Operating instructions
Hand Grip Dynamometer
KERN MAP
Version 1.2
08/2012
GB
MAP-BA-e-1212

2 MAP-BA-e-1212
GB
KERN MAP
Version 1.2 08/2012
Hand Grip Dynamometer
Table of Contents
1Technical Data ............................................................................................... 3
2Appliance overview ....................................................................................... 8
3Basic Information (General).......................................................................... 9
4Basic Safety Precautions............................................................................ 10
5Transportation & Storage............................................................................ 10
6Removing packaging and initial start-up................................................... 11
7Operation...................................................................................................... 18
8Service, maintenance, disposal.................................................................. 28
9Error messages............................................................................................ 29

MAP-BA-e-1212 3
1 Technical Data
KERN
MAP 80K1
Capacity
80 kg
(blue)
40 kg
(green)
20 kg
(red)
Readability (d)
0.1 kg / 0.2 lb
Units
kg, lb
Auto Off
After 1 min without change of load
Electric Supply
1 x CR2450
Service life 53 h
Operating temperature
+ 5°C … + 35°C
Storage temperature
- 20°C … + 60°C
Humidity of air
max. 80 % (not condensing)
Dimensions fully mounted
(W x D x H) mm
212 x 55 x 102
Weight g (net)
300

4 MAP-BA-e-1212
KERN
MAP 80K1S
Capacity
80 kg
(blue)
40 kg
(green)
20 kg
(red)
10 kg
(yellow)
Readability (d)
0.1 kg / 0.2 lb
Units
kg, lb
Auto Off
After 1 min without change of load
Electric Supply
1 x CR2450
Service life 53 h
Operating temperature
+ 5°C … + 35°C
Storage temperature
- 20°C … + 60°C
Humidity of air
max. 80 % (not condensing)
Dimensions fully mounted
(W x D x H) mm
212 x 55 x 88
Weight g (net)
300

MAP-BA-e-1212 5
KERN
MAP 130K1
Capacity
130 kg
(white)
80 kg
(blue)
40 kg
(green)
Readability (d)
0.1 kg / 0.2 lb
Units
kg, lb
Auto Off
After 1 min without change of load
Electric Supply
1 x CR2450
Service life 53 h
Operating temperature
+ 5°C … + 35°C
Storage temperature
- 20°C … + 60°C
Humidity of air
max. 80 % (not condensing)
Dimensions fully mounted
(W x D x H) mm
212 x 55 x 102
Weight g (net)
300

6 MAP-BA-e-1212
1.1 Dimensions
MAP 80K1S:

MAP-BA-e-1212 7
MAP 80K1 , MAP 130K1

8 MAP-BA-e-1212
2 Appliance overview
1. Battery compartment, see chapter 7
2. Display, see chapter. 8
3. Keyboard, see chapter. 8
4. Spring set, see chapter. 7
Transport case

MAP-BA-e-1212 9
3 Basic Information (General)
Intended use
This device allows medical staff to test a patient‟s fitness sta-
tus and to carry out controlled training during the rehabilitation
process.
The appliance should be checked for correct condition prior to
each utilisation by a person familiar with proper operation of
the balance.
Non-intended
use
Changes to the unit's design are not permitted. This may lead
to incorrect measuring results, safety-related faults and de-
struction of the unit.
The unit may only be operated in accordance with the de-
scribed default settings. Other areas of use must be released
by KERN in writing.
Warranty
Warranty claims shall be voided in case
Our conditions in the operation manual are ignored
The appliance is used outside the described uses
The appliance is modified or opened
Mechanical damage and damage caused by media, liquids
Natural wear and tear
Non-intended use or electric installation
The measuring system is overloaded
Dropping the balance
Test device
control
As a precautionary measure during quality control, the metro-
logical features of the device have to be tested on a regular
basis. The responsible user must define a suitable interval as
well as type and scope of this test. For further information
please go to KERN-Homepage (HYPERLINK http://www.kern-
sohn.com under www.kern-sohn.com).

10 MAP-BA-e-1212
4 Basic Safety Precautions
Carefully read this operation manual before setup and com-
missioning, even if you are already familiar with KERN bal-
ances.
Versions in other languages are non-binding translations.
The only binding version is the original document in German.
Staff training
The medical staff must apply and follow the operating instruc-
tions for proper use and care of the product.
5 Transportation & Storage
Testing upon
acceptance
When receiving the appliance, please check packaging imme-
diately, and the appliance itself when unpacking for possible
visible damage.
Packing
Keep all parts of the original packaging in case you need to re-
turn the appliance.
Only use original packaging for returning.

MAP-BA-e-1212 11
6 Removing packaging and initial start-up
Place of
application
The unit is designed to achieve reliable measuring results un-
der normal conditions of use.
Required conditions for place of operation:
Prevent extreme heat and temperature fluctuations
Protect the appliance against high humidity, vapours and
dust;
Do not expose the device to extreme dampness for longer
periods of time. Non-permitted condensation (condensa-
tion of air humidity on the appliance) may occur if a cold
appliance is taken to a considerably warmer environment.
If present, acclimatise device.
Avoid static charge
Avoid contact with water.
If electro-magnetic fields or static charge occur, or if the power
supply is unstable major deviations on the display (incorrect
weighing results) are possible. In that case, the location must
be changed.
Scope of supply
Device, see chapter. 3
Carrier case
3 Spring sets
Operating instructions
Battery

12 MAP-BA-e-1212
How to replace
a spring set
1. Press device until the two screws [1] become visible.
2. Remove screws.
3. Remove grip first, followed by springs.
4. Insert desired spring set.
5. Reassemble device in reverse order.
[1]
[1]

MAP-BA-e-1212 13
Install two additional washers only in the 130 kg-spring set. (s. fig.)

14 MAP-BA-e-1212
Battery
operation
1. Open battery cover, as shown on illustration.
2. Replace battery (CR-2450).
3. Reinsert the battery cover.
To save battery power, the device auto-disconnects automati-
cally after 60 seconds have passed without a change of
display.
If the batteries are run down soon, "LO" appears in the
display. Replace battery.
If the balance is not used for a longer time, take out the „
batteries and store them separately. Leaking battery liquid
could damage the balance.

MAP-BA-e-1212 15
Commissioning
Correct
left hand right hand

16 MAP-BA-e-1212
Correct
left hand
right hand

MAP-BA-e-1212 17
wrong

18 MAP-BA-e-1212
7 Operation
Overview of
displays
1. Stability display
2. Battery status
3. Operation modus
4. Percentage display
5. Weighing unit "lb"
6. Weighing unit "kg"
Keyboard
overview
Button
Function
/ Zero
Switch-on / off, zeroing
Mode
Select operating mode
Set
Confirm display
In real mode: Switch unit from kg to lb

MAP-BA-e-1212 19
Turn on/off
Zeroing
Switch on the device by pressing the /zero key.
Zero display appears.
If the device does not exactly show zero, unload the device
and press the /zero key.
To switch off, keep /zero key pressed for approx. 3
seconds.
During power-up the device will return to the mode or unit (kg/lb)
it had been in before it was switched off.

20 MAP-BA-e-1212
7.1 Operating modes
The device is in real mode at delivery. Use the mode key to switch over the device
to the following operating modes.
Operating mode
Display
Function
Real time mode
Shows current strength.

Counting mode
Counts number of gripping actions
exceeding a previously set strength
limit.

Average mode
Calculates the average strength
derived from two hand grips

Peak/Max Mode
Shows max strength of hand grip.
