Kenwood DV-6050 User manual

MULTIPLE DVD/VCD/CD PLAYER
DV-6050
SERVICE MANUAL
© 2002-10 PRINTED IN KOREA
B51-5831-00 (K/K) 1382
In compliance with Federal Regulations, following are repro-
duction of labels on, or inside the product relating to laser
product safety.
KENWOOD Corp. certifies this equipment conforms to DHHS
Regulations No.21 CFR 1040. 10, Chapter 1, subchapter J.
DANGER : Laser radiation when open and interlock defeated.
AVOID DIRECT EXPOSURE TO BEAM.
Caution : No connection of ground line if disassemble
the unit. Please connect the ground line on
rear panel, PCBs, Chassis and some others.
73
0
POWER
STANDBY
ON OFF
4¢
DISC SKIP
SEQUENCE MODE
DISC 1 DISC 2 DISC 3 DISC 4 DISC 5
Cabinet panel
(A60-2323-08)
Crystal Window
(B10-3936-08)
Con DIN socket
(E68-0018-08)
Top cover
(A01-3854-08)
Button
(K29-8238-08)
Button
(K27-2502-08)
Knob(POWER)
(K27-2503-08)
Con phono socket
(E63-1311-08)x2
Clamp AC cord
(J42-0350-08)
Wire-MCRDM
(E30-7250-08)
Slide switch
(S62-0115-08)
Con DIN socket
(E63-1192-08)
Con phono socket
(E63-1244-08)
70%

Batteries(R03/AA) ...(2)
Please confirm that the following accessories are present.
Audio video cord (Red, White, Yellow) ...(1)
(E30-2990-08)
Remote control unit ...(1)
(A70-1631-08)
Coaxial cable ...(1)
(E30-7235-08)
DV-6050
2
CONTENTS / ACCESSORIES
CONTENTS / ACCESSORIES .................................. 2
DISASSEMBLY FOR REPAIR....................................3
CIRCUIT DESCRIPTION ............................................4
ADJUSTMENT ..........................................................19
INTERCONNECTION DIAGRAM .............................20
PC BOARD .............................................................. 21
SCHEMATIC DIAGRAM .......................................... 28
EXPLODED VIEW ....................................................43
PARTS LIST..............................................................44
SPECIFICATIONS ......................................Back cover
Contents
Accessories
The marking of products using lasers
(For countries other than U.S.A., U.S.-
Military and Canada)
The marking this product has been classified as Class
1. It means that there is no danger of hazardous
radiation outside the product.
Location: Back panel
CLASS 1
LASER PRODUCT Inside this laser product, a laser diode classified as
Class 2 laser radiation is contained as alerted by the
internal caution label shown above. Do not stare into
beam.
Location: DVD laser pick-up unit cover inside this
product
CAUTION
VISIBLE LASER RADIATION
WHEN OPEN. DO NOT

DV-6050
3
DISASSEMBLY FOR REPAIR
1x9
1. How to open the tray if it does not come out.
1. Remove the plastic plate.
2. Turn the gear fully CCW using a flat driver and so on in
the drawing through the hole on the loading chassis bot-
tom.
3. Pull out the tray frontward by hand when it comes just
out.
Disassembling and Assembling the DVD mechanism, DVD B'D and OUT B'D FTMS for Video Sig-
nal Adjustment
1. To release the rear panel, remove screws (1x9)and optical cap.
x2
4
2
POWER
SWITCH
LEVER
3
3
4
4N314 N315 N312
4
3
2. Remove screws (2x2) and OUT B'D FTMS.
3. Remove connectors (3X3), power switch lever and screws (4x4).
Fig. 1
Fig. 2

DV-6050
4
DISASSEMBLY FOR REPAIR
x4
5
BOTTOM VIEW
CN1
CN74
CN15
CN53
CN33
CN55 CN2
4. Pull out the DVD mechanism horizontally.
5. Up-side-down the DVD mechanism.
6. Remove screws (5x4) and DVD B'D.
7. Unplug the connectors ( CN15,CN53,CN55,CN74) and
disconnect 3 flexible cables (CN1,CN2,CN33).
8. For the assembly procedure, follow the item 5 to 3 in
reverse.
9. Set up the DVD B'D on the top as figure 5.
Fig. 3
Fig. 4
10. Connect a jig (E35-2113-05) to CN33 instead of an origi-
nal flexible cable (E35-1990-05).
CN33 Parts No. Remark
(Flexible cable)
Original E35-1990-05 22cm
ó
JIG E35-2113-05 35cm
*
* (This is a jig for video signal adjustment, after adjusted
it put back to an original flexible cable.)
11. Plug in the connectors (CN15,CN53) and connect 2 flexi-
ble cables (CN1,CN2).
* Note : The connectors (CN55, CN74) are for audio sig-
nal line so that no necessary to put it back when
video signal output adjustment.
CN1
CN33
CN53
CN15
CN2
GND
Use an Instalting Material
12. Follow the item 2 and 1 in reverse.
13. Gruond DVD B'D and rear panel as figure 5.
14. Follow the video signal output adjustment procedure.
Fig. 5

DV-6050
5
CIRCUIT DESCRIPTION
VDAC : NTSC/PAL ENCODER
VOUT
FLI2200
CS4382
IC6
IC10
IC30
IC28
IC41
IC32
IC50
IC3
IC1
ADV7170SU
ADV7196
IC26
IC11 IC10
M95040
IC11
TVP503 AN8703FH VOUT
AVIF 2 SPDIF
3
6chOUT
2chOUT
88
MN5B00
3
SIO1 3
816
BUS 16 BU2092FV
3 SST39VF160 3
I2C
SIO0 API 3
PU FEP MN103S26E
SODC
AV Decoder
MN67 7531
64M SDRAM
VDAC
ADAC
SERIAL-
PARALLER
FLASH
ROM
16M bits
EEROM
4k bytes
SETUP
REGION
KEY
SUB µcom
MN101C35D
KEY FL
LED
MECHA.
CONTROL
REMOTE
CONTROLLER
WATER MARK
DETECTION
DVD µcom
MN102LP62G
Progre
ssive
VDAC
DRAM
2Mbyte
Driver ADAC
1. Microcomputer Periphery Block Diagram

DV-6050
6
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 DATA OUT O Communication data output to DVD system microcomputer.
2 DATA IN I Communication data input from DVD system microcomputer.
3 CLOCK I Communication clock input from DVD system microcomputer.
4~7 NC O Unused.
8 VDD - Positive power supply (+5.0V).
9 X-TAL O Master clock (8.0MHz) output.
10 EXTAL I Master clock (8.0MHz) input.
11 VSS - GND
12 NC I Unused.
13 NC O Unused.
14 NC(MMCD) I Unused.
15 VREF - AD converter reference voltage.
16~18 AD INPUT KEY (1~3) I AD input key (1~3).
19 INPUT REGION TYPE 2 I AD input region type 2 (0V).
20 INPUT MODEL TYPE I AD input model type (5.0V).
21 INPUT REGION TYPE 1 I AD input region type 1(0.64V).
22 UP SW - Unused.
23 DOWN SW - Unused.
24 VREF + - AD converter reference voltage.
25 CE I Chip enable input.
26 RST I Reset signal input.
27 OPEN SW I Open switch input from mechanism.
28 CLOSE SW I Close switch input from mechanism.
29 ROULETTE CCW O Control port of rotary motor.
30 ROULETTE CW O Control port of rotary motor.
31 OPEN/CLOSE MOTOR CCW O Control port of tray motor.
32 OPEN/CLOSE MOTOR CW O Control port of tray motor.
33 REMOCON CONTROL I Input port of remote controller signal.
34 MECHA DISC SENSOR I Detection port of disc sensor for mechanism.
35 MECHA POSITION SENSOR I Detection port of position sensor for mechanism.
36,37 NC I Unused.
38 OPEN/CLOSE CHECK I Unused.
39 EEPROM DATA OUT O EEPROM serial data out.
40 EEPROM DATA IN I EEPROM serial data input.
41 EEPROM CLOCK OUT O EEPROM serial clock input.
42 LED OUT 1(DISC1) O On/off control port for disc 1 LED.
43 LED OUT 2(DISC2) O On/off control port for disc 2 LED.
44 LED OUT 3(DISC3) O On/off control port for disc 3 LED.
45 LED OUT 4(DISC4) O On/off control port for disc 4 LED.
46 LED OUT 5(DISC5) O On/off control port for disc 5 LED.
47 EEPROM CS O Chip select output to EEPROM.
48~50 NC O Unused.
51 G14 O Unused.
52 G13 O Unused.
53~64 G12~G1 O FL grid output (G12~G1).
65~86 P02~P23 O FL segment output (P02~P23).
87 P01 O FL segment output (P01).
88~96 NC O Unused.
97 VIDEO MUTE O Video mute control.
98 AUDIO MUTE O Audio mute control.
99 POWER CONTROL O Power relay control.
100 VPP - FL negative power supply.
1-1 Pin Description of Sub Microcomputer : MN101C35D (FRONT, IC11)

DV-6050
7
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description Logic
HL
1 WAIT I Bus wait port.
2NRD(ODC/AVDEC O Bus read port for ODC/AV Decoder/SRAM.
/SRAM)
3 NWEL O Bus read port for AV Decoder/RAM.
4NWEH(ODC/AVDEC O Bus read port for ODC/AV Decoder/SRAM/ROM.
/SRAM/ROM)
5 RAMCS(SRAM) O SRAM chip select.
6 ODCCS O ODC chip select.
7 AVCS(AVDEC) O AV decoder chip select.
8 ROMCS(ROM) O Flash ROM chip select.
9 SCLOCK(VDAC) I/O VDAC 12C clock.
10 SDATA(VDAC) I/O VDAC 12C data.
11 FRD(ROM) O Flash ROM read port.
12 WORD I CSO bus width.
13~16 CPUADR(0~3) O Bus address (0~3).
17 VDD - Supply voltage (+3.3V).
18 SYSCLK(AVDEC) O External clock output for AV decoder.
19 VSS - Connected to ground.
20 XI I Unused.
21 XO O Unused.
22 VDD - Supply voltage (+3.3V).
23 OSCI(CLK135) I System clock input (13.5MHz).
24 OSCO O Unused.
25 MODE I Processor mode selection. Expension
Mode
26~33 CPUADR4~11 O Bus address (4~11).
34 AVDD - Supply voltage (+3.3V).
35~42 CPUADR12~19 O Bus address (12~19).
43 VSS - Connected to ground.
44 CPUADR20 O Bus address (20).
45 CDH O Switching of DAC. CD Except
CD
46 HFMON O HF monitor output of ADSC.
47 25BSY O Writing busy data output. Normal Busy
48 KMODE I Selection of writing mode for the ROM. Writing Normal
49 196BSY I Busy data input. Normal Busy
50 FROMWR O Enable control for writing jig.
51 TRVSW I Input port of traverse switch. Off On
52 AMUTE O Audio mute control.
53 FEPRST O FEP reset output.
54 VDD - Supply voltage (+3.3V).
55 FEPEN O Enable output to FEP (traverse).
56 NC O Unused.
57 STBSACD O Unused.
58 STBSP1 O Strobe output to serial-parallel converter.
59 STBDAC1 O Strobe output to ADAC.
60 STBPSL O Strobe output.
61 VSS - Connected to GND.
62 MSREADY I SACD ready signal input.
63 E2CS O Chip select to EEPROM.
64 PROGSW I Input port of program switch. Progressive Interlace
65 ICRST O Reset signal output to periphery ICs.
66 VDD - Supply voltage (+3.3V).
1-2 Pin Description of DVD Microcomputer : MN102LP62G (DVD AUDIO FRONT END, IC26)

DV-6050
8
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 BIAS1 I Input of bias1.
2 VIN1 I CH1 input.
3 VIN2 I CH2 input.
4 OPIN (+) I Not inverted input of OP-AMP.
5 OPIN (-) I Inverted input of OP-AMP.
6 OPOUT O Output of OP-AMP.
7 AGND - Analog ground.
8 MGND - GND
9 P.VCC2 - Power supply (+5.0V)
10 MUTE2 - Mute control of CH2.
11 DGND - Digital ground.
12 V02 (-) O Driver CH2 output (-).
13 V02 (+) O Driver CH2 output (+).
14 V01 (-) O Driver CH1 output (-).
15 V01 (+) O Driver CH1 output (+).
Voltage AD INPUT KEY 1 AD INPUT KEY 2 AD INPUT KEY 3
✽ Pin 16 ✽ Pin 17 ✽ Pin 18
0V PLAY/PAUSE STOP DISC1
0.64V - - -
1.35V OPEN/CLOSE SKIP UP/NEXT DISC2
2.18V DISC SKIP SKIP DOWN/PREV DISC3
2.75V - - DISC4
3.40V - - DISC5
Pin No. Pin Name I/O Pin Description Logic
HL
67 SCLK0 O SIO0 clock output to communicate between main
microcomputer and DVD system microcomputer.
68 SI0 I SIO0 data input to communicate between main
microcomputer and DVD system microcomputer.
69 SO0 O SIO0 data output to communicate between main
microcomputer and DVD system microcomputer.
70 SCLK1 O SIO1 clock output for control ICs.
71 SI1 I SIO1 data input for control ICs.
72 SO1 O SIO1 data output for control ICs.
73 PULL UP0 I Unused.
74 PULL UP1 I Unused.
75 NMI I Unused.
76 SODCINT0 I Interruption port from SODC.
77 SODCINT1 I Interruption port from SODC.
78 AVINT0 I Interruption 0 port from AV decoder.
79 WMINT I Interruption port from Water Mark Detector.
80 AVINT1 I Interruption port 1 from AV decoder.
81 ADSEP I Unused.
82 RST I Reset signal input.
83 VDD - Supply voltage (+3.3V).
84~91 CPUDT0~7 I/O Bus data (0~7) input and output.
92 VSS - Connected to GND.
93~100 CPUDT8~15 I/O Bus data (8~15) input and output.
2. Key Matrix ✽ Pin Numbers of Sub Microcomputer
3. Pin Description of IC's
3-1 4ch BTL Driver : BA5823FM (DVD AUDIO FRONT END, IC5)

DV-6050
9
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 LPC1 I Laser pin input (DVD head).
2 LPCO1 O Laser drive output (DVD head)pin.
3 LPC2 I Laser pin input (CD head).
4 LPC02 O Laser drive output (CD head)pin.
5 VFO SHORT - Setting pin for RF short mode.(Terminated to ground.)
6 TBAL I Tracking balance control input.
7 FBAL I Focus balance control input.
8 POFLT - Detection filter of phase difference.
9 DTRD - Data read.
10 DGT - ID gate.(Terminated to ground.)
11 STANDBY - Setting pin for standby mode.
12 SEN I Serial transfer enable input.
13 SCK I Serial transfer clock input.
14 STDI I Serial transfer data input.
15 RSCL - Connection pin for reference current generation resistance.
16 JLINE - Connection pin for input resistance.
17 TEN I Inverted input pin of tracking error output amplifier.
18 TEOUT O Tracking error signal output.
19 AGCBAL - AGC balance.
20 ASOUT O Focus addition output.
21 FEN I Inverted input pin of focus error output amplifier.
22 FEOUT O Focus error signal output.
23 AGCOFST - AGC off set.
24 MON - Monitor pin for checking.
25 AGCLVL - AGC level.
26 GND2 - Ground for AGC.
27 VREF2 O VREF for AGC.
28 VCC2 - Power supply for AGC.
29 VHALF O VCC3/2
30 DFLTON O AGC/equalizer output (-)
31 DFLTOP O AGC/equalizer output (+)
32 DCFLT - Capacitance connection for filter output.
33 GND3 - Ground for logic.
34 RFDIFO O Radial differential signal output.
35 RFOUT O RF addition amp output
36 VCC3 - Power supply for logic.
37 RFC - RF delay correction amplifier filter.
Pin No. Pin Name I/O Pin Description
16 V04 (+) O Driver CH4 output (+).
17 V04 (-) O Driver CH4 output (-).
18 V03 (+) O Driver CH3 output (+).
19 V03 (-) O Driver CH3 output (-).
20 MGND - GND
21 MUTE4 - Mute control of CH4.
22 P. VCC2 - Power supply (+9.0V)
23 MGND - PRE VCC
25 RREVCO - Terminated to VCC (+9.0V).
25 VIN3 I CH3 input.
26 LDIN I Loading input of CH4.
27 BIAS2 I Input of bias2.
28 TRIN I Traverse input of CH4.
29 MUTE3 - Mute control of CH3.
30 CNT - Control pin.
3-2 Front End Processor IC : AN8703FH (DVD AUDIO FRONT END, IC6)

DV-6050
10
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 NINT0 O Unused.
2,5 NINT(1,2) O Interruption signal (1,2) to DVD CPU.
3,31,57,78,125,143, VDD3 - Power supply (+3.3V) for IO.
156,162,169
4,19,32,60,77,81,
126,144,155,163, VSS - GND
170
6 WAITODC O Wait signal to DVD CPU.
7 NMRST O Reset output to DVD CPU (unused).
8 DASPST I Initial set point of DASP signal.
9~17,22~30 CPUADR(17~0) I Address (17~0) from DVD CPU.
18,76,152 VDD18 - Power supply (+1.8V) for IO.
20,58 DRAMVDD18 - Power supply (+1.8V) for DRAM.
21,59 DRAMVSS - Ground for DRAM.
33 DRAMVDD3 - Power supply (+3.3V) for DRAM.
34 MCS I Chip select signal from DVD CPU.
35 NWR I Write signal from DVD CPU.
36 NRD I Read signal from DVD CPU.
37~44 CPUDT(7~0) I/O DVD CPU data (7~0).
45 CLKOUT O Unused.
46 MMOD I Switching signal for test mode.
47 NRST I Reset input.
48 MSTPOL I Switching pin of polarity for master pin.
49 SCLOCK I Debug serial clock.
50 SDATA I Debug serial data.
Pin No. Pin Name I/O Pin Description
38 DCRF - DC cut filter pin for RF addition amplifier.
39 OFTR O OFTR output pin.
40 BDO O BDO output pin.
41 RFENV O RF envelope output.
42 BOTTOM - RF envelope bottom detection filter pin.
43 PEAK - RF envelope peak detection filter pin.
44 AGCG - AGC loop filter pin.
45 AGCO - AGC off set elimination filter pin.
46 TESTSG I Single signal input for test.
47 RFINP I RF differential signal input (+).
48 RFINN I RF differential signal input (-).
49 VIN5 I Internal RF (CD) input pin 1.
50 VIN6 I Internal RF (CD) input pin 2.
51 VIN7 I Internal RF (CD) input pin 3.
52 VIN8 I Internal RF (CD) input pin 4.
53 VIN9 I External RF (DVD) input pin 2.
54 VIN10 I External RF (DVD) input pin 1.
55 VCC1 - Power supply for servo.
56 VREF1 O VREF for servo.
57 VIN1(VB) I Internal RF (DVD) input pin 1.
58 VIN2VC) I Internal RF (DVD) input pin 2.
59 VIN3(VD) I Internal RF (DVD) input pin 3.
60 VIN4(VA) I Internal RF (DVD) input pin 4.
61 GND1 - Ground for servo.
62 VIN11(VE) I 3 beam sub (CD) RF input pin 2.
63 VIN12(VF) I 3 beam sub (CD) RF input pin 1.
64 HDTYPE - Switching pin of reference voltage or APC circuit polarity for DVD.
3-3 Digital Servo Control IC : MN103S26E (DVD AUDIO FRONT END, IC10)

DV-6050
11
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
51 OFTR I Input of off track signal.
52 BDO I Input of drop out signal.
53~56,61~64 PWM(1~8) I/O General PWM (1~8)output.
65 TBAL O Tracking balance adjustment output.
66 FBAL O Focus balance adjustment output.
67 TRSDRV O Traverse drive output.
68 SPDRV O Spindle drive output.
69 FG I Input of motor FG.
70 TILTP O Tilt drive output (+).
71 TILT O Tilt drive reference output.
72 TILTN O Tilt drive output (-).
73 TX O Output signal of digital out (unused).
74 DTRD O Switching signal of frequency control for data section (unused).
75 IDGT O Switching signal of CAPA section (unused).
79 OSCI1 I Input of crystal oscillator (16.9344MHz).
80 OSCO1 O Output of crystal oscillator (unused).
82 TSTSG O EQ calibration signal.
83 VFOSHORT O Output pin of VFO short (unused).
84 JLINE O Setting pin of J-LINE.
85,94,102,113 AVSS - Ground for analog.
86 ROUT O Audio output of MASH Rch (unused).
87 LOUT O Audio output of MASH Lch (unused).
88,99,109,116 AVDD - Power supply (+3.3V) for analog.
89 VCOF I Control voltage for JFVCO.
90 TRCRS I Signal input for track cross formation.
91 CMPIN I WOBBLE comparator input (unused).
92 LPFOUT O LPF output (unused).
93 LPFIN I LPF input.
95 HRFOUT O HPF output (unused).
96 HRFIN I HPF input.
97 CSLFLT I Capacitor for CPDET (unused).
98 RFDIF I RF input for CPDET.
100 PLFLT2 I Capacitor 2 for PLL.
101 PLFLT1 I Capacitor 1 for PLL.
103 RV1 I Resistance for reference current source.
104 VREFH I Reference voltage input (+2.2V).
105 PLPLG I Resistance for PLL phase gain setting (unused).
106 VHALF I Reference voltage input (+1.65V).
107 DSLF2 I Capacitor 2 for DSL.
108 DSLF1 I Capacitor 1 for DSL.
110 NARF I Equivalent RF (-) input.
111 ARF I Equivalent RF (+) input.
112 JITOUT O Output pin for jitter monitor.
114 DAC0 O Output pin of tracking drive.
115 DAC1 O Output pin of focus drive.
117 AD0 I FE input.
118 AD1 I TEph/TE3b/Tepp input.
119 AD2 I AS input.
120 AD3 I RF envelope input.
121 AD4 I Input of phase difference for tangential (unused).
122 AD5/CAPAC2 I Upper CAPA envelope input /hold capacitor
123 AD6CAPAC1 I Lower CAPA envelope input /hold capacitor
124 TECAPA I Tracking error signal for CAPA.
127~130 MON(10~13) O Internal signal monitor (unused).
131 NEJECT I/O Detection pin of eject.

DV-6050
12
CIRCUIT DESCRIPTION
Pin NO. Pin Name I/O Pin Description
1 VDD - Digital power supply.
2 VSS - Digital ground.
3 MO1 O 27MHz fixed output pin 1.
4 MCK I Serial interface bit clock input.
5 MLEN I Serial interface latch enable input.
6 VDDA - Analog power supply.
7 VSSA - Analog ground.
8 XTI I Crystal resonator connection pin.
9 XTO O Crystal resonator connection pin.
10,11,17,21 RSV - Unused.
12 SO1 O 33.8688MHz fixed output pin.
13 VSS2 - Ground 2 for output.
14 VDD2 - Power supply 2 for output.
15 SO4 O Output for 512fs.
16 SO3 O Output for 512fs.
18 VSS1 O Ground 1 for output.
19 VDD1 - Power supply 1 for output.
20 SO2 O Output for 384fs.
22 SO5 O Output for 768fs.
23 FSEL/MDT I Parallel mode : Sampling frequency Select Signal Input
Serial mode : Control Data Input
24 MO2 O 27MHz fixed output pin 2.
Pin No. Pin Name I/O Pin Description
132 NTRYCL I/O Detection pin of tray close.
133 NDASP I/O ATAPI drive active/slave input and output (unused).
134 NCS3FX I Selection of ATAPI host chip.
135 NCS1FX I Selection of ATAPI host chip.
136 DA2 I/O ATAPI host address.
137 DA0 I/O ATAPI host address (unused).
138 NPDIAG I/O Diagnosis input/output from ATAPI slave to master (unused).
139 DA1 I/O ATAPI host address (unused).
140 NIOCS16 O Selection of ATAPI host data bus width (unused).
141 INTREQ O ATAPI host interrupt request.
142 NDMACK I ATAPI host DMA request.
145 IORDY O ATAPI host ready output.
146 NIORD I/O ATAPI host data read.
147 NIOWR I/O ATAPI host data write.
148 DMARQ O ATAPI host DMA request (unused).
149~151,157~161, HDD (0~15) I/O ATAPI host data (0~15).
164~168,171~173
153 PO I Terminated to ground.
154 UATASEL I Terminated to ground (unused).
174 VDDH - Reference power supply (+3.3V) for ATAPI.
175 NRESET I ATAPI host reset input.
176 MASTER I ATAPI master/slave selection.
3-4 Clock Generator : SM8703CV (DVD AUDIO FRONT END, IC14)

DV-6050
13
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1,3,45,47 DSDA(1~4) I Direct stream digital input (unused).
2,44,46,48 DSDB(1~4) I Direct stream digital input (unused).
4 VD - Positive power supply for the digital section.
5,31 GND - Analog ground.
6 MCLK I Master clock input.
7,10 LRCK(1,2) I L/R clock input.
8,11,13,14 SDIN(1~4) I Serial audio data input.
9,12 SCLK(1,2) I Audio output bit clock.
15 SCL/CCLK I Serial clock for the serial audio interface.
16 SDA/CDIN I/O SDA is a data I/O line in two-wire mode.
CD IN is the input data line for the control port interface in SPI mode.
17 AD0/CS I AD0 is a chip address pin in two-wire mode, CS is the chip select
signal for SPI format.
18 VLC I Control port power.
19 RESET I Reset signal input.
20 FILT+ O Positive reference voltage for the internal sampling circuits.
21 VQ O Filter connection for internal quiescent voltage.
22 MUTEC234 O Power down or if the master clock to left/right frequency ratio is incorrect.
23,24 AOUTB4(-,+) O Differential analog output for super woofer channel.
25,26 AOUTA4(+,-) O Differential analog output for center channel.
27,28 AOUTB3(-,+) O Differential analog output for RS channel.
29,30 AOUTA3(+,-) O Differential analog output for LS channel.
33,34 AOUTB2(-,+) O Differential analog output for FR channel.
35,36 AOUTA2(+,-) O Differential analog output for FL channel.
37,38 AOUTB1(-,+) O Differential analog output for mix R channel.
39,40 AOUTA1(+,-) O Differential analog output for mix L channel.
32 VA - Positive power supply for the analog section.
41 MUTEC1 O Mute control output.
42 DSD SCLK I Serial clock for the direct stream digital audio interface. (unused).
43 VLS I Serial audio interface power.
Pin No. Pin Name I/O Pin Description
Q0(5) SWIDE1 O Unused.
Q1(6) SWIDE2 O Unused.
Q2(7) Bass Manage O High : When bass management
Q3(8) LPF SEL O Switching Low Pass Filter
Q4(9) DACRST O Reset for Audio DAC
Q5(10) PROGH O High : When progressive
Q6(11) RGBL O Unused.
Q7(14) DWIDE1 O Unused.
Q8(15) YCL/DWIDE2 O Unused.
Q9(16) TNOCHG O Unused.
Q10(17) CLKSEL1 O Switching of sampling frequency
Q11(18) CLKSEL2 O Switching of MP3 clock
3-5 Serial Parallel IC : BU2092FV (DVD AUDIO FRONT END, IC28)
3-6 8-Channel D/A Converter : CS4382 (AUDIO, I400)

DV-6050
14
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
Test outputs
112,113 TEST(00, 01) O These pins are test outputs and should be left unconnected in
normal operation.
Test inputs
41,50,51,108 TEST(0~5) - These pins are used for test purposes only and should always
109,111 be tied low for normal operation.
Power Supply Connections(Not shown on Block diagram)
1,33,63,73,84,95,105, Pad Ring digital power connections. Connect to the digital +3.3
114,123,137,144,151, VDD33 - volt power supply and decouple to the digital ground plane.
167
2,17,34,55,64,74,85,
96,106,115,124,132, VSS - Ground connections. Connect to the digital ground plane.
138,145,152,159,168
43 AVSS - Ground connection for the clock PLL circuits.
Connect to the digital ground plane.
16,54,107,158 AVDD25 - Core Logic digital power connections. Connect to the digital
+2.5 volt power supply and decouple to the digital ground plane.
Analog power connections for the clock PL Lcircuit. Connect
42 AVDD - to a separately decoupled +2.5 volt power supply and decouple
directly to the AVSS pin.
Control Signals
49 RESETB I Reset. When this input is set low it will reset all the internal
registers to the default states.
When this pin is set high the the outputs of the FL12200 will
53 OE O be enabled ; when it is set low the outputs will be set into a
high-impedance state.
56~58 IFORMAT(2~0) I Input signal format control.
59~61 OFORMAT(2~0) O Output signal format control.
The settings of DADDR(1,0) allow the device address of the
44,45 DADDR(1,0) - control bus to be programmed to prevent conflict with the
other devices connected to the bus.
When this pin is set low the control bus will operate in the
46 MODE - slave mode; allowing the device to programmed from an
external controller.
47 SDA I/O 2-wire serial control bus data.
48 SCL I 2-wire serial control bus clock.
40 PIXCLK I Pixel clock input. This clock is used to drive all the circuits in the FL12200.
62 N/P/IN/OUT I/O NTSC/PAL input or output.
Control Signals(contd.)
52 NOMEM I No memory mode control input.
Input Signals
18~27 G/YIN(0~9) I 10-bit green or luminance signal input bus.
6~15 B/CbIN(0~9) I 10-bit blue or Cb chroma signal input bus.
28~32 R/CrIN(0~4) I 10-bit red or Cr chroma signal input bus.
35~39 R/CrIN(5~9)
3 HSYNCREFI I Horizontal sync or reference.
4 VSYNCREFI I Vertical sync or reference.
5 FIELDIN I Field identifier input.
Output Signals
65~72 G/YOUT(2~9) O Green or luminance output bus.
75,76 G/YOUT0,1
93,94 B/CbOUT8,9 O Blue or Cb chrominance output bus.
97~104 B/CbOUT(0~7)
3-7 Video Deinterlacer : FLI2200 (VIDEO DEINTERLACER, IC1)

DV-6050
15
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
77~83 R/CrOUT(3~9) O Red or Cr chrominance output bus.
86~88 R/CrOUT(0~2)
116 CCLKO O Chroma output sampling clock.
117 YCLKO O Luma output sampling clock.
89 VREFO - Start of active field or frame indicator.
90 HREFO O Start of active line indicator output.
91 VSYNC/CREFO O Vertical sync output. This signal provides the vertical sync
function for the outputs.
92 H/CSYNCO O Horizontal or composite sync output. This signal provides the
horizontal sync function for the outputs.
110 FILM O Film mode detector output.
SDRAM Interface Signals
125~131 ADDR(4~10) -SDRAM address bus. This signal bus is used to address the
133~136 ADDR(0~3) external SDARM(s) used for field memories.
139~143,146~150 DATA(0~4, SDRAM data bus. This signal bus is used to transfer the data
153~157,160~166 5~9,10~14, - to and from the external SDRAM(s) used for field memories.
169~176 15~21,22~29)
118 MEMCLKO O SDRAM clock and 2x output sampling clock.
119 WEN - SDRAM write enable. This active low signal should be
connected to the WE pin(s) on the SDRAM(s).
120 RASN - SDRAM row address select. This active low signal should be
connected to the RAS pin(s) on the SDRAM(s).
121 CASN - SDRAM column address select. This active low signal should be
connected to the CAS pin(s) on the SDRAM(s).
122 BSEL - SDRAM bank select.
• Simplified Block Diagram
Ext. Syncs /
PIXCLK PLL/Clock
Generator
Sync
Generator Sync Out
RGB/YUV/
YCrCb/D1
10
/
/
/
Input
Signal
Formatter
Deinterlacer Core with DCDiTM
,Motion Compensation, Film
Mode Detection
and Bad Edit Correction
Output
Signal
Formatter
10
/
/
/
YU V
/RGB/
YCrCb
DADDR
SDA
SCL
2
/Control
Interface and
Registers
PLl/Clock
Generator

DV-6050
16
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1,11,25,48,61,68,85,
93,105,141,156,160, VDD - Digital supply voltage (+3.3V).
166, 172,179,188,
197,205
2~4,6~8,10,201 MA0~MA11 O SDRAM address 0~11
203,204,206,207
5,16,37,57,77,99,146, LVDD - Digital supply voltage (+1.8V) for internal logic.
174,184,191,202
9,20,31,43,53,64,72,
82,89,104,135,151, VSS - Digital ground.
157,163,169,176,182,
186,194,200,208
12 HMD I Select signal from DVD microcomputer.
13 XRST I System reset input. L : Reset
14 ERRMON O Error monitor.
15 REF O Repeat flag •first signal.
17 XHINT O Interruption to DVD microcomputer. L : Active
18 XHINT2 O Interruption to DVD microcomputer. L : Active
19 XDK O Acknowledgment to DVD microcomputer. L : Active
21 XWRH I Write enable from DVD microcomputer.
22 XWR I Write enable from DVD microcomputer.
23 XRD I Read enable from DVD microcomputer.
24 XCS I Chip select from DVD microcomputer.
26 HCLK I Clock input from DVD microcomputer.
27~30,32~36, HA1~HA17 I Address input from DVD microcomputer.
38~42,44~46
3-9 AV Decoder : MN677531KA (DVD AUDIO BACK END, IC30)
Pin No. Pin Name I/O Pin Description
1,12 VDD - Digital supply voltage (+3.3V).
2~11 Y(0~9) I 10-bit progressive scan / HDTV input port for Y data.
Input for G data when RGB data is input.
13,52 GND - Digital ground.
14~23 CR (0~9) I 10-bit progressive scan / HDTV input port for color data in 4:4:4 input mode.
In 4:2:2 mode this input port is not used. Input port for R data when RGB data is input.
24,35 VAA - Analog supply voltage (+3.3v).
25 CLKIN I Pixel clock input.
26,33 AGND - Analog ground.
27 DV/CLKOUT I/O Video blanking control signal input or clock output signal.
28 VSYNC I Vertical sync control signal input or TSYNC input control signal in async timing mode.
29 HSYNC I Horizontal sync control signal input or SYNC input control signal in async timing mode.
30 SCL I Serial interface clock input.
31 SDA I/O Serial data input/output.
32 CB OUT O Color component analog output of input data on Cb/Cr (9~0) input pins.
34 Y OUT O Y analog output.
36 CR OUT O Color component analog output of input data on Cr (0~9) input pins.
37 COMP O Compensation pin for DACs.
38 RSET I This pin is used to control the amplitudes of the DAC outputs.
39 VREF I/O Voltage reference input for DACs or voltage reference output.
40 RESET I This input resets the on-chip timing generator and sets the ADV7196A into
default register setting.
41 ALSB I This signal sets up the LSB of the MPU address.
10-bit progressive scan / HDTV input port for color data.
42~51 CB (9~0) I In 4:2:2 mode the multiplexed Cr Cb data must be input on these pins.
Input port for B data when RGB is input.
3-8 Video Encoder /DAC : ADV7196 (VIDEO DEINTERLACER, IC3)

DV-6050
17
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
47,49~52,54~56 HD0~HD15 I/O DVD microcomputer data bus 0~15.
58~60,62,63,65~67
69 AUDSTR I Valid signal of bit stream input data.
70 VSTR I Clock signal input for bit stream.
71 VRQ O Request of program stream.
73~76,78~81 STD7~STD0 I Bit stream parallel input 0~7.
83 IECOUT O IEC958 format data output.
84 DMIX O Down mix signal output (CH7/CH8).
86 DACCK O Over sampling DAC clock output.
87 LRCK O LR clock output.
88 SRCK O Bit clock output.
90~92 ADOUT(0~2) O Audio data output (0~2).
94 CLK121 I External clock (121.5MHz) input. (Unused)
95 CKIO I "L" : Fixed
96 CLK27 I System clock input (27MHz).
97 PLLVDD - Supply voltage (+1.8V) of internal logic for main PLL.
98 CLK81 - Connected to digital ground.
100 EXTCK I Clock input for audio.
101 PLLAVDD - Main PLL supply voltage (+3.3V).
102 TCPOUT 0 Unused.
103 PLLAVSS - Ground for main PLL.
106 PHCOPMO O Audio PLL phase comparison output.
107 APLLVDD - Supply voltage (+1.8V) of internal logic for Audio PLL.
108 ACKIO I "L" : Fixed
109 MODE121 I Switching port for SDRAM clock frequency.
110 DCTEST I DC test mode terminal.
111 APLLAVSS - Ground for audio PLL.
112 APLLAVDD - Supply voltage (+3.3V) for Audio PLL.
113 VREFCR I DAC reference voltage input for CR signal.
114 IREFCR I DAC bias current setting port for CR signal.
115 COMPCR I Capacitance connection for DAC (CR signal) stabilization.
116 VCROUT O CR signal output for DAC.
117,127 AVDD - Analog supply voltage (+3.3V) for DAC.
118 VREFC I DAC reference voltage input for C signal.
119 IREFC I DAC bias current setting port for C signal.
120 COMPC I Capacitance connection for DAC stabilization.
121 VCOUT O C signal output for DAC.
122,132 AVSS - Analog ground for DAC.
123 VREFCB I DAC reference voltage input for CB signal.
124 IREFCB I DAC bias current setting port for CB signal.
125 COMPCB I Capacitance connection for DAC (CB signal) stabilization.
126 VCBOUT O CB signal output for DAC.
128 VREFY I DAC reference voltage input for Y signal.
129 IREFY I DAC bias current setting port for Y signal.
130 COMPY I Capacitance connection for DAC (Y signal) stabilization.
131 VYOUT O Y signal output for DAC.
133,134 TESTSEL1,0 I Test mode terminal. L : Fixed
136 VCLK O Clock output for digital video data output.
137~140,142,143 REC(7~2) I/O REC656 input (7~2).
144 REC1 I/O REC656 input 1. Vertical synchronizing signal input/output.
XVSYNCO
145 REC0 I/O REC656 input 0. Horizontal synchronizing signal input/output.
XHSYNCO
147~150,152~155 VD0~VD7 O Digital video data output (0~7).

DV-6050
18
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1,34 VCC1,2 - VCC
2 CIN I Croma input.
3,15 MUTE (1,2) O Mute select (Unused).
4,6 VIN, YIN I Video input (Composite or Y).
5 YC MIX - YC MIX select (GND).
7 BIAS - Bias
8,10,17,20, GND - GND
23,26,29,32
9,11 NC - Unused.
12 CYIN I Luminance input
13 CLP - Input clamp select (Unused).
14,16 CbIN, CrIN I Component input.
18 CrOUT
21 CbOUT
24 CYOUT O Signal output.
27 YOUT
30 VOUT
19 CrSAG
22 CbSAG
25 CYSAG O SAG correction.
28 YSAG
31 VSAG
33 COUT O Croma output.
3-10 Video Driver : MM1568 (DVD AUDIO BACK END, IC71)
Pin No. Pin Name I/O Pin Description
158,159,161,162,164
165,167,168,170,171 MDQ0~MDQ15 I/O SDRAM data bus (0~15).
173,175,177,178,180
181
183 MCKI I Clock input from SDRAM.
185 MCK O Clock output to SDRAM.
187 DQMLE O Lower bite data, mask signal of expander SDRAM.
189 DQMLM O Lower bite data, mask signal of main SDRAM.
190 DQMUE O Upper bite data, mask signal of expander SDRAM.
192 DQMUM O Upper bite data, mask signal of main SDRAM.
193 XWE O Write enable signal of SDRAM.
195 XCAS O CAS signal of SDRAM.
196 XRAS O RAS signal of SDRAM.
198 XCSE O Chip select signal of expander SDARM.
199 XCSM O Chip select signal of main SDARM.

DV-6050
19
ADJUSTMENT
order of item output setting alignment point alignment for Fig.
adjustment
1Y LEVEL Connect an oscilloscope to Y signal of VR30 (DVD Y_signal = 1000mV p-p Fig.1
(✽ 2) the S terminal output with 75Ωresistor. AUDIO PCB) ±30mV
2 CHROMA Connect an oscilloscope to C signal of VR32 (DVD Burst of Chroma_signal Fig.2
(✽ 2) LEVEL the S terminal output with 75Ωresistor. AUDIO PCB) = 286mV p-p ±14mV
3Connect an oscilloscope to Cb signal VR31 (DVD Cb_signal = 648mV p-p
(✽ 2) Cb LEVEL of the component terminal output AUDIO PCB) ±14mV Fig.3
with 75Ωresistor.
4Connect an oscilloscope to Cr signal VR33 (DVD Cr_signal = 648mV p-p
(✽ 2) Cr LEVEL of the component terminal output AUDIO PCB) ±14mV Fig.4
with 75Ωresistor.
5 YCbCr Connect an oscilloscope to Y signal of VR1(Faroudja + Y_signal = 1000mV p-p
(✽ 3) LEVEL the component terminal output ADV7196 PCB) ±30mV Fig.1
with 75Ωresistor.
video signal output adjustment (use disc : 100% COLOR BAR)
Adjustment Procedure
1. To adjust the VR30~VR33, remove "Faroudja + ADV7196 PCB" first.
2. Then adjust VR30, VR32, VR31 and VR33 in regular order.
3. After adjusted then, put a "Faroudja + ADV7196 PCB" back.
4. Adjust a VR1.
✽ 2: Output mode is interlace.
✽ 3: Output mode is progressive.
1000mV
30mV
Y
4.7 s
-2.86
0
714
(100IRE)
[mV] white
yellow
cyan
green
magenta
red
blue
black
714
641
516
443
324
252
127
54 1000mV
286mV
14mV
30mV
IRE'
Peak white
Blank
Sync. chip
0
100
-40
Fig. 1 Fig. 2
[ mV ]
Cb Cr
[ mV ]
324 324
-324
324 324
-324 -324
53
-53
271
-271
-324
-215
-109
109
00
00
215
Fig. 3 Fig. 4

DV-6050
20
INTERCONNECTION DIAGRAM
1
20
1
20
11
20 20
11
88
124
24 1
12 12
11
8
1
8
1
10
1
10 10
11
8
8
1
1
6
1
1
6
5
1
1
5
1
12
1
12
2
1
1
114
14
3
1
3
1
2
1
2
18
1
8
1
1
1
5
5
10
1
2
1
10 1
21
1
CN1 CN51
CN52CN2
CN1
CN2
CN64 N400
CN55 N401
CN14
DOWN
LOAD
JIG
CN53 N312
K400
MIXL
MIXR
FR
FL CENTER
SW
LS
RS
K401
N314
N402
N315
N403
CN33
CP16
CP15 CP17
MP4
CP15
CN12
CP14 CN14
CP13 CN13
CN11 CN101
N316
CN103
CN102
M/S
MASTER SW
CN104
AC CORD
CN25
S-VIDEO
Pb
Pr
Y
K302
K304
K305
Pr
K301
COMPONENT
SCART
COAXIAL
OPTICAL
K303
(X37-3000-10)
MAIN BOARD
(X35-2340-10)
I/P BOARD
UNIT
TRAVERSE
AUDIO BOARD
BOARD
MECHA
INTERFACE
BOARD
BOARD
MECHA
FRONT BOARD
SUPPLY
BOARD
POWER
BOARD
STANDBY
BOARD
CLOSE
OPEN/
DV-6050
OUTPUT
