ThankyouforchoosingRKV200G-atwo-wheeledmotorcycle.This
motorcyclewasmanufacturedbycombininglocalandinternationalad-
vancedtechnologiesandwouldcertainlybringyouahappy andsafe
ridingexperience.
Motorcycleridingisoneofthemostexcitingsportsactivity.You
areadvisedtofullyunderstandtherulesandrequirementsasstipulated
inthismanual.Thisinstructionmanualcoverstheproperoperationand
maintenanceprocedures so as toensure the maximum performance
andlifespanofyourmotorcycle.
Ourcompanyis equippedwithprofessional technicalmainte-
nance personnel and department, which is able to provide you with
highqualitytechnicalmaintenanceservices.Believingintheprinciple
of“customerrst”ourcompanyputtogethergreateffortstodeveloptop
qualityproductsandperformance.
Please read carefully this manual and stand by the key rules. The
wordsof“Note”,“Caution”and“Attention”areusedheretoindicatethe
degreeofimportance.
Pleasemakesurethatyouunderstandfullythemeaningsasfollows:
Preface Note / Caution / Attention
Running-in of Motorcycle
Maintenanceofthemotorcycleduringtherst1600kmisthemostvitalpartofitsentiremotorcyclelife.Iftherunning-in
isconductedinaccordancewiththeschedule,thenalongestservicelifecanbeassuredandthetopperformanceofthe
newmotorcyclecanbefullyachieved.
RKV MANUAL - ARTWORK.indd 3 23/7/2013 11:10:51 AM
4
Anti-Theft Suggestion
1. Makesurethemotorcycleislockedeverytimeyouparkandtake
offthekeys.
2. Ifitispossible,parkyourmotorcycleinaclosedparkingarea.
Safety Notes
Safety Riding Rules
Helmet & Protection Clothes
Thisinstruction manualis apermanent documentof thismotorcycle
andifthismotorcycleissoldtoanotherpurchaser,itshouldbetrans-
ferredtothesaidpurchaser.
1. Thisisanon-roadmotorcycleandnotacompetitiontypeoran
off-roadridingvehicle;otherwiseallconsequencesaretobe
undertheresponsibilityoftherider.
2. Have a complete inspection before starting the engine so as to
preventpossibleaccidentsordamagesofmotorcycleparts.
3. The rider shall pass the examinations regulated by the Road &
TransportDepartmentandreceivethedrivinglicensebeforerid-
ingthemotorcycle.Neverlendittoanypeoplewithoutadriving
license.
4. Toavoiddamagesbyothermotorvehicles,theridershalltryhis/
herbesttobenoticedbyotherpeopleincluding:
-Wearingbrightclothes;
-Keepingawayfromothermotorvehicles;
5. Theridershallstandbythenationallocallawsandrules;
-Speedingisonethekeyreasonsofaccidents.
Sokeepthespeedwithinthelimitasstipulatedbythe
authorities.
6. Turn on the headlamp so as to be noticed by other road users
whennegotiatingcornersorchanginglanes.
7. Ridecautiouslyonfastlanes,crosswaysandpassagewaysin
parkingareas.
8. During riding the motorcycle, the rider should hold the handles
withbothhandsandwithbothfeetonthepedalswhilethepas-
sengershould holdthe motorcycleor the riderwith bothhis/her
handswithbothfeetonthepassengerpedals.
1. Forthepurposeofpersonalsafety,theridershouldwearasafety
helmetandamaskor goggles,andalsospecial boots,gloves
andprotectionclothes.Thepassengershallalsowearasafety
helmet.
2. The exhaust system would burn during riding and a short mo-
mentafterturningofftheengine.Nevertouchitduringthisperiod
andtheriderandpassengershallwearapairoflongbootsorthe
clothesthatcancoverthelegs.
3. Don’twearthoselooseclothesthatcouldbetrappedbythecontrol
levers,startingsets,pedalsorwheels.
9. Anyre-congurationordisassemblyofthepartswouldaffectthe
maintenancedataandthesafetyoftherider.
10. Thearrangementofaccessoriesshallnotaffectthesafetyofthe
riderandtheoperationperformanceofthemotorcyclebutover-
loading the electrical systems would effect the safety of the
motorcycle.
For safety purposes, the rider should be par-
ticularly careful with understanding on the
safety notes before riding.
RKV MANUAL - ARTWORK.indd 4 23/7/2013 11:10:51 AM
5
Serial Number
VehicleIdenticationNumber(VIN)andthe SerialNumberareused
fortheregistrationofthemotorcycle.Itwouldalsobeusedtoensure
thatthedistributiondepartmentcouldprovideyouwithbetterservices
whichinvolveinpurchasingofaccessoriesorotherconsignmentser-
vices.
Rememberthenumbersforthesaidpossibleusesinthefuture.
(A) VehicleIdenticationNumber(VIN)isprintedontherightsideof
theheadtube.
(B)EngineNumberisprintedontheleftsideofthecrankcase.
(C) Product Nameplate is one the right back side of the head tube,
which is printed with the product model, frame number, noise limit,
manufacturingcompanyandotherrelativeinformation.
VEHICLE IDENTIFICATIONS NUMBER (VIN):
ENGINE NUMBER:
Pleasewritedownthenumbersforyourreferences;
RKV MANUAL - ARTWORK.indd 5 23/7/2013 11:10:51 AM
6
1.PlateBracket
2.Tail/BrakeLight
3.PassengerSeat
4.RiderSeat
5.Fueltank
6.SideMirror
7.FrontFlasherLamp
8.Headlight
9.Mudguard
10.FrontTire
11.RearBrakePedal
12.RightRiderFootrest
13.RightPassengerFootrest
14.RearBrakeDisc
15.Exhaust
2
1
3
4
5
6
7
8
9
10
1112131415
Conguration of Parts
RKV MANUAL - ARTWORK.indd 6 23/7/2013 11:10:52 AM
7
1.FrontBrakeDisc
2.LeftFlasherLamp
3.FuelCockLever
4.RearShockAbsorber
5.DriveChain
6.LeftPassengerFootrest
7.MainStand
8.SideStand
9.LeftRiderFootrest
10.GearLever
3
8
14
1
2
4
5678910
RKV MANUAL - ARTWORK.indd 7 23/7/2013 11:10:52 AM
8
1)Turnsignalswitch
2)Headlightdimmerswitch
3)ChokeLever
4)Instrumentpanel
5)Ignitionswitch
6)On/Offswitch
7)Throttlegrip
8)ElectricStarterswitch
9)Hornswitch
1)Tachometer
2)FuelLevel
3)NeutralIndicator
4)DigitalSpeedometer
5)Odometer
Handlebar and Instruments Instruments and indicators
RKV MANUAL - ARTWORK.indd 8 23/7/2013 11:10:53 AM
9
Ignition Switch
Switchingisusedtocontrolopeningandclosingofthecircuit.
Advise:
Iftheengineisnotworking,pleaseswitchoffthemainswitch,toavoid
batterydrainordamage.
Lock
Donotforgettolockyourhandlebarwhenparking
1. Turnhandlebaruntillimitposition
2. Insertkeyandturnclockwise
3. Takeoutthekey
Howtoopenhandlebarlock.
TurnkeytoOFFposition
Main Switch Handlebar lock
Switch OFF
• Engineisstopped
• Lightscan’tbeused
• Hornnotworking
• Enginewon’tstart
Switch ON
• Enginecanbestarted
• Lightsonandworknormally
• Hornsisfunctioning
RKV MANUAL - ARTWORK.indd 9 23/7/2013 11:10:54 AM
10
Right Handle
1. On/Offswitch-
• When the switch is pressed to the position of “ ”, the whole
circuitisconnectedandtheenginecanbestartedup.
• When the switch is pressed to the position of “ ”, the whole
circuitisdisconnectedandtheenginecannotbestartedup.
2. Electricstarterswitch-Presselectricalstarterbuttontostartthe
engine.
Left Handle
1. Dimswitch
Distantlight–Switchto,lightofheadgoeshighbeam.
Lowlight–Switchto,lightofheadgoeslowbeam.
2. Chokelever-Switchchoketocontrolthecarburetorchoke.
3. Turnsignalswitch,releasetheswitchafterturn.
4. Hornswitch-Pressingtheswitch,hornwillsound
RKV MANUAL - ARTWORK.indd 10 23/7/2013 11:10:54 AM
11
Fuel Tank
1. Pushthekeyinbuckleandturnclockwisetoopenthelid.
2. Capwillbeopenwhenturn.
3. Addunleadedfuel.
4. Closecapinreverseorder.
Tank Capacity
17Litre(includingfuelreserve)
Advice:
Fueliscombustiblematerialandcancausere
AlwaysaddfuelinventilatedareasandwithengineOFF
Fuel Cock Lever
Onposition“”
1. Whenitappearsinthispositionfuelsupplyison.
2. AlwayssettoONwhenoperatingtheengine.
Fuel
Reserveposition“”
1. Turnatthispositionforreservefuelwhenthefuellevelinthetank
isverylow.
Closeposition“”
1. Whenitstaysatthispositionfuelsupplyisoff.
2. AlwayssettoONwhennotrunning.
On Close
Note:
Pleaseaddfuelwhenthefuelswitchisatthe“”position.
Turnthefuelswitchtothepositionof“”afteraddingfuel.
RKV MANUAL - ARTWORK.indd 11 23/7/2013 11:10:54 AM
12
Operation
Pre-starting
• Keepthemotorcycleonsidestand
• Ridermuststandontheleftofthevehicle
• Don’t start engine in enclose room as exhaust fumes is bad to
health.
Pleasecheckonthefollowingcontentsbeforeriding,whichisvery
important.
Pre-ride Inspection
Content Comment
Handlebar 1. Stable
2. Turnsmoothly
Braking
1. Frontbrakeleverandrearbrake
pedal
2. Nounsmoothspongefeeling
3. Sufcientbrakeoil
Tire
1. Appropriateairpressure
2. Appropriatetiretreaddepth
3. Nocrackorcut
FuelLevel Sufcientfuelforriding
Lighting
Operateallthelamps-headlamp,stop
lamp,instrument-panellampandsteer-
inglamp
IndicatorLight Highbeamsindicatorlamp,Gearindica-
torlight,Headlightindicatorlamp
Horn&BrakeSwitch Normalfunctions
EngineOil Appropriateoillevel
Throttle 1. Throttlegripfreeplay
2. Smoothturningandreturn
Clutch 1. Clutchlever
2. Smoothoperation
DriveChain 1. Appropriatefreeplay
2. Appropriatelubricant
Thesparetoolsarelocatedinsideoftherightprotectivecover(Ain
thegure).
Motorcycle Kits
A
RKV MANUAL - ARTWORK.indd 12 23/7/2013 11:10:56 AM
13
Caution:
Don’t increase the engine speed without any reason
beforeriding.
Shifting Gear
Thesemotorcycles have5 speed whichcan easilyshift by operating
clutchandgearlever.
Picturesbelowshowclutchleverandgearpedal.
Running-in
Themotorcyclerunning-inisfundamentaltoprolongenginelife.
0-100Km
• Fortherst100Km.Performwithcautiononthebrakesandavoid
extremebrakingforlongperiod.
0-500Km
• Fortherst500Km.don’tdriveyourmotorcyclefasterthan80%
ofthelimitshown.
After1000Km
• Speedupgraduallyyourmotorcycleuntilmaximumperformance
hasbeenreached
Engine Starting
1.Turnfuelswitchto“”position
2.Turnkeyswitchto“”position.
3.TheON/OFFpushbuttonmustremainON“”
4.Holdsteeringhandleandthenpresselectricstarterswitch.
5.Itisrecommendedtowarm-uptheenginebeforeridingoff.
Riding
1. Makesuresidestandisliftedupbeforeriding.
1
3
2
4
RKV MANUAL - ARTWORK.indd 13 23/7/2013 11:10:58 AM
14
Speed
Belowshowthrottleoperation
IncreaseSpeed ReduceSpeed
Braking
Alwaysusedfrontandrearbraketogetherwhilereducespeed.
Parking
• Parkyourmotorcycleonsteadyoor
• Don’tleaveyourmotorcyclewithoutsurveillance,norwithengine
ON,norwithkeyON
• Avoidtouchinganycomponentsthatmaybehot
Note:
You should brake early in dump ground snowy ground
orfrozengroundwheremoretimeisneededthanindry
ground.
Don’t brakes constantly during long downhill or damage
willbecaused.Checkbrakeoillevelconstantly.
RKV MANUAL - ARTWORK.indd 14 23/7/2013 11:10:59 AM
15
Brakes
• Brakepadchecking.
• Checkthebrakepadabrasionofsurfacewearlimits,replacethe
twopadwithnewones,ifnecessary.
• Brakesoillevelislowerthatthelimit,addwithbrakeoilDOT3or
DOT4.
Regular Check
• Regularcheckisnecessarytopreventaccidentsorfailure
• Takeanoverallcheckoncehalfayearforabetterperformance
Daily Check
Alwaysremembertocheckyourmotorcyclecarefullybeforeeveryday
riding.
BrakeSystem
• Controlleverandpedalforsensitivityofbrakesystem.
Tire
• Nocrackorotherdamage.
• Noabnormalabrasion.
• Properdepthortirecracking.
Engine
• Enoughengineoil.
• Checkifitrunnormallyoranynoise.
• Checkifitworkswellduringspeedacceleratinganddecelerating.
Inspection Maintenance
Caution:
Breakdownoraccidentsmayhappenforlackingofregular
checks.
Regularcheckisrequiredevenifthemotorcycleislying
idle.
Itis of greatimportance to check yourmotorcycle after
longtimeoflayoff.
Checkmorefrequentlyifmotorcycleisbeingusedunder
rainyordustyconditions.
Werecommendeddifcultcheckstobedonebylocalor
nearestservicecentre
RKV MANUAL - ARTWORK.indd 15 23/7/2013 11:11:01 AM
16
Engine Oil
Oillevelchecking
1.Checkoillevelbyviewingattheoillevelgaugeattherighthandside
ofenginecover.
2.Engineoilcan’tbeseenatthelevelgauge,youneedtoreplaceor
addoil.
Checkthefrontandrearwheelbrakepadswhetherhavebeenused
toit’slimits.If“brakepad”issmallerthan1.5mm,changethepad.
Caution:
Donotusebrakeoilwithinteriorquality
Keep brake oil from contact to paint surface to avoid
fadingandchapping.
Advice:
Checkthefreeplayofleverafteradjustment.
Hold the brake lever to ensure proper function in the
speciedbrakelimit.
Brake Pad
RKV MANUAL - ARTWORK.indd 16 23/7/2013 11:11:04 AM
17
Engineoilreplacement
1.Removedrainplugandoilllingcap.
2.Itiseasiertodraintheoilwhentheengineiswarm.
3.Changeoillter
5.Pourproperquantityofoilslowlyintotheengine
6.Tightentheoilscrewafterfullling
Caution:
Alwaysusedhighqualityengineoil.
Wesuggest thequantity of oil pouredinto the engine is
1Liter,andnotoverowtheupperlinemarked.
Remembertochangetheengineoilperiodicallyatevery
2000kminterval.
Rear Shock Absorber
Shockabsorberspringsisadjustableaccordingtoloadconditions
Springadjust
1.Liftbikewithmainsupport.
2.Verifythatbothspring(left&right)remainatsomeheight.
Cautions:
Leftandrightspringsmustbeadjustedatsameposition,
incorrectpositionwillcausepoorhandling.
RKV MANUAL - ARTWORK.indd 17 23/7/2013 11:11:04 AM
18
Caution:
Remembertoreplacethelterelementifitiswornout
Improperxingof thelterelement maycause dustinto
engine,bywhichengineperformanceandusagelifemay
beaffected
Spark Plug
• Checksparkplugatinitial1000km,ifdirtyuseasmallmetalbrush
andcleantheelectrode
• Re-adjustsparkpluggapbetween0.6-0.8mm
• Re-adjustsparkplugevery6000km
Sparkplugreplacement
1.Disconnectcableformsparkplug
2.Slackensparkplugandwithdraw
3.Insertnewsparkplugwithitsgapandtighten
4.Connectcabletosparkplugallthewayin
Advise:
Donottightentoomuch,justuntillimit.
Usesparkplug
NGKDR8EAasrecommended.
Air Filter
Airltershouldberegularlymaintained,especiallywhenridingin
areasfullofdustandsand.
Maintenanceofairlter:
1. Takeofftherightcover
2. Takeoffboltsonlidsofairlter
3. Takeofflid;
4. Takeoutlterelement;
5. Washthelterelementincleanwashingoilandmakeitdry;
6. Soakthelterelementincleanoilandsqueezeofftheextraoil;
7. Reinstallallthepartsinthereversedorder.
RKV MANUAL - ARTWORK.indd 18 23/7/2013 11:11:05 AM
19
Battery
Checktheelectrolyteofthebatteryevery1000km.
Verifyingyourbattery
1. MakesuremainswitchisOFF
2. Removeleftcoverpullingout
3. Disconnectbattery
4. Replenish the electrolyte of the battery timely except for the
maintenancefreetypewhichneedsnoinspection.
Caution:
Avoidoverlling
Doremembernottoremovethesealingplugofbattery
Fuse
Ifanyelectricalcomponentisnotworkingorisworkingimproperlyor
theenginedoesnotturnon,checkyourmotorcyclefuse.
FuseChecking
1.Setmotorcycleovermainsupport
2.Checkfusecondition,replaceifdamaged
Carburetor
Astablevaporizationisthebasisoftheengine’sperformance.The
carburetorhasbeenregulatedtoitsbestconditioninthefactory,
whichmustnotbechanged.Whatyouneedtodoistocheckonthe
freeplayofthrottlecableandidlespeed.
IdleSpeedAdjustmentofCarburetor
• Foranaccurateidlespeedadjustment,theengineshouldbe
underanormaloperatingtemperature.
• Standthemotorcycleinverticalpositionandstarttheengineto
warmup.
• Adjusttheidlespeedwithairdamperlimitscrew.
Idlespeed:1,400±100r/min
Warning:
Donotapplyfusewithimpropercapacity
Replace the electrical appliances with original brand or
otherspeciedproduct.
Advise:
Ifthefuse isoutoforder justafterreplacement, gotoa
Keeway Service Centre immediately to check any short
circuitissue.
RKV MANUAL - ARTWORK.indd 19 23/7/2013 11:11:07 AM
20
Note:
Checkthefrontandrearsprocketforanysignsofworn
outbeforechangingthechain.
Advice:
Thechainhead-clampisontheopenend,installitinreverse
directionofrunning.
1. Propthemotorcycle;
2. Loosentherearaxlenut;
3. Loosenthechainadjusternut;
4. Rotatetheadjustbolttotheleftorrighttoadjustthelooseness
andkeepthefrontandbacksprocketinaline.Referencemarks
aremadeontheswingarmsandadjusters,whichcanbeaimed
atandtakenasreferencesfromonepointtotheother.Keep
theloosenessbetween10and20mm,readjusttherearaxlenut
andhaveanalinspection.
Advice:
Thisisthemaximumintervalforadjustment.Actuallyit
shouldberegularlycheckedbeforeriding.Overlooseness
wouldmakethechainfalloffthepath,whichcanresultin
accidentsorseveredamagetotheengine.
Chainhead-clamp
Drive Chain
Appropriatelubricantandadjustmentisneededforitsservicelife.
Frequentmaintenanceisneededtoprolongchainlife.
AdjustmentofChain:
Adjusttheloosenessofthechainfrom10to15mmatevery1000km
interval.
RKV MANUAL - ARTWORK.indd 20 23/7/2013 11:11:08 AM
Table of contents
Languages:
Other KEEWAY Motorcycle manuals
KEEWAY
KEEWAY 2015 RKS 125-26 User manual
KEEWAY
KEEWAY Cruiser 250 User manual
KEEWAY
KEEWAY FACT 50 4T User manual
KEEWAY
KEEWAY RKV125 Instructions for use
KEEWAY
KEEWAY 125-2G User manual
KEEWAY
KEEWAY F-ACT EVO Instructions for use
KEEWAY
KEEWAY Speed 125 User manual
KEEWAY
KEEWAY K-LIGHT 125 Guide
KEEWAY
KEEWAY Supershadow User manual
KEEWAY
KEEWAY RK V125 C User manual
