KENYON TEXAN STAND
ASSEMBLY INSTRUCTIONS
Part # 145593
July 1, 2020

Contents
Items Required and Hardware Kits
Parts Lists
Base Kit
Enclosure Kit
Shelf Kit
Instructions
Assembling Base Texan Stand
Assembling the Enclosure Kit
Assembling the Shelf Kit
3
4
5
5
7
9
10
Please read & save
these instructions
Thank you for choosing Kenyon,
the world’s leading manufacturer
of specialty cooking appliances.
By following the instructions in this
assembly manual, your grill stand
will provide you with many years of
reliable service.

Gloves and a Helping Hand Strongly
Recommended
PLEASE READ THESE INSTRUCTIONS
IN THEIR ENTIRETY BEFORE USE.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
ITEMS REQUIRED
Phillips Head
Screwdriver
BASE STAND HARDWARE KIT
S1
(33X)
S2
(9X)
S3
(4X)
ENCLOSURE HARDWARE KIT
SHELF HARDWARE KIT
S1
(6X)
S1
(16X)
W1
(4X)
N1
(4X)
3

Part Lists
4
SIDE FRAME (2X) BACK FRAME (1X)
LEG (4X) FRONT FRAME (1X)
LOWER SHELF (1X) UPPER SHELF (1X)
Base Kit

Part Lists
5
SIDES (2X) BACK (1X)
DOORS (2X)
Enclosure Kit
Shelf Kit
SHELF (2X)

Instructions
6
1Attain all materials and hardware needed
to put together stand.
• Phillips Screw Driver
• Gloves
• A Friend (grill them some steak after!)
2Take inventory (Base Kit)
• (2X) Side Frame
• (1X) Front Frame
• (1X) Back Frame
• (4x) Legs
• (1X) Upper Shelf
• (1X) Lower Shelf
• (33X) Screw S1
• (9X) Screw S2 (for Texan Flange)
• (2X) Mounting Brackets 1
• (2X) Mounting Brackets 2
• (4X) Screw S3
• (4X) Hooks
3Take inventory (Enclosure Kit)
• (2X) Side
• (1X) Back
• (2X) Door
• (16x) Screw S1
• (2X) Handle Assembly
• (4X) White Washer W1
• (4X) Push in Nut N1
4Inventory (Shelf Kit)
• Custom Assembled at Kenyon!
• (2X) Handle Assembly
• (12x) Screw S1
If any components are missing or damaged, please
call KENYON Customer Service at 860-664-4906.

Assembling Base
Texan Stand
1Assemble stand on a carpet or soft surface
to avoid any dents or scratches.
Kenyon has done our best to deburr the sheet
metal, but it can still be sharp, please be
mindful when assembling this stand. We
recommend using gloves.
Please leave vinyl on parts until nished
assembling. The vinyl has been removed from
joining faces but the outer faces will continue
to have some protection.
Unpack stand parts carefully, lay the parts out
to check for shipping damage.
Instructions
7
2Place 2 Legs on the ground, vinyl side
down. All of the legs are the same. The legs
have holes throughout the length of them.
Place the Front Frame, vinyl side down, and
align the top (3 holes with nuts) with the top
of the legs. Fasten together lightly, do not fully
tighten yet, Screw S1 to corresponding hole 1
and hole 2.
Use: Screw S1
There will be 4 included hooks in this package.
These use Very High Bond tape so rst
adhesion is very important. Please thoroughly
clean the stainless steel where you want the
hooks to be. On the back of the hook there is
the double-sided tape. Peel the protective
layer off and then stick the hook on rmly.
Allow this to set for at least 2 hours before
putting any load on the hook.

Instructions
8
5 Put the nal two Legs on now. The
orientation should be the same as the
other legs.
Use: Screw S1
6Turn the stand over so the open frame is
down. Fasten the Back Frame to the rest of
the stand now, vinyl side out. The 3 holes with
nuts should be on the top, the same as the
Front Frame. This will bring the entire BASE
STAND together.
Use: Screw S1
7Take this time to tighten all screws (don’t
forget under the shelves!).
Now, if assembling the enclosure kit or shelf
kits skip this step and move to the next page.
If not assembling the enclosure or shelf kit,
place the Texan grill into the stand, please be
careful, 2 people recommended. Hold by the
strongest part of the ange, as close to the
Texan body as possible. Be aware, ange will
bend if held too far out. Fasten Texan to stand
using Screw S2.
Use: Screw S2
If using the mounting brackets to fasten the
stand to the deck or patio, nd the install
location to set the Texan. There are two types
of mounting brackets, they are mirrored parts
of each other. Use lag bolt S3 to fasten to the
deck or patio.
Use: Screw S3
Take all of the remaining vinyl off now and use
this time to clean and polish to put a beautiful
shine on the grill and stand’s stainless steel.
Remember to wipe with the grain, never
across or diagonally.
3 Align the Upper Shelf with hole 5. The
shelf should have the vinyl facing towards
the Front Frame and the 2 large holes in the
upper shelf should be on the opposite side of
the Front Frame, as shown in the next image.
Tighten lightly 2 screws to each Leg. Repeat
with the Lower Shelf in hole 6.
Use: Screw S1
4 Connect the Side Frames to the top 2
holes in the Legs. If you have one (or two)
Side Shelves, attach one (or neither) side
frame but leave the side shelf assembly off
until the end.
Use: Screw S1
Continue to the next page
to assemble the enclosure
and shelf kit.

Instructions
9
Assembling the Enclosure
Kit
1Lift the stand to the standing position and
open the Enclosure Kit hardware package.
Next, fasten the handles to the doors. Take
one S1 screw, put it through the hole on the
inside face of the door. Take the handle
assembly and screw S1 into one of the small
handle legs. Fasten the other screw into the
handle. Repeat with the other door.
Use: Screw S1
Hardware kit and accessories can be found
inside the rectangular packaging.
Peel vinyl at least 2 inches from each side.
This is required for the sides, back and doors
to sit ush with the shelf.
2Now, take the Screw S1, Nylon Nut N1,
White Nylon Washers W1, included to
assemble the Doors. There are 2 square holes
in the front frame and 2 square holes on the
Upper Shelf. The Nylon Nuts will snap inside
these holes. Place one White Washer (W1) on
Screw S1. Do this with all 4 pivot points on the
door set. Tighten until you feel an increase in
resistance, overtightening will strip the nut.
Use: Screw S1, Nut N1, Washer W1
3 Using Screw S1, fasten the Back and both
Sides on the stand. The Back goes on the
side closest to the 2 holes on the upper shelf.
These should have a ush mount against the
Legs, Upper Shelf, and Top Frames.
Use: Screw S1

4 Take this time to tighten all screws (don’t
forget under the shelves!).
Now, if assembling the Shelf Kit skip this step
and go to the next page. If not assembling the
shelf kit, place the Texan grill into the stand,
please be careful, 2 people recommended.
Hold by the strongest part of the ange as
close to the Texan body as possible. Be
aware, ange will bend if held too far out.
Fasten Texan to stand using Screw S2.
Use: Screw S2
If using the mounting brackets to fasten the
stand to the deck, nd the install location to set
the Texan. There are two types of mounting
brackets, they are mirrors of each other. Use
screw S3 to fasten to the deck or patio.
Use: Screw S3
Take all of the remaining vinyl off and use
this time to clean and polish to put a beautiful
shine on the grill and stand’s stainless steel.
Remember to wipe with the grain, never
across or diagonally.
Instructions
10
Continue to the next section
to assemble the shelf kit.
Assembling the Shelf Kit
1Now, we are going to fasten the handle to
the shelf. Take one S1 screw, put it through
the hole on the underside of the Side Shelf.
Repeat for each screw. Now, take the handle
assembly and easily fasten to the shelf!
Use: Screw S1
Hardware kit and accessories can be found
inside the rectangular packaging.
2Use Screw S1 to fasten the Side Shelf to
whichever side of the stand makes the most
sense for your application.
Use: Screw S1
3 The shelf can be lifted into position by
lifting the handle, reaching under and pulling
the wings of the shelf to a right angle with the
stand. There are two sets of two rubber bum-
pers under the shelf that the wings will align in
between them. This will mitigate any chance
of the wings being moved while the shelf is up
and will also be softer when putting the shelf
down.
4 Congratulations all Texan stand kits have
been assembled! Take this time to tighten all
screws (don’t forget under the shelves!). Now,
place the Texan Grill into the stand, please be
careful, 2 people recommended. Hold by the
strongest part of the ange, as close to the
Texan body as possible. Be aware, ange will
bend if held too far out. Fasten Texan to stand
using Screw S2.

Instructions
11
If using the mounting brackets to fasten the
stand to the deck, nd the install location to set
the Texan. There are two types of mounting
brackets, they are mirrors of each other. Use
screw S3 to fasten to your deck.
Use: Screw S3
Take all of the remaining vinyl off and use
this time to clean and polish to put a beautiful
shine on the grill and stand’s stainless steel.
Remember to wipe with the grain, never
across or diagonally.
Congratulations, go grill your favorite food!
If you have any questions or concerns while assembling, please
do not hesitate to call Kenyon customer service at 860-664-4906.
