3 Information on the packaging: Storage and transportation...................................... 7
2 Safety.................................................................................................................................. 8
2.1 Description of safety instructions..................................................................................... 8
2.1.1 Warning symbol ................................................................................................. 8
2.1.2 Structure ........................................................................................................... 8
2.1.3 Description of hazard levels ................................................................................. 8
2.2 Purpose – Proper use ..................................................................................................... 8
2.3 Safety Instructions......................................................................................................... 9
2.3.1 General information ............................................................................................ 9
3 Product description ............................................................................................................ 11
3.1 Scope of delivery ........................................................................................................... 11
3.2 MASTERspace® work surface ......................................................................................... 12
3.3 Technical data ............................................................................................................... 12
3.4 Rating plates................................................................................................................. 14
4 Installation and connection of MASTERspace® ................................................................15
4.1 Check the consignment for completeness......................................................................... 15
4.2 Check the mains voltage and mains frequency.................................................................. 15
4.3 Select location............................................................................................................... 15
4.4 Installation and connection of the workplace..................................................................... 15
4.5 Check mark the symbols on the attachment characteristics label ........................................ 24
4.6 Connect the gas, compressed air and electrical supplies..................................................... 25
5 First use .............................................................................................................................. 26
6 Operation............................................................................................................................ 27
6.1 Using a pneumatic hand-held nozzle................................................................................ 27
6.2 Opening and closing the gas tap...................................................................................... 27
7 Maintenance ....................................................................................................................... 29
7.1 Cleaning the workplace .................................................................................................. 29
7.2 Caring for the work surface............................................................................................. 29
7.3 Maintenance of the safety hose for the bunsen burner....................................................... 29
8 Accessories ......................................................................................................................... 31
9 Service replacement parts..................................................................................................32
10Declaration of conformity...................................................................................................33
Instructions for use MASTERspace® - Workplace
Contents
3 / 36

Instructions for use MASTERspace® - Workplace
1 User instructions | 1.1 User guide
4 / 36
1 User instructions
1.1 User guide
Requirement
Read these instructions prior to first use to avoid misuse and prevent damage.
1.1.1 Abbreviations
Ab-
brevi-
ation
Explanation
IfU Instructions for use
CI Care instructions
AI Assembly instructions
TI Technician's instructions
SC Safety checks
IEC International Electrotechnical Commission
RI Repair instructions
RK Retrofitting kit
AS Assembly set
EP Enclosed parts
EMC Electromagnetic compatibility
PI Processing instructions
1.1.2 Symbols
See the Safety/Warning Symbols section
Important information for users and technicians
CE mark (European Community). A product bearing this mark meets
the requirements of the applicable EU directive.
Action required
1.1.3 Target group
Important information for users and technicians
1.1.4 Meaning of the pictograms
Automatic mode, automatic procedure
Close, screw in, fasten etc.

Instructions for use MASTERspace® - Workplace
1 User instructions | 1.2 Service
Open, detach, loosen etc.
More, higher
Less, lower
Continuous operation
Time, time-based sequence
Disconnect the mains plug
1.2 Service
Service-Hotline:
[phone]
[e-mail]
Please indicate the product serial number in all requests!
For further information, please visit: www.kavo.com
1.3 Terms and conditions of warranty
Within the scope of the applicable KaVo delivery and payment conditions, KaVo
guarantees proper function, absence of defects in material and workmanship
for a period of 12 months from the date of purchase as confirmed by the sales-
person.
In case of justified complaints, KaVo will honour its warranty with a free re-
placement or repair.
The warranty does not cover defects and their consequences that arose or may
have arisen due to natural wear, improper handling, cleaning or maintenance,
non-compliance with operating, maintenance or connection instructions, corro-
sion, contaminated media supply or chemical or electrical influences deemed
abnormal or impermissible in accordance with factory specifications.
The warranty does not usually cover lamps, light conductors made of glass and
glass fibres, glassware, rubber parts and the colourfastness of plastic parts.
The warranty expires if defects or their consequences could possibly have
arisen because the product has been modified or changed. Warranty claims can
only be asserted when they are immediately reported to KaVo in writing.
This notification must be accompanied by a copy of the invoice or delivery note
on which the manufacturing number is clearly visible. In addition to the guar-
anty, the statutory warranty claims of the purchaser also apply with a warranty
period of 12 months.
Authorized to repair and service the KaVo products:
▪ technicians of KaVo branches throughout the world.
▪ technicians of authorised dealers specially trained by KaVo.
▪ independent technicians specially trained by KaVo.
Approvals and permits will be rendered null and void in the event that changes
are made by third parties. KaVo recommends that only genuine replacement
parts are used during operation and for repairs.
5 / 36

Instructions for use MASTERspace® - Workplace
1 User instructions | 1.4 Transportation and storage
6 / 36
1.4 Transportation and storage
1.4.1 Currently valid packaging regulations
Note
Only valid for the Federal Republic of Germany.
Dispose of and recycle the sales packaging appropriately in accordance with
current packaging regulations, employing waste management or recycling com-
panies. Comply with the comprehensive return system. KaVo has had its sales
packaging licensed for this purpose. Please comply with the regional public
waste-disposal system.
1.4.2 Damage in transit
In Germany
If the packaging is visibly damaged on delivery, please proceed as follows:
1. The recipient of the package must record the loss or damage on the delivery
receipt. The recipient and the representative of the shipping company must
sign this delivery receipt.
2. Leave the product and packaging in the condition in which you received it.
3. Do not use the product.
4. Report the damage to the shipping company.
5. Report the damage to KaVo.
6. Consult with KaVo first, before returning a damaged product.
7. Send the signed delivery receipt to KaVo.
If the product is damaged but there was no discernable damage to the pack-
aging on delivery, proceed as follows:
1. Report the damage to the shipping company immediately and no later than
7 days after delivery.
2. Report the damage to KaVo.
3. Leave the product and packaging in the condition in which you received it.
4. Do not use a damaged product.
Note
Failure on the part of the recipient to comply with any of the above-men-
tioned obligations will mean that the damage will be considered to have
arisen following delivery (in accordance with the General German Freight For-
warders´ Terms and Conditions, Art. 28).
Outside Germany
Note
KaVo shall not be held liable for damage arising from transportation.
The shipment must be checked on arrival.
If the packaging is visibly damaged on delivery, please proceed as follows:
1. The recipient of the package must record the loss or damage on the delivery
receipt. The recipient and the representative of the shipping company must
sign this delivery receipt.
Without this evidence, the recipient will not be able to assert a claim for
damages against the shipping company.

Instructions for use MASTERspace® - Workplace
1 User instructions | 1.4 Transportation and storage
2. Leave the product and packaging in the condition in which you received it.
3. Do not use the product.
If the product is damaged but there was no discernable damage to the pack-
aging on delivery, proceed as follows:
1. Report any damage to the shipping company immediately and no later than
7 days after delivery.
2. Leave the product and packaging in the condition in which you received it.
3. Do not use a damaged product.
Note
If the recipient fails to comply with any of the above-mentioned obligations,
the damage will be considered to have arisen following delivery
(in accordance with CMR law, Chapter 5, Art. 30).
1.4.3 Information on the packaging: Storage and
transportation
Note
Please keep the packaging in case you need to return the product for servi-
cing or repair.
The symbols printed on the outside are for transportation and storage, and
have the following meaning:
Transport upright with the arrows pointing upwards!
Fragile - protect against impact!
Protect from moisture!
Permissible stacking load
Temperature range
Humidity
Air pressure
7 / 36

Instructions for use MASTERspace® - Workplace
2 Safety | 2.1 Description of safety instructions
8 / 36
2 Safety
2.1 Description of safety instructions
2.1.1 Warning symbol
Warning symbol
2.1.2 Structure
DANGER
The introduction describes the type and source of the hazard.
This section describes potential consequences of non-compliance.
▶The optional step includes necessary measures for hazard prevention.
2.1.3 Description of hazard levels
The warning and safety notes in this document must be observed to prevent
personal injury and material damage. The warning notes are designated as
shown below:
DANGER
In cases which – if not prevented – directly lead to death or severe in-
jury.
WARNING
In cases which – if not prevented – could lead to death or severe in-
jury.
CAUTION
In cases which – if not prevented – could lead to minor or moderate
injury.
NOTICE
In cases which – if not prevented – could lead to material damage.
2.2 Purpose – Proper use
KaVo MASTERspace® is a high-quality equipment program for dental laborator-
ies. It offers a comprehensive range of accessories and technical equipment
which allow laboratory workstations to be laid out as single or multiple work-
places.
Note
DIN EN 61010 must be observed to ensure proper use.

Instructions for use MASTERspace® - Workplace
2 Safety | 2.3 Safety Instructions
Note
The manufacturer does not accept any liability for damage caused by im-
proper use.
2.3 Safety Instructions
2.3.1 General information
Note
The user/operator must read the Instructions for Use before the first start-up
in order to prevent faulty operation and other damage.
The user must ensure that the unit works properly and is in satisfactory condi-
tion before each use.
Users have a duty to:
▪ Only use equipment that is operating correctly
▪ Protect themselves and others against hazards.
The following persons are authorised to repair and service the KaVo product:
▪ Technicians of KaVo branch offices after appropriate product training.
▪ Specifically KaVo-trained technicians of KaVo franchised dealers.
KaVo shall not be responsible for damage caused by:
▪ external influences, poor media quality or faulty installation.
▪ The use of incorrect information.
▪ repair work carried out incorrectly.
Note
Any waste which is generated must be recycled or disposed of in strict com-
pliance with all applicable national regulations in a manner which is safe both
for people and the environment.
If you have any questions regarding proper disposal of the KaVo product,
please contact the KaVo branch.
CAUTION
Improper product servicing or repair of the product
Damage to product
▶Only use original KaVo spare parts!
▶Do not replace the removeable power cable with an inadequately dimen-
sioned power cable!
9 / 36

Instructions for use MASTERspace® - Workplace
2 Safety | 2.3 Safety Instructions
10 / 36
WARNING
Hazardous dusts
Injury hazard
▶Comply with national regulations and permissible dust loads for workplaces.
▶Comply with the safety data sheets during any aspiration of hazardous ma-
terials.
▶Wear personal protective clothing during any aspiration of hazardous ma-
terials.
▶Discharge exhaust air appropriately during any aspiration of hazardous ma-
terials.
See also:
2Safety instructions in the instructions for use of the dust extraction system

Instructions for use MASTERspace® - Workplace
3 Product description | 3.1 Scope of delivery
3 Product description
3.1 Scope of delivery
1
2
3
4
5
6
7
①Work surface ②Support plate
③Installation support ④Floor-mounted cupboards
⑤Capture cell ⑥Compensating element or side wall
or EXTRAmatic®
⑦Side panel
11 / 36

Instructions for use MASTERspace® - Workplace
3 Product description | 3.2 MASTERspace® work surface
12 / 36
3.2 MASTERspace® work surface
3.3 Technical data
Compressed air
Minimum air pressure provided by
customer
5 bar
Max. air pressure provided by cus-
tomer
6 bar
Max. air consumption 50 l/min
Gas
Gas pressure provided by customer 50 mbar
Permissible gases:
In accordance with DVGW Work Sheet G260/I
and ANSI Z21.1/CSA 1.1 pp.
Max. gas consumption
Natural Gas 0.1 m3/h
Liquid gas 0.075 kg/h
City gas 0.15 m3/h

Instructions for use MASTERspace® - Workplace
3 Product description | 3.3 Technical data
Electrical connection
Rated voltages 100 V or 110 - 120 V or 230 V at 50
- 60 Hz
Power consumption max. 16 A
Connected load at the multiple
socket outlet
(for UL versions)
max. 12 A
Leakage current max 1.5 mA
Fuse protection in accordance with
national requirements
max. 16 A
Overvoltage category II
Degree of soiling 2
Class of protection I
CAUTION
Overloading of electrical cables
Electrical shock
▶The total power of the connected electrical loads must not exceed 16 A (12
A in the case of UL versions), but can be distributed over the number of in-
stalled sockets.
▶This limitation must also be ensured if 2 workstations are connected via
fuse protection (max. 16 A (12 A in the case of UL versions)).
▶The same must be ensured if 3 workstations are connected via one power
supply cord.
Ambient conditions
Permissible installation sites Interior rooms
Maximal installation height 2000 m above sea level
Permissible ambient temperature
range
+ 5 oC to + 40 oC
Permissible relative air humidity max. 80 %
Dimensions
Height 945 or 870 mm
Adjustment range 30mm
Width 1100 or 1200 mm
Single row depth 620mm
Double row depth 1140mm
Reduction of the maximum connec-
ted load per connected workplace
lamp or extra-low voltage supply
(with UL version)
1 A
13 / 36

Instructions for use MASTERspace® - Workplace
3 Product description | 3.4 Rating plates
14 / 36
3.4 Rating plates
Type code 9XXY
▪ 9: Brief description of the TAP program
▪ XX: Table length in 10 cm (11 to 24)
▪ Y: Number of workplace rows (1 or 2)
Rating plate to be attached in a clearly visible place during the installation on site depending on the
installation conditions.
Rating plate is attached on the left rear of the installation support.
Rating plate installation support MASTERspace® Type 9222, 120 V (Mat. no.
1.004.4232) C/US
Rating plate installation support MASTERspace® Type 9222, 230 V (Mat. no.
1.004.4233) CE
Type 9091
SN Year of manufacture – serial number
HIBC Code
TÜV mark
NRTL mark
CE mark
CSA US mark (USA)
CSA C mark (Canada)
GS mark
VDE mark
For disposal instructions see: intended use
Read and take note of the content of accompanying documents

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.1 Check the consignment for completeness
4 Installation and connection of MASTERspace®
4.1 Check the consignment for completeness
▶Check the workplace for completeness
4.2 Check the mains voltage and mains frequency
▶Check that the rated voltage and rated frequency match the specifications
on the rating plate (+/- 10 %).
4.3 Select location
▶Choose an installation location with gas, compressed air and electrical con-
nections.
▶Light up the room so that it is as bright as daylight.
▶Note the necessary installation dimensions. Recommended space require-
ments per workplace: 2 m2
See also:
23.3 Technical Data, Page 12
4.4 Installation and connection of the workplace
15 / 36

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.4 Installation and connection of the workplace
16 / 36
X

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.4 Installation and connection of the workplace
17 / 36

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.4 Installation and connection of the workplace
18 / 36

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.4 Installation and connection of the workplace
19 / 36

Instructions for use MASTERspace® - Workplace
4 Installation and connection of MASTERspace® | 4.4 Installation and connection of the workplace
20 / 36
