E L I TE®
Gas ange
Estufa a as
Models, Modelos 790.7936*, 7937*
* = color number, nOmero de color
¢)_ ¢) ¢)¢)
iii...........
_,_l/l/llll_lllm/l_!
www.sears.corn Sears Roebu ck and Co., Hoffma n Estates, IL 60179 U.S.A. pin 316417320 (0601)
Table of Contents
Freestanding Range Warranty ................................................. 2
iMPORTANT SAFETY iNSTRUCTiONS ..................................... 3-5
Protection Agreements ............................................................ 6
Before Using Your Range .......................................................... 7
Range Features ......................................................................... 8
Before Setting Oven Controls .............................................. 9-10
Before Setting Surface Controls ............................................ 10
Surface Cooking ................................................................. 11-13
Setting Warmer Drawer & Controls .................................. 13-15
Electronic Oven Control Pad Features ................................... 16
Minimum &Maximum Control Pad Settings ......................... 16
Setting Oven Controls ........................................................ 17-31
Saving
Setting
Setting
Setting
Setting
Setting
Setting
Setting
Setting
Setting
Setting
Setting
& Recalling Recipe Settings ................................. 20
Preheat .................................................................. 21
Bake ...................................................................... 22
Timed Bake ........................................................... 23
Delay Start (Delayed Timed Bake) ........................ 24
Broil & Searing Grill .............................................. 25
Food Categories (Meats, Cakes & Breads) ......... 26
Convection Bake ................................................... 27
Convection Convert ............................................... 28
Add 1 Minute Feature ............................................ 28
Slow Cook ............................................................. 29
the Sabbath Feature ........................................ 30-31
Setting the Clock ............................................................... 17
Changing between 12 or 24 Hour Display ....................... 17
Continuous Bake or 12 Hour Energy Saving Mode .......... 18
Kitchen Timer .................................................................... 18
Oven Lockout ..................................................................... 19
Changing Temperature Display ........................................ 19
Silent Control Operation .................................................... 20
Kenmore Elite Appliance Warranty
One Year Limited Warranty
Setting Warm & Hold ......................................................... 31
Self-Cleaning ....................................................................... 32=34
Adjusting Oven Temperature .................................................. 35
General Care & Cleaning .................................................... 36=40
Before You Call for Service ................................................ 41 =42
Recipes for Slow Cook ............................................................ 43
Sears Service ............................................................ back cover
When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect
in material or workmanship within one year from the date of purchase, call 1=800-4=MY-HOME ® to arrange for free repair. If this
appliance is used for other than private family purposes, this warranty applies for only 90 days from the date of purchase.
This warranty covers only defects in material and workmanship. Sears will NOT pay for:
1. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.
2. A service technician to instruct the user in correct product installation, operation or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not installed, operated or maintained according to all instructions supplied with the
product.
5. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.
6. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those
recommended in all instructions supplied with the product.
7. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.
FIVE-YEAR LiMiTED WARRANTY
For the second through the fifth year from the date of purchase, when installed and operated according to the installation instructions
and Use & Care Guide, Sears will supply the following range parts free of charge if they fail for the reasons listed below. Cus-
tomer must pay labor cost of installation.
*Cooktop glass if it fails due to thermal shock.
*Cooktop elements if they are defective.
What Sears will not cover:
*Failure of the product if it is abused, misused, or used for other than the intended purpose.
*Damage to the cooktop glass caused by the use of cleaners or utensils other than the recommended cleaning cream and tools.
*Damage to the cooktop glass caused by hardened spills of sugary materials (including starches from vegetables or pastas) or
melted plastic that are not cleaned according to the directions in the Use & Care Guide.
*Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
Disclaimer of implied warranties; limitation of remedies
Customer's sole and exclusive remedy under this limited warranty shall be product repair as provided herein, implied warranties,
including warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by
law. Sears shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or
limitation of incidental or consequential damages, or limitations on the duration of implied warranties of merchantability or fitness,
so these exclusions or limitation may not apply to you.
This warranty applies only while this appliance is used in the United States and Canada.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8
important Safety instructions
Read all instructions before using this appliance. Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given.
This Symbol wi!! help ale[t You to Situations that may Cause serious bOdilYharm, death or Property damage:
This symbOl will help alert you to situations that may Cause bodily injury 0r pr0perty damage:
if the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
FOR YOUR SAFETY:
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
otherappliance.
-- WHAT TO DO IF YOU SMELL GAS:
*Do not try to light any appliance.
,Do not touch any electrical switch; do not use
any phone in your building.
immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
, if you cannot reach your gas supplier, call the
fire department.
-- Installation and service must be performed by a
qualified installer, servicer or the gas supplier.
° All ranges can tip.
• Injury to persons could result.
, Install anti-tip device packed with range.
= See Installation Instructions.
_To reduce the risk of
tipping, the rangemust be secured by
properly installed anti-tip bracket provided
with the range. To check if the bracket is
installed properly, visually check that rear
leveling leg is inserted into and fully
secured by the anti-tip bracket by
removing lower panel or storage drawer.
For models with a warmer drawer, grasp
the top rear edge of the range and
carefully attempt to tilt it forward. Refer to
the installation instructions for proper anti-
tip bracket installation.
Remove all tape and packaging before using the range.
Destroy the carton and plastic bags after unpacking the range.
Never allow children to play with packaging material.
Proper Installation--Be sure your appliance is properly
installed and grounded by a qualified technician in
accordance with the National Fuel Gas Code ANSI Z223.=
latest edition, or in Canada CAN/CGA B149.1, and CAN/CGA
B149.2, and the the National Electrical Code ANSI/NFPA
No.704atest edition, or in Canada CSA Standard C22.1,
Canadian Electrical Code, Part 1, and !ocal code
requirements. Install only per installation instructions
provided in the literature package for this range.
Ask your Sears dealer to recommend a qualified technician
and an authorized Sears repair service. Know how to
disconnect the power to the range at the circuit breaker or
fuse box in case of an emergency.
• User servicing--Do not repair or replace any part of the
appliance unless specifically recommended in the manuals.
All other servicing should be done only by a qualified
technician, This may reduce the risk of personal injury and
damage to the range.
Never modify or alter the construction of a range by
removing leveling legs, panels, wire covers, anti=tip
bracketslscrews, or any other part of the product.
Air curtain or other overhead range hoods, which operate
by blowing a downward airflow on to a range, shall not be
used in conjunction with gas ranges other than when the
hood and range have been designed, tested and listed by an
independent test laboratory for use in combination with
each other.
Stepping, leaning or sitting on the doors or
drawers of this range can result in serious injuries and also
cause damage to the range. Do not allow children to climb or
play around the range. The weight of a cMd on an open door
may cause the range to tip, resulting in serious burns or other
injury.
NEVER use this appliance as aspace
heater to heat or warm the room. Doing so may result in
carbon monoxide poisoning.
NEVER cover any slots, holes or passages in
the oven bottom or cover an entire rack with materials such as
aluminum foil. Doing so blocks airflow through the oven and
may cause carbon monoxide poisoning. Aluminum foil linings
may trap heat, causing a fire hazard.
Do not use the oven or warmer drawer (if
equipped) for storage.
•Storage in or on Appliance--Flammable materials should
not be stored in an oven, warmer drawer, near surface
burners or in the storage drawer. This includes paper, plastic
and cloth items, such as cookbooks, plasticware and towels,
as well as flammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.
Do not store items of interest to children in
the cabinets above a range or on the backguard of a range.
Children climbing on the range to reach items could be
seriously injured.
important Safety instructions
• Do Not Leave Children Alone--Children should not be left
alone or unattended in the area where appliance is in use.
They should never be allowed to sit or stand on any part of the
appliance.
• DO NOTTOUCH SURFACE BURNERS,AREAS NEARTHESE
BURNERS, OVEN BURNERS OR INTERIOR SU RFACES OF THE
OVEN. Both surface and oven burners may be hot even though
flames are not visible. Areas near surface burners may
become hot enough to cause burns. During and after use, do
not touch, or let clothing or other flammable materials touch
these areas until they have had sufficient time to cool. Among
these areas are the cook top, surfaces facing the cook top, the
oven vent openings and surfaces near these openings, oven
door and window.
• Wear Proper Apparel!Loose-fitting or hanging garments
should never be worn while using the appliance. Do not let
clothing or other flammable materials contact hot surfaces.
• Do Not Use Water or Flour on Grease Fires!Smother the
fire with a pan lid, or use baking soda, a dry chemical or
foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat or grease
may catch fire if allowed to become too hot.
• Use Only Dry Potholders--Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let
potholders touch hot heating burners. Do not use a towel or
other bulky cloth instead of a potholder.
• Do Not Heat Unopened Food Containers!Buildup of
pressure may cause container to burst and result in injury.
•Remove the oven door from any unused range if it is to be
stored or discarded.
IMPORTANT!ELECTRIC IGNITION MODELS ONLY: Do not
attempt to operate the oven during a power failure. If the power
fails, always turn off the oven. If the oven is not turned off and
the power resumes, the oven will begin to operate again. Once
the power resumes, reset the clock and oven function.
•Protective Liners!Do not use aluminum foil to line surface
burner pans, or oven bottom, except as suggested in this
manual, improper installation of these liners may result in risk
of electric shock, or fire.
• Glazed Cooking Utensils--Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cooktop service without breaking due to sudden
change in temperatures. Check the manufacturer's
recommendations for cooktop use.
IMPORTANT INSTRUCTIONS FOR USING YOUR OVEN
• Use Care When Opening Oven Door or Warmer Drawer i
Stand to the side of the range when opening the door of a hot
oven. Let hot air or steam escape before you remove or
replace food in the oven.
• Keep Oven Vent Ducts Unobstructed. The oven vent is
located below the backguard. Touching the surfaces in this
area when the oven is operating may cause severe burns.
Also, do not place plastic or heat-sensitive items on or near
the oven vent. These items could melt or ignite.
• Placement of Oven Racks. Always place oven racks in
desired location while oven is cool. If rack must be moved
while oven is hot use extreme caution. Use potholders and
grasp the rack with both hands to reposition. Do not let
potholders contact the hot heating elements in the oven.
Remove all utensils from the rack before moving.
• Do not use the broiler pan without its insert. The broiler pan
and its insert allow dripping fat to drain and be kept away from
the high heat of the broiler.
• Do not cover the broiler insert with aluminum foil. Exposed
fat and grease could ignite.
•Cold temperatures can damage the electronic control. When
using the appliance for the first time, or when the appliance
has not been used for an extended period of time, be certain
the unit has been in temperatures above 32°F (0°C) for at
least 3 hours before turning on the power to the appliance.
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
Use Proper Flame Size!Adjust flame size so
it does not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to flame will also improve efficiency.
• Know which knob controls each surface burner. Place a
pan of food on the burner before turning it on, and turn the
burner off before removing the pan.
•Always turn knob to the full LITE position when igniting top
burners. Visually check that burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
• Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Burners--To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
that it is turned inward, and does not extend over adjacent surface
burners.
• Never Leave Surface Burners Unattended at High Heat
SettingsiBoilovers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR RANGE
• Clean the range regularly to keep all parts free of grease
that could catch fire. Pay particular attention to the area
underneath each surface element. Do not allow grease to
accumulate. Refer to the range manufacturer's instructions for
cleaning.
• Kitchen cleaners and aerosols!Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and injury.
SELF CLEANING OVENS
• Clean in the self-cleaning cycle only the parts listed in this
Use & Care Guide. Before self cleaning the oven, remove the
broiler pan and any utensils or foods from the oven.
• Do Not Use Oven CleanersiNo commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
• Do Not Clean Door Gasket--The door gasket is essential for
a good seal. Care should be taken not to rub, damage or
move the gasket.
important Safety instructions
FOR CERAMIC-GLASS COOK TOP MODELS (some models)
Do Not Cook on Broken Cook Top--If cook top should break, cleaning solutions and spillovers may penetrate the broken cook top
and create a risk of electric shock. Contact a qualified technician immediately.
Clean Cook Top with Caution--if a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid a steam burn.
Some cleaners can produce noxious fumes if applied to a hot surface.
Grounding type
wall receptacle
Power supply cord
with 3=prong
grounding plug
Do not, under any |
circumstance, cut, J
remove, or bypass
the grounding prong.
J
Grounding Instructions
(electric ignition models only)
Avoid fire hazard or electrical shock. Do not use an adapter plug,
an extension cord, or remove grounding prong from electrical power cord.
Failure to follow this warning can cause serious injury, fire or death.
This appliance is equipped with a 3-prong grounding plug for
your protection against shock hazard and should be plugged directly into a
properly grounded receptacle. DO NOT cut or remove the grounding prong from
this plug.
For personal safety, the range must be properly grounded. For maximum safety,
the power cord must be plugged into an electrical outlet that is correctly polarized
and properly grounded.
If a 2-prong wall receptacle is the only available outlet, it is the personal
responsibility of the consumer to have it replaced with a properly grounded 3-
prong wall receptacle installed by a qualified electrician.
See the INSTALLATION INSTRUCTIONS packaged with this range for complete
installation and grounding instructions.
Important Safety Notice
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances
known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of
potential exposure to such substances.
Conversion to Liquefied Petroleum Gas (or L.P. Gas)
The natural gas range is designed to allow for conversion to
Liquefied Petroleum (LP.) Gas.
If L.P. conversion is needed, contact 1-800-4-MY-HOME®for
assistance. The LP. Conversion Kit is provided with this range
and is located on the left lower REAR (back side) panel of the
range. Before installing the kit be sure to follow the LP.
Installation Instructions carefully.
Personal injury or death from electrical
shock may occur if the range is not installed by a
qualified installer or electrician.
Any additions, changes or conversions
required in order for this appliance to satisfactorily meet
the application needs must be made by Sears Service.
PROTECTION AGREEMENTS ACUERDOS DE PROTECCION
In the U.S.A.
Master Protection Agreements
Congratulations on making a smart purchase. Your new
Kenmore ®product isdesigned and manufactured for years
of dependable operation. But like all products, it may require
preventive maintenance or repair from time to time. That's
when having a Master Protection Agreement can save you
money and aggravation.
Purchase a Master Protection Agreement now and protect
yourseff from unexpected hassle and expense.
The Master Protection Agreement also helps extend the life
of your new product. Here's what's included in the
Agreement:
5_ Expert service by our 12,000 professional repair
specialists.
5_ Unlimited service and no charge for parts and labor
on all covered repairs.
5_ "No-lemon" guarantee- replacement
of your covered product iffour or more product failures
occurwithin twelve months.
5_ Product replacement if your covered product can't be
fixed.
5_ Annual Preventive Maintenance Check at your
request - no extra charge.
5_ Fast help by phone - phone support from a Sears
technician on products requiring in-home repair, plus
convenient repairscheduling.
5_ Power surge protection against electrical damage
due to power fluctuations.
5_ Rental reimbursement if repair of your covered
product takes longer than promised.
Once you purchase the Agreement, a simple phone call is
all that it takes for you to schedule service. You can call
anytime day or night, or schedule a service appointment
online.
Sears has over 12,000 professional repair specialists, who
have access to over 4.5 million quality parts and
accessories. That's the kind of professionalism you can
count on to help prolong the life of your new purchase for
years to come. Purchase your Master Protection
Agreement today!
Some limitations and exclusions apply.
For prices and additional information call
1-800-827-6655.
Sears Installation Service
For Sears professional installation of home
appliances, garage door openers, water heaters,
and other major home items, in the U.S.A. call
1-800-4-MY-HOME ®.
En los EE.UU.
Acuerdos maestros de protecci6n
Lo felicitamos por haber hecho una compra inteligente. Su
nuevo producto Kenmore®fue disefiado y fabricado para
ofrecer muchos afios de servicio confiable. Sin embargo,
como todo producto, el mismo podria requerir mantenimiento
preventivo o reparaciones ocasionales. Es por eso que el
tener un Acuerdo maestro de protecci6n podria ahorrarle
dinero y molestias.
Adquiera ya un Acuerdo maestro de protecciOn y protejase de
gastos y frustraciones inesperados.
El Acuerdo maestro de protecci6n tambien ayuda a extender
la vida de su producto nuevo. El Acuerdo incluye Io siguiente:
Servicio profesional por nuestros 12.000 profesionales
especialistas en reparaci6n.
5_ Servicio ilimitado sin cargos adicionales por piezas
y servicio en todas las reparaciones cubiertas.
5_ Garantia de "no-lim6n" - reemplaza su producto
cubierto si ocurren cuatro o mas desperfectos en los
primeros doce meses.
5_ Reemplazo del producto si el mismo no puede ser
reparado.
5_ Verificaci6n de mantenimiento preventivo anual a
su petici6n y sin cargos adicionales.
5_ Pronta ayuda por tel_fono - apoyo por telefono por un
tecnico de Sears en los productos que requieran
reparaci6n en casa, ademas de la conveniencia de hacer
una cita para la reparaci6n.
5_ Protecci6n contra picos de energia o dafios
electricos causados por fluctuaciones de la corriente
electrica.
Reembolso del alquiler si la reparaci6n de su producto
cubierto toma mas del tiempo prometido.
Una vez que adquiera este Acuerdo, una simple Ilamada
telef6nica es todo Io que necesita para hacer una cita de
servicio. Usted puede Ilamar a cualquier hora del dia o de la
noche para programar una cita de servicio por Internet.
Sears cuenta con mas de 12.000 profesionales especialistas
de reparaci6n con acceso a mas de 4,5 millones de piezas y
accesorios de calidad. Esa es la clase de profesionalismo
con la que puede contar para extender la vida Qtilde su nueva
adquisici6n por muchos aSos. iAdquiera su Acuerdo maestro
de protecci6n hoy!
Algunas limitaciones y exclusiones podrian aplicarse.
Para precios e informaci6n adicional, Ilame al
1-800-827-6655.
Servicio de instalaci6n Sears
Para una instalaci6n profesional de Sears en
electrodomesticos, abridores de puertas de garaje,
calentadores de agua y otros articulos mayores del hogar,
Ilame al 1-888-SU-HOGAR®, REV.030509
Before Using Your Range
Assembly of Burner Heads & Burner Caps (for Deep Well Cooktop models only)
Your range is shipped with the Burner Heads and Burner Caps in the correct locations. Packing material is located between
the Burner Heads and Burner Skirts.
1. Be sure to follow the Installation Instructions before
installing and using your new range.
2. Remove all packing tape from cooktop area. Remove all
Burner Caps and Burner Heads.
3. Discard all packing material located under Burner Heads.
4. To replace Burner Heads & Caps, match the letters
located under center of Burner Caps with the letters
located inside Burner Heads (Fig. 1).
5. Match the letters stamped on Burner Skirts with Burner
Heads and Burner Caps (See Fig. 1). Replace the Burner
Heads and Caps on cooktop (See Fig. 2). Carefully align
the Electrodes into slot or hole of each Burner Head (Fig.
3). Note: The Burner Heads should sit flat on Cooktop
Burner Skirts.
6. Unpack Burner Grates and position on the cooktop.
Fig. 2
_ectrodes must
align into slot or hole for each
Fig. 3 Burner Head ::iii++'
Assembly of Burner Heads & Burner Caps (for Ceramic Glass Cooktop models only)
Your range is shipped with the Burner Heads and Burner Caps in the correct locations+ Packing material is located between
the Burner Heads and Burner Skirts.
1. Be sure to follow the Installation Instructions before
installing and using your new range.
2. Remove all packing tape from cooktop. Remove Burner
Caps and Burner Heads (See Fig+4).
3. Discard all packing material located under all Burner
Heads.
4. To replace Burner Heads & Caps, match the letters
located under center of Burner Caps with the letters
located inside Burner Head (only positions A & F are
marked with letters -See Fig. 5). Place all Burner Heads
& Caps on the cooktop (See Fig. 4) while carefully
aligning the Electrodes into slots or holes of the Burner
Heads (Fig. 7). Note: The Burner Heads should sit flat on
Cooktop Burner Skirts.
5. Replace Bridge Burner Caps. These include one Bridge
Burner Center Cap (rectangular shaped) and the two
Bridge Burner End Caps (The Bridge Burner End Caps will
fit either the front or rear Bridge Burner Head locations).
Make sure that the tabs located under the Bridge Burner
Caps fall into the slots located in the Bridge Burner Head
(See arrows in Fig. 6) and that all the Bridge Burner Caps
lie flat and evenly on the Bridge Burner Head.
6. Unpack Burner Grates. NOTE: Do not force End Burner
Grates down on cooktop. Be careful to line up the 2 Grate
Pins located on each of the 2 End Burner Grates into the
Pilot holes located on top of the Burner Caps (See Fig. 8).
Position Burner Grates on cooktop and check that all the
Burner Grate legs lie on the glass surface.
7. Place Center Burner Grate between the end Burner
Grates. _ ridge
Burner
End
Cap
Fig. 6
Fig. 7
Fig. 8
Range Features
Your Elite Gas Range Features Include:
1. Electronic Oven Control with Kitchen Timer.
2. Glass Touch Sensitive Control Panel.
3. Left Front Burner Valve & Knob.
4. Left Rear Burner Valve & Knob or Bridge Burner Valve & Knob
(some models).
5. Center Burner VaJve & Knob (some models).
6. Right Rear Burner VaJve & Knob.
7. Right Front Burner Valve & Knob.
8. Easy to clean Deep Well Cooktop (some models) or Ceramic
Gas through Glass Cooktop (some models).
9. Dishwasher safe Burner Grates (colors vary).
10. Dishwasher safe Center Burner Grate (colors vary).
11. Warmer Drawer Control & Indicator Light.
12. Self-Clean Oven Door Latch.
13. Automatic Oven Door Light Switch.
14. Dual Oven interior Lights with Shields.
15. Self-Cleaning Oven interior.
16. Convection Bake Fan & Cover.
17. Adjustable Porcelain Coated Oven Racks (includes Handle &
Half Oven Racks).
18. Large 1 piece Oven Door Handle (styles & colors vary with
model).
19. Full width Oven Door (styles & colors vary with model).
20. Warmer Drawer with Handle & Warmer Drawer Rack.
21. 5,000 BTU Simmer Burner.
22. 9,500 BTU Center Burner (some models).
23. 9,500 BTU Power Burner.
24. 14,200 BTU Power Burner.
25. 16,200 BTU Power Burner.
26. *9,000 BTU Burners ( When used as a Bridge Burner with all 3
burners combined is 27,000 BTU).
27. 17,200 BTU Power Burner
(some models).
28. Broil Pan.
29. Broil Pan insert.
30. Searing Grill.
31. Roasting Rack.
32. Griddle.
33. Leveling Legs and Anti-tip
Bracket (included).
NOTES: The features of your range
may vary according to model type &
color.
*Bridge Burner featured on Glass
Cooktop models only.
Deep Well Cooktop style
*Ceramic Glass Cooktop style
8
Before Setting Oven Controls
OVEN VENT Oven Vent Location
The oven vent is located below the backguard (See Fig. 1). When the oven is on,
warm air is released through this vent. This venting is necessary for proper air
circulation in the oven and good baking results. DO NOT BLOCK THE VENT.
Fig. 1
Fig. 2
Always use pot holders or oven mitts when adjusting the oven racks.
Wait until the oven has completely cooled if possible. Oven racks may be HOT and
may cause burns.
Removing & Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front of rack and slide out.
To replace, fit the rack onto the guides on the oven walls. Tilt the front of the rack
upward and slide the rack back into place.
Recommended Rack Positions for Broiling, Baking & Roasting:
Food Rack Position
Broiling hamburgers & steaks 1
Broiling meats, chicken orfish 1,2 or 3
Cookies, cakes, pies, biscuits 3 or 4
& Muffins
Frozen pies, angel food cake, 5 or 6
yeast, bread, casseroles, small
cuts of meat or poultry
Turkey, roast or ham 5 or 6
Types of Oven Racks
Flat Handle Oven Rack Flat Half Oven Rac_
Fig. 3
Your range may be equipped with one or more
of the oven rack types shown; a Porcelain
coated Flat Handle Oven Rack (Fig. 3) or a
Porcelain coated Flat Oven Half Rack (Fig.
4). The Flat Oven Half Rack has a removable
insert that can provide extra space for larger
food items. The right half rack portion may still
be used for other food items like a casserole
dish (See Fig. 4).
Fig. 5
Fig. 4
®g
Fig. 6
To remove the Half Oven Rack insert, squeeze on the left front insert side (See Fig. 5) of the rack and tilt out clockwise. To
reinstall insert rear hooks at back of insert (See 1-Fig. 6) and lay insert down. Make sure both insert front hooks snap into
rack (See 2-Fig. 6).
Do not use cookware that extends beyond the edge of the Oven Flat Half Rack. For best results, allow 2 inches between
the pan placed on the rack and oven side or rear walls.
Before Setting Oven Controls
Baking Layer Cakes with Ior 2 Oven Racks
For best results when baking cakes using 2 oven racks, place cookware on oven rack positions 2 & 5 (See Fig. 1 and Fig.
2 on page 9). For best results when using a single oven rack, place cookware on oven rack position 4 (See Fig. 2 and Fig.
2 on page page 9).
Air Circulation in the Oven
For best air circulation and baking
results allow 2-4" (5-10 cm) around
the cookware for proper air circulation
and be sure pans and cookware do not
touch each other, the oven door, sides
or back of the oven cavity. The hot air
must be able to circulate around the
pans and cookware in the oven for
even heat to reach around the food. Fig. 1 Fig.2
Before Setting Surface Controls
Control Locations of the Gas Surface Burners
(For models with a Deep Well Cooktop-See Fig. 3)
Ther SIMMER Burner is best used for simmering delicate
sauces, etc. This burner is located at the right rear burner
position on the cooktop.
The STANDARD Burners can be used for most surface
cooking needs. These burners are located at the left front
and center positions on the cooktop.
The POWER Burners are best used for bringing large
quantities of liquid rapidly up to temperature or when
preparing larger quantities of food. These burner are
located at the right front and left rear positions on the
cooktop.
(For models with a Ceramic Cooktop-See Fig. 4)
Ther SIMMER Burner is best used for simmering delicate sauces,
etc. This burner is located at the right rear burner position on the
cooktop.
The STANDARD sized burners are used for most surface cooking
needs. These burners are located at the left front and left rear
positions on the cooktop.
The POWER Burner is best used for bringing large quantities of
liquid rapidly up to temperature or when preparing larger quantities
of food. This burner is located at the right front position on the
cooktop.
The BRIDGE Burner is best suited when using rectangular or long
shaped cookware. The left rear and left middle positions are
combined. The left front Burner may also be added for a total of 3
burners.
ii ii
i
FRONT R_AR C_NTER FRONT R_AR
Left Left Center Right Right
Front Rear Burner Front Rear
Burner Burner Burner Burner
Fig. 3 10
FI_ONT REAR BBIDG£ FRON{ REAl{
Left Left Rear & Right Right
Front Bridge Burner Front Rear
Burner Burner Burner
Fig. 4
