Kenwood DNN9230DAB Quick start guide

KENWOOD MULTIMEDIA NAVIGATION SYSTEM
DNN9230DAB
EasySet-up
Guide
Version
1.1

KENWOOD
Easy Set-up Guide
Table of Contents
Step 1:- Register On-line Kenwood’s Route Collector...........................................................1
Step 2:- Setting Up DNN9230DAB with Wifi Connection......................................................7
Step 3:- Date/Time Set-up and Turning Off Demo Mode......................................................9
Date and Time Set-up.............................................................................................................................9
Turning Off Demo Mode.......................................................................................................................12
Step 4:- Owner Account Setup............................................................................................13
Step 5:- Setting Up Facebook Account................................................................................15
Step 6:- Setting Up Twitter Account.....................................................................................17
Step 7:- Setting Up Gmail Account......................................................................................18
Step 8:- Setting Up Dropbox Account..................................................................................20
Step 9:- Setting Up RSS Feeds...........................................................................................26
How to add more User Accounts.........................................................................................29
How to switch between User Accounts................................................................................................30
How to change over to Guest Account ................................................................................33
Use system with no Facebook, Twitter & Gmail...................................................................................33
How to change back from Guest Account to Owner Account ..............................................................34
How to use Trip Planner......................................................................................................36

1
Step
1
Step 1:- Register On-line Kenwood’s Route
Collector
The very first thing you should do is set-up an account on Kenwood’s Route Collector website
via your computer/laptop https://www.route-collector.com/
Route Collector is necessary if you want to use features such as Facebook, Twitter, Gmail,
RSS, Dropbox and Route Planner.

•Click on [Sign Up Now!]
•Input an Account name (Use at least 5 characters (a-z,A-Z,0-9,_))
•E-mail address (Ensure that this e-mail address has not been used before on the Route
Collector website.
•Password (Use at least 8 characters.(a-z,A-Z,0-9,_) and no spaces)
•Retype password
•Then tick [I Agree]
•Click on [Create]
NOTE: Please remember these details
2

•Check that the details are correct and then click on [Create]
•Now check your e-mail inbox for a confirmation message
•Click the link in the confirmation message
3

•Now click on [Input User Info]
•Fill in information (Please note that these fields are not mandatory)
•The click on [Next]
4

•Fill in information (Please note that these fields are not mandatory)
•The click on [Next]
5

•Check info and click [OK]
The account is now set-up. Go to Step 2 to see how to link this account onto the DNN9230DAB. (We will
explain further features on the Route Collector website later in this guide)
6

Step
2
Step 2:- Setting Up DNN9230DAB with Wifi
Connection
You will require access to the internet to set up the system. This can be done via a wireless
router or by using your phone’s/tablet’s Wifi personal hotspot. (For initial setup we recommend
using a wireless route for quicker internet access)
Before starting please ensure that you have the password for your Wifi router or phone’s/tablets personal
hotspot.
•Power on DNX9230DAB, once powered up you will see the Initial SetUp Page as below
NOTE: If you do not see this screen please select the [Menu] button hard key on the front panel and
then selecting [Setting].
•Select [Wifi Setup]
NOTE: If the demo movie starts then touch the touch-screen anywhere and this will bring you back to
the original screen you where on.
7

•Switch the Wifi on by touching
the screen as shown
•It will then display “Turning Wifi
on” for a few seconds
•The unit will then automatically
scan for Wifi devices
•Once the list has populated
select the Wifi device you wish to
connect with as show above
•Touch the touch-screen as
shown
•A keyboard will appear, input the password for your router/phone/tablet then select [Done]
•Then select [Connect]
•Your selected Wireless router will then display “Connected”
•Then select the [Home] hard key button on the front of the DNN9230DAB. This will take you
back to the “Initial Setup” screen
8

Step
3
Step 3:- Date/Time Set-up and Turning Off
Demo Mode
The Date & Time needs to be set-up and Demo Mode should be switched off before you
connect your Route Collector account to the DNN9230DAB and all it’s features such as
Facebook, Twitter, Gmail, RSS Feeds, Dropbox etc.
Date and Time Set-up
Setting the date and time manually is only required if there is no Navigation GPS signal and Tuner RDS
reception.
If the DNN9230DAB has the correct date and time please proceed to Turning Off Demo Mode.
•Select [Date Setup]
9

•Uncheck [Automatic date & time
NAV-SYNC]
•Select [Set Date]
•Adjust the date accordingly
•Select [Set]
10

•Select [Set Time]
•Adjust the date accordingly
•Select [Set]
•Then press the [Return
arrow] button hard key on the front
of the DNN9230DAB
11

Turning Off Demo Mode
•Select [Next]
•Turn Demo mode [Off]
•Then select [Finish]
12
•Gently swipe the touch-screen
upwards

Step
4
Step 4:- Owner Account Setup
NOTE: Please ensure that you have your sign in details for your Route Collector
account which you generated in Step 1 of this guide. Also, if you have just
registered your account as per Step 1 it may take an hour or so before you can link
your DNN9230DAB with your Route Collector.
•Select [Administrator]
•Select [OK]
•Wait for the “Network History” page
to load and then press the [Menu]
button hard key on the front of the
DNX9230DAB
13

•Select [Account]
•Select [Set Owner Account]
•Now input your Route Collector Sign
in details.
•Then select [OK]
If you get an error message please
note that if you have just registered
your account as per Step 1 it may take
an hour or so before you can link your
DNN9230DAB with your Route
Collector.
•Select [Auto Login]
•Then on the next screen select
[ON] to enable “Auto Login”
•Then press the [Home] button
hard key on the front of the
DNN9230DAB
14

Step
5
Step 5:- Setting Up Facebook Account
•The “Home Screen” has 4 different
screens. You can see what screen you
are on by the dots highlighted at the
top of the screen. This image shows
that you are on screen 3 the “Source
Screen”. By gently swiping the screen
with your finger back or forwards you
can see other screens.
•Go to “Home Screen 4” and select
[SNS]
15

•Select [Facebook] icon
•Input your login details
•Then select [Log In]
Once your News Feeds have loaded you can view and listen to the posts (select the “Ear icon”). To
update feeds manually gently swipe the screen downwards.
16

Step
6
Step 6:- Setting Up Twitter Account
•Select [Twitter] icon
•Gently swipe the screen upwards
•Input your login details
•Then select [Log In]
17

Step
7
Step 7:- Setting Up Gmail Account
•Select the [Envelope] icon for e-mail
18
•The only form of email available on
this system is Gmail.
•Select [Gmail]
