KegLand RAPT KL22927 User manual

RAPT Temperature Controller Instruction Manual
Page 1of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
RAPT Temperature Controller
KL22927
Instruction Manual
KegLand Distribution PTY LTD

RAPT Temperature Controller Instruction Manual
Page 2of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Contents
Display Legends ...................................................................................................................................3
Display Legend –Graph Enabled......................................................................................................3
Display Legend –Graph Disabled.....................................................................................................3
Registering your Device.......................................................................................................................5
1. Sign up for a RAPT Account..........................................................................................................5
2. Connect your RAPT Temperature Controller to your Home Wi-Fi Network..................................5
3. Register your RAPT Temperature Controller to your Account on the RAPT Cloud........................6
Remote Operation via the RAPT Portal ................................................................................................6
Setting the Target Temperature ......................................................................................................6
Setting up a Temperature Profile.....................................................................................................6
Starting a Temperature Profile ........................................................................................................6
Saving a Temperature Profile on the RAPT Temperature Controller ................................................6
Operation Instructions.........................................................................................................................7
Manual Operation ...............................................................................................................................8
Setting the Target Temperature ......................................................................................................8
Starting a Saved Temperature Profile ..............................................................................................8
Mounting your RAPT Temperature Controller into your Brewery........................................................9
Removing the Mounting Plate .........................................................................................................9
Wall Mounting Option 1 ..................................................................................................................9
Wall Mounting Option 2 ..................................................................................................................9
Wall Mounting Option 3 ................................................................................................................10
Wall Mounting Option 4 ................................................................................................................10
Vertical Bench/Panel Mounting .....................................................................................................11
Advanced Settings .............................................................................................................................13
Default Settings .................................................................................................................................13
Display Icon Legend ...........................................................................................................................14
Updating Firmware............................................................................................................................14
Temperature Probe Calibration .........................................................................................................15
Troubleshooting Registration and Telemetry.....................................................................................16
No telemetry is displayed on the RAPT Poral .................................................................................16
Determine whether your RAPT Temperature Controller is connected to Wi-Fi and check the
signal strength ...........................................................................................................................16
Re-register your RAPT Temperature Controller ..........................................................................16

RAPT Temperature Controller Instruction Manual
Page 3of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Display Legends
Display Legend –Graph Enabled
Display Legend –Graph Disabled
The display on the RAPT Temperature controller will display a graph of temperature vs time by
default. If instead you prefer a numerical old school interface this can be easily changed by
unselecting the Show graph checkbox in the Settings. This will show an interface like the following:

RAPT Temperature Controller Instruction Manual
Page 4of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM

RAPT Temperature Controller Instruction Manual
Page 5of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Registering your Device
The Wi-Fi connectivity of the RAPT Temperature Controller allows you to monitor, track and start a
complex temperature profile involving multiple steps remotely through the RAPT Portal. In order to
fully utilise the capabilities of this device you should connect your RAPT Temperature Controller to
your Wi-Fi network and register it to your RAPT account at https://app.rapt.io
This will allow you to track and monitor your fermentation in real time remotely without needing to
walk over to your temperature controller. It also allows you to setup and send complex fermentation
profiles involving multiple steps to your RAPT Temperature Controller which will then automatically
run through this profile and adjust the set temperature as required.
In order to have access to this Wi-Fi functionality you will need to sign up for a RAPT Account,
connect your RAPT Temperature Controller to your home Wi-Fi network and register your device on
your account on the RAPT Portal by following the instructions below:
1. Sign up for a RAPT Account
To utilise the Wi-Fi connectivity of the RAPT Temperature Controller you will need to sign up for an
account on the RAPT portal. This will allow you to create custom fermentation profiles, track and
monitor your fermentation temperature and heating/cooling utilisation etc.
1. sign up for an account on the RAPT portal.
https://app.rapt.io/
2. Once signed up log in to your account on the RAPT website.
2. Connect your RAPT Temperature Controller to your Home Wi-Fi Network
1. On your smart phone or tablet, open your Wi-Fi settings and connect to the KegLand RAPT
Wi-Fi Access Point using the Wi-Fi name and password displayed on the RAPT Temperature
Controller.
2. Your smart phone or tablet should provide a prompt to sign into the network of your RAPT
Temperature Controller when you connect to its Wi-Fi Network. Clicking on this prompt will
open the RAPT Captive Portal.
If you are not prompted to sign into the network of your RAPT Temperature controller by
your smart phone or tablet then open your Wi-Fi settings and select the RAPT Wi-Fi Network
again to open the RAPT Captive Portal
3. Select your Wi-Fi network, enter your Wi-Fi password and select Jon. This will connect your
RAPT Temperature controller to your Wi-Fi network.
If your RAPT Temperature controller has been successfully connected to your Wi-Fi network
then a Wi-Fi symbol will be present on the top left-hand corner of the RAPT Temperature
Controllers display.

RAPT Temperature Controller Instruction Manual
Page 6of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
3. Register your RAPT Temperature Controller to your Account on the RAPT
Cloud
1. Once your RAPT Temperature Controller is connected to your Wi-Fi network you will then
need to register your device with your RAPT account. When prompted on the screen, press
select (⏎)to enter the main menu then select Register Device.
2. Follow the prompts on the display of your RAPT Temperature Controller. Log in to your
account on the RAPT Portal and select Add new Device
3. Select RAPT Temperature Controller and input the MAC Address and Validation Code
displayed on your RAPT Temperature Controller when prompted.
Congratulations! Your RAPT Temperature Controller is connected to Wi-Fi and registered to your
RAPT Account and can now be controlled through the RAPT Portal.
Remote Operation via the RAPT Portal
Setting the Target Temperature
At the home screen of the RAPT Temperature Controller press the Up or Down arrow to adjust the
Target value on the bottom left of the display. The Target value displayed will be the set point for
the device.
The RAPT Temperature controller will then automatically turn on/off the heating and/or cooling
devices plugged into the outlets as required.
The temperature set point can also be set through the RAPT Portal or a profile session can be started
from the RAPT Portal which will automatically begin the profile you have created.
Setting up a Temperature Profile
Once you have registered your temperature controller on the RAPT Portal you can then log
telemetry from the device and set up complex temperature profiles involving multiple steps.
To setup a temperature profile on the RAPT Portal, select Profiles and then Create New Profile.
Then add your temperature profile steps such as primary fermentation, diacetyl rest, dry hop, cold
crash etc.
Starting a Temperature Profile
Once you have made your temperature profile, either select Send Profile to Device from the profile
or Start Profile Session on the Dashboard to send the profile to your RAPT Temperature Controller.
Saving a Temperature Profile on the RAPT Temperature Controller
Temperature profiles are automatically stored on the RAPT Temperature Controller once the profile
session has been started from the RAPT Portal and profile session has been started on the device
from the RAPT Portal.

RAPT Temperature Controller Instruction Manual
Page 7of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Note: You can not make a Temperature Profile on the RAPT Temperature Controller itself. It must
be made and started from the RAPT Portal first and then it will be automatically stored on the
device to be started manually in the future.
If you make any changes to the temperature profile on the RAPT Portal the RAPT Temperature
Controller which check for any updates and apply these changes automatically when the profile is
started manually through the controller.
Operation Instructions
1. Sign up for an account on the RAPT Portal.
2. Connect your RAPT Temperature Controller to your Wi-Fi network.
3. Register your device on your account on the RAPT Portal.
4. Insert the temperature probe into the thermowell of your fermentation vessel.
5. Plug your heating device into the red 240V outlet on the RAPT Temperature Controller and
plug your cooling device into the blue 240V outlet on the RAPT Temperature Controller.
6. Set your target temperature on the RAPT Temperature Controller manually or through the
RAPT Portal. Alternatively, you can begin a Fermentation profile on the RAPT Portal.

RAPT Temperature Controller Instruction Manual
Page 8of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Manual Operation
If you do not intend to connect your device to the RAPT Portal and hence do not want to utilise the
Wi-Fi functionality you can operate the controller completely manually via the buttons on the
display.
To remove the prompts requestion you to register your device to the RAPT Portal you will need to
disable the Wi-Fi in the settings. To do this press select (⏎) to enter the menu, then select Settings,
then navigate using the arrows to the Disable Wi-Fi setting. Press select (⏎)to disable the Wi-Fi and
the controller will then restart automatically.
If you decide you don’t want to register your RAPT Temperature Controller to the RAPT portal and
hence not use the Wi-Fi functionality of the controller you will in turn lose a lot of the functionality
of the controller which is offered through the RAPT Portal. This includes features such as setting up
complex temperature profiles which are run automatically and logging past temperature profiles.
Setting the Target Temperature
At the home screen press the up or down arrows to adjust the target temperature. The temperature
controller will then automatically send power to the heating or cooling terminals to power on your
heating or cooling device to maintain this target temperature.
Important: Make sure you have plugged your heating device such as a heat wrap into the red
outlet and your cooling device such as your fermentation chamber into the blue outlet.
Starting a Saved Temperature Profile
Temperature profiles which have been savedon the temperature controller can be manually started
without the need to log in to the RAPT portal. You will need to use the RAPT Portal to initially store
the temperature profile on the temperature controller. For instructions on how to store a
temperature profile on the device refer to Storing a Temperature Profile on the RAPT Temperature
Controller.
Once your Temperature profile is stored on the device simply press select (⏎) to enter the menu and
navigate to Start profile. Then select your desired profile which will display a graph of the steps in
the profile. Then press select again to start the profile. Your device will then automatically restart
and begin the temperature profile.
To stop running the temperature profile press select (⏎) to enter the menu and then select Profile
control. Then navigate using the arrows to the stop button and press select (⏎) to stop the
profile.

RAPT Temperature Controller Instruction Manual
Page 9of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Mounting your RAPT Temperature Controller into your Brewery
The RAPT Temperature Controller offers a number of different mounting options offering the
versality to be able to change how to controller is mounted depending on what you are using the
controller for.
The controller is provided as standard with a mounting plate which is installed onto the controller
out of the box. This mounting plate can be removed if you would instead prefer to mount the
controller onto the wall for example.
Removing the Mounting Plate
To remove the mounting plate, slide the mounting plate down towards the bottom of the controller.
Wall Mounting Option 1
If you prefer to mount the RAPT temperature controller to your wall however you did not want to
damage the wall by screwing into it you can attach the mounting plate to the wall using strong
double-sided tape and then slide the RAPT temperature controller onto the mounting plate to
secure it.
Wall Mounting Option 2
Screw two screws into the wall using the following template as a guide. Then simply hook the
controller onto the screws using the mounting points provided on the back of the controller.
RAPT Temperature Controller Drill Mounting Template

RAPT Temperature Controller Instruction Manual
Page 10 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Wall Mounting Option 3
Unscrew the hanging hook and rotate it 180 degrees, retighten and attach the controller to the wall
using this hanging hook. This can be mounted to your wall using a screw or hanging the controller
onto a hook which is already mounted on your wall for example.
Wall Mounting Option 4
Another option for mounting the RAPT Temperature Controller onto a wall is to drill a screw through
the recessed holes below the front face plate which continue all the way through to the two
mounting holes at the back of the controller.
These holes can be identified by running your finger along the face plate in the area shown below.
You can then either peel away the face plate and use an 8G x 60mm countersunk screw or you can
drill straight through the face plate using an 8G x 60mm or 10G x 60mm countersunk screw as
shown below:

RAPT Temperature Controller Instruction Manual
Page 11 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
This is designed for an 8G screw, however 10G will also work but it will sit a little proud on the face
of the controller.
Vertical Bench/Panel Mounting
WARNING: Ensure the temperature controller is unplugged from the wall socket before changing
the orientation of the cables.
If you want to neatly mount the RAPT Temperature controller vertically onto your bench or into a
custom designed cabinet/panel for example, the orientation of the cables can be quickly and easily
rearranged. To achieve this, undo the 4 screws which hold the front and back housings together and
then pull the two housings apart.
Unscrew the two screws which hold the slotted blanking plate to the housing and remove the
slotted blanking plate.

RAPT Temperature Controller Instruction Manual
Page 12 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Move the cable glands to the back of the unit and secure in place with the slotted blanking plate,
then secure the slotted blanking plate to the housing using the two screws. Then reassemble the
front and back housings and secure with screws.
You can then custom design your own panel or cabinet to mount this temperature controller into
with the outlets and wiring now exiting out the back of the controller allowing for a very neat
mounting arrangement.
Alternatively, if you want to mount this on your bench top or on top of your fermentation chamber
you can use the mounting plate as a stand to keep the temperature controller in an upright position.
Simply slide the temperature controller housing onto the guides on the mounting plate as shown to
the right.

RAPT Temperature Controller Instruction Manual
Page 13 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Advanced Settings
The advanced settings should not need to be adjusted out of the box unless necessary. For more
advanced users the RAPT Temperature controller has an advanced settings menu that can be
adjusted allowing further instructions to be given to the controller such as different cooling start
delay times, tighter temperature hysteresis settings and more frequent telemetry frequencies.
To change any of the advanced settings enter the Menu by pressing select (⏎). Once in the menu
navigate to Settings and press select (⏎).
Navigate to the advanced setting you need to adjust and press select (⏎) on this setting. Then use
the Up or Down arrow to adjust the set value for the setting.
Default Settings
SETTING
DEFAULT
MIN
MAX
Cooling Hysteresis Error
2.0°C
0.1°C
10.0°C
Heating Hysteresis Error
2.0°C
0.1°C
10.0°C
Compressor Delay
5.0 min
2.0 min
10.0 min
Switch Mode Delay
5.0 min
2.0 min
10.0 min
Telemetry Frequency
30 min
15 min
180 min
Set Temperature
20.0°C
-5.0°C
60.0°C
Boolean Heating On/Off
ON
OFF
ON
Boolean Cooling On/Off
ON
OFF
ON
PID Cycle Time (Heating)
120 sec
30 sec
3600 sec
PID P Coefficient (Heating)
PID I Coefficient (Cooling)
PID Cycle Time (Cooling)
120 sec
30 sec
3600 sec
PID P Coefficient (Cooling)
PID I Coefficient (Cooling)
High Temp Alarm
120°C
-20.0°C
120.0°C
Low Temp Alarm
-10°C
-20.0°C
120.0°C
NOTE: The device will alarm if the Min/Max values are exceeded.

RAPT Temperature Controller Instruction Manual
Page 14 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Display Icon Legend
ICON
MODE
FUNCTION
On / Off
Cooling On
On with countdown overlay / Off
Cooling Start Delay
On / Off
Heating On
On with countdown overlay / Off
Heating Start Delay
On / Off
Alarm
Updating Firmware
Your RAPT Temperature Controller will automatically check for and install firmware updates when
turned on and connected to a Wi-Fi network.
To check the firmware version on your RAPT Temperature controller, press select (⏎) to enter the
menu and then navigate to diagnostics.
To manually update the firmware in the event that this is not up to date, navigate to settings and
then navigate to Check for OTA Update. Your device will then automatically download and update
the most current available firmware.

RAPT Temperature Controller Instruction Manual
Page 15 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Temperature Probe Calibration
If you have replaced the temperature probe for any reason or require greater accuracy the NTC
temperature probe can be quickly calibrated:
1. Enter the menu by pressing Select (⏎)
2. Use the Up or Down arrows to navigate to Settings and press Select (⏎)
3. Use the Up or Down arrows to navigate to 2-point calibration and press Select (⏎)
Once in the 2-point calibration mode set up two glasses of water. Ice water to one glass and add hot
water to the second glass.
Calibration Point 1
Insert the temperature probe of the RAPT Temperature Controller into the glass of ice water while
simultaneously measuring the temperature of the ice water using a calibrated external thermometer
such as a digital instant read thermometer (KL23320). Wait for the temperature reading on both the
RAPT Temperature Controller and the external calibrated thermometer to stabilise as much as
possible.
Then adjust the temperature shown on the RAPT Temperature Controller to match the temperature
measured on the external calibrated thermometer.
Press Select (⏎)to lock in this calibration point 1 and move on to calibration point 2.
Calibration Point 2
Insert the temperature probe of the RAPT Temperature Controller into the glass of hot water while
simultaneously measuring the temperature of the hot water using a calibrated external
thermometer. Wait for the temperature reading on both the RAPT Temperature Controller and the
external calibrated thermometer to stabilise as much as possible.
Then adjust the temperature shown on the RAPT Temperature Controller to match the temperature
measured on the external calibrated thermometer.
Press Select (⏎)to lock in this calibration point 2.
Once both calibration points have been set the NTC temperature probe has been calibrated.

RAPT Temperature Controller Instruction Manual
Page 16 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
Troubleshooting Registration and Telemetry
The default setting for telemetry is 60 minutes. As a result, you will not see telemetry in the RAPT
Portal right away.
Should the telemetry data not appear, then you may need to re-register your RAPT Temperature
Controller with the RAPT Portal.
No telemetry is displayed on the RAPT Poral
If you are experiencing issues receiving telemetry or sending a profile to your RAPT Temperature
Controller from the RAPT portal then you should first check that your RAPT Temperature controller
controller is connected to your Wi-Fi network.
Determine whether your RAPT Temperature Controller is connected to Wi-Fi and check the
signal strength
To check your BrewZilla Gen 4.0 controller is connected to your Wi-Fi network with good signal
strength press ‘Select’ and navigate to the Settings and then Diagnostics.
The Wi-Fi strength will be displayed in this Diagnostics menu and the Wi-Fi network which the
controller is connected to will be shown next to wifi AP.
Signal strength is represented on a scale of 0 to -100dbm
Re-register your RAPT Temperature Controller
If your RAPT Temperature Controller is still not sending telemetry to the RAPT Portal or you are
unable to remotely start a profile despite being connected to Wi-Fi with a good, reliable signal
strength then you may need to re-register your RAPT Temperature Controller to your account. To
re-register your BrewZilla controller do not delete the device from the RAPT Portal, instead follow
the steps below:
1. Go to the settings menu on your RAPT Temperature Controller.
2. Navigate to clear registration and press select (⏎).
3. Register your device to your RAPT account according to the instructions on page 3.
Signal Strength (dBm)
What it means
0 to -30dBm
Maximum signal
-50dBm
Excellent signal
-67dBm
Good, reliable signal
-70dBm
Ok, not a strong signal
-80dBM
Poor, unreliable signal
-90dBM
Unusable

RAPT Temperature Controller Instruction Manual
Page 17 of 17 www.KegLand.com.au Last Updated 24/05/2022 12:17 PM
If you are unable to sign up an account or your RAPT Fermentation Fridge or RAPT portal displays an
error please forward as many visual pieces of supporting information and a detailed description of
the error to
