Keystone WT06 User manual
Installing the APP
1. Before powering up the Sensor, please install our free ‘NEXUSHOME ‘ APP onto your phone. The APP is available in an IOS version on the
Apple App Store and an Android version on the Google Play Store. Ensure your phone is connected to WIFI to complete account setup.
2. Once downloaded, click and open the APP. The following message will appear. Please click OK.
3. Now complete your User Prole by inpung your email address and a 6 digit or longer Password, click the REGISTER buon, check your
email and click the link in the email from “Nefy” to complete registraon.
WT06
WIFI DOOR/WINDOW SENSOR
Product Specicaon
• Built-in WIFI module that sends all alerts to your Smartphone
• Super low power consumpon, typically only 2 x AAA baeries/year
• Separate low baery and loss of signal nocaons
• Life-me cloud service provided free of charge
• Powerful APP for your Smartphone provided free of charge
• User can create oorplans in the APP showing device locaon
• APP records last 30 acvaons me and date stamped
• 3M double sided tape for permanent xing included
• Blue LED for status indicaon
• Schedule up to 4 periods per day when unit is automacally turned o
Geng started
Congratulaons on your purchase of this powerful WIFI Door/Window Sensor. Once the magnet (smaller part) is moved away from the reed
switch (built into the larger part) or both parts close again, the unit will send an alarm signal to your smart phone via your home/business
WIFI connecon. Such signal is selectable as an Alarm Sound + Nocaon, Nocaon Sound + Nocaon or just a silent Nocaon. This
product works together with your smart phone and internet via WIFI. Please check that your smart phone is either an Android or IOS (iPhone)
and that the latest rmware has been installed. Please also check that your WIFI router is working properly and that its operang manual
conrms that it operates on 2.4 GHz with WPA/WPA2 encrypon.
1 2 3
install click OK register
Seng up your DEVICE
1. Go to the locaon in the Building where you eventually wish to install the Sensor. Look at your smart phone and ensure you have a good
and steady WIFI connecon there. Now, exit the APP, open SETTINGS on your smart phone and click “Wi-Fi”. Check what is showing. If
you just have a main Router, it should be showing its reference name (or SSID). Each Router or Extender has its own unique reference
name or SSID. However, if you have a network with one or more extenders, it may also be showing, underneath, under “Choose a
Network”, the SSID of an overlapping Extender, as in the picture 1 above. In this case, check whether you are closest to the main Router or
to an Extender and manually select, if necessary, the alternave closest/strongest SSID. THIS IS VERY IMPORTANT. The Sensor will only
communicate Alarm signals to the WIFI Router or Extender that you are about to “pair” it to so it is essenal that you pair it to the closest/
strongest Wi-Fi signal.
2. Re-Open the APP and click PROFILE at the boom of the opening HOME page. This will take you to the APP’s SETTINGS Page. Click
“ADD DEVICE/WIFI SETTING”.
3. Please select “Wireless” at the boom right hand side of the Page.
connect WiFi click “Add Device/WiFi Setting”
1 32
choose Wireless Pairing
1
4. Move the Sensor temporarily, right next door to the Router or Extender that you are pairing to. Carefully unscrew and open the baery
cover. Insert two new, good quality Alkaline AAA baeries, ensuring correct polarity. The Sensor will now automacally enter “Pairing
Mode”. You have 30 seconds to start the Pairing Process.
5. Go back to the App on the “ADD DEVICE/WIFI SETTING” page. You will see the same SSID of the Router/Extender that you selected in
your phone’s WIFI Sengs at the top of the Page. Enter the password of that Router or Extender and press PAIR NEW DEVICE.
6. The Sensor will now start pairing to the Router or Extender and you will see the wheel whirling. It can take up to 60 seconds for a “pairing
successful” message to appear. If you see the message “me out, try again”, disconnect the baeries from the sensor, reconnect them
to enter pairing mode again and repeat the process. If this error message connues, double check that the SSID on this page and the
password both match the Router or Extender to which you are aempng to pair the Sensor to. Once pairing is successful, you can now
close the baery door. Mount the Sensor onto the Door or Window using the double sided tape provided, ensuring that the arrows on
the both the magnet and the main unit align and that the magnet is no more than 5mm apart from the main unit.
4 5
enter the name of WIFI and password Pairing
6
insert two AAA batteries
How to use
1. Exit the PAIRING Page in the APP by clicking at the top of the screen (iOS only, for Android users press Backwards on your
Smartphone). Then, click at the top of the APP’s SETTING PAGE to return you to the APP’s Home Screen. Now press SECURITY SENSOR
TAG. This will take you to the Alert Mode Screen. This allows you to choose the Sound you will hear on your phone when an Alarm
nocaon is received from both the Door Sensor and all other Nexus devices you may have paired to your Router.
Alert Mode = Siren Sound (5 seconds repeated twice) + incoming Nocaon
Chime Mode = Short Alert Tone + incoming Nocaon
Silent Mode = No Siren, no Alert Sound, just the Nocaon
O Mode = No Siren, no Alert Sound and no Nocaon (All alerts from the Sensor will sll be listed the DEVICE’s HISTORY page)
2. Click at the boom of the screen. This will take you to the DEVICE page. Here you will see all the Sensors, including any other type of
Nexus sensors that have been paired to the APP.
Open the Door/Window on which the Sensor has been installed. You will see the blue LED ash once followed, a few seconds later by a
further two quick ashes, to indicate a nocaon Alert has been sent to the APP. If you see 3 ashes, it means the Alert has not been
sent, so wait 20 secs and repeat the process. Depending on the Alert Mode you have chosen, this will be audible or silent. You will see
the nocaon appear NexusHome now
DOOR SNESOR : Open and the Device will start to ash with the Alert’s me and date stamped alongside. Press the
“Refresh” Buon at the top le hand side of the page to cancel the ashing. If you now press the Device Icon, you will be taken to its
HISTORY PAGE which will list the last 30 nocaons. On this page you can also:
i) Toggle between turning a local Alarm On or o (On means that when the sensor is triggered, the oponal Nexus WIFI socket
will also start beeping)
ii) Swipe the “History Secon” to the Le to get to the “Device Disabled Sengs”. Here you can select up to 4 daily periods in which the
Sensor is automacally switched to O Mode.
a/ Tap on One of the 4 periods to take you to the Time Selecon Screen.
b/ Select the Time Period at the top of the Screen you want the Sensor to turn O automacally and then select the Days of the Week.
Press to return to the Time Selecon Screen.
c/ The Periods you selected will now be shown on the Screen. Click on to manually turn a Time Period O.
2
device list and history
1
4 different modes
ii)
b/ select time period
c/ turn a time
period off
a/ Top on one of
the 4 periods
Device Disabled Settings Device Disabled Settings
i)
DOOR SENSOR
DOOR SENSOR
PANIC BUTTON
VIBRATION SENSOR
DOOR SENSOR
2
How to share an Alert Nocaon from a DEVICE with another Smartphone
1. Ensure that the free ‘NEXUSHOME ‘ APP has been installed on the other Smartphone and complete the registraon process, following the
procedure detailed in “Installing the APP” above.
2. Press at the top right of the Device Page in the APP on the Smartphone.
3. Now select the Sensor you wish to share, then press and complete the “Share Device to” box with the other user’s email address they
used when registering their user prole. Press to exit.
4. Open the APP on that other User’s Smartphone and press PROFILE at the boom of the opening Home Page.
This will take you to the APP’s SETTINGS PAGE. In the secon “Received Device” you will see a number in green. This denotes the number
of Devices that you have selected to share with that User.
5. Press “Received”. This will take you to a list of those Devices. The new User can now choose whether to accept or reject Nocaons
from those Devices. Note that the new User can select, separately, on their APP’s Device Alert Page whether such nocaons are
Audible, Silent or O.
Advanced Informaon for the DEVICE PAGE
Press to Refresh/Reset the Device Page and stop a ashing Sensor Icon.
Press this Icon, at the top of the page, to return to the APP’s Home Screen
(iOS only, for Android press back on smartphone).
Enables you to share Alert nocaons for a Sensor with any other user who has already
downloaded the Nexus APP. See below for full details. Whilst in this secon, you can also alter
the order in which the Devices are listed on your screen. Press on” the right of the Device
whose order you wish to change and then drag it to its new posion on the screen.
A personalized descripon of the Sensor.
Press the Sensor’s Icon, to go to its HISTORY page and press “DOOR SENSOR” seen just above
the ID. Complete CHANGE DEVICE NAME and save it.
This is the Device’s unique ID.
How to delete a DEVICE from the APP
Whilst on the DEVICE PAGE, hold and swipe the Devices Descripon to the le of your screen and press
For Android, just press and hold then conrm with the prompt window for deleon.
3
Personalized Icon or Photo for the Sensor.
Press the Sensor’s Icon to go to its HISTORY PAGE, then press its Icon again on
this page. Choose “Take photo”, “From album” or “Default icons” to create a
personalized Icon.
Flashing - Indicates a Sensor has sent an Alert nocaon.
Press the Icon to go to the Sensor’s HISTORY PAGE
Indicates a Low Baery.
Although baeries should connue to last for up to a month aer this Icon
appears, you should change them immediately, respecng the correct polarity
and using good quality Alkaline baeries. Always test a Sensor aer replacing the
baeries.
The Sensor sends a “heartbeat” signal to the Router every 4 hours.
This Icon indicates that contact has been lost between them.
Shows that a Device is acve.
Click on this Icon to toggle the Device to be acve or non-acve
Indicates whether the Sensor is also sending an Alert Signal to the oponal
Nexus Indoor Siren (sending a signal as shown). Press the Sensor’s icon to go to
DEVICE HISTORY, then press the Siren Icon on that page to toggle O
Press this icon to return to the APP’s Alert Mode Screen.
Press this icon to take you to the APP’s Floorplan Screen.
Here you can create personalized Floorplans showing the locaons of Doors, Windows and
individual Sensors (see below)
1
2
34
5
press edit press share press “Received Device”
DOOR SENSOR
PANIC BUTTON
PANIC BUTTON PANIC BUTTON
DOOR SENSOR
TEMP. SENSOR
PANIC KNOB
Advanced Informaon for the Floor plan Page
Swipe the screen to the Le to reach a new oorplan
Press to add an addional oorplan.
Press to show the list of all your Devices. Then press on an individual device
from that list to add it to that Floorplan. Press to add an addional oorplan.
Drag a Device Icon here to delete it from that oorplan.
Press to turn Devices on this page On/O .
Press to edit the oorplan on the screen. This will then take you to the screen
below le.
Whilst in Eding Mode:
Use your nger on the screen up/down/
sideways to create a drawing.
Press to delete this Floorplan completely
Press to delete your last acon
Press to add Door/Window Symbols, drag to Floorplan locaon,
press screen to return
Press to remove all from this Floorplan
(Boom Right) Drag a Socket Icon here to delete it from that
Floorplan
Press to Save the Drawing
IMPORTANT
1. Do not place any other magnets or magnezed materials close to a Sensor as this could cause a false trigger.
2. Make sure your WIFI router and its signal strength cover all the Sensors locaons. Please note that a WIFI signal may not penetrate
through concrete walls or solid doors and that, if it does, it is usually SEVERELY reduced. You may therefore need to add one or more WIFI
Repeaters to increase signal coverage. If you do this, then ensure that individual devices are paired to the closest Repeater or Router.
Since all Router/Repeater SSID’s are dierent, you must ensure that the Sensor is paired to the correct SSID (see seng up your WIFI
Device above).
3. Aer installing a Sensor, please test it at least a couple of mes to check the performance.
Trouble Shoong
• CANNOT PAIR THE SENSOR SUCCESSFULLY
1. Check whether the Sensor has enough baery power. Always use new, good quality, Alkaline baeries.
2. If there are too many WIFI connecons around your Sensor, turn them o to avoid any disturbance and pair again.
3. Check that the router is working properly and that it operates on 2.4GHz
4. Check that the SSID and password are correct.
• DOESN’T WORK PROPERLY or LOSS OF SIGNAL ICON APPEARS
1. Check whether the Sensor is within coverage of your WIFI router/repeater. Move the Sensor or Router to a dierent locaon.
2. Check that the router is working properly
3. Check the power level of the tag. If it shows a baery low icon in the APP, please replace the baeries.
4. Check that the magnet and reed switch are aligned correctly with the arrows directly opposite each other.
5. Check that the distance you have mounted the magnet away from the built-in reed switch is no more than 5mm.
Safety
FIRE, BATTERY AND ELECTRIC SHOCK HAZARDS
1. Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects into the
Sensor. Such acons could result in an electric shock. Clean the Sensor only with a dry cloth.
2. Do not expose the Sensor to extremely high or low temperatures or leave them in direct sunlight for extended periods of me.
3. Do not leave the Sensor near open ames such as cookers, candles or replaces.
4. It’s dangerous if you replace baeries incorrectly or with the wrong polarity. You should only use the same or equivalent type of baery to
replace a damaged or drained one. The Baery should not be exposed to an overheang environment such as extreme sunshine or re.
Always use a good quality Alkaline baery for best results.
4
