SAFETY & OPERATING
INSTRUCTION MANUAL
REF.17.200010-00
CAR POLISHER
MODEL N°: 17.200010-00
SAFETY & OPERATING
INSTRUCTION MANUAL
H.C.T.-NV
Europalaan 24b
9800 Deinze
Belgium (Europe)
T + 32 (0)9 380 45 43
F + 32 (0)9 380 46 00
mail@kemtex.be

1
The values shown are based on a nominal voltage of 230V/50Hz. In the case of voltages and
frequencies of different power, values may vary. Refer to the label technical specifications to
the nominal values of the tool.
GENERAL WARNINGS
The safety and accident prevention instructions are reported in the “SAFETY
INSTRUCTION” booklet which forms an integral part of these documents. This
OPERATING INSTRUCTIONS MANUAL indicates the additional information required
specifically for use of the tool.
CORRECT USAGE
This tool is designed to be used as a polisher. Read all the warnings, instructions,
indications provided on drawings and specifications supplied with this tool. Failure to
comply with all the instructions provided below may cause electrical shocks, fire and/or
serious injuries.
This tool is not intended to be used for smoothing, metal brushing and cutting
operations. The use of this tool for unintended applications may cause hazards and
injuries to people.
The tool must be used with accessories that have been specifically designed or
recommended by the manufacturer. The fixing of the accessory to the tool does not
guarantee a safe operation.
The rated speed of the accessories must be at least equivalent to the maximum speed
specified on the tool. Using the accessories at speeds above the rated maximum, may
cause them to break or be projected into the air.
The external diameter and thickness of the accessories must match the specifications of
the tool. Accessories with incorrect dimensions cannot be adequately protected or
controlled.
The configuration of accessories must match the tool. The use of accessories that cannot
be perfectly fitted on the tool may result in imbalance, excessive vibrations and in the
impossibility of controlling the tool.
Do not use damaged accessories. Before use, inspect all the accessories. Inspect the
supporting pads and verify there are no cracks, tears or excessive wear. If the tool or
accessory has been dropped, verify that it is not damaged or install a new accessory.
After inspecting or installing an accessory, test the operation of the tool at maximum
speed and without load for one minute, keeping at a safety distance. If the accessories
are damaged, they will break during this test.
SAFETY WARNING APPLICABLE TO POLISHING OPERATIONS
Verify that no loosened part of the polishing tool shroud or the locking ties can rotate
freely. Safely position or cut all the loosened fixing wires. Loosened or revolving fixing
wires may twist around the operator’s fingers or get caught by the work piece being
machined.
STARTING UP
Before starting-up the tool ensure that:
The packaging is complete and does
not show signs of having been
damaged during storage or
transport;
The tool is complete; check that the
number and type of components
comply with that reported in this
instruction booklet;
The power supply and socket outlet
can support the load reported in

2
the table and that indicated on the
tool identification plate
reproduced.
BEFORE STARTING THE TOOL
Ensure that:
The power supply conforms with
the characteristics of the tool;
The power supply cable and plug
are in perfect condition;
The ON/OFF switch works properly
though with the power supply
disconnected;
All the parts of the tool have been
assembled in the proper manner
and that there are no signs of
damage;
The ventilation slots are not
obstructed.
STARTING AND STOPPING
Starting: push the lever of the
switch towards the body of the
tool; if the tool is to be locked in
the ON position, press button at the
same time and keep it pressed
while releasing lever, thus locking
the switch.
Stopping: release the lever of the
switch or, if locked in position. Push
the lever to release the lock button.
TEST RUN
Start the tool and check that there are no unusual vibrations, or no mismatching of the
buffing pad. Otherwise switch-off the tool immediately and eliminate the fault.
ELECTRONIC RPM REGULATION
The rpm can be adjusted by rotating the wheel. The choice of speed depends on the
characteristics of the buffers and the material to be worked.
REPLACING THE BUFFING PAD
Pull the used pad off and apply the new one, pressing it onto the disc pad.
MAINTENANCE
All maintenance operations are carried out with the power supply disconnected.
At the end of each work session, or when required, remove any dust from the body of
the tool using a jet of compressed air, paying particular attention to the motor
ventilations slots. No other maintenance operations must be undertaken by the user.
Maintenance and cleaning of the inner parts, like brushes, ball bearings, gears etc. or
others, must be carried out only by an authorized customer service workshop.
TOOL IDENTIFICATION PLATE
POSITION AND MAENING OF INFORMATION
1-Type of tool.
2-Nominal working voltage in volts(V).
3-Working frequency in hertz(HZ).
4-Absorbed current in Amperes (A). Ensure that the power supply to which the tool is
connected can easily tolerate the indicated current as a minimum.
5-Absorbed power expressed in Watts(W).
6-Tool code or serial number.
7-Technical data of the tool.
8-Maximum rpm

3
9-The double square indicates that the tool is doubly insulated and therefore does not
require earthing through the power supply cable.
10-Read all these instructions before operating this product and save these instructions.
11-Personal safety devices.
GENERAL SAFETY INSTRUCTIONS
NON-OBSERVANCE OF THE SAFTTY RULES CAN LAED TO ELECTRIC SHOCK, FIRE AND/OR
INJURIES.
SAVE THESE INSTRUCTIONS
WARNING! When using electric or pneumatic tools, basic safety precautions including
the following, should always be followed to reduce the risk of the fire, electric shock and
personal inquiry.
Work and Safety
Keep work area clean and well lit.
Cluttered or dark areas invite
accidents.
Do not operate power tools in
explosive atmospheres , such as in
the presence of flammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
Electrical Safety
Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power
tools. Unmodified plugs and
matching outlets will reduce risk of
electrical shock.
Avoid body contract with earthed
or grounded surfaces, such as
pipes, radiators, ranges and
refrigerators. There is an increased
risk of electrical shock if your body
is earthed or grounded.
Do not expose power tools to rain
or wet conditions Water entering a
power tool will increase the risk of
electrical shock.
Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat , oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of
electrical shock.
When operating a power tools
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use
reduces the risk of electrical shock.
If operating a power tool in a damp
location unavoidable, use a residual
current device (RCD) protected
supply. Use of an RCD reduces the
risk of electrical shock.
Personal Safety
Stay alert, watch what you are
doing and use common sense when
operating a tool. Do not use a tool
while you are tired or under the
influences of drugs, alcohol or
medication. A moment of
inattention, while operation tools
may result in serious personal
injury.
Use personal protective equipment.
Always wear eye protection.
Protective equipment. Such as a
mask, non-skid safety shoes, hard
hat, or hearing protection used for
appropriate conditions will reduce
personal injuries.

4
Prevent unintentional starting.
Ensure the switch is in the off
position before connecting to
power source and/or battery pack,
picking up or carrying the tool.
Carrying tools with finger on the
switch or emerging power tools
that have the switch on invites
accidents.
Remove any adjusting key or
wrench before turning the tool on.
A wrench or a key left attached to a
rotating part of the tool may result
in personal injury.
Do not overreach. Keep proper
footing and balance at all times.
This enable better control of the
tool in unexpected situation.
Dress properly. Do not wear loose
clothing or jewellery . Keep your
hair, clothing and gloves away from
moving parts. Loose clothes,
jewellery or long hair can be caught
in moving parts.
If devices are provided for the
connection of dust extraction and
collection facilities, ensure these
are connected and properly used.
Use of dust can reduce dust-related
hazards.
Tool Use and Care
Do not force the power tool. Use
the correct tool for your
application. The correct power tool
will do the job better and safer at
the rate for which it was designed.
Do not use the tool if the switch
does not turn it on or off. Any
power tool that cannot be
controlled with the switch is
dangerous and must be repaired.
Disconnect from the power source
and/or the battery pack from the
power tool before making any
adjusting, changing accessories, or
storing power tools. Such
preventive safety measures reduce
the risk of starting the power tool
accidentally.
Store idle tools out of the reach of
children and do not allow persons
unfamiliar with the tool or these
instructions to operate the power
tool. Tools are dangerous in the
hands of untrained users.
Maintain tools. Check for
misalignment binding of moving
parts, breakage of parts and any
other conditions that may affect
the tool’s operation. If damaged,
have the power tool repaired
before use. Many accidents are
caused by poorly maintained tools.
Keep cutting tools sharp and clean.
Properly maintained cutting tools
with sharp cutting edges are less
likely to bind and are easier to
control.
Use the tool, accessories and tool
bits etc. In accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the tool for
operations different from those
intended could result in a
hazardous situation.
Service
Have your tool serviced by a
qualified repair person using only
identical replacement parts. This
will ensure that the safety of the
power tool is maintained.

5
Additional Safety Instructions for all Operations.
Kickback and Related Warning
Kickback is a sudden reaction to pinched or snagged rotating wheel, backing pad, brush
or any other accessory. Pinching or snagging causes rapid stalling of the rotating
accessory which in turn causes uncontrolled tool to be forced in the direction opposite of
the accessory’s rotation at the point of the binding. For example, if an abrasive wheel is
snagged or pinched by the work piece, the edge of the wheel that is entering into the
pinch can dig into the surface of the material causing the wheel to climb out or kick out.
The wheel may either jump toward or away from the operator, depending on the
direction of the wheel’s movement at the point of pinching. Abrasive wheels may also
break under these conditions. Kickback is a result of tool misuse and/or incorrect
operating procedures or conditions and can be avoided by taking proper precautions as
given below.
Maintain a firm grip on the tool and position your body and arm to allow you to
resist kickback forces.
Always use auxiliary handle, if provided, for maximum control over kickback or
torque reaction during start-up. The operator can control torque reactions or
kickback forces, if proper precautions taken.
Never place your hand near the rotating accessory. Accessory may kickback over
your hand.
Do not position your body in the area where tool will move if kickback occurs.
Kickback will propel the tool in direction opposite to the wheel’s movement at the
point of snagging.
Use special care when working corners, sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp edges or bouncing have a tendency to snag
the rotating accessory and cause loss of control or kickback.
Do not attach a saw chain woodcarving blade or toothed saw blade. Such blades
create frequent kickback and loss of control.
WARRANTY
When purchasing a new machine we provide a 1-year manufacturer warranty, beginning
on the day of the sale of the machine to the end user. The warranty covers only damages
that can be traced back to material and/or manufacturing faults as well as the non-
compliance of promised features. In case of assertion of claims from this warranty the
original sales receipt that shows the purchase date has to be submitted. The customer is
responsible for the delivery of the tool to us and any expenses associated with delivery.
Warranty repairs may be made only by shops or service stations authorized by us. An
assertion of claims exists only when used appropriately. Excluded from this warranty are
in particular regular operational wear, improper use, partially or completely
disassembled power tools, as well as damage due to overload of the machine, the use of
non-permitted, defective, or improperly applied tools and accessories. Damages caused
by the machine on the application tool or work piece, use of force, consequential
damages, that can be traced to improper or insufficient maintenance by the customer or
third parties, damaging due to external influence such as sand or stones as well as
damages due to non-observance of the instructions such as connection to wrong voltages
or type of electricity
Table of contents
