w [ KEATING) OF CHICAGO, INc. @
COOKING
COMPUTER
OPERATOR'S
MANUAL
SECTION I
FEATURES
The Keatingcookingcomputer automatically adjuststimetocompensatefor temperature variation, andassures
a consistent-tasting product. Cooking times and temperatures may'be programmed using a special program
mode.When programmed, frying is as simple as pressing a button.
The Keating computer features:
1-1. MULTI-PROGRAMMABILITY
-- .
Eight different cook cycles may be programmedinto
L
the computer.Eachcook cycle hasaseparate control
with arangebetween
1 -secondand99-minutes, 59-
seconds. Cookingtimes andtemperatures cannot be
altered by kitchen help.
1-2. CONSTANT COOKING TEMPERATURES
A cooking range of 290°F. to 39g°F. may be
programmed intothe computer. Cooking at constant
temperatures provides a more consistent-tasting
product.The computer will automatically adjusttime
for any variations inthe oil temperature.
1-3. PRE-ALARM
One pre-alarmmay beprogrammedfor eachcooking
cycle (cook key).The pre-alarm may be used to:
1. Warn your cook that a cook cycle is near
completion.
2. Notify your cook when a basket needs to be
shaken or a product needs to be turned.
3. Coordinate two products with different cooking
times which must be finished at the sametime.
A pre-alarmof 1 -secondto 99-minutes, 59-seconds
may be programmedfor each cook key.
w
1-4. HOLD CYCLE
Hold cycle automatically activates at the end of the
cook cycleandindicatestoyour cookwhenanunsold
product should be discarded.
1-5. HILIMIT SAFETY SENSOR
The Hi Limit is a safety device which continually
checks the temperature of the cooking oil. If the oil
rises40° abovethe set temperature, "Hi"will appear
in the display window. If the temperature reaches
425OF., the fryer automatic Hi Limit control is
activated. The burnerdelements will automatically
shut off. The fryer will not operate until the oil has
cooled and the fryer Hi Limit is reset.
NOTE: The reset button is located under the control
panel inside the fryer cabinet.
1-6. MANUAL MODE
A malfunction in the thermostat probe will result in
the word "Probe" appearing in the display window.
Turning off the computer will automatically engage
the back-up thermostat which is set at 350'. To
increase or decrease this temperature, remove the
control panel and adjust the thermostat dial. (See
Fryer Operator's Manual.)
1-7. MELT CYCLE
The computer comes pre-programmed with a melt
cycle. This allows solid shortening to be safely
melted.
The burnerdelements will cycle on for 5-seconds
andoff for 50-seconds, untiltheshortening ismelted.
Atthat point,the burnerdelementswill stay on until
the shortening reaches cooking temperature. Once
cooking temperature has been reached,
[-- - -1 will
appear inthe display window. The meltcycle may be
removed from the program if liquid shortening is
used. (See programming instructions, Section 3-7.)

SECTION 2
CONTROLS
/I
Computer
ControlledCooking
1. LED Display Window
6. Hold/ BoilControl Button
2. Cook Key
7. Temp/XFast Control Button
3. Cook Key lndentifier
8. Timer/Fast Control 'Button
4. Cook Key IndicatingLight
9. Test/Slow Control Button
5. Scan Control Button
2-1. LED DISPLAYWINDOW Cook -
Indicatesthe operation mode of the fryer. The COOK key activates a pre-programmed cook
cycle.There are eight cook keys, enablingyoutocook
Program -
ub to eight different products. A cooking cycle is
A display of "PR-A" melt mode indicates the activated by depressinga selected cook key.
computer is in the programming mode.
2-3. COOK KEY IDENTIFIER
Cook
-
When thecomputer isturnedon, "LO" willappear in There is oneCook Key Identifier beloweachcook key.
the display window. This indicatesthefryer isnot up The identifier allows the operator to label a cook key
to programtemperature. If meltcycle is programmed with the product for which that particular key is
(PR-A),the burners/elements will cycle on and off programmed.
until the fryer has reached 250°F. The burners/
elementswillthenstay on untilthefryer hasreached
the programmedcookingtemperature. If melt cycle is
removed (PR-F), burners/elements will stay on
continuously until fryer has reached program
temperature. At that point, the display window will
show
[- -- -1 andfryer isreadytocook.(SeeMeltCycle,
Section
3-7.)
During the cook cycle, the display windowwill show
thecooktimeremaining.The shortestcookingtime, if
more than one cook key is being used, will be
displayed.
2-2. COOK KEY
Proaram
-
2-4. COOK KEY INDICATING LIGHT
Program
-
Cook Key is selectedto set cookingtimefor eachof 8
products.
Cook
-
A Cook Key indicating lightwill flash to tell the cook
whichof the eight programsiscurrently inprocess.If
more than one Cook Key is inoperation at the same
time, the cycle with the least time remaining will
flash.The indicating lightsfortheother cookcyclesin
operation will be lit, but will not flash.
2-5. SCAN CONTROL BUTTON
Program
-
Q
TheSCAN control button isusedtoenter acommand
-
~eGessthe COOK key to programa cooking or pre- into the computer (temperature, time, pre-alarm,
alarm time for each of the eight cooking cycles. hold).

Cook - Cook -
When SCAN is pressed and held, cooking time BOlL is usedwhen boilingoutthefryer duringclean-
remaining for each cook cycle in operation will be up. Depressthe BOlL buttonafter thefryer has been
displayed for one second in sequence. Pre-alarm, filled with-water.The boil cycle will hold the water
hold alarm or completed cooking cycle alarm will temperature at 212OF. during boil-out.
override the SCAN function.
NEVER leavethefryer unattendedduringboil
2-6. HOLD/BOIL CONTROL BUTTON
Program
-
The Hold button is usedtoprogram the4 holdtimes
which tell your cook when a product should be
discarded.
The hold button does not need to be depressed to
activate the hold cycle in the ope.ration mode. The
HOLD cycle will automatically count down, once the
cooking cycle iscomplete andthecook key hasbeen
depressed.
cycle.
2-7. 'rEMP/XFAST CONTROL BUTTON
Program
-
Depress to programtemperature for all cook cycles.
TheXFAST button isused inthe program mode. It is
the fastest setting at which the displayed time or
temperature may be adjusted.
Cook
-
DepresstheTEMP bu'ttonat anytimetochecktheoil
temperature.Thetemperaturewillbedisplayedinthe
COOK KEY ACTIVATE LED display window.
#1 and #5 HOLD CYCLE (1H00) NOTE: Notemperature will display iftheoil isbelow
#2 and #6 HOLD CYCLE (2H00) 250°F.
#3 and #7 HOLD CYCLE (3H00) 2-8. TIMER/FAST CONTROL
#4 and #8 HOLD CYCLE (4H00) TheFASTbuttonisusedintheprogrammode.Itisthe
-
NOTE: Eachpair of CookKeysactivatethesameHold second fastest setting at whichthedisplayedtimeor
b
Cycle. For example, if both Cook Keys #I and #5 are temperature may be adjusted.
being used at the same time, the first cook cycle
completedwillactivate Hold#l.Ifthesumofthetime
2-9. TEST/SLOW CONTROL BUTTON
of Cook Cycle #1 and Hold Cycle #1 is lessthan the TheSLOW key isusedintheprogrammingmode.
It is
time required to complete Cook Cycle#5, then HOLD the slowest setting at which the displayed time or
will sound for Cook Key #l. temperature may be adjusted.
SECTION 3
PROGRAMMING
3-1. ENTER PROGRAM MODE
1. ACTION: Simultaneously press SCAN and TEMP.
RESPONSE: LED will display 18.
2. ACTION: Simultaneously press HOLD and TEST.
RESPONSE: LED will display PR-A.
NOTE: If LED displays PR--F, PressTEST 1.(Computer may be programmed ineither PR-A or PR-F.See
Section 3-7, MELTCYCLE.)
3-2. PROGRAM COOKING TEMPERATURE
1. ACTION: Press TEMP.
RESPONSE: LED will display pre-programmed temperature.
2. ACTION: PressXFAST then FAST then SLOW until
. . .
RESPONSE: LED displays desired cooking temperature.
3. ACTION: Press SCAN to enter temperature.
RESPONSE: LED will display PR-A.

3-3. PROGRAM COOK TIME
1. ACTION: Press selected cook key.
RESPONSE: LED will display pre-programmed cook time.
2. ACTION: Press XFAST then FAST then SLOW until
. . .
RESPONSE: LED displays desired cook time (minutes and seconds).
3. ACTION: Press SCAN to enter cook time.
RESPONSE: LED will display pre-alarm time.
NOTE: Cookingtemperature is nowset although PRE-ALARMtime isbeingdisplayed.To programPRE-
ALARM, proceedto Section 3-4, Step 3. If you want to exit program, pressSCAN andproceedto
3-6.
3-4. PROGRAM PRE-ALARM TIME z
NOTE: Use Steps 1 and 2 only if you have just entered PROGRAM MODE.
1. ACTION: Press selected cook key.
RESPONSE: LED will display pre-programmed cook time.
2. ACTION: Press SCAN key.
RESPONSE: LED will display PRE-ALARMtime.
3. ACTION: PressXFAST then FAST then SLOW until'.
. .
RESPONSE: LED displays desired pre-alarmtime.
NOTE: Set time to 000 if no pre-alarm is desired.
4. ACTION: PressSCAN to enter pre-alarm time.
RESPONSE: LED will display PR-A.
NOTE: To program additional cook keys, returnto Step 1. (lo exit, proceed to 3-6.)
-
3-5. PROGRAM HOLD TIME U
NOTE: If you are beginning at this point, first enter PROGRAM MODE, Section 3-1, Steps 1 and 2.
1. ACTION: Press HOLD
RESPONSE: LED will display 1
H00.
NOTE: Hold time isdisplayed inminutes only.
2. ACTION: PressXFAST then FAST then SLOW until
. . .
RESPONSE: LED displays desired holdtime.
NOTE: Set HOLD to "OC" if no holdtime is desired.
3. ACTION: Press SCAN to enter hold time.
RESPONSE: LED will display 2H00.
NOTE: Repeat Steps 2 and 3 to program each of 4 holdtimes.
3-6. EXIT PROGRAM
NO'CE: Press SCAN until PR-A or PR-F is displayed.
1. ACTION: Simultaneously press SCAN and TEMP.
RESPONSE: LED will display
[-- - -1.
3-7. MELT CYCLE
ACAIJTION: MELT CYCLE should be removed from the program ONLY if liquid shortening is
being used.
1. ACTION: PressTEST.
RESPONSE: LED will display PR-F.
2. ACTION: Simultaneously press SCAN and TEMP.
RESPONSE: LED will display
[- - - -1.
