INSTALLATION, OPERATION AND
USE INSTRUCTION
KENSOL Heat Pump model:
KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW
Table of contents
1. INTRODUCTION........................................................................................................................................................1
1.1 Law ........................................................................................................................................................................................1
1.2 Risk of electrocution ......................................................................................................................................................2
1.3 Consumer information and safety..............................................................................................................................2
1.4 Warranty protection ........................................................................................................................................................2
1.5 Components of the set....................................................................................................................................................2
2. INTRODUCTION ......................................................................................................................................................3
2.1 Product overview .............................................................................................................................................................3
2.2 Heating tables ...................................................................................................................................................................3
2.3 Cooling capacity tables..................................................................................................................................................5
2.4 Heat pump operating envelope ...................................................................................................................................6
2.5 Technical data ...................................................................................................................................................................7
2.6 Device dimensions .........................................................................................................................................................8
2.7 Heat pump construction diagram ..............................................................................................................................10
3. INSTALLATION ......................................................................................................................................................11
3.1 Installation details..........................................................................................................................................................11
3.2 Condensate drainage .....................................................................................................................................................11
3.3 Installation location .......................................................................................................................................................12
3.4 Installation diagrams.....................................................................................................................................................12
3.5 Hydraulic connection .....................................................................................................................................................12
3.6 Electrical connection.....................................................................................................................................................14
3.7 Motherboard diagram ....................................................................................................................................................15
4. INSTALLATION OF KT-MULTI CONTROLLER................................................................................................. 18
4.1 Electrical diagram of KT-MULTI module .................................................................................................................18
4.2 Electrical installation of KT-MULTI controller.....................................................................................................20
4.3 Technical data of control automation...................................................................................................................... 22
4.4 Description of controller installation ....................................................................................................................23
4.5 Installation of KT-MULTI module...............................................................................................................................24
4.6 Installation of temperature sensors ......................................................................................................................25
4.7 Connecting pumps .........................................................................................................................................................27
4.8 Connecting a room thermostat .................................................................................................................................27
4.9 Connecting the Internet module ...............................................................................................................................28
5. CONTROLLER OPERATION.................................................................................................................................28
5.1 Setting of set temperature..........................................................................................................................................29
5.2 Time schedules.................................................................................................................................................................31
5.3 Weather control ..............................................................................................................................................................32
5.4 Mode settings...................................................................................................................................................................32
5.5 User settings....................................................................................................................................................................34
5.6 Cooperation with the Internet module....................................................................................................................35

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW
6. DESCRIPTION OF SERVICE PARAMETERS....................................................................................................36
6.1 Sample installation diagrams and suggested settings ....................................................................................43

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 1/49
1. Introduction
This guide contains instructions for installing,
operating and using KENSOL Inverter Air Heat
Pump. The following safety guidelines are desi-
gned to prevent unforeseen hazards and damage
resulting from improper or unsafe operation
of the device. Questions about this equipment
should be directed to the manufacturer or an
authorized KENSOL service partner. It is impe-
rative that you read all of the information in this
instruction and user guide before beginning in-
stallation and use. Any activity that contravenes
the provisions of the stipulations may result in
loss of life or health.
NOTE TO INSTALLER: THIS INSTRUCTION
CONTAINS IMPORTANT INFORMATION ON
THE INSTALLATION, OPERATION AND SAFE
USE OF THIS DEVICE. THIS INFORMATION
SHOULD BE PROVIDED TO THE OWNER OR
OPERATOR OF THE DEVICE AFTER INSTAL-
LATION. IT IS FORBIDDEN TO CARRY OUT
ANY ACTIVITY THAT CONTRADICTS THE
PROVISIONS OF THIS INSTRUCTION. THE
INSTALLER SHOULD READ THE ENTIRE CON-
TENTS OF THE INSTRUCTION BEFORE STAR-
TING ANY WORK. MATTERS OF CONCERN TO
THE INSTALLER SHOULD BE CONSULTED
DIRECTLY WITH THE MANUFACTURER. THE
INSTALLER SHOULD, HAVE ALL THE LEGAL
AUTHORIZATIONS NECESSARY TO INSTALL
EQUIPMENT CONTAINING FLUORINATED
GREENHOUSE GASES.
NOTE TO USERS: THIS INSTRUCTION CON-
TAINS IMPORTANT INFORMATION THAT WILL
HELP IN THE OPERATION AND MAINTENAN-
CE OF THE HEAT PUMP. KEEP IT FOR FUTURE
USE.
Remember the system contains fluorinated liqu-
or gas - difluoromethane (R 32) any installation
activities, servicing and use should be carried
out by entities experienced and authorized to
perform such work. A list of the manufactu-
rer’s authorized service partners is available
on its website. If this instruction is lost or de-
stroyed, the user may request a copy from the
manufacturer.
WARNING - READ AND FOLLOW ALL WAR-
NINGS INCLUDED IN THIS INSTRUCTION BE-
FORE INSTALLING THIS PRODUCT. FAILURE
TO FOLLOW SAFETY WARNINGS AND
INSTRUCTIONS MAY RESULT IN SERIOUS
PERSONAL INJURY, DEATH OR PROPERTY
DAMAGE. THE MANUFACTURER SHALL NOT
BE LIABLE FOR ANY DAMAGE CAUSED BY
FAILURE TO COMPLY WITH THE PROVISIONS
OF THIS INSTRUCTION OR IMPROPERLY
PERFORMED INSTALLATION OR OPERATION
OF THE DEVICE.
1.1 LAW:
KENSOL EVI DC inverter heat pump shall be
installed in accordance with the indications of
technical knowledge and in accordance with
the laws generally applicable in the Republic of
Poland on the date of installation. The instal-
lation shall be carried out in accordance with
the provisions of the Construction Law and in
accordance with the provisions of legal acts
regulating the installation and use of equipment
containing fluorinated greenhouse gases. By
proceeding with the installation, the installer
confirms that he has adequate knowledge, skills
and experience, and that he is familiar with all
technical standards necessary for the proper
installation of KENSOL heat pump. The beginning
of the installation is tantamount to the installer
accepting full responsibility for the proper exe-
cution of the installation work. The owner of the
device has the right to verify the authorizations
and permits used by the installer. If doubts are
raised about the reliability of the installer, or if
his qualifications are questioned, the user should
use the services of another entity, a list of which
can be found on the manufacturer’s website.
1.2 1.2 RISK OF ELECTRIC SHOCK.
The electrical supply of this product must be
carried out in accordance with the indications
of technical knowledge and only by an entity
that has the applicable authorization to perform

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 2/49
this type of work. Improper installation poses a
risk of electric shock, which can cause death or
serious injury to heat pump users, installers or
others. Read and follow the detailed guidelines
in this instruction, if you have any doubts about
how to connect the electrical supply or find that
the electrical supply equipment is not working
properly, call an authorized service partner
immediately to diagnose the problem.
WARNING - MINORS ARE NOT ALLOWED
TO OPERATE THE DEVICE. ANY TAMPERING
WITH THE PRODUCT MUST BE IN ACCORDAN-
CE WITH THE PROVISIONS OF INSTRUCTION
AND CAN ONLY BE DONE BY ADULTS.
1.3 CONSUMER INFORMATION AND SAFETY
KENSOL EVI DC inverter heat pumps are designed
and manufactured to provide years of safe and
reliable operation when installed, operated and
maintained in accordance with the information
provided in this instruction and the installation
regulations referred to in the following sections.
Read and follow all warnings and recommenda-
tions of the manufacturer. The consumer must
refrain from any tampering with the device bey-
ond those activities that are specifically stated
in this instruction.
1.4 GUARANTEE PROTECTION
The guarantee terms and conditions of the devi-
ce, as well as the procedure for handling claims
are specified in the device’s guarantee card. Any
service work should be performed by an autho-
rized entity with express authorization from the
manufacturer to perform the work. Any case
in which it is found that service work has been
performed by an unauthorized party may result
in the loss of guarantee protection.
The first commissioning can only be performed
by an Authorized Service Center designated by
the manufacturer.
1.5 KIT COMPONENTS
Make sure that all components are included in
the package before starting installation:
— KENSOL KTM monobloc heat pump
— Anti-vibration pads - set of 4 pcs.
— KT-MULTI heat pump controller
— Control panel with room thermostat
function
— ECOnet External Internet Module,
— 3 pcs of CT-10 temperature sensors,
— Installation Instruction.

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 3/49
2. Introduction
2.1 PRODUCT OVERVIEW
KENSOL pump uses the energy in the air and transfers it to our buildings, allowing us to heat and cool
our rooms and prepare hot water.
The KENSOL series uses a DC Twin Rotary inverter compressor thanks to this technology, the unit
ensures smooth operation from -30°C to 43°C. The unique control logic allows our series to intelli-
gently regulate the water temperature in accordance with the changing ambient temperature. With
this feature, our users can enjoy comfort at a lower cost.
The control system guarantees simple and intuitive management of the entire heating system. A buil-
t-in installer and user assistant provides support for the setup and operation process.
The ability to equip the heating circuit system with additional room thermostats makes it possible
to maintain the thermal comfort level set by the user from any room. A web-based system with a
mobile application that performs management and service functions allows us to remotely operate
and diagnose our device.
Reducing and preventing global warming is an important mission for KENSOL.
By using the low greenhouse effect potential of R32 refrigerant, the device is part of the green trend.
In addition, the use of R32 refrigerant provides 20% higher efficiency at low ambient temperatures.
2.2 HEATING TABLES
KTM6kW
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 3.8 4.3 5.1 6.1 7.1 8.4 8.9 9.3
Current consumption 1.4 1.5 1.5 1.6 1.7 1.9 1.9 1.9
COP 2.69 2.93 3.37 3.84 4.23 4.49 4.77 4.97
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 0.6 0.7 0.8 0.9 1.2 1.6 1.7 1.9
Current consumption 0.19 0.20 0.21 0.23 0.28 0.32 0.34 0.36
COP 3.27 3.41 3.63 4.01 4.38 4.91 5.09 5.14
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 3.7 4.1 4.9 5.9 6.9 8.1 8.6 9.0
Current consumption 1.6 1.7 1.7 1.9 2.0 2.2 2.2 2.2
COP 2.24 2.44 2.81 3.19 3.52 3.74 3.97 4.14
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 0.6 0.7 0.7 0.9 1.2 1.5 1.7 1.8
Current consumption 0.22 0.24 0.25 0.27 0.32 0.37 0.40 0.42
COP 2.72 2.84 3.02 3.34 3.64 4.08 4.23 4.27
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 3.5 4.0 4.7 5.7 6.6 7.8 8.3 8.6
Current consumption 1.9 1.9 2.0 2.1 2.2 2.5 2.5 2.5
COP 1.89 2.05 2.36 2.69 2.96 3.15 3.35 3.48
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 0.6 0.6 0.7 0.9 1.1 1.5 1.6 1.7
Current consumption 0.25 0.27 0.28 0.31 0.37 0.42 0.45 0.48
COP 2.29 2.39 2.54 2.81 3.07 3.44 3.57 3.60
Outdoor temperature (°C) -25 -20 -12 -7 0 7 15 21

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 4/49
KTM10kW
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 5.9 6.6 7.9 9.5 11.0 13.0 13.8 14.4
Current consumption 2.3 2.4 2.4 2.6 2.7 3.0 3.0 3.0
COP 2.58 2.81 3.23 3.68 4.05 4.30 4.58 4.76
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 1.8 1.9 2.2 2.6 3.4 4.4 4.9 5.2
Current consumption 0.54 0.57 0.60 0.66 0.78 0.90 0.96 1.02
COP 3.26 3.40 3.62 4.00 4.36 4.89 5.07 5.12
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 5.7 6.4 7.6 9.2 10.7 12.5 13.3 13.9
Current consumption 2.6 2.7 2.8 3.0 3.2 3.5 3.5 3.5
COP 2.14 2.34 2.69 3.06 3.37 3.58 3.81 3.96
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 1.7 1.9 2.1 2.5 3.3 4.2 4.7 5.0
Current consumption 0.63 0.66 0.70 0.77 0.90 1.04 1.11 1.18
COP 2.71 2.83 3.01 3.33 3.63 4.07 4.22 4.26
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 5.4 6.1 7.3 8.8 10.2 12.0 12.8 13.3
Current consumption 3.0 3.1 3.2 3.4 3.6 4.0 4.0 4.0
COP 1.81 1.97 2.27 2.58 2.84 3.02 3.21 3.34
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 1.6 1.8 2.0 2.4 3.1 4.1 4.5 4.8
Current consumption 0.71 0.75 0.79 0.87 1.03 1.19 1.27 1.35
COP 2.28 2.38 2.54 2.80 3.06 3.43 3.55 3.59
Outdoor temperature (°C) -25 -20 -12 -7 0 7 15 21
KTM14kW
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 8.2 9.3 11.0 13.3 15.5 18.2 19.3 20.1
Current consumption 3.1 3.2 3.3 3.5 3.7 4.1 4.1 4.1
COP 2.65 2.89 3.33 3.78 4.17 4.43 4.71 4.90
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 2.4 2.6 2.9 3.5 4.6 5.9 6.5 7.0
Current consumption 0.72 0.76 0.80 0.88 1.04 1.20 1.28 1.36
COP 3.28 3.42 3.64 4.02 4.39 4.92 5.10 5.15
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 8.0 8.9 10.6 12.8 14.9 17.6 18.7 19.4
Current consumption 3.6 3.7 3.8 4.1 4.3 4.8 4.8 4.8
COP 2.21 2.40 2.77 3.15 3.47 3.68 3.92 4.08
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 2.3 2.5 2.8 3.4 4.4 5.7 6.3 6.8
Current consumption 0.84 0.88 0.93 1.02 1.21 1.39 1.48 1.58
COP 2.73 2.84 3.03 3.35 3.65 4.09 4.24 4.28
Outdoor temperature (°C) -25 -20 -12 -7 0 7 15 21

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 5/49
KTM14kW
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 7.6 8.6 10.2 12.3 14.3 16.8 17.9 18.6
Current consumption 4.1 4.2 4.4 4.6 4.9 5.4 5.4 5.4
COP 1.86 2.03 2.33 2.65 2.92 3.10 3.30 3.43
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 2.2 2.4 2.7 3.3 4.2 5.5 6.0 6.5
Current consumption 0.95 1.00 1.06 1.16 1.37 1.58 1.69 1.80
COP 2.30 2.39 2.55 2.82 3.07 3.45 3.57 3.61
Outdoor temperature (°C) -25 -20 -12 -7 0 7 15 21
KTM17kW
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 10.4 11.7 13.9 16.8 19.5 23.0 24.4 25.5
Current consumption 4.0 4.1 4.2 4.5 4.7 5.2 5.2 5.2
COP 2.63 2.87 3.30 3.76 4.14 4.40 4.67 4.87
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(30°C/35°C)
Heating capacity (kW) 3.0 3.3 3.7 4.5 5.8 7.5 8.3 8.9
Current consumption 0.92 0.97 1.02 1.12 1.33 1.53 1.63 1.73
COP 3.27 3.41 3.63 4.01 4.37 4.90 5.09 5.13
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 10.1 11.3 13.4 16.2 18.8 22.2 23.6 24.6
Current consumption 4.6 4.7 4.9 5.2 5.5 6.1 6.1 6.1
COP 2.19 2.39 2.75 3.13 3.44 3.66 3.89 4.05
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(40°C/45°C)
Heating capacity (kW) 2.9 3.2 3.6 4.3 5.6 7.2 8.0 8.6
Current consumption 1.06 1.12 1.18 1.30 1.54 1.77 1.89 2.01
COP 2.72 2.83 3.02 3.34 3.64 4.08 4.23 4.27
MAX
MAX Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 9.6 10.8 12.9 15.5 18.1 21.3 22.6 23.5
Current consumption 5.2 5.4 5.6 5.9 6.2 6.9 6.9 6.9
COP 1.85 2.01 2.31 2.63 2.90 3.08 3.28 3.41
MIN
MIN Temp.
of water
(Inlet/ Outlet)
(50°C/55°C)
Heating capacity (kW) 2.8 3.1 3.4 4.2 5.4 6.9 7.7 8.2
Current consumption 1.21 1.28 1.35 1.48 1.75 2.02 2.15 2.29
COP 2.29 2.39 2.54 2.81 3.07 3.44 3.56 3.60
Outdoor temperature (°C) -25 -20 -12 -7 0 7 15 21
2.3 TABELE WYDAJNOŚCI CHŁODNICZEJ
KTM6kW
MAX
Cooling capacity (kW) 7.8 7.2 6.2 5.8
Current consumption (kW) 2.4 2.4 2.2 2.0
EER 3.25 2.98 2.85 2.85
MIN
Cooling capacity (kW) 1.3 1.1 1.0 0.9
Current consumption (kW) 0.3 0.3 0.3 0.3
EER 4.10 3.57 3.41 3.27
Outdoor temperature (°C) 21 30 35 43

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 6/49
KTM10kW
MAX
Cooling capacity (kW) 10.3 9.4 8.2 9.0
Current consumption (kW) 3.6 3.6 3.3 4.7
EER 2.82 2.59 2.48 1.92
MIN
Cooling capacity (kW) 3.7 3.2 2.8 3.1
Current consumption (kW) 0.9 0.9 0.9 0.8
EER 3.96 3.44 3.29 3.84
Outdoor temperature (°C) 21 30 35 43
KTM14kW
MAX
Cooling capacity (kW) 14.5 13.3 11.5 10.7
Current consumption (kW) 4.5 4.5 4.1 4.1
EER 3.24 2.98 2.85 2.60
MIN
Cooling capacity (kW) 5.0 4.4 3.8 3.5
Current consumption (kW) 1.2 1.2 1.1 1.1
EER 4.13 3.59 3.43 3.29
Outdoor temperature (°C) 21 30 35 43
KTM17kW
MAX
Cooling capacity (kW) 18.3 16.8 14.6 13.6
Current consumption (kW) 5.7 5.7 5.1 5.2
EER 3.24 2.97 2.84 2.59
MIN
Cooling capacity (kW) 6.3 5.4 4.7 4.4
Current consumption (kW) 1.5 1.5 1.4 1.3
EER 4.09 3.56 3.40 3.26
Outdoor temperature (°C) 21 30 35 43
2.4 HEAT PUMP OPERATION ENVELOPE
EVI OFF
EVI ON
-35
60
50
55
70
65
45
40
35
30
25
20
15
10
5
0
-30 -25 -20 -15 -10 -5 0 5 10 15 20 25 30
40~80Hz
30~90Hz
20~110Hz
OUTDOOR TEMPERATURE (⁰C)
MAXIMUM SUPPLY TEMPERATURE (⁰C)

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 7/49
2.5 SPECIFICATIONS
Product model KTM6KW KTM10KW KTM14KW KTM17KW
Heating mode
Heating capacity
(kW) 1.57~8.40 4.40~13.00 5.9~18.2 7.5~23.0
Current con-
sumption (kW) 0.32~1.87 0.90~3.02 1.20~4.11 1.53~5.23
Znamionowy prąd
roboczy (A) 1.42~8.30 1.39~4.68 1.86~6.37 2.37~8.11
COP 4.49~4.91 4.30~4.90 4.43~4.92 4.40~4.90
Cooling mode
Cooling capacity
(kW) 0.99~6.22 2.80~8.20 3.81 ~11.53 4.73~14.6
Current con-
sumption (kW) 0.29~2.18 0.85~3.31 1.11 ~4.05 1.39~5.14
Znamionowy prąd
roboczy (A) 1.28~9.67 1.32~5.13 1.72~6.28 2.16~7.97
EER 2.85~3.41 2.48~3.29 2.85~3.43 2.84~3.40
DHW mode
Heating capacity
(kW) 1.28~6.81 3.52~10.50 4.80~14.72 6.1 ~18.5
Current con-
sumption (kW) 0.31~2.13 0.88~3.39 1.17~4.60 1.53~5.97
Znamionowy prąd
roboczy (A) 1.38~9.45 1.36~5.26 1.82~7.15 2.37~9.26
COP 3.2~4.1 3.1~4.0 3.2~4.1 3.1~4.0
Power supply (Voltage, Phases,
Frequency)
230V/1 Ph
/50-60Hz 380V/3Ph/50-60Hz
Maximum water temperature 60°C
Working range -30~48°C
Seasonal energy efficiency class
(W35°) A+++
Seasonal energy efficiency class
(W55°) A++
Refrigerant R32
Compressor Panasonic
IP degree (protection level) IPX4 IPX4 IPX4 IPX4
Electric shock resistance IIII
Noise (dB(A)) ≤53 ≤55 ≤57 ≤58
Water pressure drop (kPa) 31 25 35 45
Required minimum flow rates (l/ min) 23.3 36.6 51.6 66.6

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 8/49
Product model KTM6KW KTM10KW KTM14KW KTM17KW
Water connection (mm) DN25 DN25 DN25 DN25
Min. cross section of the main power
cable (mm²) 3x4 5x2.5 5x4 5x4
Recommended protection C20A C16A C20A C20A
Housing dimensions (w*d*h) (mm) 970x475x835 1100x475x985 1050x480x1330 1050x480x1330
Net weight / Gross weight (kg) 110/120 140/150 170/180 180/190
NOTES:
Heating mode: Ambient Temp (DB/WB): 7/6°C. Water Temp (Inlet/Outlet): 30/35°C
Cooling Mode - Ambient Temp (DB/WB): 35/24°C Water Temp (Inlet/Outlet): 12/7°C DHW
mode - Ambient temp (DB/WB): 20/15°C. Water Temp (Inlet/Outlet): 15/55°C
Attention:
The above design and specifications are subject to change without prior notice for product
improvement. Detailed technical data of the devices can be found on the nameplates placed on
the devices
2.6 DIMENSIONS OF THE DEVICE
KTM6KW

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 9/49
KTM10KW
KTM14KW/KTM17KW

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 10/49
2.7 SCHEMAT BUDOWY POMPY CIEPŁA
NR Części zamienne Kod
1Flow sensor DR-S00101020-00
2Top cover PT050202008KH5
3Electrical box cover PT050202008KH2
4Electric cabinet PT050202008KH1
5Back mesh PT05020200810-08
6Electronic expansion
valve 1 ZF-DZ00008SH-00
7Electronic expansion
valve 2 ZF-DZ00001SH-02
8Right rear panel PT05020200810-04
9Induction choke DR-D00300905-15
10 Four-way valve ZF-SD00023CH-03
11 Needle valve NZ-GJX010001-03
12 High pressure switch DR-YO1440380-02
13 Low pressure switch DR-Y02005015-01
14 Right side panel PT05020200810-05
15 Filter ZG-G051S0303-00
16 Shell heater exchanger ZE-KG01ZF091-01
17 Compressor ZY-D138ZBA2J-03
18 Tank ZH-081514005-02
19 Plate heat exchanger ZE-B36R20450-QT
20 Middle partition PT05020200810-06
21 Fan bracket PT05020200810-13
22 Frame PT05020200810-01
23 Front right panel PT05020200810-03
24 Wind shield PT05020200810-02
NR Części zamienne Kod
25 Fan motor DR-F00810080-00
26 Fan protection mesh PT05020200810-16
27 Capacitor ZC-030072602-00
28 Left mesh PT05020200810-07
29 Common terminal block DT-J13044501-02
30 Magnetic ring DF-H10HX2017-01
31 Power terminals DJ-J19032501-04
32 Functional terminals DT-J06101001-06
33 Controller interface DR-D00300905-15
34 Frame PT05020200810-14

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 11/49
3. INSTALLATION
WARNING!
Do not install the heat pump near hazardous materials and areas. Do not install the heat pump under
deeply sloping roofs without gutters, exposing the unit to excessive flooding and drenching. Place
the heat pump on a structure founded on a stable foundation with adequate load-bearing capacity,
such as a concrete foundation. This will allow proper drainage of condensate and rainwater from the
base of the unit. Use anti-vibration washers for mounting. During operation of the device, condensate
condenses from the evaporator, which drains at a constant rate, depending on the temperature and
humidity of the air in the environment. The higher the ambient humidity, the greater the condensation
will be. The lower part of the unit acts as a tray that retains rainwater and condensation. The drain
holes located on the lower base plate of the unit should always be free of debris. It is required to raise
the unit to a minimum height of 30 cm.
3.1 INSTALLATION DETAILS
All criteria given in the following sections are for minimum spacing. However, each installation should
be evaluated on a case-by-case basis, taking into account local conditions such as the proximity and
height of walls and the proximity of areas accessible to people. The heat pump should be placed in
such a way as to provide clearance on all sides for maintenance and inspection.
1. The installation site of the heat pump must provide free air exchange, and the air inlet/outlet
must not be obstructed.
2. Ensure adequate drainage of condensation, for example, into an absorbent substrate.
3. Do not install the device in areas of accumulation of contaminants, such as agresive gases (chlo-
rine or acids), dust, sand, leaves, etc
4. To facilitate maintenance and troubleshooting, no obstructions around the unit should be closer
than 0.5 m. There must be no obstructions that impede ventilation within 2 m vertically of the
unit. (see Figure 1)
5. The heat pump must be installed on anti-vibration bushings to prevent vibration or unbalance.
6. Hydraulic lines must be installed with adequate support to prevent possible damage caused by
vibration.
7. The outdoor unit should be connected to the system with flexible conduits to ensure compensa-
tion for any movement between the heat pump and the system.
8. Since the heat pump operates in bivalent mode, each installation must be equipped with an
automatic peak heat source. Such a source must meet the following requirements:
a) It must be activated via a potential-free contact with the PC.
b) It must work for all heating circuits and DHW depending on demand
9. In order to protect the heat pump from impurities, it is absolutely necessary to install a magnetic
separator and a mesh filter on the return
10. The heat pump system must operate in a closed system. In addition, such an installation should
be protected against large pressure changes with a diaphragm vessel and against excessive
pressure with a safety valve (max 3bar)
11. Heating water parameters:
a) Temperature: ≤60oC

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 12/49
b) pH: 7-9 pH
c) Alkalinity: 60mg/l<HCO3<300mg/l
d) Conductivity: <500µS/cm
e) Hardness: 3,5-8,4 odH
12. The unit must have external antifreeze protection. This protection is designed to prevent the
circulating water in the system from freezing in the event of an electrical failure/outage.
Acceptable anti-freeze solutions:
a) Propylene glycol solution to a concentration of 30%
b) Solution of other antifreeze with corrosion inhibitors
c) Anti-freeze valves
d) UPS-based anti-freeze systems with manufacturer’s guarantee for tripping in emergency
situations
NOTE
Own solutions are not allowed as the only option to protect the heat pump from freezing
3.2 CONDENSATE DRAINAGE
Condensation occurs during the heat pump defrost process. The frequency of this process and the
rate of condensate drainage will depend on the outside temperature and humidity. The higher the
humidity, the greater the condensation will be. The lower part of the device functions as a drip tray
that catches rainwater and condensation. The drain holes, located on the lower base plate of the unit,
should always be kept free of debris..
INSTALLATION LOCATION
IIO-848:2022/EN rev. 2.0
Figure 1
Air inlet
Air outlet
Heat pump
Air in.
Air in
0.5m
0.5m 0.5m
0.5m
0.5m
2m
0.5m

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 13/49
3.3 INSTALLATION DIAGRAMS
17
Wi-Fi
ISM
H1-P
H2-S
H2-P
H2-M
BH
BL
C-P
HDW
Z3D
OUT
ISM
4
18
1
6
5
7
9
12 16
15
11
14
13
8
10
21
22
19
20
3
2
3
1
The hydraulic diagram shown is not a substitute for the design of the central heating system and is
for illustrative purposes only..
Diagram with heat buffer and DHW tank: 1 - KENSOL KTM heat pump, 2 - KT-MULTI controller, 3 - Internet modu-
le, 4 - 3-way valve, 5 - DHW tank temp sensor, 6 - DHW tank, 7 - circulation pump, 8 - lower buffer temperature
sensor, 9 - upper buffer temperature sensor, 10 - heat buffer, 11 - control panel with room thermostat function,
12 - circulating pump I circuit 1, 13 - wireless room thermostat, 14 - mixer temp sensor 2, 15 - circulating pump
II circuit 2, 16 - mixing valve with actuator, 2, 17 - circulating pump, 18 - flow heater, 19 - antifreeze protection,
20 - magnetic separator + mesh filter, 21 - central heating safety group, 22 - DHW safety group.
3.4 HYDRAULIC CONNECTION
Required minimum flows:
Type of heat pump KTM 6kW KTM 10kW KTM 14kW KTM 17kW
Minimum flow [liter/minute] 23,3 36,6 51,6 66,6
To ensure minimum flow rates, hydraulic connections must be made with appropriate diameters.
Recommended pipe diameters:
Type of heat pump KTM 6kW KTM 10kW KTM 14kW KTM 17kW
PP 32mm 32mm 40mm 50mm
Clamping steel 28mm 28mm 35mm 42mm
PeX 32mm 32mm 40mm 63mm

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 14/49
NOTE! Avoid the use of unnecessary angle joints, connectors and constrictions. If there are
a large number of connectors, increase the diameter of the wires. Pipelines and connections
should be thermally insulated. It is recommended to connect the outdoor unit with flexible
installation elements or use expansion joints.
BUFFER TANK
In heat pump heating systems, the buffer tank performs key functions. The main tasks of buffer tank
– heat accumulation for the defrost process,
– hydraulic separation of the heat pump circuit and the central heating system circuit, ensuring the
minimum heating water flow rate required by the heat pump,
– possibility of expanding the heating system with other heat sources,
– extending the operating time of the heat pump in periods of partial demand, this affects the reduc-
tion of cycles of compressor start-ups extending its service life
– storage of thermal energy, e.g., during the cooperation of a heat pump with a PV plant
WARNING - In the case of a heating system based on a radiator system and the occurrence of
other heat sources, it is necessary to include a buffer tank in the heat pump installation.
A minimum water charge should be ensured in the installation. For Kensol heat pumps, assume the
relationship for the minimum water charge: 15L of discharge per 1kW of nominal PC power A buffer is
not required, but it is recommended to install a heat buffer on the system in parallel connection due
to a number of advantages. You can hook up the PC directly to the system, however, you must ensure
a minimum water charge and minimum flows regardless of the external control of the circuits on the
system.
DWH STORAGE TANK
The DHW tank is a tank equipped with a heat exchanger that stores hot water distributed for domestic
use.
Average daily energy consumption for DHW heating per person can be assumed from 1.5 kWh to 2.5
kWh and water consumption of 50-70 L per person.
The use of DHW circulation can increase energy consumption for DHW purposes by up to two times.
When selecting a coil tank for a heat pump, it is important to pay attention to its appropriate capacity
for the DHW demand and the heat transfer surface area.
For single-family houses, small and medium-sized heat pump installations, the minimum exchanger
area should be taken as 0.2 m² per 1 kW (recommended 0.25 m² per 1 kW) of storage charging capacity.
3.5 ELECTRICAL CONNECTION
WARNING - Electrical shock hazard may occur when working on the device.
Before installing the heat pump, make sure that all high-voltage circuits are disconnected. Contact
with these circuits can cause death or serious injury to users, installers and others from electrical
shock, and can also cause damage to property.

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 15/49
NOTE - Before disconnecting the wires when servicing the heat pump, mark all wires. Wiring
errors can cause incorrect and unsafe operation of the device. After servicing, check that the
device is working properly.
SUPPLY
1. If the supply voltage is too low or too high, it may cause damage and/or unstable operation of
the heat pump unit due to high inrush currents
2. The minimum starting voltage should be above 90% of the rated voltage. The allowable opera-
ting voltage range should be within ±10% of the rated voltage.
3. The wires used must be designed for permanent installation and be resistant to external
conditions.
4. The cross-section of the wire depends on the distance between the device and the switchboard.
The value should be verified by a person with appropriate electrical qualifications.
5. The electrical installation should be carried out by a person with the appropriate authorization
and in accordance with applicable national regulations.
6. All power wires should be run in insulation. The length of the stripped section of wire should not
be longer than 50mm.
7. Do not frequently interrupt the voltage supply to the heat pump, as this may shorten its life.
8. Do not unplug the wires and sensors located in the outdoor unit.
A PC<->KT-Multi communication wire is included with the controller.
MAIN POWER SUPPLY CONNECTION
NOTE - Before installing the heat pump, verify the connection power of the building and the
protection used. In addition, note that the heat pump and the controller must be protected by a
residual current circuit breaker with a tripping current of IΔn ≤30mA
1. The device should be powered directly from the electrical switchboard.
2. The heat pump should be protected by an overcurrent circuit breaker with characteristic C and
a 30mA residual current device
Recommended protection and minimum cross-section of the main power wire:
1-phase system (KTM6KW) C20A 3x4 mm²
3-phase system (KTM10KW) C16A 5x2,5 mm²
3-phase system (KTM14KW) C20A 5x4 mm²
3-phase system (KTM17KW) C20A 5x4 mm²
3. The wire should be inserted through the cable gland and plugged in according to the wiring
diagram.

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 16/49
3.6 MOTHERBOARD DIAGRAM
1-PHASE SYSTEM (KTM6KW)
M
~M
~
Compressor AR-YCDLM2129-20 Magnetic ring
UW
V
UVW
PFC
DC FAN
EGND
ON
SW1-1
DC 1 is valid
DC 1 is invalid
Reserved With hot water With coding
NO codingNo hot waterReserved
SW1-2 SW1-3 SW1-4
OFF
AC-N AC-N
AC-L
RY1
Circul.Pump
Auxiliary Heating
4-Way Valve 3-Way Valve Cranks haft Chassis
OUT1
CN6 CN8
Low pressure Sensor
Control
panel
VCC
Red
white
Black
T1 T2 T3 T4 T5 T6 T7 T8
T11 T10 T9
GND
low pressure
High
pressure
switch
Low
pressure
switch
Water
flow
Compressor
OLP
RY1
PE
CN-RAT2
CN-RAT1
OUT2 OUT3 OUT4 OUT5 OUT6
Main EEV
SW1
Auxiliary EEV
OUT7
L N
AC220V/50Hz
1
Auxiliary
heating
Circul.
pump
3-way
valve
Neutral
line
Linkage
switch
COM
234 56
Heating Coil Sensor
Water Tank Sensor
Water inlet Sensor
Discharging Sensor
Suction gas Sensor
Cooling Coil Sensor
Ambient Sensor
Water Outlet Sensor
EVI Outlet Sensor
EVI Inlet Sensor
IN1 IN2 IN3 IN4

Installation, operation and use instructions for KTM 6 KW, KTM 10 KW, KTM 14 KW, KTM 17 KW 17/49
3-PHASE SYSTEM (KTM10KW)
1
Water tank
heater
Pump
3-way
valve
Neutral
line
Linkage
Switch
COM
RY
G
R
B
AC380V/50Hz
S
T
N
PE
Reactor
EARTH
PE
RAT 1
RAT 2
DC-FAN1
DC-FAN2
CN18
CN3
2N3
LED RUN
Control
panel
CN17
Driver
Board
R
S
U
Y W
T
FAN1
PE
2 3 4 5 6
PE
GND
EGND
N
pump
4-way
valve 4-Way
3-Way
CHA
OUT13 OUT12 OUT11 OUT10 OUT9 OUT8
E-VAL1
Auxiliary EEV Main EEV
Main Board E-VAL2 E-VAL3
SW1
ON
1 2 34
DIP
OUT7 OUT6 OUT5
Water tank
heater
Crankshaft
heater
Chassins
heating
3-Wa y
valve
4-Wa y
valve
E-Heater
Circul pump
OUT4 OUT3 OUT2 OUT1
COMIN5IN4IN3IN2IN1
T9 T10 T11
COM
Linkage Switch
Water flow switch Low pressure switch High pressure switch
EVI outlet temp EVI inlet temp
Cover protection switch
CRA
Crankshaft
Heater
AR-YCDLM2129-21
Water tank heater
Chassis
heating
N
L
L
ON
SW1-1
DC 1 is valid
DC 1 is invalid
Reserved With hot water With coding
NO codingNo hot waterReserved
SW1-2 SW1-3 SW1-4
OFF
M
Compressor
U
Y
G RW
V
A B
CN485
T1 T2 T3 T4 T5 T6 T7 T8
Water Outlet Temp
Ambient temp
Cooling coil temp
Return gas temp
Exhaust gas temp
Water Inlet temp
Water tank temp
Heating coil temp
