FL-LED-R2B-140PS-8CSB-ST
HIGH-POWER LED FLOODLIGHT
140W High-Power LED Rectangular Floodlight; 120–277V Input
PRODUCT FEATURES
• High-power LED rectangular floodlight with innovative design
based on established floodlight principles
• Suitable for ground-, pole-, or building-mount applications
• Selectable wattage technology (140/100W)
• Selectable CCT technology (3000/4000/5000K)
• Die-cast aluminum housing with optional glare shield
accessory (sold separately)
• Heavy-duty trunnion- and slipfitter-mount options included
• 3-pin twist lock photocell and shorting cap included with
NEMA/ANSI C136.10 3-pin twist lock receptacle
• Precision-crafted NEMA 7H × 6V optics lens
• 0–10V dimming driver with 12V AUX power tap and 6kV surge
protection
• Ambient operating temperature: −40°C/-40°F to 50°C/122°F
• UL and DLC 5.1 listed, IP65 rated
• Power factor: >0.95
• THD: <20%
• L70 @ 100,000 hours @ 25°C/77°F ambient fixture temperature
• Meets FCC Part 15, Part B, Class A standards for conducted
and radiated emissions
ELECTRICAL SPECIFICATIONS
Catalog Number Wattage CCT Lumens Efficacy Input Voltage Optics Type Dimming Housing Color CRI Rated Life Legacy
Equivalent
FL-LED-R2B-140PS-8CSB-ST
140W
3000K 17,500 125 lm/W
120–277V 7H × 6V 0–10V Bronze >80 50,000 hrs 400W MH
4000K 20,300 145 lm/W
5000K 18,900 135 lm/W
100W
3000K 13,500 135 lm/W
4000K 15,500 155 lm/W
5000K 14,500 145 lm/W
Note: Mounting options are universal: 2 3/8" Trunnion or Slipfitter. Photocell included.
Page 1 of 4
FL-LED-R2B-140ps-8CSB-st
high-power led floodlight

DIMENSIONS
FL-LED-R2B-140PS-8CSB-ST
HIGH-POWER LED FLOODLIGHT
Page 2 of 4
SELECTABLE WATTAGE AND SELECTABLE CCT ADJUSTMENT INSTRUCTIONS
This fixture is equipped with field-adjustable selectable wattage and selectable CCT technology.
1. Ensure power is off to the fixture.
2. Unscrew the gasketed caps from the back of the fixture as shown in the images below.
3. Adjust dip switches to desired settings.
4. Screw on gasketed caps.
5. Restore power to fixture.
SLIPFITTER-MOUNTTRUNNION-MOUNT
12.05" 6.72"
18.23"
12.05" 6.72"
16.85"
FL-LED-R2B-140ps-8CSB-st
high-power led floodlight

FL-LED-R2B-140PS-8CSB-ST
HIGH-POWER LED FLOODLIGHT
Page 3 of 4
PHOTOCELL INSTRUCTIONS
This fixture comes with a 3-pin twist-lock photocell accessory.
This fixture is compatible with NEMA/ANSI C136.10-2010 3-pin twist-lock photocells.
1. Ensure power is off to the fixture.
2. Remove existing twist lock shorting cap from receptacle.
3. Push the photocell onto the receptacle and twist clockwise to lock into place.
4. For optimal performance, install the photocell with sensor
director facing north as indicated on the top of the accessory. Adjust if necessary,
while ensuring proper water-tight install.
5. Restore power to fixture when ready.
WIRING DIAGRAMS
Pink (Dim−)
White (Neutral)
Purple (Dim+)
Green (Ground)
Black (Live)
120–277V Input Dimming wires to 0–10V
IEC-compliant control
Black (Line)
White (Neutral) Purple (Dim+)
Pink (Dim−)
Green (Ground)
Driver
GENERAL WIRING DIAGRAM
Photocell
Shorting cap
Socket
Lamp
FL-LED-R2B-140ps-8CSB-st
high-power led floodlight

FL-LED-R2B-140PS-8CSB-ST
HIGH-POWER LED FLOODLIGHT
Page 4 of 4
HIGH-POWER LED FLOODLIGHT ORDERING INFORMATION
Catalog Number Pack Qty. UPC
FL-LED-R2B-140PS-8CSB-ST 1 843654148700
LIGHT DISTRIBUTION PATTERN
BUILDING-MOUNT VIEW FROM ABOVE
Floodlight mounted at 30' above ground; beam angled 30º below
horizontal
GROUND-MOUNT VIEW FROM ABOVE
Floodlight mounted at 6" above ground; beam angled 10º above
horizontal; shining toward building wall from 35' away
0.1 fc
0.2 fc
0.5 fc
1.0 fc
2.0 fc
5.0 fc
10.0 fc
