Kenwood DEM-9991D User manual

LASER DISC RF DEMODULATOR
DEM-9991D
SERVICE MANUAL
© 1998-2/B51-5412-00 (K/K) 3728
POWER
RF
LOCK
LASER DISC RF DEMODULATOR DEM-9991D
OFF OPT. COAX.
EXTERNAL DC SUPPLY DC 12V
DIGITAL OUTPUT
COAX.
DIGITAL INPUTRF INPUT
COAX.
DC IN
OPT.
AC-3 RF
Chassis *
(A10-)
Indicator
(B08-9063-04)
Slide switch
(S62-0008-05)
DC jack
(E30-0315-05)
Rear panel
(A80-3383-04) Optic receiving module
(W02-1181-05)
Phono jack
(E63-1035-05)
Panel
(A60-1377-04)
* Refer to parts list on page 8.
DEM-9991D(J,K)COVER( 98.4.250:09AM y[W 2

DEM-9991D
2
CONTROLS
1POWER switch
Press to turn the power on (OPT./COAX. position) or
off.
• Regardless of the OPT./COAX. switch setting, the
input is switched automatically to the Dolby Digital
RF input when ever a Dolby Digital RF signal is
input.
2POWER indicator
Lights (red) when the power switch (1) is set to ON.
3RF LOCK indicator
Lights when a Dolby Digital (AC-3) RF signal is input
to the AC-3 RF INPUT jack (5)
4DIGITAL OUTPUT COAX. (coaxial) jack
Connect this jack with the AC-3 DIGITAL IN jack of
your Dolby Digital (AC-3) decoder or receiver.
• When there are simultaneous inputs from the RF
INPUT (AC-3 RF) jack and DIGITAL INPUT (OPT.
/ COAX.) jack, the RF INPUT (AC-3 RF) signal is
output with priority.
5AC-3 RF INPUT jack
Connect this jack to the AC-3 RF OUTPUT jack on
your LD player.
6DIGITAL INPUT COAX. (coaxial) jack
Connect with the COAXIAL OUTPUT jack of your LD
player.
7DIGITAL INPUT OPT. (optical) jack
Connect with the OPTICAL OUTPUT jack of your LD
player. BE sure to remove the cap before using this
jack.
8DC IN (12V) jack
Connect the inlet type power cord from the provided
AC adapter. Do not plug the power cord into the wall
outlet until all other connections have completed.
DEM-9991D(J,K)COVER( 98.4.250:09AM y[W 3

Port NO Port Name I/O Descriptions
59 TLDB I Test port of IC.
60 TCK I Test port of IC.
61 TRP O Output port of IC test.
62 TDO O Output port of IC test.
63 PDO O Phase comparator (3 states)
64 TI4 I Test port of IC.
65 PDDIS I Output control of PDO. L = output.
66 MUTO O Muting output. H = mute. Also H = MUTI is “H” or out of synchronous of AC-3.
67 TI5 I Test port of IC.
68 VLDY O Output port of IC test.
69 DASYO O Output port of IC test.
70 DAOUT O Digital out (serial data stream output)
71 DAIN I Extra input of digital.DASEL = ”H” : signal though DAOUT.
72 DASEL I Choice of digital output
73 TI8 I Test port of IC.
74 C2F1 O Display of C2 error correction. Output of condition on error correction.
75 C2F0 O Display of C2 error correction. Output of error count on C2.
76 C1F1 O Display of C1 error correction. Output of error or non-error on C1.
77 C1F0 O Display of C1 error correction. Output of error count on C1.
78 MUT1 I Muting input. H = mute.
79 VDD – Power supply (+5V).
80 GND – GND (0V).
81 AVDD – Analog Comparator power supply (+5V)
82 CPIN I Analog comparator input. Negative port (invert).
83 CMIN I Analog comparator input. Positive port (non-invert:QOSK input).
84 AGND – Analog comparator GND.
85 TM4 I Test port of IC.
86 VDD – Power supply (+5V).
87 DIN I Test port of IC.
88 DOUT O Analog comparator output.
89 DOUTB O Inverted analog comparator output.
90 C9M O 9.216MHz output. 1/2 divided output of VIN (55P).
91 GND – GND (0V).
92 WINGT O Output port of IC test.
93, 94 SYST0, 1 O Output port of IC test.
95, 96 ADST0, 1 O Output port of IC test.
97 TM5 I Test port of IC.
98 BUNRI I Test port of IC.
99 AGND – GND of 46.08MHz.
100 AVDD – Power supply of 46.08MHz (+5V).
Port NO Port Name I/O Descriptions
1 GND – GND (0V).
2 VDD – Power supply (+5V).
3 RESET I System reset. L = reset.
4 OSCON I Oscillation control. H = oscillation. L = standby.
5 DATA I Test port of IC.
6 MCK I Test port of IC.
7 MLTB I Test port of IC.
8 IDST O Output port of IC test.
9 IDCK O Output port of IC test.
10 IDO O Output port of IC test.
11 TMO I Test port of IC.
12 ECCK O Output port of IC test.
13 DEN O Output port of IC test.
14 DEY O Output port of IC test.
15 MSYC O Output port of IC test.
16 TM1 I Test port of IC.
17 A0 O Address 0 output of extra RAM (LSB).
18~22 A1~5 O Address 1~5 outputs of extra RAM.
23, 24 TM2, 3 I Test port of IC.
25 XOUT O Output port of IC test.
26, 27 XIN / XEXT I Test port of IC.
28 GND – GND (0V).
29 VDD – Power supply (+5V).
30, 31 A6, 7 O Address 1~5 outputs of extra RAM.
32 GND – GND (0V).
33 VDD – Power supply (+5V).
34 A12 O Address 12 outputs of extra RAM.
35 A14 O Address 14 outputs of extra RAM (MSB).
36 WEB O Write enable signal of extra RAM. L = active.
37~39 A13 / 8, 9 O Address 13, 8, 9 outputs of extra RAM.
40 GND – GND (0V).
41 A11 O Address 11 outputs of extra RAM.
42 OEB O Output enable signal of extra RAM. L = active.
43 A10 O Address 10 outputs of extra RAM.
44~51 DB7~0 I/O Data port of extra RAM. Data bus7~0.
52 VDD – Power supply (+5V).
53 GND – GND (0V).
54 TI1 I Test port of IC.
55 VIN I VCXO input.
56 VOUT O VCXO output.
57, 58 TI2, 3 I Test port of IC.
