Kia Sorento 2008 Parts list manual

features & functions
GUIDE
SORENTO

Congratulations On Your New Kia!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable,
safe and dependable driving. Kia is committed to quality, innovation, safety and – above all – your satisfaction.
Using This Guide
The information contained in this guide will help you become familiar with the operation and features of
your new Kia vehicle. The ipbook format facilitates information access, while the detailed illustrations
ensure the instructions are easy to follow.
This Features & Functions Guide provides an overview of vehicle operation and equipment. It is not
meant as a substitute for your Owner’s Manual. Your Owner’s Manual contains specic information
about the operation and maintenance of your Kia vehicle, including safety information, cautions and
warnings that you need to know. In the interests of your safety and that of your family, and to help
you avoid risks that may result in death or serious injury, Kia reminds you to carefully read your
Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While the information contained in this guide is accurate at the time of printing, Kia may change
vehicle specications without notice in advance or after the fact, and assumes no liability in
connection with such changes.
SORENTO
Driver’s ControlsInstrument Cluster
Steering Wheel/
Panel/Stalk Controls
Center Panel
Controls
Roof Panel ControlsSeatingSafety Safety
Maintenance
Services Seating Instrument
Cluster
Steering Wheel/
Panel/Stalk
Controls
Center Panel
Controls
Roof Panel
Controls
Driver’s
Controls

Ki a Deliv ery Fir st –the Pri ori t y that De liv ers Mo re 1
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
KIA SORENTO FEATURES & FUNCTIONS GUIDE
QUICK GUIDE:
Instrument Cluster 2
• Warning Lights 02
• Tire Pressure Monitoring System
(TPMS) 03
Steering Wheel/Panel/
Stalk Controls 4
• Instrument Panel Dimmer 04
• Electronic Stability Control (ESC) 04
• 4WD Transfer Mode Shift Knob* 05
• Headlights Control & Turn Signals 06
• Windshield Wiper &
Washer Controls 07
• Steering Wheel Audio Controls* 08
• Cruise Control* 09
Center Panel Controls
10
• Audio Systems* 10
• Digital Clock 12
• Automatic Gear Shift 12
• Climate Controls* 13
• Air Vent Operation 14
Seating
16
• 8-Way Power Adjustable
Driver’s Seat* 16
• Driver’s Seat Lumbar Support 16
• 8-Way Manual Adjustable
Driver’s Seat* 17
• Front Active Headrests 18
Driver’s Controls
19
Exterior
• Double-Turn Unlocks All 19
• Key Fob/Remote Keyless Entry* 19
• Fuel Cap/Check Engine Light 19
Interior
• Power Windows 20
• Central Door Lock Button 20
Roof Panel Controls
21
• Map Light 21
• Center Dome Light 21
• Rear Dome Light 21
• Multi-Meter* 22
Safety
23
• Passenger Air Bag Off 23
• Child Safety Locks 23
Service Maintenance
24
• Normal Maintenance
Schedule 24
ContEnts:
●How Does the Tire Pressure Monitoring System (TPMS) Work? Page 03
●How Do I Use My Windshield Wiper & Washer? Page 07
●How Do I Use My Cruise Control? Page 09
●How Do I Set My Climate Control? Page 13
●How Do I Prevent My Windshield from Fogging Up? Pages 13–14
●How Do I Adjust My Seats? Page 16

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
2
iNstrUMeNt ClUster
– Front Fog Lights*
– High Beam Indicator
– Rear Window Defroster Indicator
– Air Bag Warning
– Door Ajar
– Rear Hatch Open
– “Check Engine” Lamp
– Oil Pressure Warning
– Safety Belt Warning
– Parking Brake/Fluid Warning
80
100
120
140
60
40
20
0
20
40
60
80
100
120
140
160
180
200
220
MPH
H
C
F
E
x1000 rpm
km/h
8
7
6
5
4
3
2
1
0
– Charging System Warning
– CRUISE*
– SET*
– 4WD LOW*
– 4WD Warning System*
– ESC (Electronic Stability Control) Warning
– ESC OFF
– ABS Warning
– Low Fuel
ESC
ESC
OFF
SET
CRUISE
Warning Lights: The warning lights and indicators alert you to situations that may need attention.
Refer to your Owner’s Manual for more information on the function of all the warning lights.

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 3
iNstrUMeNt ClUster
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
80
100
120
1
40
60
40
20
0
20
40
60
80
100
120
140
160
180
200
220
MPH
H
C
F
E
x1000 rpm
km/h
8
7
6
5
4
3
2
1
0
80
100
120
1
40
60
40
20
0
20
40
60
80
100
120
140
160
180
200
220
MPH
H
C
F
E
x1000 rpm
km/h
8
7
6
5
4
3
2
1
0
P
R
N
D
ATachometer
BOdometer
CTripmeter
DTurn Signal Indicators
ESpeedometer
F
Shift Pattern Indicator
GEngine Temperature Gauge
HFuel Gauge
Tire Pressure Monitoring System (TPMS)
TPMS detects loss of tire pressure that reaches specic limits. The system will turn
on a warning lamp to alert the driver of a tire(s) with a low pressure condition. Low
Tire Pressure Position Indicator alerts the driver to the position of the tire(s) that
are signicantly under-inated. If the letters TPMS appear and remain illuminated, this
indicates the Tire Pressure Monitoring System is not functioning properly. Consult
your dealer for service. For proper maintenance, safety, and maximum fuel economy,
you must always maintain recommended tire ination pressures and stay within the
load limits and weight distribution recommended for your vehicle.
F
E
A
B
D
G
H
C
D
TPMS

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
4
steeriNG Wheel / stalK / PaNel CoNtrols
Instrument Panel Dimmer
The Instrument Panel Dimmer Ais located to the left of the steering
column. When the parking lights or headlights are on, rotate the
control knob to adjust the instrument panel display brightness to the
desired level.
Electronic Stability Control (ESC)
The Electronic Stability Control (ESC) monitors information from
various vehicle sensors, then compares the driver’s commands with
the behavior of the vehicle. If an unstable condition occurs, ESC
intervenes within fractions of a second via the engine computer and
brake system. To turn the ESC OFF, press ESC button. To turn ESC
ON, press again. System defaults to “ON” position at start.
A

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 5
steeriNG Wheel / stalK / PaNel CoNtrols
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
AUTO
LOW
4WD Transfer Shift Knob*
Full-time 4WD*:
AUTO: Use for normal on-road driving.
LOW: Use in off-road driving or inclement weather.
Part-time 4WD*:
4x2 HI (Rear-wheel Drive): Use when driving on normal roads
and highways.
4x4 HI (High-range 4-Wheel-Drive): Use when driving off-road,
in snowy or wet conditions at normal speed.
4X4 LO (Low-range 4-Wheel-Drive): Use for ascending or
descending hills, off-road driving, and low-speed towing.

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
6
steeriNG Wheel / stalK / PaNel CoNtrols
Headlights Control & Turn Signals
High Beams: Push light control away from you. Pull back for low beams.
Light Control: Turn control stalk knob to the desired position:
OFF –Exterior lights off
–Parking lights on
–Headlights on
AUTO* –Headlight auto function
HINT: Auto light function may cause headlights to activate in low
light conditions.
Front Fog Lights*: With the headlights on, rotate the control ring
Bto
the “ON” position for improved visibility in inclement weather. To turn
the fog lights off, turn the Control Ring
Bto “OFF” position.
Turn Signals: Move stalk control up to signal a right turn, or down to
signal a left turn.
OFF
ON
OFF
AUTO
OFF
ON
OFF
AUTO
ROTATE
PUSH
OFF
ON
OFF
AUTO
PULL
ROTATE
B

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 7
steeriNG Wheel / stalK / PaNel CoNtrols
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
Windshield Wiper & Washer Controls
MIST: Push the lever up and release for a single wipe, or hold for
continuous operation.
OFF: Wiper is not in operation.
INT: Wiper operates intermittently. To vary the speed, rotate the
control ring
C.
LO: Normal wiper speed.
HI: Fast wiper speed.
Windshield Washer:
Pull control stalk toward you, hold for continuous spray and wipe.
Rear Wiper/Washer
Rotate the switch
D
to the desired position:
Top : Sprays washer uid with 1-2 cycles.
OFF: Wiper is not in operation.
INT: Wiper operates intermittently at the same wiping intervals.
ON: Continuous wiper speed.
Bottom : Sprays washer uid and wipes.
REAR
INT
OFF
MIST
OFF
INT
ON
INT
LO
HI
PULL
ROTATE
MIST
OFF
INT
LO
HI
MOVE UP
MOVE DOWN
PULL
C
D

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
8
steeriNG Wheel / stalK / PaNel CoNtrols
Steering Wheel Audio Controls*
MODE: Press to toggle the following modes: FM1/FM2/AM/CD/CDC*.
SEEK/PRESET (
▲ /▼
): Works as follows in each mode when pressed
for more than 1 second:
Radio Mode: AUTO SEEK select button.
CDP (CD Player) Mode: FF/REW button.
CDC (CD Changer) Mode: DISC UP/DOWN button.
Works as follows in each mode when pressed for less than 1 second:
Radio Mode: PRESET STATION select button.
CDP (CD Player) Mode: TRACK UP/DOWN button.
CDC (CD Changer) Mode: TRACK UP/DOWN button.
VOLUME
E
: Press the VOLUME ▲to increase or VOLUME ▼to
decrease volume.
VOL
VOL
MODE
RES
SET
ACCEL
CANCEL
COAST
VOL
VOL
MODE
E

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 9
Always check the Owner’s Manual for complete operating information and safety warnings. *If equipped.
VOL
VOL
MODE
RES
SET
ACCEL
CANCEL
COAST
RES
ACCEL
CANCEL
OFF
ON
COAST
SET
Cruise Control*
To Set Cruise Control, Do the Following:
1. Push the CRUISE ON/OFF button
F
to turn the system on.
2. Accelerate to the desired speed, must be more than 24 mph (40 km/h).
3. Depress the COAST/SET and release it at the speed you want.
The “SET” light in the instrument cluster will illuminate. Release the
accelerator at the same time. The desired speed will automatically be
maintained.
To Cancel Cruise Control, Do One of the Following:
1. Press the brake pedal.
2. Push the CANCEL switch.
3. Toggle CRUISE ON/OFF button.
To Increase Cruising Speed, Do One of the Following:
1. Push the RES/ACCEL switch and release it. This will increase your
current cruising speed by 1 mph (1.6 km/h).
2. Hold the RES/ACCEL switch, your speed will increase gradually. Let go
of the button when you reach your desired speed.
To Decrease Cruising Speed, Do One of the Following:
1. Push the COAST/SET switch and release it. This will decrease your
current cruising speed by 1 mph (1.6 km/h).
2. Hold the COAST/SET switch, your speed will decrease gradually. Let
go of the button when you reach your desired speed.
To Resume Speed:
1. After brake application, press RES/ACCEL to reset previous speed.
NOTE: The cruise control ON/OFF function will reset with ignition key cycle.
F
steeriNG Wheel / stalK / PaNel CoNtrol s

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
10
CeNter PaNel CoNtrols
AM
Delco Electronics
2
FF
1
REW
PUSH
VOLUME
POWER
PUSH
CONTROL
TUNEFILE
AUDIO
ENTER
6
INFO
3
RPT
4
RDM
5
MARK
FM1 FM2 CD SCAN
EQ
DIR
SEEK
TRACK
14
43
1
2
5
6
7
15 16 17
12
11
10
13
18
8
10
10
9
AM/FM/CD/MP3 Audio System*
1
SEEK and buttons
2
CD EJECT button
3
AM button
4
FM1 button
5
FM2 button
6
CD insert
7
CD button.
8
SCAN button
9
EQUALIZER button
10
DIR and buttons (MP3 and WMA discs)
11
POWER ON-OFF / VOLUME CONTROL knob
12
REWIND button
13
FAST FORWARD button
14
REPEAT button
15
RANDOM button
16
MARK button
17
INFO button
18
CD SELECTOR buttons (1-6)
19
MP3 FILE SEARCH / TUNE / AUDIO CONTROL knob
19

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 11
CeNter PaNel CoNtrols
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
AM
Delco Electronics
2
FF
1
REW
PUSH
VOLUME
POWER
PUSH
CONTROL
TUNEFILE
AUDIO
ENTER
6
INFO
3
RPT
4
RDM
5
MARK
FM CD EQ SCAN
LOAD
DIR
SEEK
TRACK
14
4
3
1
2
5
6
7
15 16 17
12
11
10
13
18
8
10
10
9
AM/FM/6-Disc Changer/MP3 Audio System*
1
SEEK and / Track Select buttons
2
CD EJECT button
3
AM button
4
FM1 or FM2 select button
5
CD or MP3 mode button
6
CD insert
7
EQUALIZER button
8
RADIO STATION / CD TRACK / MP3 FILE SCAN button
9
LOAD button
10
DIR and buttons (MP3 and WMA discs)
11
POWER ON-OFF / VOLUME CONTROL knob
12
REWIND button
13
FAST FORWARD button
14
TRACK REPEAT / DISC REPEAT button
15
RANDOM CD TRACK button
16
MARK button
17
INFO button
18
STATION PRESET buttons
19
AUDIO CONTROL / FILE / TUNE knob
19

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
12
CeNter PaNel CoNtrols
4:35
H
M
R
Digital Clock
With the ignition in the “ACC” or “ON” position, the clock buttons
operate as follows:
HOUR: Press “H” to advance the time displayed by one hour.
MINUTE: Press “M” to advance the time displayed by one minute,
or hold to rapidly advance.
RESET: Press “R” to clear away minutes and set to the nearest hour.
Automatic Gear Shift
P (Park): Press the brake pedal to move the gearshift from PARK.
R (Reverse): Reverse.
N (Neutral): Gears disengaged.
D (Drive): The transaxle will shift through the gears automatically.
NOTE: Press the brake pedal to move gear shift from N to P or R position.
Sport Mode: Move the shift lever from the D position to the right gate
to select.
Sport Mode Shifting: Move the shift lever forward (+) to upshift or
(-) to downshift.
+
-
SLIDE

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 13
CeNter PaNel CoNtrols
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
Manual Climate Control
1
Fan Speed Control Knob
2
Air Intake Control Button
3Mode Selection Control
4
Air Conditioning Button*
5
Temperature Control Knob
OFF
5
4
1
3
2
Manual system functions to operate defrost:
1. When defrost mode is selected A/C is operational, fresh air vent is open, although A/C lamp is off.
2. Set fan speed 1to maximum.
NOTE: In defrost mode some moisture may be visible on the windshield during cool A/C operation. To
eliminate this effect adjust Temperature Control Knob 5as desired. This condition happens more at night
and on cloudy days. Keep inside glass as clean as possible to help reduce window fogging.
3. Set temperature 5to hot.
Windshield Defogging/Defrosting
Defrost – Turns the defroster function
ON and OFF.

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
14
CeNter PaNel CoNtrols
Automatic Dual-Zone Climate Control*
1
Automatic Operation
2
Climate Control Display
3Dual Temperature Control Selection Button
4Driver’s Temperature Control Knob
5
Passenger’s Temperature Control Knob
6Air Conditioning Button
7
Windshield Defroster Button
8
Climate Control Off
9
Mode Selection Button
10
Fan Speed Control Button
11 Recirculated Air Intake Button
12
Fresh Air Intake Button
MODE
5
6
4
1 3
2
7
89
10
11
Automatic system functions to operate defogging:
1. Select Defrost mode.
2. Select the desired temperature.
3. Set the fan speed to maximum. When defrost is selected, the outside air and air conditioning functions
are activated automatically, to further reduce window fogging. This is accomplished by helping to remove
moisture from the incoming air.
NOTE: The purpose of defogging is to remove interior moisture from the vehicle windows.
12

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 15
CeNter PaNel CoNtrols
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
Air Vent Operation
For Air Vent Operation, do the following:
1. Turn wheel 1up to open or down to close (or left or right if wheel is
situated horizontally) an individual vent.
2. Use tab 2to change the direction of air exiting the vent, moving the vent
up, down, left or right.
1
1
2
2

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
16
se atiNG
8-Way Power Adjustable Driver’s Seat*
Seat Recline Adjustment: Push top portion of switch A
forward or backward to adjust recline angle.
Adjusting the Seat Forward and Backward: Push
switch
B
forward or backward to move the seat accordingly.
Cushion Height Adjustment: Push switch
B
upward or
downward to adjust the height of the entire seat cushion.
Rear Seat Cushion (tilt) Height Adjustment: Push the
back portion of switch
B
downward to lower, or upward to
raise.
Front Seat Cushion (tilt) Height Adjustment: Push the
front portion
AB
Driver’s Seat Lumbar Support
Located on the right side of the driver’s seatback, pivot the lever
forward to increase or rearward to decrease lumbar support.

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e 17
se atiNG
Always check the Owner’s Manual for complete operating information and safety warnings.
*If equipped.
8-Way Manual Adjustable Driver’s Seat*
Adjusting the Seat Forward and Backward:
1. Pull up on the seat slide adjustment lever
C
under the seat cushion
and hold it.
2. Slide the seat until the desired position is attained.
3. Release the seat slide adjustment lever
C
and make sure the seat
is locked in place.
Front Cushion Height Adjustment:
To raise: Rotate the knob
D
clockwise.
To lower: Rotate the knob
D
counterclockwise.
Rear Cushion Height Adjustment:
To raise: Rotate the knob
E
clockwise.
To lower: Rotate the knob
E
counterclockwise.
Seat Recline Adjustment:
1. Lean forward slightly and pull up on the seatback recline lever
F.
2. Lean back on the seat until the desired position is attained.
3. Release the seatback recline lever
F
and make sure the seat is
locked in place.
WARNING: Adjusting the driver seat with the vehicle in motion could
cause loss of control and a serious accident.
CDE
F

Ki a Del ivery Firs t –t he Prio rit y th at Del iver s Mor e
18
se atiNG
Front Active Headrests
Moves forward to help prevent the driver’s and front passenger’s heads
from moving backward, thus helping to prevent neck injuries in the
event of a rear impact.
