KGuard Security Mars Home MH-4140 User manual

Mars Home NVR Combo Kit
USER MANUAL
MH-4140
Default user name: admin
Default password: 123456
NVR

ENGLISH
Mars Home NVR Combo Kit: Preface
2
NVR User’s Manual
About this Manual
The material in this document is for informaon purpose and is subject to change without prior noce. We
made every eort to ensure that this user’s manual is accurate and complete. However, no liability is assumed
for any errors and omissions that may have occurred.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instrucons, may cause harmful interference
to radio communicaons. However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or television recepon, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the product and receiver.
• Connect the product into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Declaraon of Conformity
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operaon.
Copyright
Limitaon of Liability
• This publicaon is provided “AS IS” without warranty of any kind, either expressed or implied, including
but not limited to, the implied warranes of merchantability, tness for any parcular purpose, or non-
infringement of a third party’s rights.
• This publicaon may include technical inaccuracies or typographical errors. Changes may be made to the
informaon herein, at any me, for publicaon improvements and/or of the corresponding device(s).
Disclaimer of Warranty
In no event shall the supplier be liable to any party or any person, except for replacement or reasonable
maintenance of the product, for the cases, including but not limited to the following:
• Any damage or loss, including but without limitaon, direct or indirect, special, consequenal or exemplary,
arising out of or relang to the device;
• Personal injury or any damage caused by inappropriate use or negligent operaon of the user;
• Unauthorized disassemble, repair or modicaon of the device by the user;
• Any problem, consequenal inconvenience, or loss or damage, arising out of combining the system with the
devices of a third party;
• Any claim or acon for damages, brought by any person or organizaon being a photogenic subject, due to
violaon of privacy with the result of pictures from a surveillance camera, including saved data, for some
reason, becomes public or is used for the purpose other than for surveillance.

ENGLISH
Mars NVR Home Combo Kit: Preface
NVR User’s Manual
3
Safety Informaon
Warning
This is the symbol for indicang any potenal hazard,
risk or condion requiring special aenon.
The user needs to refer to the important operang
and maintenance or servicing instrucons.
Cauon
The lighng ash with an arrow head symbol, in an
equilateral triangle, is intended to alert the user.
There is dangerous “voltage” presence near by the
product’s enclosure which may be risk of person.
Safety Precauons
• Do not touch live electrical parts.
Electric shock can be avoided. Follow the
recommended pracces listed below. Faulty
installaon, improper grounding, and incorrect
operaon and maintenance of electrical equipment
are always sources of danger.
• Do not try to install equipment outdoor, during strong
wind and rain.
• Do not install or remove equipment outdoor, when
raining.
• Do not try to install or operate any equipment, during
a thunderstorm.
• Always ground all electrical equipment and the work
plaorm.
Prevent accidental electrical shocks. Connect power
source, control cabinets, and work plaorm to an
approved electrical ground.
• Always use the correct cable size.
Sustained overloading will cause cable failure and
result in possible electrical shock or re hazard. Work
cable should be the same rang as the factory.
• Always keep cables and connectors in good condion.
Improper or worn electrical connecons can cause
short circuits and can increase the chance of an
electrical shock. Do not use worn, damaged, or bare
cables.
• Always avoid open-circuit voltage.
The added voltages increase the severity of electric
shock hazard.
• Always wear insulated gloves while you adjust
equipment.
Electric power should be turned o and insulated
gloves should be worn when making any equipment
adjustment to assure shock protecon.
• Always wear protecve clothing such as long
sleeve shirts while you are installing or removing
equipment.
• Always wear high, snug ng shoes.
• Always wear clean clothes without grease or oil.
• Protect neighboring workers from exposure to arc
radiaon.
• Always wear long trousers or jeans while you are
installing or removing equipment.
• Always wear safety helmet or hard hat and safety
shoes before work.
• Always keep the equipment in dry places.
• Always wear safety harnesses/belt while you work in
high places.
• Always wear dry clothing and avoid moisture and
water.
• Always wear Public Safety Vest, while you work at
night.
• Make sure all electrical connecons are ght, clean,
and dry.
• Make sure that you are well insulated to eliminate
electric stac charge.
• Always wear dry gloves, rubber-soled shoes, or stand
on a dry board or plaorm.
• Always follow recognized safety standards.
• Always wear correct eye, ear, and body protecon.
• Always have second person on-site, while you work in
dark, poor venlaon, or high places.
• Make sure that you are well protected against arc
ashes, mechanical injury, or other mishaps.
• Make sure that the polarity of wire is correct before
installing equipment.
• Always handle equipment with care.
• Do not block the venlaon of equipment.
• Do not put the magnec parts around the equipment.
• Do not put the objects on top of the equipment.

ENGLISH
Mars Home NVR Combo Kit: Contents
4
NVR User’s Manual
Contents
About this Manual .................................................................................................................... 2
FCC Compliance Statement....................................................................................................... 2
Copyright .................................................................................................................................. 2
Safety Informaon .................................................................................................................... 3
Quick Setup Guide.............................................................................................. 6
Step 1: Unpack Your NVR .......................................................................................................... 6
Mars Home NVR ...................................................................................................... 6
Step 2: Install the Hard Disk Drive (HDD) .................................................................................. 7
Step 3: Make the Connecons .................................................................................................. 8
Front Panel ....................................................................................................................... 8
Rear Panel ........................................................................................................................ 9
Perform the connecons as shown on the diagrams. .............................................................. 9
Step 4: Install the NVR to a Stand (Oponal) .......................................................................... 12
Step 5: Power ON the NVR...................................................................................................... 12
Step 6: Go through the Items in Startup Wizard ..................................................................... 13
Step 7: Make Sure the Camera(s) are Funconing .................................................................. 16
Step 8: Mount the Camera(s).................................................................................................. 17
Understanding the Live Viewing Screen ............................................................ 18
Pop-Up Menu on Live Viewing Screen .................................................................................... 20
Basic NVR Operaon ........................................................................................ 24
Using the Supplied USB Mouse .............................................................................................. 24
Virtual Keyboard ..................................................................................................................... 24
Locking the Screen .................................................................................................................. 24
Using the Supplied Remote Control ........................................................................................ 25
Reboong/Shung Down the NVR ........................................................................................ 26
Accessibility Features ....................................................................................... 27
How to Connect the NVR to the Network ............................................................................... 27
KView Center .......................................................................................................................... 27
KViewQR App .......................................................................................................................... 28
Using Cloud Storage ................................................................................................................ 32
Dropbox .......................................................................................................................... 32
How to Create a Dropbox Account ........................................................................ 32
How to Congure the Cloud Storage Sengs for Dropbox ................................... 33
Advanced E-mail Setup ......................................................................................... 35
Acvate Cloud ....................................................................................................... 35
Google Drive ................................................................................................................... 38
How to Create a Google Account .......................................................................... 38
How to Congure the Cloud Storage Sengs for Google Drive ............................ 38
Check the Photos/Videos on Google Drive ........................................................... 40
Operang the NVR ........................................................................................... 41
Main Menu ............................................................................................................................. 41
Display: Camera ...................................................................................................................... 42
Display: Camera Setup ............................................................................................................ 44

ENGLISH
Mars NVR Home Combo Kit: Contents
NVR User’s Manual
5
Display: Output ....................................................................................................................... 45
Display: Privacy Zone .............................................................................................................. 45
Record: REC Para ..................................................................................................................... 46
Record: Schedule .................................................................................................................... 47
Search: Record Search ............................................................................................................ 48
Playback Screen .............................................................................................................. 49
Backing Up Videos .......................................................................................................... 50
Trimming Videos ............................................................................................................. 51
Search: Event Search ............................................................................................................... 52
Search: Log Search .................................................................................................................. 52
Network: Network .................................................................................................................. 54
Network: MainStream ............................................................................................................ 56
Network: SubStream ............................................................................................................... 56
Network: Email ....................................................................................................................... 57
Network: DDNS ....................................................................................................................... 58
Network: Switch (Not Supported in Mars Home NVR) ........................................................... 61
Alarm: Moon ........................................................................................................................ 61
About Moon Detecon ................................................................................................ 61
Set Moon Detecon Area ............................................................................................. 62
Device: HDD ............................................................................................................................ 63
Device: Cloud Storage ............................................................................................................. 64
Google Drive ................................................................................................................... 64
Dropbox .......................................................................................................................... 65
Device: PTZ (Not Supported in Mars Home NVR) ................................................................... 68
System: General ...................................................................................................................... 68
System: DST ............................................................................................................................ 69
System: NTP ............................................................................................................................ 70
System: Users .......................................................................................................................... 70
System: Info ............................................................................................................................ 72
System: Channel Info .............................................................................................................. 73
Advanced: Maintain ................................................................................................................ 73
Remote Access Via Web Client.......................................................................... 77
Logging In ............................................................................................................................... 77
Interface Overview ................................................................................................................. 78
Live Viewing ............................................................................................................................ 78
Viewing or Hiding Channels ............................................................................................ 79
Recording Channels Manually ........................................................................................ 79
Taking Snapshots ............................................................................................................ 79
Using PTZ Controls (Not Supported in Mars Home NVR)........................................................ 80
About the Main Menu ............................................................................................................ 81
Local Sengs .................................................................................................................. 81
Logging O ..................................................................................................................... 81
Appendix.......................................................................................................... 82
Troubleshoong ...................................................................................................................... 82
Specicaons .......................................................................................................................... 84

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
6
NVR User’s Manual
Quick Setup Guide
Thank you for purchasing the Mars Home Series Network Video Recorder (NVR). This NVR is developed by KGuard
Security and includes the advanced H.264 video encoding and decoding technology for delivering high performance,
and ulmate reliability.
This NVR is able to monitor or record 4 channels. You can dene the recording mode for each channel independently
or apply the congured sengs for some or all of the cameras.
As to the accessibility opons, the NVR allows you to see live view from the cameras via smart phone/tablet or PC. For
an easy access and backup purposes, you can congure the NVR to send photos or videos from the device directly to
the cloud storage (Dropbox or Google Drive). You can also congure the NVR to send Push Nocaons directly to your
smart phone/tablet if an alarm situaon occurs.
Step 1: Unpack Your NVR
Please take a moment to check if all the necessary items are included in the package. If anything is missing or
damaged, please contact your retailer immediately.
Mars Home NVR
• NVR • Stand • IP camera • Mouse
PWR
HDD
K
GUARD
UECURITY
• 15V/4A power adapter • Power cord • HDMI cable • Ethernet cable
• PoC cable • Remote control • Baery* • 2.5”/ 3.5” HDD screws
123 456 789
ALL
0
MENU
AUDIO/
SEARCH
MUTE
SEL
• Camera screw kit
NOTE: * Not available in all countries.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
7
Step 2: Install the Hard Disk Drive (HDD)
Step 2: Install the Hard Disk Drive (HDD)
The reason you need to install an HDD on the NVR is to be able to save video footages from the security camera(s).
This NVR supports one 3.5” or 2.5” SATA HDD up to 4TB. The installaon procedure of 3.5” and 2.5” is slightly dierent.
CAUTION: DO NOT install or remove the hard disk drive while the device power is turned ON.
To install the HDD, follow the instrucons below.
K
GUARD
UECURITY
1. Remove the cover
L o o s e n t h e s c r e w s a s s h o w n .
3. Connect the HDD
Install the HDD module to the NVR
and slide to connect to the SATA
connector on mainboard.
Carefully remove the cover.
2. Aach the HDD brackets
Remove the screws from the
HDD brackets. Then remove the
brackets (HDD brackets are put
separately in package in some
countries).
Aach the HDD brackets to the HDD using
the supplied 2.5”/3.5” HDD screws.
2.5” HDD
3.5” HDD
2.5” HDD
4. Secure the HDD
-2.5” HDD: Snap the HDD module
into the hooks on the NVR case.
-3.5” HDD: Secure the HDD module
to the NVR with the screws.
3.5” HDD
Connued...

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
8
NVR User’s Manual
5. Replace the cover
Aach the cover and secure with the screws.
K
GUARD
UECURITY
Connued...
Step 3: Make the Connecons
In order to make the connecons, you need to know the connecon ports and the meaning of the control LEDs. Please
take a moment to review the front and rear panel.
Front Panel
PWR HDD
1 2 3 4
1) Power Indicator: Lights red to indicate the power is turned on.
2) HDD Indicator: Flashing green when the HDD is being accessed (read/write operaon).
3) USB 2.0 Port: Connects to a USB mouse, ash disk, and other external storage drive.
4) IR Sensor: Receives the infrared signal from the remote control.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
9
Rear Panel
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
1 2 3 4 5 6
1) VGA output: Connects to a VGA monitor.
2) HDMI output: Connects to a monitor/TV via HDMI.
3) USB port: Connects to a USB mouse, ash disk, and other external storage drive.
4) WAN Port: Connects to a router via RJ-45.
5) LAN1 ~ LAN4 Port: Main video input from the IP cameras.
6) Power: Connects to the power adapter.
Perform the connecons as shown on the diagrams.
1. Connect the monitor/TV to the NVR via HDMI (recommended), or VGA connector.
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
HDMI
VGA
Connect the video output
of the NVR to the monitor
via VGA connector.
Connect the video output
of the NVR to the monitor/
TV via HDMI output
(recommended).

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
10
NVR User’s Manual
2. Assemble the IP Camera(s)
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
(Oponal)* Power adapter is not
required as the NVR will provide
power through the Ethernet cables
(PoC cables) to the IP Camera.
Microphone
(ICB-100 only)
Weatherproof
connector
NOTE:
• If the IP camera is installed more than 60m away from the NVR, you need to use an addional power adapter
(12V/1A).
Ethernet Cables (PoC Cables)

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
11
3. Connect the NVR to the Internet.
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
WAN LAN LAN LAN LAN
Internet
WAN
The network connecon is necessary for
accessing the NVR remotely via smart phone/
tablet/PC or for saving images/videos to the
cloud storage (Dropbox or Google Drive).
Ethernet cable
4. Connect a USB mouse to the USB port on the NVR.
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
You need the USB mouse to
go through the inial setup
menus once the NVR is
powered on.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
12
NVR User’s Manual
Step 4: Install the NVR to a Stand (Oponal)
The NVR is equipped with a stand for the device’s vercal installaon. To install the NVR to the stand, please refer to
the following illustraon.
K
GUARD
UECURITY
PWR
HDD
K
GUARD
UECURITY
Step 5: Power ON the NVR
Follow the instrucons from “A” to “C” on the illustraon to power on the NVR.
15V
VGA HDMI WAN LAN1 LAN2 LAN3 LAN4
19V
C) Plug in the power
adapter to the wall outlet.
A) Connect the power
adapter to the Power
input on the rear of
the NVR.
B) Connect the power cord
to the power adapter.
Aer the NVR is powered on, the Startup Wizard appears on your monitor/TV screen (please see the next step). If it
is the rst me you power ON the NVR, we recommend to go through the wizard and ll in the various setup opons
available.
NOTE: If you decide to skip the Startup Wizard, you can sll access all the setup opons later via the NVR’s OSD menu.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
13
Step 6: Go through the Items in Startup Wizard
For going through the items on Startup Wizard, the most convenient way is to use the supplied USB mouse. See the
USB mouse operaons in “Using the Supplied USB Mouse” on page 24.
The wizard includes setup screens which allow you to choose how you want the NVR to operate. All items on the
wizard are also accessible via the NVR’s Main Menu (see “Main Menu” on page 41).
Startup Wizard
If you do not want to go through the Startup Wizard but access the Live Viewing screen immediately (step 7), you can
click Cancel. A conrmaon message appears on the screen, click OK.
If you want to disable the Startup Wizard aer reboot, click OK.
NOTE: All the items on Startup Wizard can be accessed also through the NVR’s Main Menu.
Click Next Step to move to the next screen.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
14
NVR User’s Manual
HDD Wizard
If you start up the NVR for the rst me, you need to format the HDD. Only then the NVR can record the footages on it.
To format the HDD, check the Select checkbox and click Format HDD. A warning message opens where you are asked
to conrm your selecon. Click OK.
Wait for the Format Completed ! nocaon message to appear on the screen. Click OK.
NOTE: Next me you startup the NVR, the recording from the cameras is performed automacally, or based on a
dened schedule, and you do not need to reformat the HDD again, unless there is a problem with the hard disk.
Overwrite: Use this opon to overwrite the old recordings on the HDD when the HDD is full. For example, if you
choose the opon 7 days then only the last 7 days recordings are kept on the HDD. To prevent overwring any old
recordings, select Disable.
Click Next Step to move to the next window.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
15
General Seng
It is very important that the me and date are set correctly. In case of a robbery, for example, the video footage can
be used as an evidence in the court, and if the date and me do not match, the footage is not regarded as a legimate
evidence.
Date and Time: The current date and me are displayed on the screen. To change the date and/or me, you need to
click on the corresponding eld and do the modicaons via the on-screen keyboard.
Date Format: Choose how you would like the date to appear on the screen. We recommend to use the standard
formats in your locaon.
Time Format: Choose how you would like the me to appear on the screen. The available opons are 24-hour format
or 12-hour format (AM/PM).
Language: Choose the preferred language you wish the menu items to appear on your NVR.
Flicker: Choose 50 Hz or 60 Hz, depending on your geographical locaon.
Menu Time Outs: Choose the preferred menu me out. If you want to disable this feature, choose OFF.
Click Next Step to move to the next window.
Network
Network sengs should be congured if you want to connect to the NVR remotely for live viewing or for example, if
you want the NVR to synchronize the date and me automacally.
PPPoE / DHCP / Stac: Select the network type you are using. The most common types are DHCP or Stac. Most
probably your network type is DHCP, unless the network is manually addressed (usually called- Stac).
NOTE: If your network type is Stac, ask your ISP for assistance on determining the IP address, Subnet mask, Gateway,
and DNS 1/2 server. If your network type is DHCP, your NVR will obtain the connecon parameters, like IP address,
Subnet Mask, Gateway and DNS 1/(2) automacally.
Client Port and HTTP Port: For me being, keep the default port values. Client and HTTP ports are important for
accessing the NVR remotely from a PC via HTTP Interface or smart phone/tablet.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
16
NVR User’s Manual
Click Save to save the sengs. A nocaon message appears on the screen, click OK.
Step 7: Make Sure the Camera(s) are Funconing
It may take up to 1 minute for the Cameras to start transming video to the NVR. When you are able to see images on
the Live Viewing screen, it means the camera(s) are funconing.
For more informaon, please see “Understanding the Live Viewing Screen” on page 18.

ENGLISH
Mars Home NVR Combo Kit: Quick Setup Guide
NVR User’s Manual
17
Step 8: Mount the Camera(s)
If you wish to mount the camera(s), please follow the instrucons below:
Position Gasket
2. Drill the holes and aach the camera.
Use a posion gasket to idenfy the correct posion of Insert the plasc washers into the holes. Then place
the screw holes. Then drill three (3) small holes on the the three (3) supplied screws into the three holes at
mounng locaon. the end of the camera Mount Bracket, and secure
them into the holes on the wall, using a screwdriver.
1. Locate your ideal camera posion on the selected surface, for example on the wall.
CAUTION: Avoid installing the camera near the indoor lights, for example under uorescent light, and do NOT point the
camera to the light directly.
3. Adjust the camera.
Loosen the adjustment screw of the camera, using the When the adjustment is done and the best
star wrench. Adjust the camera posion to suit the posion is found, ghten the adjustment screw to
monitoring area. x the posion.
90°

ENGLISH
Mars Home NVR Combo Kit: Understanding the Live Viewing Screen
18
NVR User’s Manual
Understanding the Live Viewing Screen
First screen you see aer going through or skipping the Startup Wizard, is the Live Viewing screen. It is considered the
main screen. On this screen you see the live views from all connected cameras.
• 4 Split Screen
Live Viewing Screen (4 Cameras Connected)
Those channels that do not have any cameras connected, are in the status “No Camera”.
Live Viewing Screen (No Camera)

ENGLISH
Mars Home NVR Combo Kit: Understanding the Live Viewing Screen
NVR User’s Manual
19
• Full Screen Mode (one channel in full screen)
You need to double click on a channel live view, to see the channel in full screen. If you want to exit the full screen
mode, double-click, again.
Live Viewing Screen (Full Screen Mode)
The Live Viewing Screen Icons
On a Live Viewing Screen, you can see the channel name, current date and the indicator. These indicators inform you if
the video recording is in process, is the moon detected, has the (internal) HDD failed, or is there a connecon to the
camera(s).
Channel name
Device type
Current date
/ me
Indicator
Page scroll

ENGLISH
Mars Home NVR Combo Kit: Understanding the Live Viewing Screen
20
NVR User’s Manual
The meaning of the indicators is as follows:
Icon Descripon
If you see this icon on a live view, it means a moon has been detected on that channel. If you want
to enable this funcon, see “Alarm: Moon” on page 61.
If you see this icon on a live view, it means the NVR cannot detect a HDD or the HDD is not
formaed. Please make sure you have installed a HDD into the NVR, see
“Step 2: Install the Hard Disk Drive (HDD)” on page 7 or see “Device: HDD” on page 63.
If you see this icon on a live view, it means the video recording is in progress. By default the video
recording is enabled for all channels. if you want to change this opon, you can disable the recording
of a channel, see “Record: REC Para” on page 46.
• R: Indicates normal recording.
• M: Indicates moon/alarm triggered recording. If you want to enable this funcon, see “Alarm:
Moon” on page 61.
No Camera Camera is not connected to the NVR.
When viewing each channel in full screen, use these icons to scroll the Live Viewing page to the le
or to the right.
Pop-Up Menu on Live Viewing Screen
Via Pop-up menu you can access the Main Menu, for making modicaons to the NVR’s conguraon and other
common features. To bring up the Pop-up Menu, click on the right mouse buon on Live Viewing screen or press the
MENU buon on the remote control.
1 3 46 7 8 9
25
No. Buon Descripon
1
Main Menu This is the Main Menu where you can congure all the sengs of the NVR.
