SERVICE MANUAL
This product uses Lead Free solder.
This product complies with the RoHS directive for the European market.
© 2008-1 PRINTED IN JAPAN
B53-0611-00 (N)519
KAC-9104D
CLASS D MONO POWER AMPLIFIER
BASS BOOST
LEVEL[dB]
LPF
FREQUENCY[Hz]
INPUT
SENSITIVITY[V]
[MIN] [MAX]
OFF 15Hz
ISF
LINE IN LINE OUT
25Hz
PHASE
SP LEVEL INPUT
SIGNAL SENSING
TURN-ON
FUSE[30Ax2] P.CON
POWER IN SPEAKER OUTPUT
180û0û
Accessories
(W01-1606-05)
Screw & wrench key set
(N99-1820-05)
Connecting cord assy
(E30-6145-05)
19cm
Dressing Panel
(A21-6637-01): (E,K type)
(A21-6638-01): (M type)
M type
E,K type
Fuse (30A)
(F52-0015-05)

2
KAC-9104D
BLOCK DIAGRAM
FREQ
(50~200Hz)
LEVEL
SIFT
D-AMP
ON/OFF
DRIVE FINAL
MOS-FET LC FILTERCOMP DEAD TIME
SUMMING
AMP
TRIANGLE
WAVE
SP
OUTPUT
BATT.
GND
P-CON
THERMAL
DET
OVERLOAD
DET
DC-OFFSET
DET
MUTE ATT
±15V
AVR
POWER
ON/OFF
±B+HB
AVR
LC FILTER
ISO-AMP
SP INPUT
LINE IN
L
R
(0.2~5V)
L+
L-
R-
R+
LEVEL
0~18dB
NF
DC/DC
CON
I.S.F
SEL.
Bass
Boost
SENS.
VOL
L.P.F
I.S.F
15Hz
25Hz
FREQ=40Hz
LINE OUT
L
R
INV
SEL
+6dB 6dB
+35dB
AUTO
P-CON
0
10
20
dB
30
40
50
D CLASS POWER AMPFILTERISO AMP
LEVEL DIAGRAM
IC1 IC2(2/2)
IC3(1/2)
IC3(2/2) IC4 IC5
Q313,314Q315
IC6(2/2)
IC6(1/2)
IC7 IC8,9 Q102-104,108,109
Q105-107,
Q110-112 Q701-704
Q101
IC13 IC17 (2/2) Q307-311
Q24-27 D21,22 Q30
IC15
Q2,3Q4,5

3
KAC-9104D
COMPONENTS DESCRIPTION
●AUDIO UNIT (X09-8750-10)
Ref. No. Application / Function Operation / Condition / Compatibility
IC1 Isolation amplifier Isolates noises caused by potential differences in GND
IC2 Phase Change phase (0° →180°)
IC3 INFRA SONIC FILTER Cuts off ultra low frequency of audio signal
IC4 LOW PASS FILTER Cuts off high frequency of audio signal
IC5 BASS BOOST Bass boost (Variable level)
IC6 (1/2) Triangular wave generation Generates reference signal for digitalizing analog signal
IC6 (2/2) Error amplifier Compensates errors by feedback from the output
IC7 Comparator Digitalizes by comparing analog signal with triangular waves
IC8,9 NAND Generates and shapes the inverted waveform and to create dead time in D-
class section
IC10,11,14 Resonance detection circuit Detects short in SP output circuit, measures over current in the circuit, and
activates the protection operation
IC13 Comparator, Control circuit Controls D/D CON and D-class On/Off with the over current detection and
Pcon control signals
IC15 DC/DC converter IC Generates drive signal for switching component
IC16 (1/2)
Attenuation circuit to attenuate input signal by 6dB Attenuates output when temperature in the set becomes too high
IC16 (2/2)
Attenuation circuit to attenuate input signal by 1.5dB Attenuates output when temperature in the set becomes high
IC17 (1/2) Power supply voltage PWM control
Controls the dead time of DC/DC converter when the power supply voltage in
the secondary side becomes too high. Prevents the power supply from pumping
IC17 (2/2) Temperature protection Turns off DC/DC converter when temperature in the set becomes too high
Q1-3 PCON switch Turns on the circuit when ON signal is applied to the PCON circuit
Q4,5 AUTO Pcon Sends DC voltage from SP IN to Pcon control circuit
Q6,7 Mute Generates mute drive signal and turns off LED
Q8,9 DC/DC converter ON/OFF control Turns off DC/DC converter when protection is detected
Q10 4.4V AVR Vef 5V reference AVR
Q11,12 DC/DC converter pulse ON/OFF control ON or OFF of DC/DC converter drive waveform
Q13-16 Gate driver Gate driver in DC/DC converter FET
Q17-22 DC/DC converter DC/DC converter switching
Q23 FAN drive Limits FAN power supply voltage under the rated voltage
Q24-27 AVR ±15V AVR
Q28,29 Tracking when ±15V AVR is turned OFF Matches the trailing edge of “-15V” AVR with that of “+15V” AVR
Q30 HB 15V AVR Stacking AVR to obtain High+B for D-class
Q101,113 D-class amplifier switch Turns the D-class amplifier ON or OFF
Q102-112 Pulse amplification, shaping and level shift Generates the signal that drives the D-class final FET
Q301-304 Current-voltage conversion
Converts current to voltage to detect over current and sends it to the comparator
Q305,306 Resonance detection circuit Detects short in SP output circuit, measures over current in the circuit, and
activates protection operation
Q307-311 Latch circuit Detects abnormal output DC voltage and retains it
Q312 Comparator, Control circuit Controls D/D CON and D-class On/Off with the over current detection and
Pcon control signals
Q313
Attenuation circuit to attenuate input signal by 1.5dB Attenuates output when temperature in the set becomes high
Q314
Attenuation circuit to attenuate input signal by 6dB Attenuates output when temperature in the set becomes too high
Q315 Mute Turns off audio signal
Q701-704 Electric power amplification Switching of D-class high current
