Kellfri 13-VT275 User manual
Carefully read the operating instructions before
using the product!
Operating instructions translated from Swedish
13-VT275
FIREWOOD CONVEYOR
Table of contents
Kellfri designs and supplies ecient, aordable machinery and components for forestry, ag-
riculture, construction and gardening in Sweden, the rest of the Nordic region and Europe.
We recommend that you always read and follow the safety instructions and the instructions in
the product's operating manual.
Kellfri is not liable for any errors in this document.
TABLE OF CONTENTS
INTRODUCTION 3
PRODUCT INFORMATION 3
MACHINE’S FUNCTION 3
SAFETY INSTRUCTIONS4
INSTRUCTIONS FOR EMERGENCY SITUATIONS 4
PERSONAL PROTECTION 4
SURROUNDINGS 5
BEFORE USE 5
WARNING! 5
USE 6
AFTER USE 6
MAINTENANCE AND SERVICE 7
TRANSPORTATION AND SETUP7
RECYCLING 7
COMMONLY USED SYMBOLS FOR ELECTRIC MACHINES 8
ON/ OFF 8
AC POWER 8
DC CURRENT 8
OVERLOAD PROTECTION 8
DISCONNECT ALL EQUIPMENT FROM THE GENERATOR DURING
MAINTENANCE OR WHEN THE UNIT IS LEFT UNATTENDED 8
FOR OUTDOOR USE ONLY 8
EARTH CONNECTION 8
OPERATION 9
WARNING DECALS 10
PARTS INCLUDED 11
ASSEMBLY 12
OTHER PART NO. 22
Table of contents
INTRODUCTION
Thank you for choosing a product from Kellfri AB. Compliance with the safety instructions,
operating manual and sound common sense will guarantee many years of enjoyment using
the product. Kellfri’s equipment and products are aimed at self-employed farmers, horse en-
thusiasts and other country-dwellers who have stringent performance demands.
PRODUCT INFORMATION
• 7.5 metres
• Increase production and take the strain o your body
• Emergency stop for high safety
• Transport wheels for easy moving
• Stable suspension
The conveyor is easy to move with the wheels positioned centrally for good weight distribu-
tion.
Simple height adjustment and belt tensioner and the position of the motor in the top part
ensure it is well-protected against impact and sawdust. Reinforced screws.
Large feed point and uted conveyor belt with 19 cleats provides maximum capacity. 230 V
power socket with emergency stop for excellent safety.
Supplied unassembled.
MACHINE’S FUNCTION
The rewood conveyor is designed solely for the transport of materials, such as wood.
TECHNICAL DATA 13 VT275
Operating length 7500 mm
Conveyor belt width 100 m
Wheelbase Width 1114 mm
Feed width 600 mm
Feed height 376 mm
Engine 230 V 50 Hz 370 W 1400 RPM
Engine power 0.5 kW
Firewood trough 424 mm
Weight 90 kg
Table of contents
SAFETY INSTRUCTIONS
Before using the equipment or product, and for the safety of yourself and others, you must
read the safety instructions and instruction manual and understand their contents. Always
keep the safety instructions and operating manual handy for users of the equipment or prod-
uct. For the safety of both yourself and others, it may be a good idea to read through the safety
instructions every now and then. If the safety instructions or the operating manual are dam-
aged, or become unusable for any other reason, new copies may be ordered from: Kellfri AB,
Munkatorpsgatan 6, SE-532 37 SKARA, Sweden. Tel.: +46 511 242 50
The safety instructions can also be downloaded from Kellfri’s website: www.kellfri.co.uk
Do not use the equipment or product if you feel ill, tired or are under the inuence of alcohol.
Do not use the equipment or product if you are taking prescribed medication or drugs, or suf-
fering from severe depression or mental illness. Always comply with general rules of the road
and applicable rules stipulated by animal welfare legislation. People under the age of 15 are
not allowed to use the equipment.
INSTRUCTIONS FOR EMERGENCY SITUATIONS
In case of emergency, call 112
Always have a mobile phone or emergency phone available when working alone. A rst-aid
kit and re extinguisher must be kept in an easily accessible location when carrying out any
work, maintenance or service.
Warning!
The original design of the machine must not, under any circumstances, be modied with-
out the approval of the manufacturer. Unauthorised modications and/or accessories
may cause life-threatening injuries or death to users and others.
PERSONAL PROTECTION
Always use suitable protection equipment. Do not wear loose clothing or jewellery while
working with the equipment. Long hair should be tied up when working with equipment
that has moving parts. Use protective gloves to avoid the risk of burns if hot surfaces such
as exhaust pipes are touched, and to avoid oil and petrol getting in contact with the skin. Ear
defenders must be worn whilst the engine is running.
Kellfri is not liable for any modications, changes or rebuilds carried out by customers.
Where the machine is used professionally, employers are responsible for ensuring that users of the
machine have theoretical and practical knowledge of the machine and that work is performed in
a safe manner. Stay informed by complying with work environment legislation; contact your local
work environment authority.
Table of contents
SURROUNDINGS
Check that the work area is free from bystanders and objects before hitching or using the
equipment. Otherwise, there is a risk of serious injury. Be extra careful if there are children in
the vicinity of the area where the equipment or product is used or stored. Check that there
are no low-hanging electrical cables within the work area. Exercise caution when working on
slopes and close to ditches.
Always work alone with equipment or products that are made for working alone. Never leave
rubbish in the work area, and keep work surfaces clean. Always respect the equipment’s risk
zone.
BEFORE USE
Carefully read the safety instructions and the operating manual. Make sure that you under-
stand the safety instructions, the operating manual and warning decals. Use common sense
and suitable personal protective equipment when using the product. Always check the per-
formance of the machine combination to be used. It is important that these are compatible
and work satisfactorily together. This is to ensure that the equipment or product works as
expected, and to guarantee the safety of yourself and others. Carry out a visual inspection
of the equipment or product before use. Repair or replace damaged or worn parts to reduce
the risk of injury. Grease moving parts and check that all nuts and bolts are tightened. Repair
if necessary. Learn and remember the correct working method. Beginners must work slowly
until they have learned how the machine or product works.
Users/customers are responsible for ensuring users can handle the situation. If a user feels
that the machine is dangerous to use, they should not use it until they have received thorough
training.
WARNING!
Never use equipment or products with defective safety components.
Children must not be left unsupervised in the area!
Warning!
