Keces S4 User manual

S4
Stereo Preamplifier
USER MANUAL

Warning
1. Installation and service should be performed only by qualified and
experienced technicians and comply with all local codes and rules to
maintain your warranty.
2. To reduce the risk of fire or electric shock, do not expose the product to
rain or moisture.
3. Wipe the case with a dry soft cloth. For tough stains, slightly apply with
diluted neutral detergent and wipe with a dry soft cloth.
4. Do not apply benzene or thinner to the case, which may cause the surface of
unit to be melted or fogged.
5. Avoid operating or storing the unit in the following locations:
6. Extremely humid, dusty, or hot/cold environments (recommended operating
temperature: 0°C to +40°C)Close to sources of powerful radio or TV
transmitters.
Get Started
This user manual is designed as a reference for the installation and
manipulations of the unit including the product’s features, functions.
Please read this manual thoroughly and save it for future use before
attempting to connect or operate the unit. The reader is supposed to be
able to get the following information in this manual.
1. Product Overview: the main functions and system requirements of
the unit.
2. Installation and Connection: instructions on unit installation and wire
connections.
3. Administration and Configuration: the main menu navigation and
controls explanations.

FCC Compliance Statement
Information to the user: This unit has been tested and found to comply with
the limits for FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that
may cause undesired operation. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This unit generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the manual, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this unit does cause harmful interference to radio or television reception,
which can be determined by turning the unit off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the unit and receiver.
3. Connect the unit to an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
<
Caution
>
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the unit.

Pack Contents
1. KECES S4 Preamplifier
2. KECES S4 Power
3. KECES Remote
4. AC Power Cable
5. DC Power Cable
6. User manual
7. DC12V Trigger Cable
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation. The manufacturer declares that the unit supplied with this guide
is compliant with the essential protection requirements of EMC
(2014/30/EU) Directive and General Product Safety (2014/35/EU)
Directive.
CE Statement

Unpacking Your S4 & Placement Guidelines
Unpacking
Carefully remove your S4 from its shipping carton and locate the enclosed
accessories:
• AC and DC power cord
• A 12V trigger wire for auto turn on. It has a mono 3.5 mm mini plug at each end.
• Remote.
While you are unpacking your S4, inspect it thoroughly for possible shipping
damage and tell your KECES dealer immediately if you find any evidence of
shipping damage. This would be a good time to make a copy of your sales
receipt to store with the S4’s original packing.
Note:
Please save and store both the inner and outer cartons and, most especially, the
foam packing inserts to protect the S4 if you have to move it or ship it. You may
wish to flatten the cardboard cartons to save room in storage after cutting the
taped seams on the bottom flaps.
--------------------------------------------------------------------------------------------------------
Placement Guidelines
The S4 will be easier to use and will last longer if you follow these simple
guidelines:
• Place the S4 on a surface that will adequately support its weight.
• Use input and output cables that are long enough to leave some slack; that will
enable you to pull the S4 out of a cabinet to check or to change connections
without inadvertently disconnecting cables.
• The S4 should never be placed in a completely enclosed cabinet.
• Place your S4 where you can route input and output signal cables as far as
possible from any AC cords.
Ventilation Requirements
• Always position the S4 horizontally.
• The S4 should never be stacked directly above another power amplifier or
directly below another component.
• Do not install the S4 in an unventilated equipment cabinet or compartment.
Pockets of stagnant hot air can build up even in a cabinet with an open front and
back. A ventilation fan is recommended to prevent “hot spots” in confined
spaces.

AC Mains Voltage
Make sure the 115V/230V Voltage Selector switch on the S4 Power bottom plate
is set for the correct Ac line(mains) voltage before you plug in the power cord. It
can be seriously damaged if this switch is set for the wrong AC mains voltage.
In the 115V position the S4 can safely operate with AC Line voltages between
110-125V which is correct for North America, Mexico, and Taiwan. In some
countries, such as Brazil, AC voltages differ by region. Most other countries
require setting it to 230V. With the 230V setting the S4 can operate safely with AC
line voltages between 220-250V. If the AC Voltage Selector is changed the rear
panel fuse value must also be changed. The S4 operates on 50Hz or 60Hz AC.
Note:
An S4 that has been damaged by connection to the incorrect AC mains voltage
is not covered by the KECES warranty.
--------------------------------------------------------------------------------------------------------

Interface

Audio Connections
Always disconnect the AC cord to your S4 Power before making or changing any
input, output or trigger wire connections. Inserting or removing an input or output
cable while the S4 is turned on can result in a blast of sound that can damage
your loudspeakers. Make sure there is no strain or tension on any cables that
could cause them to pull loose.
Audio Input Connections
Balanced XLR Input/Output Jacks
In most systems balanced XLR connections will give you the best sound. If your
Source/Power Amplifier have balanced XLR output/Input jacks, we recommend
that you connect them to the S4 inputs/output. Refer to the Balanced and
Unbalanced Lines in Technically Speaking section for additional information
about why we recommend using balanced lines.
Unbalanced RCA Input/Output Jacks
Use these inputs/output if your source/power amplifier don’t have balanced XLR
output/input connections or if you simply prefer to use unbalanced connections.
MM/MC Input RCA Jack and Selector Switch
Place the switch for the MM or MC on the rear panel. When switch to MC mode,
please also selector the loading impedance. When switch to MM mode, you do
not need select any impedance.
Optical (DS Audio) Input RCA Jack
It is optical cartridge input.
Balanced XLR Pin Configuration
The S4 XLR jacks conform to the industry standard of:
Pin 1: Ground Pin 2: Positive(+) Pin 3: Negative(-)

Front Panel Operation
Knob
Push 3 seconds to turn on/off the S4. When the S4 is turned on the S4 Power
LED will change from Red to Blue. Short push it to select input channel. Spin to
change the volume.
Mute/Dim
When push the mute button, the display will be flashing. Push any button or
change the volume can remove the mute.
When push the Dim button, all of LED will turn off. Push any button or change the
volume can remove the Dim.
Headphones+Pre out/Headphones Only
Headphones +Pre out means Headphones and speakers both are output the
sounds.
Headphones Only means just speakers output the sounds.
Problems and Remedies
Unit will not turn on
• Check the trigger cable is secure between S4 and S4 Power.
• Check that the rear panel power switch is on and that the AC power is live.
No sound from speakers
• Check that input/output cables wires are secure at both ends.
• Make sure the S4 is switched to the correct input.
Overheating
• Remove any nearby external sources of heat such other audio equipment or
heaters.
• Increase ventilation around the S4.

Specifications
Input
MM/MC*1, Optical*1, RCA*1, XLR*2
Input Impedance
MC: 56/100/220/470/47K, MM: 47K,
Opt: more than 10K
RCA/XLR:170K
Output
RCA*2, XLR*1, Headphone XLR-4pin
Total harmonic distortion (THD+N)
MM<0.02%, MC<0.05%, OPT<0.04%
RCA<0.0015%, XLR<0.0015%
S/N R:
MM:78dB A-Weighted, MC: 70dB
A-weighted, Optical: 75dB A-weighted
RCA: 110db A-weighted, XLR: 110dB
A-weighted
Gain
MM:52dB, MC:72dB, Opt:32dB
RCA/XLR: 20dB
Power Requirement
Standby: 0.5 Watt
Maximum: 90 Watts
Casing
All Aluminum
Dimension (WxDxH)
300x279x66mm*2
Weight
Net Weight 4.5KG(Power)+3.5KG(Pre)
Shipping Weight 10KG

S4 產品使用手冊'
中文版'

包裝內容
* KECES S4 前級擴大機
* KECES S4 電源供應器
* KECES 遙控器
* AC 電源線
* DC 電源線
*產品使用手冊 (內含保固卡)
* DC12V 觸動線
S4
使用準則
將S4 從箱中取出，並找到所附的配件。
* AC/DC 電源線
* 12V 觸發連接線。兩端各有一個 3.5 毫米單聲道迷你插頭。
* 遙控器
當您打開 S4 的包裝時，請檢查是否有損壞，如果發現任何因運
輸過程造成之損壞，請立即連繫 KECES 經銷商。並請妥善留存 S4 原始包裝與
產品、配件及保修卡。
-
注意
- 如需移動或裝運 S4，請妥善保存內外紙箱，以及 EPE 泡棉，以防 S4 本體
之損壞。
安裝指南
以下準則，將有助您瞭解如何使用 S4，並延長產品之使用年限：
* 將S4 放置於平坦且穩固的桌面或平台。
* 您所使用的輸入和輸出電源線必須預留一定的長度；使您能夠將
S4 從機櫃中拉出以檢查或更改連接，以不造成線材鬆脫。
* 請勿將 S4 放在完全封閉的機櫃中。
* 將S4 放置在您可以插拔輸入和輸出信號線的地方，並且盡可能
遠離電源線。
通風要求
* 水平放置 S4。
* 因開機後需保持良好的通風，故請勿將 S4 堆疊在其他功率放大
器上方或下方。
* 請勿將 S4 安裝在不通風處。即使放置在單面開啟的櫥櫃中，亦
會造成機器通風不良。建議使用通風風扇，以防止因密閉空間而出
現過熱情況發生。

交流電源電壓
在插入電源線前，請確認 S4 Power 底板上的 115V / 230V 電壓選擇開關是否為正
確的交流電壓。若開關切換至錯誤的交流電壓，會使機器產生嚴重損壞。
電壓設置為 115V 時，S4 可以在交流電壓介於110-125V 時使用，適用於北美、墨
西哥和台灣。在某些國家/地區，如巴西，交流電壓會因地區而異。
其他大多數國家/地區都要求將其設置為 230V。電壓切換為230V 時，S4 可以在
220-250V 之間的交流電壓下安全運作。
若切換交流電壓，必須同時更換背面板的保險絲。S4 可以正常運作在50Hz 或60Hz
AC 的環境下。
-
注意
- KECES 產品之保固範圍，不包含因交流電源電壓連接錯誤
而造成之損壞。
音頻連接
在安裝輸入或輸出信號線甚至 12V 觸發線前，請務必拔除電源線。若S4 處於開機
狀態時插入或拔除信號線，可能會產生爆炸聲並造成機器或喇叭損壞。
音頻輸入連接
平衡XLR 輸入、輸出
在大多數系統中，平衡XLR 連接將為您帶來最佳的聲音。如果你的訊源、後級放
大器具有平衡的XLR 輸出、輸入插孔，建議您將它們連接到 S4 輸入、輸出。
非平衡的RCA 輸入、輸出插孔
用於您的訊源、後級放大器沒有平衡的XLR 輸出連接，或者您只想使用非平衡的
連接。
ＭＭ/ＭＣ的RCA 輸入和切換開關
MM/MC 輸入需要透過背板來做切換。另外，MC 輸入阻抗可以透過背板的開寬來
做切換ㄡ。MM 輸入不需要做任何的輸入阻抗切換。
Optical 的RCA 輸入
此檔位是給DS Audio 的光學唱頭使用。
平衡XLR 引腳配置
S4 XLR 插孔符合以下標準:
Pin 1: 地 Pin 2:正極 Pin 3:負極

外觀

前面板操作
旋鈕
當S4 Power 電源開啟，按壓此選鈕三秒鐘後開、關機（S4 Powere 關機 LED 亮
紅燈，開機亮藍燈）。切換輸入檔位，短按壓此選鈕做切換選擇。調整音量則旋轉
此選扭來改變音量大小。
Mute/Dim
按壓Mute 時，此時音量數字會閃爍，代表進入靜音模式。隨意按下一顆按鈕或音
量調整及解除。
按壓Dim 時，所有燈號顯示會關掉。隨意按下一顆按鈕或音量調整及解除。
Headphones+Pre out/Headphones Only
Headphones+Pre 代表耳機和喇叭同時輸出聲音。
Headphones Only 代表只有耳機輸出聲音。
問題和補救措施
機器無法開啟
* 檢查 S4 到S4 Power 的觸發線是否有接上。
* 檢查 S4 Power 後面板電源開關是否已打開以及交流電源是否在正確電壓。
揚聲器無聲音
* 檢查信號輸入輸出線是否牢固。
* 確保 S4 切換到正確的輸入。
過熱
* 移除附近的任何其他外部熱源，例如其他音頻設備或加熱器。
* 保持 S4 周圍的通風。

規格'
Input
MM/MC*1, Optical*1, RCA*1, XLR*2
Input Impedance
MC: 56/100/220/470/47K, MM: 47K,
Opt: more than 10K
RCA/XLR:220K
Output
RCA*2, XLR*1, Headphone XLR-4pin
Total harmonic distortion (THD+N)
MM<0.02%, MC<0.05%, OPT<0.04%
RCA<0.0015%, XLR<0.0015%
S/N R:
MM:78dB A-Weighted, MC: 70dB
A-weighted, Optical: 75dB A-weighted
RCA: 110db A-weighted, XLR: 110dB
A-weighted
Gain
MM:52dB, MC:72dB, Opt:32dB
RCA/XLR: 20dB
Power Requirement
Standby: 0.5 Watt
Maximum: 90 Watts
Casing
All Aluminum
Dimension (WxDxH)
300x279x66mm*2
Weight
Net Weight
4.5KG(Power)+3.5KG(Pre)KG
Shipping Weight 10KG

S4
Stereo Vorverstärker mit Phonovorstufe
Bedienungsanleitung
