User’s Guide

KeyLlama USB Value

Introduction

Installation

Reading the Data

Configuration Options

Troubleshooting

User greement

Page

Check http://KeyLlama.com/KeyLlamaUsbValue.pdf for the latest ersion of this document.

www.KeyLlama.com

Introduction

KeyLlama USB Value

The KeyLlama USB Value records e erything typed on a USB keyboard. It stores the data to

internal flash memory. The data may be retrie ed on any computer with a USB port and keyboard.

This hardware keylogger is 100% stealthy and no software or dri ers are required.

Features

•Huge memory

•Compatible with wired USB keyboards (including Linux)

•100% Stealthy – Can’t be detected by security software

•No software or dri ers needed

•National keyboard layout support

•64bit encryption to help keep sensiti e data safe

•Only 1.6" long

Requirements

•USB port

•USB keyboard

•Operating System that supports USB de ices

Installation

Installation of the KeyLlama USB Value takes just seconds.

Simply plug it in between the USB keyboard and the USB port. No software or dri ers are needed.

The KeyLlama immediately starts recording e erything that is typed. The de ice is completely

stealthy.

Reading the Data

Once data has been captured in record mode, it may be retrie ed on any computer with a USB

keyboard and port. Each de ice has a 3 or 4 key password combination: by default , m, p. Type

“ mp” in sequence and hold (first press ‘ ’ and hold, then ‘m’ and hold, finally ‘p’ and keep holding

all three down). You should see: mppp When the keyboard stops typing, you know the

keylogger is switching to flash dri e mode.

www.KeyLlama.com

Flash Dri e mode disables the USB keyboard, so the following operations should be done with the

mouse.

After a few seconds, the hardware keylogger will automatically be detected as a mass storage

de ice. After another moment, the de ice will be isible as a new “Remo able Dri e”. In Windows,

select “Computer” or “My Computer” to open this disk.

The Flash Dri e will contain the file keys.txt with a text log of all captured data. This file can be

iewed and searched with any text editor, such as Notepad or MS Word.

Note: While in Flash Dri e mode, the USB keyboard is disabled. Use the mouse to operate on the

log file.

Erase Memory

Select the keys.txt file and select Delete. A new file will be created when the keylogger is

reinstalled.

www.KeyLlama.com

Configuration Options

Software Configuration:

No software is required to use the keylogger, but we include a handy program that is helpful for

changing the configuration: The program is named KeyLlamaConfig.exe and comes installed on

the keylogger.

Step 2 allows you to create two passwords.

Lea e Password #2 as “ mp” until you ha e

tested your new password to make sure it

works!

In Step 3 you can select to log Special Keys

(like Ctrl, Enter, F1, F2, etc).

You may also elect to disable recording.

Step 1 allows you to select a keyboard

language setting. This allows the keylogger

to be used with many languages, in addition

to the default US English.

Double-click KeyLlamaConfig.exe to begin

www.KeyLlama.com

In Step 4, you must select the appropriate dri e letter, by matching it to letter listed under

“My Computer” or “Computer”

In this case, the “Remo able Dri e” is letter F, so that is what has been selected for Step 4.

Step 5 simply confirms all your settings. If

all is correct, click “Apply”. If you need to

make changes, select “Exit” and start o er.

After a few moments, this screen will appear

to show that your changes ha e been made.

Unplug and then reinstall the KeyLlama to

test.

www.KeyLlama.com

Manual Configuration:

Basic changes may be configured through the file: options.txt. Use any text editor to change the

options.txt:

Be ery careful – any errors can render the keylogger inoperable! Use the software configuration

option if you ha e any doubts.

$Password1 sets the 3 or 4-key combination for triggering Flash Dri e mode. Default alue is

mp.

$Password2 sets the 3 or 4-key combination for triggering Flash Dri e mode. Default alue is

123.

IMPORTANT: Not all combinations work! Because of the way USB keyboards are designed, some

characters will cancel others out when both are held down. Keep one password as " mp" until you

ha e tested to ensure the new is OK.

$Spe ialKeys sets the logging le el for special keys, such as Enter, Escape, F1...F12 etc. Special

keys are logged in brackets, i.e. [Ent]. Allowed alues are No (only text is logged) and Yes (text

with all special keys are logged). Default alue is No.

$Status allows you to to disable logging, howe er does not affect mode switching. Allowed alues

are On (logging enabled) and Off (logging disabled). Default alue is On.

Example configuration file settings:

$Password1= mp

$Password2=x p

$SpecialKeys=no

$Status=on

All KeyLlama products come with 1 year warranty against manufacturer defects. Defecti e products

must be shipped to KeyLlama by the customer. All warranty repairs and deli ery to the customer

will be paid by KeyLlama.

www.KeyLlama.com

Troubleshooting

The KeyLlama USB will not work for the following hardware configurations:

1. PS/2 keyboards (e en with adapters)

2. Internal laptop keyboards

The keylogger does not enter Flash Drive Mode

Please check the following:

1. Ensure the keylogger is inserted between the USB keyboard and the USB port on the PC or

hub: Keyboard  KeyLlama  Computer

2. Is your 3-key combination correct? The default is ,m,p

3. Are you pressing the 3 keys sequentially? (First press ‘ ’ and hold, then ‘m’ and hold, finally

‘p’ and keep holding all three down)

4. Sometimes, this issue is caused be another USB de ice interfering. USB printers are the

most common problem. For testing:

•Disconnect all USB devices except the keyboard and the mouse.

•Install the keylogger between keyboard and computer

•Type a test sentence

•Us the 3-key combination to enter flash dri e mode and see if it was recorded properly

If that fixes it, connect the printer and the keylogger to the USB ports

that are physically as far apart as possible – like in the photo at right.

This will help ensure they are on a separate internal USB hub.

It still doesn’t work!

If you are still experiencing problems, please do the following:

1. Check if the problem appears on a different keyboard.

2. Check if the problem appears on a different computer.

3. Contact us (http://KeyLlama.com/). We sell se eral models of keyloggers, so please be

sure to tell us you ha e the KeyLlama 4MB USB Value.
