Ken A Vision PupilCAM 1401KEM User manual

Image Sensor KAV 1/4" CMOS
Pixel Count ACT 1280(H) X 1024(V)
Frame Rate Yes Variable with selected screen size
Default 13 fps at max resolution of 1280 X 1024 (1.3)
VGA 30 fps at resolution of 640 X 480
OSD Yes Controlled by software buttons
Output Resolution Yes 1.3 Mega pixel
Output Yes VGA, RGB (DVI, HDMI depending on your computer's configuration)
RS232 Yes via Software interface of computer
USB Connection Yes USB 2.0 compliant
USB Cable Yes Factory installed 1.7 m USB 2.0
Operating
Temperature Use 0° C - 50° C
Lighting Use Low Lighting to work with electtrical microscopes
Power Source N/A 5 VDC, 200 mA from USB port ONLY meeting green initiative
Cross Platform OS Yes Windows, Mac, LINUX
UVC Driverless Yes Works on Windows, MAC, and Linux
MSI support Yes installation, maintenance, and removal of software via Microsoft server
Memory Yes Image / Video
Image Recording: 400 minimum* average 132,000 images per standard hard drive space of 20GB
at 1280 X 1024
Video Recording: 8 minutes minimum* OR 4 hours per standard hard drive space of 20 GB at AVI
resolution 640 X 480
Advance Imaging Yes
For Science Studies to include 3D rendering, measurement of varied angles, counting, and much
more
Average Set up time N/A less than 5 minutes for 1 – 1,000 units using MSI for Cross platform software installations
Free Updates Yes For the life of the product on software and hardware
IWB Compliant Yes Interactive White Board Compliant for most current boards.
Viewing Angle Yes 60 degree: diagonal, 50 degree: Horizontal
Connect to Microscope Yes
Built-in 28mm 10x eyepiece replaces microscope eyepiece, Setreo adapter ring, to fit most Stereo
microscope eyepiece tubes.
Lens 8 mm
Digital Zoom Yes Controlled by software buttons up to 16x
Focus Factory Set for optimal viewing
White Balance Yes Auto or manual controlled by software buttons
Color/B&W Yes Black and White controlled by software buttons
Gamma Adjustment Yes Auto or manual controlled by software buttons
Negative/Positive Yes Controlled by software buttons
Image Rotation Yes 360° in both directions controlled by software buttons
Capture/Freeze Yes Freeze image via software button
Audio Recording Yes Synchronized recording via software buttons
Image Compression Yes JPEG
Annotation Yes in software or working with Interactive Whiteboard interfaces
Light Control Yes Software controlled
Full Screen Yes desktop enabled icon and single click software button via software
Image Compression Yes Software Enabled JPEG
Split Screen Yes Software
Multiple Camera
Support
Yes
Minimum of 2; up to 8 running simultaneously
PupilCAM®
1401KEM
Camera
Controls
Detailed Specifications (September 2012)
Ken-A-Vision Mfg. Co., Inc.
www.ken-a-vision.com [e-mail] Specifications are subject to change without notice. 1 of 2

PupilCAM®
1401KEM
Time Lapse Recording Yes Both Image and Video playback
Drawing Yes Multiple pallet tools
Video Playback Yes Through varied programs
Image Orientation Yes Single Click software buttons
Auto Format Image Yes 16:9 format and/or 4:3 fomat auto or manual select by software
Distance Learning Yes Single Click software button UVC compliant
Export to MS Office Yes Drop down to MS Word or EXCEL
Size 4.5" X 6.5" X 5.5" / 11.4 cm X 16.5 cm X 14 cm
Weight 1 lb / 0.45 kgs
Boxed Size 10" X 6" X 7" / 25.4 cm X 15.2 cm X 17.8 cm
Boxed Weight 2 lbs / 0.91 kgs
Additional Parts N/A None, all required components are attached or downloadable
Certifications CE, FCC, RoHS, ISO 9001-2008
Warranty 1 Year
USB EXTENDER USB Extender Cable 16ft (4.8m) up to 80ft (24.3m) with 4 pieces
Processor 1.4 GHz (or greater) AMD or Intel processor
RAM 512 MB RAM (or greater)
Free Hard Drive *200 MB free hard drive space
OS Windows XP, VISTA; Mac OS 10 or higher; LINUX
Connection USB 2.0
Display 800 X 600 or higher-resolution display with 256 colors or greater
Peripherals Keyboard and mouse or IWB or slate or compatible pointing device
Classroom
Requirements:
Computer
Other Information
Optional
Accessories
Ken-A-Vision Mfg. Co., Inc.
www.ken-a-vision.com [e-mail] Specifications are subject to change without notice. 2 of 2
