Kia Sorento Features & Functions Guide
© 2006 Kia Motors America,Inc. All rights reserved.
PROTEcT YOuR WaRRaNTY BY PERfORmiNg ThiS REquiREd maiNTENaNcE
A Change: Engine oil, engine oil lter
Inspect*: Transfer case uid (4WD), fuel tank, cap, lines and hoses, disc brakes and pads,
power steering uid, steering operation, linkage and hoses
B Inspect*: Air cleaner element
C Inspect*: Front differential uid**, rear differential uid, cooling system
D Inspect*: Automatic transmission uid, battery condition, brake lines, hoses and
connections, parking brake, brake uid, tire tread, driveshaft and boots
Lube: Locks and hinges
E Replace: Front differential uid**, rear differential uid, cooling system
F Inspect*: Fuel tank air lter
G Replace: Fuel tank air lter, air cleaner element
Inspect*: Drive belts, crankcase ventilation hoses, front suspension ball joints,
chassis/body nuts and bolts
H Replace: Fuel lter
Inspect*: Valve clearance
I Replace: Spark plugs
*and, if necessary, adjust, clean, replace or correct.
**If equipped.
Rotate tires every 7,500 miles or sooner if needed.
Check the tire pressure monthly.
Replace climate control air lter every 10,000 miles. **
Replace engine coolant every 60,000 miles, then replace every 30,000 miles thereafter.
Warranty may be voided if maintenance schedule is not followed. See your local Kia retailer for factory
trained technicians and genuine Kia parts.
See your Owner’s Manual for more details and complete maintenance information, including
severe maintenance schedule.
Call 1-800-333-4KIA (4542) for Roadside Assistance.
7,500 miles
A
BC
15,000 miles
A
BCD F
22,500 miles
A
B E
30,000 miles
A
CDG
37,500 miles
A
BC
45,000 miles
A
B D E F
52,500 miles
A
BC
60,000 miles
A
CDGH
67,500 miles
A
B E
75,000 miles
A
BC D F
82,500 miles
A
BC
90,000 miles
A
D E G
97,500 miles
A
BC
100,000 miles I
105,000 miles
A
BC D F
Driver’s Controls Instrument Cluster Steering Wheel/
Panel/Stalk Controls
Center Panel
Controls Roof Panel Controls Seating Safety
Please take a moment to complete and submit this evaluation of the Kia Sorento Features & Functions Guide and your Delivery experience. Your feedback is an important contribution to the continuous improvement of our resources so they better meet your future consumer needs. No postage required.
Strongly
Disagree Disagree Neutral Agree Strongly
Agree
This guide was well-organized and easy to use. 1 2 3 4 5 This guide clearly explained the operation of the features and controls. 12345 This guide covered features and controls that are important to me. 12345
I. Features & Functions Guide A. Please answer the following questions from 1-5, 1 = Strongly Disagree, and 5 = Strongly Agree.
II. Your Delivery Experience
B. Please answer YES or NO to the following questions, by circling YES or NO.
YES NO
Do you plan on using this guide as a quick reference tool? YES NO Did your Sales Consultant utilize this guide during your Delivery Product Presentation? YES NO Did your Sales Consultant have extensive knowledge of the topics covered on this guide? YES NO
YES NO
1. Did your Sales Consultant explain the Kia Delivery
First Promise to you? YES NO
2. Did your Sales Consultant provide you with Pre-
Delivery Inspection and Walkaround Checklists? YES NO
3. Did you receive a thorough Delivery Product
Presentation from your Sales Consultant? YES NO
If yes, how long was your Delivery Product Presentation? If yes, was the Delivery Product Presentation: Just the right amount of time
Too Long Not Long Enough
THANK YOU!
WE APPRECIATE YOUR RESPONSES!
SORENTO FEATURES & FUNCTIONS GUIDE SURVEY
Dealership Name: State: Sales Consultant’s Name: Vehicle Model Year: Date:
(Please print) (Please print) (Please print) (Please print)(Please print)

Congratulations On Your New Kia!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable,
safe and dependable driving. Kia is committed to quality, innovation, safety and – above all – your satisfaction.
Using This Guide
The information contained in this guide will help you become familiar with the operation and features of
your new Kia vehicle. The ipbook format facilitates information access, while the detailed illustrations
ensure the instructions are easy to follow.
This Features & Functions Guide provides an overview of vehicle operation and equipment. It is not
meant as a substitute for your Owner’s Manual. Your Owner’s Manual contains specic information
about the operation and maintenance of your Kia vehicle, including safety information, cautions and
warnings that you need to know. In the interests of your safety and that of your family, and to help
you avoid risks that may result in death or serious injury, Kia reminds you to carefully read your
Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change
vehicle specications without notice in advance or after the fact, and assumes no liability in
connection with such changes.
SORENTO
Driver’s ControlsInstrument Cluster
Steering Wheel/
Panel/Stalk Controls
Center Panel
Controls
Roof Panel ControlsSeatingSafety
sa fe t y
PASSENGER
AIR BAG OFF
Passenger Air Bag Off
If there is no passenger or the adult passenger is small or out of
position, the front PASSENGER AIR BAG OFF indicator may turn ON.
When this indicator is ON, the front passenger’s air bag will not operate.
Please refer to your Owner’s Manual and the separate brochure
entitled “Your Safety is Important to Kia” for more detailed
information regarding your vehicle’s air bags.
WARNING: Always properly restrain children in the rear seat of
your vehicle. Seat covers must NOT be used because they can
affect how the system operates.
Child Safety Locks
Located on the rear edge of the door, push the child safety lock to
the “lock” position to disable the inner door handles from opening
the rear doors. WARNING: To prevent a child from opening rear
doors from the inside, rear door safety locks should be activated
whenever children are in the vehicle.
Kia D eli v ery firs t –t he Pr ior i t y th at D eli v ers M o re
Always check the Owner’s Manual for complete operating information and safety warnings.
* If equipped.
25
Driver’s Controls Instrument Cluster Roof Panel Controls Driver’s Controls Instrument Cluster Steering Wheel/
Panel/Stalk Controls
Center Panel
Controls Roof Panel Controls Seating Safety
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
BUSINESS REPLY MAIL
FIRST-CLASS MAIL PERMIT NO 71-000 ROCHESTER HILLS MI POSTAGE WILL BE PAID BY ADDRESSEE
KIA UNIVERSITY 2044 AUSTIN ROCHESTER HILLS, MI 48309-9871

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 1
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
KIA SORENTO FEATURES & FUNCTIONS GUIDE
CONTENTS:
Driver’s Controls 2
Exterior
• Double-Turn Unlocks All 02
• Key Fob/Remote Keyless Entry* 02
• Fuel Cap/Check Engine Light 02
Interior
• Power Windows 03
• Central Door Lock Button 03
• Power Outside Mirrors 03
Instrument Cluster 4
• Warning Lights 04
• Tire Pressure Monitoring System
(TPMS)
05
Steering Wheel/Panel/
Stalk Controls
6
• Instrument Panel Dimmer 06
• Electronic Stability Control (ESC) 06
• 4WD Transfer Mode Shift Knob* 07
• Headlights Control & Turn Signals 08
• Windshield Wiper &
Washer Controls
09
• Steering Wheel Audio Controls* 10
• Cruise Control* 11
Center Panel Controls
12
• Audio Systems* 12
• Digital Clock 14
• Automatic Gear Shift 14
• Climate Controls* 15
Roof Panel Controls
18
• Map Light 18
• Center Dome Light 18
• Rear Dome Light 18
• Multi-Meter* 19
• Sunroof* 19
• Auto-Dimming Rearview
Mirror with HomeLink®*
20
Seating
21
• 8-Way Power Adjustable
Driver’s Seat*
21
• Driver’s Seat Lumbar Support 21
• 8-Way Manual Adjustable
Driver’s Seat*
22
• Manual Adjustable
Passenger’s Seat*
23
• Front Active Headrests 23
• 60/40-Split Folding Rear Seats 24
Safety
25
• Passenger Air Bag Off 25
• Child Safety Locks 25
Maintenance

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
2
CLICK!
CLICK!
CLICK!
Double-Turn Unlocks All
Unlock all doors and rear hatch by turning the key toward the rear of the
vehicle twice within 4 seconds. Turn toward the front of the vehicle once
to relock all doors.
Key Fob/Remote Keyless Entry*
Lock: Press the lock button
A
to lock all doors.
Unlock: Press the unlock button
B
once to unlock the driver’s door,
twice within 3 seconds to unlock all doors.
NOTE: If doors are not opened, they will automatically relock after 30 seconds.
Rear Hatch Open: Press and hold the rear hatch window unlock button
C
for more than 1 second.
Panic: Press the panic button
D
for longer than 1 second.
Fuel Cap/Check Engine Light
Tighten cap at least 3 clicks or more, otherwise the ‘Check Engine’
light in the instrument cluster may illuminate, requiring you to securely
tighten the cap.
DRIVER’S CONTROLS - EXTERIOR
BACKSIDE
A
B
CD

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 3
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
AUTO
L
R
Power Windows
Auto Down: Press the power window switch
E
to the second detent
position and release to completely lower the window. Lift momentarily
to stop the window.
Lockout Switch
F
:Located on the driver’s door panel, p ress to disable
passenger’s power windows.
Central Door Lock Button
L
ocated on driver and passenger door panels, press the front portion of
this button to lock all doors, press the rear portion to unlock all doors.
Power Outside Mirrors
Move the mirror selection switch
G
to the L or R position for the left or
right mirror and use the mirror adjustment control
H
to select the desired
position.
DRIVER’S CONTROLS - INTERIOR
E
H
F
G

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
4
– Front Fog Lights*: Indicates the front fog lights are on.
– High Beam Indicator: High beam lights are “ON.”
– Rear Window Defroster Indicator: Rear hatch window
defroster is on. Defroster automatically turns off after
20 minutes.
– Air Bag Warning: Air bag system is malfunctioning.
– Door Ajar: One of the doors is not fully closed.
– Rear Hatch Open: The rear hatch is not closed
securely.
– Check Engine: May indicate a problem with the
emission control system.
– Oil Pressure Warning: Indicates low oil pressure.
– Safety Belt Warning: Driver’s safety belt is not fastened.
– Parking Brake/Fluid Warning: Brake fluid level is low
or parking brake is engaged.
80
10 0
12 0
1
40
60
40
20
0
20
40
60
80
100
120
140
160
180
200
220
MPH
H
C
F
E
x1000 rpm
km/h
8
7
6
5
4
3
2
1
0
80
10
0
12
0
1
40
60
4
0
2
0
0
2
0
40
6
0
80
1
0
0
12
0
1
40
1
6
0
1
8
0
20
0
22
0
MP
H
H
C
F
E
x1000 r
p
m
km
/h
8
7
6
5
4
3
2
1
0
– Charging System Warning:
The electrical charging system is
malfunctioning.
– CRUISE*: Indicates the cruise control
is currently enabled.
– SET: Indicates the cruise control
function is “ON.”
– Low Washer Fluid: The washer fluid reservoir is nearly
empty.
– 4WD LOW: Transfer shift knob is set to the 4WD low
position.
– 4WD Warning System: Transfer shift knob is set to
4WD high position.
– ESC (Electronic Stability Control): System is enabled
at engine start-up and illuminates for 3 seconds.
– ESC OFF: Illuminates if ESC button is pushed to turn
system “OFF”.
– ABS Warning: Indicates a potential problem with the
Anti-lock Brake System. Brake lining may occasionally
squeak, that is normal.
– Low Fuel: There is approximately 2.4~2.6 gallons or
less of fuel remaining.
ESC
ESC
OFF
SET
CRUISE
Warning Lights: The warning lights and indicators alert you to situations that may need attention.
Refer to your Owner’s Manual for more information on the function of all the warning lights.
INSTRUMENT CLUSTER

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 5
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
ATachometer:
The tachometer indicates number of engine revolutions per minute.
BOdometer:
The odometer indicates the total distance the vehicle has been driven.
CTripmeter:
Located in the instrument cluster, press TRIP
button to select tripmeter A or B to display distance
traveled. Press TRIP button for more than 1 second
to reset the tripmeter currently displayed to “0”.
DTurn Signal Indicators:
The
indicator will illuminate when
the turn signal control is engaged.
ESpeedometer:
Indicates speed of vehicle.
F
Shift Pattern Indicator: Indicates shift
lever selection.
GEngine Temperature Gauge:
Shows the temperature of the engine coolant. If the needle nears the “H” position on the gauge, it
indicates an overheating engine. Do not drive your vehicle in this condition.
HFuel Gauge:
Displays approximate amount of fuel remaining in the vehicle’s fuel tank.
INSTRUMENT CLUSTER
Tire Pressure Monitoring System (TPMS)
TPMS detects loss of tire pressure that reaches specific limits. The system will turn
on a warning lamp to alert the driver of a tire(s) with a low pressure condition. Low
Tire Pressure Position Indicator alerts the driver to the position of the tire(s) that
are significantly under-inflated. If the letters
TPMS appear and remain illuminated, this
indicates the Tire Pressure Monitoring System is not functioning properly. Consult
your dealer for service. For proper maintenance, safety, and maximum fuel economy,
you must always maintain recommended tire inflation pressures and stay within the
load limits and weight distribution recommended for your vehicle.
80
10 0
12 0
1
40
60
40
20
0
20
40
60
80
100
120
140
160
180
200
220
MPH
H
C
F
E
x1000 rpm
km/h
8
7
6
5
4
3
2
1
0
F
EA
B
D
G
H
0
C
D
TPMS

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
6
STEERING WHEEL / PANEL / STALK CONTROLS
Instrument Panel Dimmer
The Instrument Panel Dimmer Ais located to the left of the steering
column. When the parking lights or headlights are on, rotate the
control knob to adjust the instrument panel display brightness to the
desired level.
NOTE: Detent on dimmer will turn on Map and Dome lights with lights
ON only.
Electronic Stability Control (ESC)
The Electronic Stability Control (ESC) monitors information from
various vehicle sensors, then compares the driver’s commands with
the behavior of the vehicle. If an unstable condition occurs, ESC
intervenes within fractions of a second via the engine computer and
brake system. To turn the ESC OFF, press ESC button. To turn ESC
ON, press again. System defaults to “ON” position at start.
A

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 7
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
STEERING WHEEL / PANEL / STALK CONTROLS
AUTO
LOW
4WD Transfer Shift Knob*
Full-time 4WD*:
AUTO: Use for normal on-road driving.
LOW: Use in off-road driving or inclement weather.
Part-time 4WD*:
4x2 HI (Rear-wheel Drive): Use when driving on normal roads
and highways.
4x4 HI (High-range 4-Wheel-Drive): Use when driving off-road,
in snowy or wet conditions at normal speed.
4X4 LO (Low-range 4-Wheel-Drive): Use for ascending or
descending hills, off-road driving, and low-speed towing.

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
8
STEERING WHEEL / PANEL / STALK CONTROLS
Headlights Control & Turn Signals
High Beams: Push light control away from you. Pull back for low beams.
Light Control: Turn control stalk knob to the desired position:
OFF –Exterior lights off
–Parking lights on
–Headlights on
AUTO* –Headlight auto function
HINT: Auto light function may cause headlights to activate in low
light conditions.
Front Fog Lights*: With the headlights on, rotate the control ring
Bto
the “ON” position for improved visibility in inclement weather. To turn
the fog lights off, turn the
Control Ring
Bto “OFF” position.
Turn Signals: Move stalk control up to signal a right turn, or down to
signal a left turn.
OFF
ON
OFF
AUTO
OFF
ON
OFF
AUTO
ROTATE
PUSH
OFF
ON
OFF
AUTO
PULL
ROTATE
B

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 9
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
STEERING WHEEL / PANEL / STALK CONTROLS
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
Windshield Wiper & Washer Controls
MIST: Push the lever up and release for a single wipe, or hold for
continuous operation.
OFF: Wiper is not in operation.
INT: Wiper operates intermittently. To vary the speed, rotate the
control ring
C.
LO: Normal wiper speed.
HI: Fast wiper speed.
Windshield Washer:
Pull control stalk toward you, hold for continuous spray and wipe.
Rear Wiper/Washer
Rotate the switch
D
to the desired position:
Top :Sprays washer fluid with 1-2 cycles.
OFF: Wiper is not in operation.
INT: Wiper operates intermittently at the same wiping intervals.
ON: Continuous wiper speed.
Bottom :Sprays washer fluid and wipes.
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
ROTATE
MIST
OFF
INT
LO
HI
MOVE UP
MOVE DOWN
PULL
C
D

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
10
STEERING WHEEL / PANEL / STALK CONTROLS
Steering Wheel Audio Controls*
MODE: Press to toggle the following modes: FM1/FM2/AM/CD/CDC*.
SEEK/PRESET (
▲ /▼
): Works as follows in each mode when pressed
for more than 1 second:
Radio Mode: AUTO SEEK select button.
CDP (CD Player) Mode: FF/REW button.
CDC (CD Changer) Mode: DISC UP/DOWN button.
Works as follows in each mode when pressed for less than 1 second:
Radio Mode: PRESET STATION select button.
CDP (CD Player) Mode: TRACK UP/DOWN button.
CDC (CD Changer) Mode: TRACK UP/DOWN button.
VOLUME
E
: Press the VOLUME ▲to increase or VOLUME ▼to
decrease volume.
MODE
MODE
E

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 11
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
RES
ACCEL
CANCEL
OFF
ON
COAST
SET
RES
ACCEL
CANCEL
OFF
ON
COAST
SET
STEERING WHEEL / PANEL / STALK CONTROLS
Cruise Control*
To Set Cruise Control, Do the Following:
1. Push the CRUISE ON/OFF button
F
to turn the system on.
2. Accelerate to the desired speed, must be more than 24 mph (40 km/h).
3. Depress the COAST/SET and release it at the speed you want.
The “SET” light in the instrument cluster will illuminate. Release the
accelerator at the same time. The desired speed will automatically
be maintained.
To Cancel Cruise Control, Do One of the Following:
1. Press the brake pedal.
2. Push the CANCEL switch.
3. Toggle CRUISE ON/OFF button.
To Increase Cruising Speed, Do One of the Following:
1. Push the RES/ACCEL switch and release it. This will increase your
current cruising speed by 1 mph (1.6 km/h).
2. Hold the RES/ACCEL switch, your speed will increase gradually. Let
go of the button when you reach your desired speed.
To Decrease Cruising Speed, Do One of the Following:
1. Push the COAST/SET switch and release it. This will decrease your
current cruising speed by 1 mph (1.6 km/h).
2. Hold the COAST/SET switch, your speed will decrease gradually.
Let go of the button when you reach your desired speed.
NOTE: The cruise control ON/OFF function will reset with ignition key cycle.
F

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
12
CENTER PANEL CONTROLS
AM
Delco Electronics
2
FF
1
REW
PUSH
VOLUME
POWER
PUSH
CONTROL
TUNEFILE
AUDIO
ENTER
6
INFO
3
RPT
4
RDM
5
MARK
FM1 FM2 CD SCAN
EQ
DIR
SEEK
TRACK
14
43
1
2
5
6
7
15 16 17
12
11
10
13
18
8
10
10
9
AM/FM/CD/MP3 Audio System
1
Press / for the next highest/lowest channel in radio
mode or for the next/previous track or file in CD/MP3 mode.
2
Press to eject a CD, or hold to forcibly eject a jammed CD.
3
Press to switch to radio and select AM band.
4
Press to switch to radio and select FM1 band.
5
Press to switch to radio and select FM2 band.
6
Insert a CD to automatically begin playback.
7
Press to select CD/MP3 mode.
8
Plays 5 seconds of each station in radio mode, 10 seconds
of each track or file in CD/MP3 mode.
9
Press to select ROCK, POP, JAZZ, CLASSIC, TALK and OFF
modes for the desired tone quality.
10
Press or to search for a specific file folder directory,
then press
19
to access the directory selected.
11
Press to turn the system On or Off, rotate the knob clockwise
to increase or counterclockwise to decrease the volume.
12
Press and hold to rewind through a CD track or MP3 file.
13
Press and hold to fast-forward through a CD track or MP3 file.
14
In CD mode, press to repeat playback on the current track or
hold to repeat playback of the selected CD. For an MP3 CD,
hold to repeat playback within the selected folder.
15
In CD mode, press for randomized selection of tracks. For an
MP3 CD, press for randomized selection of tracks within the
selected folder.
16
Press and hold MARK for more than .8 seconds to add current
file to the playlist.
17
When playing an MP3 CD, press repeatedly to display track
information on LCD screen such as file name, artist name,
and song title.
18
Press and hold the corresponding preset button (1-6) until you
hear an audible beep to store a station in memory.
19
In radio mode, turn the knob clockwise to increase or
counterclockwise to decrease the frequency. Press to cycle
through the audio controls (BASS, TREBLE, etc.), then rotate
the knob to adjust accordingly. In MP3 mode, turn the knob to
find the desired file, then press the button to play the file.
NOTICE: Forcing the CD into the slot may damage the player.
19

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 13
CENTER PANEL CONTROLS
AM
Delco Electronics
2
FF
1
REW
PUSH
VOLUME
POWER
PUSH
CONTROL
TUNEFILE
AUDIO
ENTER
6
INFO
3
RPT
4
RDM
5
MARK
FM CD EQ SCAN
LOAD
DIR
SEEK
TRACK
14
4
3
1
2
5
6
7
15 16 17
12
11
10
13
18
8
10
10
9
AM/FM/6-Disc Changer/MP3 Audio System*
1
Press / for the next highest/lowest channel in radio
mode or for the next/previous track or file in CD/MP3 mode.
2
Press to eject a CD, or hold to eject all CDs from changer.
3
Press to switch to radio and select AM band.
4
Press to switch to radio and select the FM1 band or FM2 bands.
5
Press to select CD/MP3 mode.
6
Press the LOAD button, then insert a CD to automatically
begin playback.
7
Press to select ROCK, POP, JAZZ, CLASSIC, TALK and OFF
modes for the desired tone quality.
8
Plays 5 seconds of each station in radio mode, 10 seconds of
each track or file in CD/MP3 mode.
9
Press the LOAD button, display will instruct: WAIT, INSERT
CD, LOADING CD, READING CD. Repeat procedure to LOAD
multiple CDs.
10
Press or to search for a specific file folder directory,
then press
19
to access the directory selected.
11
Press to turn the system On or Off, rotate the knob clockwise to
increase or counterclockwise to decrease the volume.
12
Press and hold to rewind through a CD track or MP3 file.
13
Press and hold to fast-forward through a CD track or MP3 file.
14
In CD mode, press to repeat playback on the current track or
hold to repeat playback of the selected CD. For an MP3 CD,
hold to repeat playback within the selected folder.
15
In CD mode, press for randomized selection of tracks. For an
MP3 CD, press for randomized selection of tracks within the
selected folder.
16
Press and hold MARK for more than .8 seconds to add current
file to the playlist.
17
When playing an MP3 CD, press repeatedly to display track
information on LCD screen such as file name, artist name, and
song title.
18
Press and hold the corresponding preset button (1-6) until you
hear an audible beep to store a station in memory.
19
In radio mode, turn the knob clockwise to increase or
counterclockwise to decrease the frequency. Press to cycle
through the audio controls (BASS, TREBLE, etc.), then rotate
the knob to adjust accordingly. In MP3 mode, turn the knob to
find the desired file, then press the button to play the file.
NOTICE: Forcing the CD into the slot may damage the player.
19
Always check the Owner’s Manual for complete operating information and safety warnings. *If equipped.

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
14
CENTER PANEL CONTROLS
4:35
H
M
R
Digital Clock
With the ignition in the “ACC” or “ON” position, the clock buttons operate
as follows:
HOUR: Press “H” to advance the time displayed by one hour.
MINUTE: Press “M” to advance the time displayed by one minute,
or hold to rapidly advance.
RESET: Press “R” to clear away minutes and set to the nearest hour.
NOTE: Hold for more than 4 seconds to toggle between 12 hour
and 24 hour formats.
Automatic Gear Shift
P (Park): Press the brake pedal to move the gearshift from PARK.
R (Reverse): Reverse.
N (Neutral): Gears disengaged.
D (Drive): The transaxle will shift through the gears automatically.
NOTE: Press the brake pedal to move gear shift from N to P or R position.
Sport Mode: Move the shift lever from the D position to the right gate
to select.
Sport Mode Shifting: Move the shift lever forward (+) to upshift or
(-) to downshift.
+
-
SLIDE

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 15
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
CENTER PANEL CONTROLS
Manual Climate Control
1
Fan Speed Control Knob
2
Air Intake Control Button
3
Mode Selection Control
4
Air Conditioning Button*
5
Temperature Control Knob
5
4
1
3
2
Manual system functions to operate defrost:
1. When defrost mode is selected A/C is operational, fresh air vent is open, although A/C lamp is off.
2. Set fan speed 1 to maximum.
NOTE: In defrost mode some moisture may be visible on the windshield during cool A/C operation. To
eliminate this effect adjust Temperature Control Knob 5as desired. This condition happens more at night
and on cloudy days. Keep inside glass as clean as possible to help reduce window fogging.
3. Set temperature 5to hot.
Windshield Defogging/Defrosting
Defrost –
Turns the defroster function
ON and OFF.

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
16
CENTER PANEL CONTROLS
Automatic Dual-Zone Climate Control*
1
Automatic Operation
2
Climate Control Display
3
Dual Temperature Control Selection Button
4
Driver’s Temperature Control Knob
5
Passenger’s Temperature Control Knob
6
Air Conditioning Button
7
Windshield Defroster Button
8
Climate Control Off
9
Mode Selection Button
10
Fan Speed Control Button
11
Recirculated Air Intake Button
12
Fresh Air Intake Button
MODE
5
6
4
1 3
2
7
89
10
11
Auto Function:
Press 1 to select automatic system operation, Full
Automatic Temperature Control will control fan speed,
air intake, air flow, and air conditioning by setting desired
temperature 4
or 5 .
NOTE: During automatic operation, air conditioning system
will turn on at any time, this is done to help reduce humidity.
12

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE 17
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
CENTER PANEL CONTROLS
Automatic system functions to operate defrost:
For maximum defrosting, do the following:
1. Select Defrost mode.
2. Set the temperature to hot.
3. Set the fan speed to maximum. When defrost
is selected, the outside air and air conditioning
functions are activated automatically, to further
reduce window fogging. This is accomplished
by helping to remove moisture from the
incoming air.
NOTE: In defrost mode some moisture may
be visible on the windshield during cool A/C
operation. This condition happens more at night
and on cloudy days. Keep inside glass as clean
as possible to help reduce window fogging.
Automatic system functions to operate
defogging:
1. Select Defrost mode.
2. Select the desired temperature.
3. Set the fan speed to maximum. When defrost
is selected, the outside air and air conditioning
functions are activated automatically, to further
reduce window fogging. This is accomplished
by helping to remove moisture from the
incoming air.
NOTE: The purpose of defogging is to remove
interior moisture from the vehicle windows.

KIA DELIVERY FIRST –THE PRIORITY THAT DELIVERS MORE
18
TILT SLIDE
CENTER PANEL CONTROLS
OFF DOOR ON
Map Light
Push switch Ato turn light on, push again to turn
light off.
Center Dome Light
Press switch
B
to keep light OFF. Press switch
C
to select ON position
to keep dome light on. Press switch
D
to select DOOR position to
make the light come on when a door is opened and go off when all
doors are shut.
Rear Dome Light
Set switch to OFF position
to keep dome light off, or set to ON position
to keep dome light on. In the center position, dome light will come
on when the rear hatch or rear hatch window is opened and go off
when closed.
OFF ON
A
BCD
A
