Kenwood KDC-X997 User manual

Important information
Before using the this unit for the first time
KDC-X997, KDC-BT955HD, KDC-X897, KDC-BT855U, KDC-X697, and KDC-655U are factory-set to operate
in the Demonstration mode initially.
When using this unit for the first time, cancel the Demonstration mode. Refer to <Cancel the Demonstration
mode>.
Cleaning the connector
The unit may not function properly if the connectors between the unit and faceplate are dirty. Detach the
faceplate and clean the connector with a cotton swab gently, being careful not to damage the connector.
Condensation
When the car is air-conditioned, moisture may collect on the laser lens. This may cause disc read errors. In
this case, remove the disc and wait for the moisture to evaporate.
How to reset your unit
If the unit fails to operate properly, press the Reset button. The unit returns to the factory settings when the
Reset button is pressed.
Notes
When you purchase optional accessories, check with your Kenwood dealer to make sure that they can
work with your model and in your area.
Characters that conform to ISO 8859-1 can be displayed.
The illustrations of the display and panel appearing in this manual are examples used to explain more
clearly how the controls are used. Therefore, what appears on the display in the illustrations may differ
from what appears on the display on the actual equipment, and some of the images on the display may
be inapplicable.

Specifications
FM tuner section
Frequency range (200 kHz step)
: 87.9 MHz – 107.9 MHz
Usable sensitivity (S/N = 30dB)
: 9.3dBf (0.8 μV/75 Ω)
Quieting Sensitivity (S/N = 46dB)
: 10.2 dBf (1.13 μV/75 Ω)
Frequency response (±3 dB)
: 30 Hz – 15 kHz
Signal to Noise ratio
: 75 dB (MONO)
Stereo separation
: 45 dB (1 kHz)
Digital FM tuner section (KDC-X997/ KDC-BT955HD)
Frequency range (200 kHz step)
: 87.9 MHz – 107.9 MHz
Frequency response (±3 dB)
: 20 Hz – 20 kHz
Signal to Noise ratio (STEREO)
: 75 dB
AM tuner section
Frequency range (10 kHz step)
: 530 kHz – 1700 kHz
Usable sensitivity (S/N = 20dB)
: 28 dBµ(25 µV)
Digital AM tuner section (KDC-X997/ KDC-BT955HD)
Frequency range (10 kHz step)
: 530 kHz – 1700 kHz
Frequency response (±3 dB)
: 40 Hz – 15 kHz
Signal to Noise ratio (STEREO)
: 70 dB
CD player section
Laser diode
: GaAlAs
Digital filter (D/A)
: 8 Times Over Sampling
D/A Converter
: 24 Bit
Spindle speed (Audio files)
: 500 – 200 rpm (CLV)
Wow & Flutter
: Below Measurable Limit
Frequency response (±1 dB)
: 10 Hz – 20 kHz
Total harmonic distortion (1 kHz)
KDC-X997 KDC-X897 KDC-X697
: 0.008 %
KDC-BT955HD KDC-BT855U KDC-655U KMR-555U
: 0.010 %
Signal to Noise ratio (1 kHz)
KDC-X997 KDC-X897 KDC-X697
: 110 dB
KDC-BT955HD KDC-BT855U KDC-655U KMR-555U
: 105 dB
Dynamic range
: 93 dB
MP3 decode
: Compliant with MPEG-1/2 Audio Layer-3
WMA decode

: Compliant with Windows Media Audio
AAC decode
: AAC-LC ".m4a" files
USB interface
USB Standard
: USB1.1/ 2.0 (Full speed)
File System
: FAT12/16/ 32
Maximum Supply current
: DC 5 V =1 A
Decode
: MP3, WMA, AAC, WAV
Audio section
Maximum output power
: 50 W x 4
Full Bandwidth Power (at less than 1% THD)
: 22 W x 4
Preout level/ Load (CD)
KDC-X997 KDC-BT955HD KDC-X897 KDC-BT855U
KDC-X697
: 4000 mV/10 kΩ
KDC-655U KMR-555U
: 2500 mV/10 kΩ
Preout impedance
: ≤600 Ω
Speaker Impedance
: 4 – 8 Ω
Tone
KDC-X997
Band1 : 62.5 Hz ±9 dB
Band2 : 100 Hz ±9 dB
Band3 : 160 Hz ±9 dB
Band4 : 250 Hz ±9 dB
Band5 : 400 Hz ±9 dB
Band6 : 630 Hz ±9 dB
Band7 : 1 kHz ±9 dB
Band8 : 1.6 kHz ±9 dB
Band9 : 2.5 kHz ±9 dB
Band10 : 4 kHz ±9 dB
Band11 : 6.3 kHz ±9 dB
Band12 : 10 kHz ±9 dB
Band13 : 16 kHz ±9 dB
KDC-BT955HD
Band1 : 62.5 Hz ±9 dB
Band2 : 160 Hz ±9 dB
Band3 : 400 Hz ±9 dB
Band4 : 1 kHz ±9 dB
Band5 : 2.5 kHz ±9 dB
Band6 : 6.3 kHz ±9 dB
Band7 : 16 kHz ±9 dB
KDC-X897 KDC-BT855U KDC-X697 KDC-655U
KMR-555U
Bass : 100 Hz ±8 dB
Middle : 1 kHz ±8 dB
Treble : 12.5 kHz ±8 dB
Bluetooth section (KDC-X997/ KDC-BT955HD/ KDC-X897/ KDC-BT855U)
Version
: Bluetooth Ver. 2.1+EDR Certified
Frequency range
: 2.402 – 2.480 GHz
Output Power
: +4dBm (MAX), 0dBm (AVE) Power Class 2
Maximum Communication range
: Line of sight approx.10m (32.8 ft)
Profiles
: HFP (Hands Free Profile)
: SPP (Serial Port Profile)
: PBAP (Phonebook Access Profile)
: OPP (Object Push Profile)

: A2DP (Advanced Audio Distribution Profile)
: AVRCP (Audio/Video Remote Control Profile)
Auxiliary input
Frequency response (±3 dB)
: 20 Hz – 20 kHz
Input Maximum Voltage
: 1200 mV
Input Impedance
: 10 kΩ
General
Operating voltage
KDC-X997 KDC-BT955HD KDC-X897 KDC-BT855U
: 14.4 V (10.5 – 16V allowable)
KDC-X697 KDC-655U KMR-555U
: 14.4 V (11 – 16V allowable)
Maximum Current consumption
: 10 A
Installation Size (W x H x D)
: 182 x 53 x 159 mm
7-3/16 x 2-1/16 x 6-1/4 inch
Weight
KDC-X997 KDC-BT955HD KDC-X897 KDC-BT855U
: 2.9 lbs (1.3 kg)
KDC-X697 KDC-655U KMR-555U
: 2.7 lbs (1.2 kg)
Specifications subject to change without notice.

Trademarks
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their
respective owners.
"Made for iPod" and "Made for iPhone" mean that an electronic accessory has been designed to connect
specifically to iPod or iPhone, respectively, and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may
affect wireless performance.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S.
and other countries.
iTunes and Safari are trademark of Apple Inc.
Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. All rights reserved.
HD Radio Technology manufactured under license from iBiquity Digital Corporation. U.S. and Foreign
Patents. HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary trademarks of
iBiquity Digital Corp.
PANDORA, the PANDORA logo, and the Pandora trade dress are trademarks or registered trademarks of
Pandora Media, Inc., used with permission.
aha, the Aha logo, and the Aha trade dress are trademarks or registered trademarks of HARMAN
International Industries, used with permission.
Android and Chrome are trademark of Google Inc.
BlackBerry®, RIM®, Research In Motion® and related trademarks, names and logos are the property of
Research In Motion Limited and are registered and/or used in the U.S. and countries around the world.
Used under license from Research In Motion Limited.

Internet Explorer and Windows Media are registered trademark of Microsoft Corporation in the United
States and other countries.
The "AAC" logo is a trademark of Dolby Laboratories.

Component names
1. [1/6] button
When listening to the iPod, audio file, CD, or radio, press this button to enter the search mode.
In each of the selected modes, press the button to return to the previous item.
2. [SRC] button
Press this button to enter source select mode. Refer to <Source selection>.
3. [Control] knob (Volume knob)
In the normal mode, turn the knob to adjust the volume or press the knob to enter the Function setting
mode.
In the Function mode, turn the knob to select an item or press the knob to determine the selection.
4. [R]/ [S] button
Press the button to select an audio file folder or use it as a Likes/ Dislikes button on Aha etc.
The [R] button can be used to select broadcast band as well.
5. [G] button
Press the button to eject the disc.
6. Disc slot cover
When this cover opens upward, the disc insertion slot appears.
7. USB terminal (inside of the cover)
Connect an iPod or USB device.
8. Auxiliary input (inside of the cover)
Connect the output of an external device using a stereo mini-jack.
9. REAR USB indicator
When a USB device or iPod is connected to the USB terminal of the rear, this indicator stays lit. During
playback of the connected device, this indicator blinks.
10. [E]/ [F] button
Press the button to select a song or station.
11. Release button
Press the button to detach the faceplate.
12. KDC-X997 KDC-BT955HD KDC-X897 KDC-BT855U [Ú] button
Press the button to make, answer, or disconnect a hands-free call.
13. KDC-X697 KDC-655U KMR-555U [A~Z] button
Press any of (A to Z) button during the Music search mode to enter the alphabet search mode.

Preparations
Cancel the Demonstration mode
KDC-X997 KDC-BT955HD KDC-X897 KDC-BT855U KDC-X697
KDC-655U
Cancel the Demonstration mode when you use the unit for the first time after installation.
1. Press [Control] knob to cancel the Demonstration mode when the message "To cancel DEMO
Press the volume knob" appears (approx. 15 seconds).
2. Turn [Control] knob to select the "YES", and then press [Control] knob.
Detaching/ Attaching the faceplate
!
Remove the faceplate at once after pressing the Release button; otherwise it can fall down due to
vibration.
The faceplate is a precision component of the unit and can be damaged by shocks or jolts.
Keep the faceplate in its case while detached.
Do not place the faceplate (and case) in areas exposed to direct sunlight, excessive heat or humidity.
Also avoid places with too much dust or the possibility of water splashing.

How to select the item
For how to select setting items such as a function setting item, see the following example:
Example: Setting the Date format of the display
1. Press [Control] knob.
"Function" appears and enters the Function setting mode.
2. Select the Date Mode function item
Turn [Control] knob to select "Settings", and then press [Control] knob.
Next, turn [Control] knob to select "Clock&Date", and then press [Control] knob.
Finally, turn [Control] knob to select "Date Mode", and then press [Control] knob.
To cancel and return to the previous item, press [1/6].
3. Turn [Control] knob to select a format (7 types), and then press [Control] knob.
Returns to the previous item.
4. Press and hold [1/6].
Exits the Function setting mode.
About the description in this manual
In this manual, operations performed in steps 2 and 3 are described as follows:
2. Select "Settings" >"Clock&Date" >"Date Mode" using [Control] knob.
3. Select a format (7 types) using [Control] knob.

3-4. Adjusting the clock
1. Press [Control] knob.
Enters the Function setting mode.
2. Select "Settings" >"Clock&Date" >"Clock Adjust" using [Control] knob.
.
3. Set the hour using [Control] knob.
4. Set the minute using [Control] knob.
Exiting from the Function setting mode
Press and hold [1/6].

General operations
Power
Press [SRC] to turn the power ON.
Press and hold [SRC] to turn the power OFF.
Source selection
1. Press [SRC].
The currently selected source is displayed and enters the Source selection mode.
2. Select a source using [Control] knob.
Source Display
Standby "STANDBY"
SiriusXM (optional accessory)[1] "SiriusXM"
HD Radio[2] "HD RADIO"
Tuner[4] "TUNER"
USB device connected to front USB terminal "USB(FRONT)"
USB device connected to rear USB terminal "USB(REAR)"
iPod connected to front USB terminal[1] "iPod(FRONT)"
iPod connected to rear USB terminal[1] "iPod(REAR)"
Pandora® of iPod connected to front USB terminal[1] "Pandora(FRONT)"
Pandora® of iPod connected to rear USB terminal[1] "Pandora(REAR)"
Pandora® of device connected via Bluetooth[1][3] "Pandora"
iHeartRADIO of iPod connected to front USB terminal [1] "iHeartRADIO (FRONT)"
iHeartRADIO of iPod connected to rear USB terminal [1] "iHeartRADIO (REAR)"
iHeartRADIO of device connected via Bluetooth[1][3] "iHeartRADIO"
aha™ of iPod connected to front USB terminal[1][3] "aha(FRONT)"
aha™ of iPod connected to rear USB terminal[1][3] "aha(REAR)"
aha™ of device connected via Bluetooth[1][3] "aha"
Bluetooth audio[3] "BT AUDIO"
CD[1] "CD"
Auxiliary Input "AUX"
[1] This source can be selected only when it can be played.
[2] Function of KDC-X997/ KDC-BT955HD.
[3] Function of KDC-X997/ KDC-BT955HD/ KDC-X897/ KDC-BT855U.
[4] Function of KDC-X897/ KDC-BT855U/ KDC-X697/ KDC-655U/ KMR-555U.
Setting the source switching
Source switching can be set so that pressing [SRC] switches among sources. For more details, refer to
<14-6. Initial settings>.
Source switching can be set so that "Pandora", "iHeartRADIO", "aha", and "AUX" sources can not be
selected when not in use. For more details, refer to <14-6. Initial settings>.
Volume
Turn [Control] knob.
USB terminal
A USB device or iPod can be connected.
The CA-U1EX (Max. 500mA) or KCA-iP102 (optional accessories) is recommended to connect a
USB device or iPod.
Auxiliary input
A portable audio device can be connected with a stereo mini-plug (3.5 mm ø).

Audio control
You can adjust the audio control items.
1. Press [SRC] and select a source other than Standby ("STANDBY") using [Control] knob.
.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" using [Control] knob.
.
4. Select a audio control item using [Control] knob.
Display Audio control item Range
"SubWoofer Level" Subwoofer level –15 — +15 (dB)
"Bass Level" Bass level –8 — +8 (dB)
"Middle Level" Middle level –8 — +8 (dB)
"Treble Level" Treble level –8 — +8 (dB)
"Equalizer PRO"
"Bass Adjust"
"Bass Center FRQ" Bass Center Frequency 60/ 80/ 100/ 200 (Hz)
"Bass Level" Bass level –8 — +8 (dB)
"Bass Q Factor" Bass Q Factor 1.00/ 1.25/ 1.50/ 2.00
"Bass EXT" Bass Extend OFF/ ON
"Middle Adjust"
"Middle Center FRQ" Middle Center
Frequency 0.5/ 1.0/ 1.5/ 2.5 (kHz)
"Middle Level" Middle level –8 — +8 (dB)
"Middle Q Factor" Middle Q Factor 0.75/ 1.00/ 1.25
"Treble Adjust"
"Treble Center FRQ" Treble Center Frequency 10.0/ 12.5/ 15.0/ 17.5 kHz
"Treble Level" Treble level –8 — +8 (dB)
"Preset Equalizer" Preset Equalizer curve "Rock"/ "Pops"/ "Easy"/ "Top40"/ "Jazz"/ "Powerful"/ "Natural"/
"User"
"Bass Boost" Bass Boost "OFF"/ "Level1"/ "Level2"/ "Level3"
"Loudness" Loudness "OFF"/ "Level1"/ "Level2"
"Balance" Balance Left 15 — Right 15
"Fader" Fader Rear 15 — Front 15
"SubWoofer" Subwoofer output ON/ OFF
"Detailed Settings"
"HPF" High Pass Filter Through/ 100/ 120/ 150 (Hz)
"LPF SubWoofer" Low Pass Filter 85/ 120/ 160/ Through (Hz)
"SubWoofer
Phase" Subwoofer Phase Reverse (180°)/
Normal (0°)
"Supreme" Supreme setting OFF/ ON
"Audio Preset" Audio Preset memory Recall/ Memory
"Volume Offset" Volume offset –8 — ±0 (dB)
(AUX: -8 — +8)
Function of KDC-X897/ KDC-X697.
, .
"User": The customized Bass, Middle, and Treble settings are effective.
Displayed only when "LPF SubWoofer" is set to "85"/ "120"/ "160".
Audio file source only
5.
Select a value using [Control] knob.

5. Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [1/6].
Adjusting Bass, Middle, and Treble levels
You can set Bass, Middle, and Treble levels for each source.

Audio preset
You can register the values set the Audio control items.
1. Set the audio control items
2. Select "Audio Control" >"Detailed Settings" >"Audio Preset" >"Memory" using [Control]
knob.
3. Select "YES" using [Control] knob.
"Memory Completed" appears.
Exiting from the Function setting mode
Press and hold [1/6].
Number of Audio preset memories that can be stored
Register a pair of Audio preset memories. You cannot register them by source.
When reset
When you press the Reset button, audio control values of all sources will be set to the values
registered here.
Audio control items that can be registered
The following Audio control items can be registered.
"Bass Center FRQ"*, "Bass Level", "Bass Q Factor"*, "Bass EXT"*, "Middle Center FRQ"*, "Middle Level",
"Middle Q Factor"*, "Treble Center FRQ"*, "Treble Level", "SubWoofer Level", "HPF", "LPF SubWoofer",
"SubWoofer Phase"
*KDC-X897, KDC-X697 only

Audio preset recall
1. Press [SRC] and select a recall source using [Control] knob.
Refer to <Source selection>.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" > "Detailed Settings" >"Audio Preset" > "Recall" using [Control] knob.
.
4. Select "YES" using [Control] knob.
"Recall Completed" appears.
Exiting from the Function setting mode
Press and hold [1/6].

Audio control
You can adjust the audio control items.
1. Press [SRC] and select a source other than Standby ("STANDBY") using [Control] knob.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" using [Control] knob.
4. Select a audio control item using [Control] knob.
Display Overview
"SubWoofer Level" You can set subwoofer level.
"–15" — "0" — "+15"
"Preset
Equalizer"[1][5]
Select from among preset equalizer curves to set the sound quality.
"User"[2]/ "Natural"/ "Rock"/ "Pops"/ "Easy"/ "Top 40"/ "Jazz"/ "Powerful"/ "iPod"(During iPod
source only)
"Manual
Equalizer""[1][5]
Set the equalizer curve manually.
.
"Pro Setup"
"DSP Set"
Turn on/off the DSP function.
"Bypass": Disables the DSP function.
"Through": Enables the DSP function.
"Car Type"[5] To get clear sound, set the sound environment according to the location and size of physically
installed speakers with reference to the followings:
"Speaker
Setting"[5]
"X'Over"[5]
"DTA Settings"[5]
"Sound Enhancements"[5]
"Supreme"[6]
Turns ON/OFF the Supreme function.
Can be set while Audio file source of USB/CD and iPod source.
"ON"/ "OFF"
"HIGHWAY-
SOUND" [3]
Compensates the low volume or bass sound being lost by road noises to make vocal sound clearer.
"OFF"/ "Low"/ "Middle"/ "High"
"Space
Enhancer"[3]
[4]
Virtually enhances the sound space using the DSP.
"OFF"/ "Small"/ "Medium"/ "Large"
"Sound
Realizer"[4]
Virtually makes the sound more realistic using the DSP.
"OFF"/ "Level1"/ "Level2"/ "Level3"
"Sound
Elevation"[4]
Virtually raises the sound field using the DSP.
"OFF"/ "Low"/ "Middle"/ "High"
"Volume offset" Sets each source's volume as a difference from the basic volume.
"–8" — "0" (AUX: "–8"— "+8")
"SubWoofer
Mute"
Sets the Subwoofer Mute.
"ON"/ "OFF"
"Audio Preset" You can register the values set the Audio control items.
, .
"Bass Boost"[5] Sets the Bass Boost level in 3 steps.
"OFF"/ "Level1"/ "Level2"/ "Level3"
"Loudness"[5] Makes the sounds at high and low frequencies louder.
"OFF"/ "Low"/ "High"
"Balance" Adjusts left/right speaker balance.
"Left15" — "0" — "Right15"
"Fader" Adjusts front/rear speaker balance.
"Rear15" — "0" — "Front15"
(Colored text: Factory setting)

[1] You can select for each source.
[2] "User": The Equalizer curve set in the section
[3] This function is not effective for the HD Radio source.
[4] Function of KDC-X997.
[5] Displayed only when "DSP Set" is set to "Through".
[6] Audio file source only
5. Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [1/6].
When you selected "iPod" for "Preset Equalizer"
When you selected "iPod" for "Preset Equalizer", next select an equalizer curve. Select a desired
equalizer curve using [Control] knob from among 22 equalizer curves displayed after you selected
"iPod".

5-2. Manual equalizer control
You can adjust the equalizer curve manually.
1. Press [SRC] and select a source other than Standby ("STANDBY") using [Control] knob.
.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" >"Manual Equalizer" using [Control] knob.
.
4. Select a equalizer control item using [Control] knob.
Display Description Range
"Gain" Adjust the gain of each band. -9 – 0– +9 dB
"Q Factor"[1] Adjust Q of each band. 1.35/ 1.50/ 2.00
"Bass EXT" – "OFF"/ "ON"
(Colored text: Factory setting)
[1] Function of KDC-X997.
When "Bass EXT" and "Q Factor" are selected, skip step 5.
5. Select a Band using [Control] knob.
KDC-X997
"BAND1"; 62.5 Hz, "BAND2"; 100 Hz,
"BAND3"; 160 Hz, "BAND4"; 250 Hz,
"BAND5"; 400 Hz, "BAND6"; 630 Hz,
"BAND7"; 1 kHz, "BAND8"; 1.6 kHz,
"BAND9"; 2.5 kHz, "BAND10"; 4 kHz,
"BAND11"; 6.3 kHz, "BAND12"; 10 kHz,
"BAND13"; 16 kHz
KDC-BT955HD
"BAND1"; 62.5 Hz, "BAND2"; 160 Hz,
"BAND3"; 400 Hz, "BAND4"; 1 kHz,
"BAND5"; 2.5 kHz, "BAND6"; 6.3 kHz,
"BAND7"; 16 kHz
6. Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [1/6].
When the "Manual Equalizer" item is not displayed
This function is not available when "iPod" is selected for "Preset Equalizer".

Car type selection
You can compensate the delay of the sound arrival time by selecting your environment from the car types.
1. Press [SRC] and select a source other than Standby ("STANDBY") using [Control] knob.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" > "Pro Setup" >"Car Type" using [Control] knob.
4. Select a car type using [Control] knob.
Display Car type
"OFF" Not compensating.
"Compact" Compact car
"Full Size Car" Full size car
"Wagon" Station wagon
"Minivan" Minivan
"SUV" Sport-utility vehicle
"Minivan (Long)" Long Minivan
Exiting from the Function setting mode
Press and hold [1/6].
To set the delay time finely

Speaker setting
The speaker X'Over is automatically set when the position and size of each speaker are selected from the
following items.
1. Press [SRC] and select a source other than Standby ("STANDBY") using [Control] knob.
.
2. Press [Control] knob.
Enters the Function setting mode.
3. Select "Audio Control" >"Pro Setup" >"Speaker Setting" using [Control] knob.
4. Select a speaker type using [Control] knob.
Speaker
type Setting item Setting value
"Front"
Front speaker
location "Door", "On Dash", "Under Dash"
"SIZE"
Front speaker size
KDC-X997
"O.E.M.", "3 1/2in", "4in", "4 3/4in", "5in", "6 1/2in", "6 3/4in", "7in", "4x6", "5x7",
"6x8", "6x9", "7x10"
KDC-BT955HD
"Small", "Medium", "Large"
"TW" Tweeter size
"None", "Small", "Medium", "Large"
"Rear"
Rear speaker
location
"Door", "Rear Deck"
("2nd Row", "3rd Row"[1])
"SIZE"
Rear speaker size
KDC-X997
"None", "O.E.M.", "3 1/2in", "4in", "4 3/4in", "5in", "6 1/2in", "6 3/4in", "7in", "4x6",
"5x7", "6x8", "6x9", "7x10"
KDC-BT955HD
"None", "Small", "Medium", "Large"
"SubWoofer" "SIZE"
Speaker Size Subwoofer
KDC-X997
"None", "6 1/2inch", "8inch", "10inch", "12inch", "15inch Over"
KDC-BT955HD
"None", "Small", "Large"
(Colored text: Factory setting)
[1] .
5. Select a setting item using [Control] knob.
6. Select a setting value using [Control] knob.
Exiting from the Function setting mode
Press and hold [1/6].
Value set when "Minivan" or "Minivan (Long)" is selected
