Kedacom KDM2410M User manual

KDM2410M
Installation Guide

Trademarks
Kedacom™, TrueSens™ and are registered trademarks of Suzhou Keda
Technology Co., Ltd. in China and various other countries. All other trademarks mentioned
in this document are the property of their respective holders.
Suzhou Keda Technology Co., Ltd.
131 Jinshan Road
New District, Suzhou, 215011
People's Republic of China
http://www.kedacom.com/en
Tel: [phone]
Fax: [phone]
© 2016 Suzhou Keda Technology Co., Ltd. All rights reserved.
Without the prior written permission of Suzhou Keda Technology Co., Ltd., any reproduction,
translation or retransmission of all or any part of this document for any purpose in either
electronic or mechanical form is not allowed.
Notice
The information in this document is subject to change without notice. Every effort has been
made in the preparation of this document to ensure accuracy of the contents, but all
statements, information, and recommendations in this document do not constitute a warranty
of any kind,express or implied. Suzhou Keda Technology Co., Ltd. is not responsible for
printing or clerical errors.
™

About the KDM2410M
1 Product Introduction
2 Product Appearance
2.1 Front Panel
On the front panel of the Mobile NVR, you can see the following items:
1
Kedacom KDM2410M (hereinafter referred to as the Mobile NVR) supports 3G/4G/WiFi/WiFi-
AP wireless network transmission, satellite positioning, and H.264 and H.265 encoding
formats. The Mobile NVR accommodates two SIM cards, one 2.5-inch hard disk drive (HDD) or
solid-state drive (SSD), and one secure digital (SD) card. For storage devices, the Mobile NVR
adopts the hard disk vibration damping technology. The Mobile NVR can connect to PTZ
cameras and control them. The Mobile NVR can be controlled by Kedacom Video Management
System (VMS), which is a comprehensive platform for managing cameras, NVRs, encoders,
and decoders.
3G signal bar
Power indicator
VMS connection indicator GPS indicator
SD card indicator
Disk indicator
Ethernet port USB port SD card slot
Reset button
Pressing and holding this
button for 5s will reset the
system to factory defaults.
Audio out Audio in
Hook the groove on the cover
and gently open the cover.

2
The following table helps you read the indicators on the front panel.
Indicator State Description
3G signal bar On A 3G or 4G connection is established.
Off No 3G or 4G connection is established.
Power On The Mobile NVR is powered on.
Off The Mobile NVR is powered off.
VMS connection On The Mobile NVR is connected to a VMS.
Off The Mobile NVR is disconnected from the VMS.
GPS
Blue The Mobile NVR is collecting data.
Red Data Error
Off The GPS module of the Mobile NVR is faulty.
SD
Blue An SD card is installed.
Blinking blue The Mobile NVR is performing the writing or reading
operation on the SD card.
Red The SD card is faulty.
Off No SD card is installed.
Disk
Blinking blue The Mobile NVR is performing the writing or reading
operation on the disk.
Red No disk is installed, the disk is not formatted, or the disk is
faulty.

2.2 Inserting a Disk
Hard disk tray
Disk lock
Disk slider
4
32
On the front panel, you can insert one disk. To insert a disk:
Slide the slider right to unlock the protection mask.
1.
Take out the key from the key slot.
2.
1
3. Insert the key into the disk lock and turn the key clockwise to unlock the disk slider.
4. Slide the disk slider left to unlock the hard disk tray.
When the hard disk tray is unlocked but you do not insert or remove a disk, the KDM2410 will
sound the buzzer at an interval of 3s.
5. Press the left end of the hard disk tray until the right end stands up.
5
Key slot
3

4
Pull out the hard disk tray from the disk slot and unscrew the cover of the hard disk tray.
6.
7. Put the disk into the hard disk tray and screw it.
8. Put the hard disk tray back to the disk slot.
Slide the disk slider right to lock the hard disk tray.
9.
Turn the key counterclockwise to lock the disk slider.
10.
Put the key back to the key slot.
11.
Lock the protection mask.
12.
2.3 Rear Panel
Camera
PTZ camera Car power
GPS antenna
3G
3G
Extension port
Alarm light
1 × alarm output
Smoke detector
4 × alarm input
Monitoring keyboard
(Optional) Antenna for
the BeiDou Navigation
Satellite system
(Optional)
3G/4G antenna
Monitor WIFI antenna
Feed power to
vehicle PTZ
cameras (9-36 V)
The following figure shows the rear panel of the Mobile NVR.

2.4 Pins
1
2
34
1+2
3+4
Red VCC_PTZ
Black GND_PTZ
PWR-PTZ
1+2+3+4
6+7+8+9
Red CAR_IN+
Black CAR_IN-
PWR
Yellow ACC
5
1
2
3
4
5
67
8
9
CAM 2+3
5
6
7
Red 12V_OUT
Black GND
Black GND
Green AUDIO IN
1+4+8+9
10
Black ETH
Yellow VIDEO IN
5
1
2
3
4
6
7
8
9
10
MULTI-MEDIA 1
2
3
4
5
6
7
8
9
10
Red 12V_OUT
Yellow VIDEO OUT
Green AUDIO IN
Red RS485A
Black GND
Black GND
Yellow AUDIO OUT
Green RS485B
Red DP
Green DM
[Aviation Plugs]
[Extension port] Orange RS232_TXD
Brown RS485-A
White ALM_IN2
Green RS232_RXD
Black 4×GND
Purple ALM_OUT_B
Red RS485-B
Blue ALM_OUT_A
Yellow ALM_IN3
Pink ALM_IN4
White ALM_IN1
51
2
3
4
6
7
8
9
10
5
Requiring 18 AWG cables or cables with a
greater diameter (for example 16 AWG)
VCC: Requiring 16 AWG cables or cables with a greater
diameter (for example 14 AWG)
CAR:
Requiring 22 AWG cables or cables with a greater
diameter (for example 18 AWG)
ACC:
Same as above
GND:
Requiring 18 AWG cables or cables with a greater
diameter (for example 16 AWG)
VCC:
Same as above
GND:
The PWR plug supports the 12/24 V power inputs.
Before using the Mobile NVR, connect CAR_IN+ to the
anode of the car battery, CAR_IN- to the cathode of
the car battery, and ACC to the ignition system of the car.
This can achieve delayed poweron and poweroff for the
Mobile NVR.
The CAM plug supports the 12 V (12 W) DC power
output.
The MULTI-MEDIA plug supports the 12 V (24 W) DC
power output. The DP and DM pins can connect to USB
storage devices.
The PWR-PTZ plug can connect only to 9-36 V PTZ
cameras.

1.3×105
2.4×105
7×105
Particle Diameter Range
[0, 0.5]
[0.6,1]
[1.1,3.0]
[3.1,5.0]
Number of Particles per Cubic Meter
Installing the Mobile NVR
1 Preparations
1 .1 System Specifications
1 .2 Equipment Cleanliness
The following table provides the mapping between the particle diameter range and number of
particles per cubic meter.
Ensure that the specifications of the Mobile NVR are complied with. For example, the operating
temperature for the NVR must be within the range of -40°C to 70°C.
For the physical specifications of the Mobile NVR, see chapter "Physical Specifications."
6
1.4×107
You must install the Mobile NVR in an environment as free from dust and foreign conductive
material (such as metal flakes from construction activities) as is possible.
1 .3 ESD
To reduce the effects of electrostatic discharge (ESD), you should observe the following
guidelines.
Wear a grounding wrist strap. If a grounding wrist strap is unavailable, touch an unpainted
metal surface on the appliance chassis periodically to neutralize any static charge.
Keep components in their antistatic packaging until they are installed.
Avoid wearing clothing made of wool or synthetic materials.
Ensure that the Mobile NVR is well grounded.
Keep the area around the Mobile NVR clean, free of clutter, and well ventilated.
Ensure that the operating temperature and the relative humidity within the range complying
with the Mobile NVR.

1 .4 EMI
2 Unpacking
Perform the following steps to unpack the system:
1) Inspect the package to make sure that it has not been damaged.
If you find damage, contact the local authorized Kedacom agent.
2) Open the package and check whether any item on the packing list is missing.
3) Take all items out of the package and check whether any item is in poor condition.
If you find damage, contact the local authorized Kedacom agent.
To shield electromagnetic interference (EMI), you should observe the following guidelines:
Keep the ground system of the Mobile NVR away from that of the power supply system or
lightning protection system.
Place the Mobile NVR away from high-frequency devices, such as radio or radar stations.
When necessary, deploy EMI shielding devices.
7
3 Installing the Mobile NVR
To install the Mobile NVR, contact the local authorized Kedacom agent.
After the installation is completed, please note the following:
To power on the Mobile NVR, turn on your car engine.
To power off the Mobile NVR, shut your car engine off.
For details on how to use the Mobile NVR, see the user guide inlcuded in the KEDACOM
Document and Utility CD.
4 Power-on Self-Test
After the Mobile NVR is powered on, check whether the six indicators on the front panel are
normal. If not, contact the local authorized Kedacom agent.
To prevent the risk of lightning, you are advised to ensure the following:
The Mobile NVR is well grounded.
Based on onsite conditions, install lightning arrestors.
5 Product Care
5.1 Lightning Protection

8
Type
Battery Life
No Charge
Replacement
Refer to the manufacturer's instructions or contact the manufacturer for details.
When the battery loses its charge, the CMOS data (such as the system time
and BIOS settings) may be incorrect or even lost.
1. Prepare a new ML414H-IV01E battery.
2. Switch off the Mobile NVR and disconnect it from a power outlet.
3. Wear a grounding wrist strap to replace the old battery with the new one.
During replacement, do not mix up the anode and cathode.
Contact the local authorized Kedacom agent if you encounter any problem
when replacing the battery.
Disposal Dispose of used batteries according to local laws or regulations.
6.2 Battery Replacement
6.3 Miscellaneous
Do not place heavy objects on the Mobile NVR. Do not block the air vent.
Switch off the Mobile NVR if you are not using it for a long period of time.
Regularly check the Internet connection status of the Mobile NVR.
ML414H-IV01E (a coin-cell battery)

9
Initial Configuration
To initially configure the Mobile NVR:
1. Configure network settings.
2. Enter the VMS configurations.
3. Set the time.
For details, see chapter Getting Started of the user guide for the Mobile NVR.
The following table provides the physical specifications of the Mobile NVR.
Physical Specifications
9-36 V
15 W (HDD not included)
-40℃ to 70℃
-60 m-5000 m
60 mm x 188.4 mm x 252 mm
2.45 kg (HDD not included)
10% to 85% (non-condensing)
Power
Power consumption
Operating temperature
Operating humidity
Elevation
Size(height x width x depth)
Weight

10
This page is intentionally left blank.

WHAT IS COVERED BY THIS WARRANTY?
Kedacom warrants the Kedacom-branded hardware product and accessories contained in the original
packaging (hereinafter referred to as "Kedacom Product") against defects in materials and workmanship when
used normally in accordance with Kedacom's published guidelines for a period of TWO (2) YEARS from the
date of original retail purchase in areas other than mainland China by the end-user purchaser (hereinafter
referred to as "Warranty Period"). For the Kedacom Product purchased in mainland China, see the simplified
Chinese version of this warranty for details. Kedacom's published guidelines include but are not limited to
information contained in technical specifications, user guides, and service communications.
The preceding applies unless otherwise agreed in the contract.
Kedacom Two (2) Year Limited Hardware Warranty
WHAT IS NOT COVERED BY THIS WARRANTY?
This warranty does not apply to any non-Kedacom branded hardware products or any software, even if
packaged or sold with Kedacom hardware. Manufacturers, suppliers, or publishers, other than Kedacom, may
provide their own warranties to you but Kedacom, in so far as permitted by law, provides their products "AS IS".
Software distributed by Kedacom with or without the Kedacom brand (including, but not limited to system
software) is not covered by this warranty. Please refer to the licensing agreement accompanying the software
for details of your rights with respect to its use. Kedacom does not warrant that the operation of the Kedacom
Product will be uninterrupted or error-free. Kedacom is not responsible for damage arising from failures to
follow instructions relating to the Kedacom Product's use.
This warranty does not apply: (a) to consumable parts, such as batteries, unless failure has occurred due to a
defect in materials or workmanship; (b) to cosmetic damage, including but not limited to scratches, dents, and
broken plastic on ports; (c) to damage caused by use with another product; (d) to damage caused by acts
outside the control of Kedacom, including without limitation acts of God, accidents, abuse, misuse, fire,
storms, earthquakes, flood, or other external cause; (e) to damage caused by exposure of the product to heat,
bright light, sun, liquids, sand, or other contaminants; (f) to damage caused by operating the Kedacom Product
outside Kedacom's published guidelines; (g) to damage caused by service (including upgrades and
expansions) performed by anyone other than a representative of Kedacom, Kedacom employee, or authorized
Kedacom agent; (h) to an Kedacom Product that has been modified to alter functionality or capability without
the written permission of Kedacom; (i) to defects caused by normal wear and tear or otherwise due to the
normal aging of the Kedacom Product, or (j) if any serial number has been removed or defaced from the
Kedacom Product.
YOUR RESPONSIBILITIES
If your Kedacom product is capable of storing data and other information, you should make periodic backup
copies of the information contained on the storage media to protect the contents and as a precaution against
possible operational failures.
Before receiving warranty service, Kedacom or its authorized agents may require that you furnish proof of
purchase details, respond to questions designed to assist with diagnosing potential issues, and follow
Kedacom's procedures for obtaining warranty service. Before submitting your Kedacom Product for warranty
service, you should maintain a separate backup copy of the contents of its storage media, remove all personal
information that you want to protect, and disable all security passwords.

During warranty service, it is possible that the contents of the Kedacom product's storage media will be lost,
replaced or reformatted. In such an event, Kedacom and its authorized agents are not responsible for any loss
of data or other information contained on the storage media or any other part of the Kedacom product serviced.
Following warranty service, your Kedacom Product or a replacement product will be returned to you as your
Kedacom Product was configured when originally purchased, subject to applicable updates. You will be
responsible for reinstalling all other data and information. Recovery and reinstallation of other data and
information are not covered under this warranty.
WHAT WILL KEDACOM DO IF THE WARRANTY IS BREACHED?
If during the Warranty Period, you submit a valid claim to Kedacom or an authorized Kedacom agent, Kedacom
will, at its option, (i) repair the Kedacom Product using new or previously used parts that are equivalent to new
in performance and reliability, or (ii) exchange the Kedacom Product for a refund of your purchase price.
A Kedacom replacement part or product, including a user-installable Kedacom part that has been installed in
accordance with instructions provided by Kedacom, assumes the remaining warranty of the Kedacom Product
or ninety (90) days from the date of replacement or repair, whichever provides longer coverage for you. When a
product or part is replaced or a refund provided, any replacement item becomes your property and the replaced
or refunded item becomes Kedacom's property.
Kedacom reserves the right to refund the purchase price as its exclusive warranty remedy.
HOW TO OBTAIN WARRANTY SERVICE?
To seek warranty service, please contact a local authorized Kedacom agent. When contacting the agent via
telephone, other charges may apply depending on your location.
User Information
Complete the form below and keep for ready reference.
User Name:
Address: Postal Code:
Tel: Mobile:
Fax: E-Mail:
Product Name: Product Model:
Date of Purchase:

中国: 江苏省苏州市高新区金山路131号(215011)
Tel: [phone] Fax: [phone]
Suzhou Keda Technology Co.,Ltd.
Singapore: 627A Aljunied Road, #09-07, BizTech Centre, Singapore 389842
Tel: [phone] Fax: [phone]
05.03.800425 V1 20160826
