KEMKRAFT KEI-095A Operating and maintenance manual

96-005.doc Page 1 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
INSTRUCTIONAL MANUAL
3 / 4 / 8 CH. BRAKE PEDAL
TRAVEL TESTER (METRIC)
MODEL KEI-095A

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 2 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
TABLE OF CONTENTS
PAGE
GENERAL DESCRIPTION ...........................................................................................................................3
INSTALLATION............................................................................................................................................3
OPERATION..................................................................................................................................................4
To run a test: .............................................................................................................................................5
SYSTEM SETUP ...........................................................................................................................................6
Enter a new Pedal Length: ........................................................................................................................7
Change Data Sample Rate.........................................................................................................................7
Enter Data Trigger Parameter: ..................................................................................................................7
Enter RUN Display Options: ....................................................................................................................8
Enter HUD (Heads up Display) Setup: .....................................................................................................8
Enter a new time and date:......................................................................................................................10
Display Pedal and Floor transducer angles: ............................................................................................10
TRANSDUCER CALIBRATION ................................................................................................................10
To calibrate the Angle Transducers: .......................................................................................................11
To calibrate the Pedal Force Transducer:................................................................................................13
To calibrate the Brake Pressure Transducer: ..........................................................................................13
To calibrate the AUX. Pressure Transducers:.........................................................................................14
DOWNLOADING DATA ............................................................................................................................15
To download data:...................................................................................................................................15
REAL TIME DATA DOWNLOAD TO PC.................................................................................................16

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 3 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
GENERAL DESCRIPTION
The KEMKRAFT Model KEI-095 Brake tester is a precision test instrument which will display
and record brake pedal travel, brake pedal effort, brake line pressure, and car deceleration
during vehicle drive testing. Setup is accomplished in a few minutes with four transducers and
a cigarette lighter plug. Data is stored in the Brake Tester for approximately 4.5 minutes of test
time at the rate of 10 data readings per second. Multiple tests can be run and each test is
identified by its start and stop time/date.
INSTALLATION
1. Open the KEI-095 Brake tester box and remove the two pedal transducers and power cable.
2. Place the Floor transducer on a stable area of the car with the front line marking facing
toward the front of the car. Align the transducer so that the axis of the transducer is exactly
parallel to the centerline of the car. See figure 1. Rotate the transducer so that the number
label faces up.
3. Place the Pedal transducer on the pedal arm. Lock the fixture securely in place. Adjust the
multi-axis fixture so that the transducer is level and parallel to the centerline of the car.
Rotate the transducer so that the number label faces up, with the wires toward the front of
the car.
PEDAL
XDCR
FLOOR
XDCR
FRONT
FRONT
NUMBER LABEL
Figure 1
CAR DIRECTION
OF TRAVEL

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 4 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
4. If the Pedal force transducer is used, place it on the brake pedal and secure it firmly in
place.
5. If the Brake Pressure transducer is used, install it on the master cylinder using an adapter
(user supplied). The threads are 1/4-18 NPT Male. If the Brake Pressure Transducer is not
being used, a terminating plug (KE095P1) for the Pressure connector is supplied.
6. Route all transducer cables so that they do not interfere with pedal operation. The cables
must have enough slack to move freely without binding.
7. Plug the transducer cables and the power cable into the Brake tester. The brake tester
connectors are marked and keyed so no damage can occur from incorrect cable connection.
8. Start the car and plug the power cable into the car cigarette lighter.
9. Turn the Brake Tester on. The start-up screen will be displayed. Press any key to enter the
Main menu.
MAIN MENU
10. Press the 2 key to enter the system setup menu and press the 4 key again to display the
pedal angles.
11. Adjust the pedal and floor transducers so that their angles read less than +/- 2 degrees.
Adjust the transducer angles by loosening the center thumbscrew slightly, adjusting the
transducer, and carefully re-tightening the screw.
The installation is now complete. Press the * key twice to return to the main menu and the
tester is ready to be used.
OPERATION
The operation of the KEI-095 Brake Tester is controlled by various menus. Select the required
operation from the menu using numbers on the keypad. Any entered data is entered on the
keypad. Decimal points are added automatically.
0 = Start Test
1 = Calibrate
2 = System Setup
3 = Download Data

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 5 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
To run a test:
1. Be sure all setup is complete as detailed in the Installation section. Be sure the car is
running. Turn on the Brake Tester power switch. Always start and stop the engine with
Brake Tester power off.
2. Press the 0 key to select START TEST. The Test menu will be displayed. Press the 0 key
again to start the test.
3. A menu screen will display that shows the functions of each key during testing. Press any
key to start the test.
4. The test screen will now be displayed.
The current value is displayed in the first data column and the greatest positive or negative
peak value is displayed in the second data column.
The Units are:
Travel = Centimeters
Force = Newtons
Decel = 100%= 1g
Pressure = Bars
5. With the engine on, the shifter in park, and your foot off the brake pedal, press the 0 key to
Zero all values. The Brake tester will store the zero values until the unit is switched off.
6. While testing, the Peak value can be reset by pressing the 3 key at any time. This has no
effect on data storage or any other reading, it resets the displayed peak only.
0 = Zero All XDCRs
1 = Data Col STR/STP
3 = Reset Peak
Press (*) to Abort
TRAV: 0.0 0.0
FRCE: 0.0 0.0
DCEL: 0.0 0.0
PRES: 0.0 0.0

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 6 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
7. To begin data storage at any time press the 1 key.
This data storage screen will now be displayed.
The first line of the test screen R:000, indicates that the brake tester is now collecting data. The
number will begin counting upward to indicate how much memory has been used.
The second line of the test screen T:000, tells you the total memory that has been used. The
memory is full when the display reaches T:285.
The third line of the test screen S:00, indicates the number of samples per second.
The fourth line of the test screen will change to RUN, indicating that the Brake Pedal tester is
in data acquisition mode.
To stop data collection at any time, press the 1 key again.
The start and stop time of each test (pressing the 1 key) is recorded and stored in memory to
identify tests.
8. Press the * key at any time to abort the data collection and return to the test menu. If data
collection is in progress, when the * key is pressed, the data collection will be stopped and
the data end time stamped with the current time.
SYSTEM SETUP
Certain system parameters must be modified when changing to a new vehicle or adjustment is
required. The pedal length from pivot point to the middle of the brake pedal must be changed
when switching to a new vehicle.
The clock should be checked for accuracy and reset for daylight savings time.
R:000 0.0 0.0
T:000 0.0 0.0
S:.10 0.0 0.0
RUN: 0.0 0.0

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 7 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
Enter a new Pedal Length (cm):
1. Turn on the brake tester. Press any key to display the main menu.
2. Press the 2 key to enter the System Setup Menu.
3. Press the 1 key to enter the Test Parameters Menu.
The Test Parameters Menu will be displayed.
4. Press the 1 key to change the pedal length.
5. The display will show the current pedal length. Enter the Four numbers of the new pedal
length on the keyboard. Be sure to enter any leading zeros and the hundreds place decimal
point will be entered automatically.
When the forth number is entered, the display will go back to the Test Menu. The new pedal
length is stored in memory and will remain until it is changed again.
Change Data Sample Rate
1. Press the 2 key to enter the System Setup Menu.
2. Press the 1 key to enter the Test Parameters Menu.
3. Press the 2 key to change the sample rate. The standard default rate is 10 samples per
second with a maximum rate of 50. If the sample rate of 10 is changed to 50 the data
storage time is decreased.
Enter Data Trigger Parameter:
1. Press the 2 key to enter the System Setup Menu. Press the 2 key to enter the Test Options
Menu.
Test Parameters Menu
1 = Set Pedal Length
2 = Vary Sample Rate
* = ABORT

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 8 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
2. Press the 1 key to enter the Triggering Settings Menu.
3. Enter a 0 to disable the triggering or 1 to enable the triggering.
4. Enabling the triggering allows you to select which transducer and value will trigger the data
recording during a test.
Enter RUN Display Options:
1. Press the 2 key to enter the System Setup Menu. Press the 2 key to enter the Test Options
Menu.
2. Press the 2 key to enter the Display Options Menu.
This menu allows the user decide how many channels are displayed in the RUN menu. On a 4
channel KEI-095 3 or 4 channels are selectable. An 8 channel allows the user to select 3,4 or 8
channels.
This menu also allows the user to decide if the first channel displays angle or travel. Default is
set for travel.
Enter HUD (Heads up Display) Setup:
1. Turn on the brake tester. Press any key to display the main menu.
2. Press the 2 key to enter the System Setup menu. Press the 2 key to enter Test Options
Menu.
3. Press the 4 key in the setup menu to set HUD (Factory)Default bargraph values for Upper
Limit, Target, Lower Limit.
4. Press the 3 key to enter the HUD Option menu.
The display will show the following.
*** HUD OPTIONS ***
Head Up Disp. = OFF
0 = OFF 1 = ON
Press * to Abort

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 9 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
5. Press the 0 key to Disable the HUD data communications.
6. Press the 1 key to Enable the HUD data communications.
7. Press the * key to abort or continue through the menus.
8. Press the 0 key to Disable the LCD display.
9. Press the 1 key to Enable the HUD display.
The following display is a 4 Channel unit.
The following display is an 8 Channel unit.
10. Press the 0 – 8 key to select the channel that will be displayed on the HUD.
11. Enter the Upper, target and lower values to be displayed on the bargraph.
*** HUD OPTIONS ***
Numeric Disp. = OFF
0 = OFF 1 = ON
Press * to Abort
0 = Pedal Travel
1 = Deceleration
2 = Force
3 = Pressure
1,2,3,4 = Aux. Channel
5 = Pedal Travel
6 = Deceleration
7 = Force 8 = Pressure
Pedal Travel Setup
UPPER xxxx.x
TARGET xxxx.x
LOWER xxxx.x

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 10 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
12. Press the 3 key to turn off the LCD display update, Press the 4 key to turn on the LCD
display update. (The Bargraph will continue to operate until disabled.)
13. Press the * key to return to the System Setup and main menus.
Enter a new time and date:
1. Turn on the brake tester. Press any key to display the main menu.
2. Press the 2 key to enter the System Setup menu. Press the 3 key to set the time and date.
3. The display will show the current time and date.
4. Press the 1 key to change the time if required.
5. Enter the new time, in 24 hr format (1:00 pm = 13:00:00), on the keypad. Enter a 2 number
hours, 2 number minutes, and 2 number seconds. The display will return to display the new
time.
6. Press the 0 key to change the date if required.
7. Enter the new date on the keypad. Enter a 2 number months, 2 number days, and the last 2
digits of the year. The display will return to display the new date.
8. Press the * key to return to the System Setup and main menus.
Display Pedal and Floor transducer angles:
1. Press the 2 key to enter the System Setup Menu.
2. Press the 4 key to display the transducer angles.
3. Press * to Exit.
TRANSDUCER CALIBRATION
The KEI-095 brake tester works by comparing the angle on the brake pedal level transducer to
the angle of the floor transducer. The angles must be the same from each transducer. Because
the pedal travel and deceleration values are derived from these angles, the angles must be
accurate for the system to be accurate. Periodic re-calibration of the system is necessary.

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 11 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
Calibration requires a Calibration Stand Model KE095CS that has four precision +/- angles,
and zero, to set the pedal and floor transducers to, a precision known weight for the force
transducer, and a Pressure Calibration box Model KE095CB that has a precision known value
for the pressure transducer.
To calibrate the Angle Transducers:
1. Connect the KEI-095 brake tester to a 12.6 to 15 volt, 500 ma power supply. Connect all
transducers to their brake tester ports.
2. Turn on the brake tester. Press any key to display the main menu.
3. Mount pedal angle transducer and floor angle transducer to the calibration stand. Make
sure the number labels on both transducers are facing up.
4. Press the 2 key to enter the System setup mode. Press the 2 key to set the pedal length.
Enter 17.78 cm as the pedal length. This is required to calibrate the transducers using
Calibration stand KE095CS. Press * to return to the Main menu.
5. Press the 1 key to enter the Calibration mode.
6. To prevent unwanted access to the calibration modes a numeric code must be entered.
Enter "1", "2", "3", "4" on the keypad.
The calibration menu will be displayed.
7. Press the 1 key to calibrate both transducers at the same time.
8. The display will show the current raw transducer output. For the angle transducers, place
the calibration stand on a level surface and adjust the transducer so that the reading is as
close to zero as possible. Press the 1 key when close to 0.00 degrees.
9. The display will instruct the operator to set the angle transducers to a known negative
angle. The recommended first angle is -60 degrees, however any angle 0 to -99.999 degrees
can be used. Set the transducers to the angle and enter the 5 digits of the angle (60.000) on
the keyboard or select * if the displayed angle is correct to continue.
1 = Cal Angle XDCRs
2 = Cal Force XDCR
3 = Cal Press XDCR
4 = Cal Aux. XDCRS

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 12 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
10. When the fifth number is entered, the display will show the next recommended angle to be
entered.
11. The display will instruct the operator to set the angle transducers to the next negative angle.
The recommended angle is -45 degrees, however any angle from 0 to the previous angle
can be used. Set the transducers to the angle and enter the 5 digits of the angle (45.000) on
the keyboard or select * if the displayed angle is correct to continue.
12. When the fifth number is entered, the display will go show the next recommended angle to
be entered.
13. The display will instruct the operator to set the angle transducers to the next negative angle.
The next recommended angle is -30 degrees, however any angle from 0 to the previous
angle can be used. Set the transducers to the angle and enter the 5 digits of the angle
(30.000) on the keyboard or select * if the displayed angle is correct to continue.
14. The display will instruct the operator to set the angle transducers to the next negative angle.
The next recommended angle is -15 degrees, however any angle from 0 to the previous
angle can be used. Set the transducers to the angle and enter the 5 digits of the angle
(15.000) on the keyboard or select * if the displayed angle is correct to continue.
15. The display will instruct the operator to set the angle transducers to zero angle. The
recommended angle is 0 degrees, however any angle from the previous angle to the next
angle can be used. Set the transducers to the zero angle and enter the 5 digits of the angle
(00.000) on the keyboard or select * if the displayed angle is correct to continue.
16. The display will instruct the operator to set the angle transducers to the first positive angle.
The recommended angle is 15 degrees, however any angle from 0 to 99.999 can be used.
Set the transducers to the angle and enter the 5 digits of the angle (15.000) on the keyboard
or select * if the displayed angle is correct to continue.
17. The display will instruct the operator to set the angle transducers to the next positive angle.
The recommended angle is 30 degrees, however any angle greater than the previous angle
can be used. Set the transducers to the angle and enter the 5 digits of the angle (30.000) on
the keyboard or select * if the displayed angle is correct to continue.
18. The display will instruct the operator to set the angle transducers to the next positive angle.
The recommended angle is 45 degrees, however any angle greater than the previous angle
can be used. Set the transducers to the angle and enter the 5 digits of the angle (45.000) on
the keyboard or select * if the displayed angle is correct to continue.
19. The display will instruct the operator to set the angle transducers to the last positive angle.
The recommended angle is 60 degrees, however any angle greater than the previous angle

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 13 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
can be used. Set the transducers to the angle and enter the 5 digits of the angle (60.000) on
the keyboard or select * if the displayed angle is correct to continue.
20. When the last angle is entered, the display will read "Calibration Complete".
21. Calibrate all transducers and check the angle values using the System Setup menu XDCR
Angles display.
To calibrate the Pedal Force Transducer:
1. Connect the KEI-095 brake tester to a 12.6 to 15 volt, 500 ma power supply. Connect all
transducers to their brake tester ports.
2. Turn on the brake tester. Press any key to display the main menu.
3. Press the 1 key to enter the Calibration mode.
4. To prevent unwanted access to the calibration modes a numeric code must be entered.
Enter "1", "2", "3", "4" on the keypad. The calibration menu will be displayed.
5. Press the 2 key to calibrate the pedal force transducer.
6. The display will show the current raw transducer output. For the pedal force transducer, just
place on a level surface. Press the 0 key.
7. Place a known weight from 22.2 to 440.4 N on the transducer and enter the five numbers of
the weight on the keypad. Be sure to enter any leading zeros and the decimal point will be
entered automatically.
8. When the fourth number is entered, the calibration is complete. Press the * key to exit the
calibration mode.
To calibrate the Brake Pressure Transducer:
1. Connect the KEI-095 brake tester to a 12.6 to 15 volt, 500 ma power supply. Connect all
transducers to their brake tester ports.
2. Connect the pressure transducer through the KE095CB with the cable and transducer.
3. Turn on the brake tester. Press any key to display the main menu.
4. Press the 1 key to enter the Calibration mode.

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 14 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
5. To prevent unwanted access to the calibration modes a numeric code must be entered.
Enter "1", "2", "3", "4" on the keypad. The calibration menu will be displayed.
6. Press the 3 key to calibrate the brake pressure transducer.
7. The display will show the current raw transducer output. For the brake pressure transducer
set the calibration box switch to ZERO. Press the 0 key.
8. Set calibration box switch to CAL. Enter the 5-digit calibration number that is on the label
on the front panel. Each pressure XDCR has it’s own CAL# depending on the serial
number of the transducer.
9. When the fifth number is entered, the calibration is complete. Press the * key to exit the
calibration mode.
To calibrate the AUX. Pressure Transducers:
1. Connect the KEI-095 brake tester to a 12.6 to 15 volt, 500 ma power supply. Connect all
transducers to their brake tester ports.
2. Connect the pressure transducer to AUX. CH1-4.
3. Turn on the brake tester. Press any key to display the main menu.
4. Press the 1 key to enter the Calibration mode.
5. To prevent unwanted access to the calibration modes a numeric code must be entered.
Enter "1", "2", "3", "4" on the keypad. The calibration menu will be displayed.
6. Press the 4 key to calibrate the AUX. pressure transducers.
7. Press 1 to select the channel 1 to calibrate.
8. The display will show the current raw transducer output. With the Aux. pressure transducer
set to ZERO. Press the 0 key.
9. Apply calibrated pressure to the Aux. transducer under test. Enter the calibrated pressure
value in Bars.
10. When the fifth number is entered, the calibration is complete. Press the * key to exit the
calibration mode.

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 15 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
11. Repeat steps 7 through 10 for channels 2-4.
DOWNLOADING DATA
The KEI-095 Brake Tester can store data for download to a computer and further analysis. The
Kemload32 program and the Download menu are used for this purpose. After downloading the
data, the memory can be reset using the same menu.
To download data:
1. Connect the KEI-095 Brake Tester RS-232 port to the computer COM1 port. The
connections are detailed in the following menu. Turn on the Brake tester.
2. From Windows 95/98 start the KEMLOAD32 program. Verify COM baud rate is set for
19200,n,8,1 and program is set for ASCII text mode.
3. From the KEI-095 main menu press the 3 key. The Download Data Menu will be
displayed.
4. Press the 5 key to begin the data download. If the Download Error message is displayed,
check the cable.
5. The data will display on the computer screen as it is being received by the computer. When
the download is complete, both the computer and Brake tester will indicate this.
6. If the data is to be saved on disk, select file then, Save…or Save as… The data will be
automatically saved to a file upon successful download. This auto save feature can be
disabled in the properties menu.
CABLE CONNECTIONS ARE:
KEI-095 RS-232 (9 Pin) D-Type COMPUTER COM1 (9 Pin) D-Type
Pin 2 (RxD) Pin 2 (TxD)
Pin 3 (TxD) Pin 3 (RxD)
Pin 5 (GND) Pin 5 (GND)
--------- Download ----------
5 = Download Data
9 = Reset Memory
Press * to Abort

KEMKRAFT
ENGINEERING, INC.
MODEL KEI-095A BRAKE PEDAL TESTER (METRIC)
96-005.doc Page 16 of 16 Revised: 11-NOV-99
47650 CLIPPER DR. PLYMOUTH TWP., MICHIGAN 48170 [phone]
7. The data remains in the KEI-095 Brake tester memory and can be download as many times
as desired. To clear the memory and reset the pointer to T:000, select the Download menu
and press the 9 key to reset memory. ** NOTE:** Be sure no important data remains in the
Brake Tester memory before clearing or resetting it as all data is irretrievably lost.
REAL TIME DATA DOWNLOAD TO PC
The KEMKRAFT Model KEI-095 has Real Time download capabilities. This feature is
desirable when you are doing multiple test runs and need to display and store the information
while conducting the test. The software allows you to capture large amounts of information
without the worry of using up the memory in the KEI-095 before the testing is complete.
SETUP
1. Install KEMLOAD32 download software.
2. Disable the HUD display on the KEI-095.
3. To download the data collected in memory from the KEI-095 follow the procedure outlined
in the DOWNLOAD section of this manual.
4. The Real Time Download (RTDL) does not effect collection of data in the memory of the
KEI-095 Brake pedal tester.
Data to be collected in memory can be started and stopped while the data is also being dumped
to the PC.
OPERATION
1. With the KEI-095 all setup and in the Start Test Menu , Select Options Menu on the PC
and enable the RTDL option then press F6 to start the real time download. (Maximum data
collection in KEMLOAD32 is around 14,000 lines or about 20 - 25 min. of continuous data
dump depending on available base memory of the P.C.)
2. To stop real time download to the PC press the KEI-095 * Key to Abort. This will stop the
data dump to the PC and data collection in memory on the KEI-095, if the internal memory
storage is running.
3. To Save the data the procedure is the same as is outlined in the Download section of this manual.
