P045 Galaxy
KICK Galaxy 55″ Telescopic
Rods Foosball Table (Black)
Assembly Instructions

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
2

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
3
PARTS LIST
H1
5/16＂x2＂BOLT
8pcs
H2
5/16＂WASHER
20pcs
H3
5/16＂LOCK NUT
12pcs
H4
5/16＂ELASTIC WASHER
8pcs
H5
5/8＂ROUND HEAD SCREW
12pcs
H6
3/8＂x2-5/8＂BOLT
8pcs
H7
3/8＂WASHER
8pcs
H8
3/8＂NUT
8pcs
H9
1/4＂x3＂BOLT
8pcs
H10
1/4＂WASHER
8pcs
H11
1＂FLAT HEAD SCREW
14pcs
H12
F8 x 40mm SCREW
8pcs
H13
5/8＂ROUND HEAD SCREW
8pcs
H14
METAL ROD
2pcs
A1
SOCCER BALL
3pcs

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
4
PARTS LIST
A2
TOOL
1pc
A3
WRENCH (13mm)
2pcs
A4
WRENCH (14mm)
1pc
P1
SIDE PANEL
2pcs
P2
END PANEL
2pcs
P3
WOODEN TENON(8x30mm)
8pcs
P4
PLAYING FIELD
1pc
P5
PLAYFIELD SUPPORT BRACE
2pcs
P6A
RIGHT LEG
2pcs
P6B
LEFT LEG
2pcs
P7
LEG PANEL
2pcs
P8
DECORATIVE STRIP
2pcs
P9
GOAL BOX
2pcs
P10
BALL CATCHER
2pcs
P11
BALL RUNNER
2pcs

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
5
P12
LEG LEVELER
4pcs
P13
BEARING A
8pcs
P14
BEARING B
8pcs
P15
HANDLE
8pcs
P16
SCORER (RED)
1pc
P17
SCORER (BLUE)
1pc
C1
1 HOME PLAYEYS ROD
1pc
C2
2 HOME PLAYEYS ROD
1pc
C3
5 HOME PLAYEYS ROD
1pc
C4
3 HOME PLAYEYS ROD
1pc
C5
1 AWAY PLAYEYS ROD
1pc
C6
2 AWAY PLAYEYS ROD
1pc
C7
5 AWAY PLAYEYS ROD
1pc
C8
3 AWAY PLAYEYS ROD
1pc

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
6
Assembly Instructions
1. INSERT THE WOODEN TENON P3 INTO THE HOLE OF THE END PANEL P2.SEE FIGURE 1.
2. INSERT THE WOODEN TENON P3 ON THE END PANEL P2 INTO THE HOLE OF THE SIDE PANEL P1.
SEE FIGURE 2.
3. ATTACH SIDE PANEL P1 TO END PANEL P2 WITH BOLT H1 AND WASHER H2.SEE FIGURE 3-4.
4. SLIDE THE PLAYING FIELD P4 INTO THE GROOVE ON THE SIDE PANEL P1 AND END PANEL P2 .
SEE FIGURE 5.
5. ATTACH SIDE PANEL P1 TO END PANEL P2 WITH BOLT H1 AND WASHER H2.SEE FIGURE 6.
1
2
P3
P3
P4
P1
P2
3
P1
4
H2
H1
H2
H1
P2
5
6
H2
H1
P1
P2
P2

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
7
Assembly Instructions
6. ATTACH PLAY FIELD SUPPORT BRACE P5 TO THE SIDE PANEL WITH METAL ROD H14,WASHER H2
AND NUT H3 .SEE FIGURE 7-9.
7. ATTACH BALL CATCHER P10 TO SIDE PANEL WITH SCREW H5.SEE FIGURE 10.
8. ATTACH GOAL BOX P9 TO END PANEL WITH SCREW H5.SEE FIGURE 11.
9. CONNECT GOAL BOX P9 AND BALL CATCHER P10 WITH BALL RUNNER P11.SEE FIGURE 12-13.
7
8
9
10
H14
H5
P10
P11
P9
H5
11
12
13
P5
H14
P5
H2
H3
H2
H3
P5
P11

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
8
Assembly Instructions
10. ATTACH RIGHT LEG P6A AND LEFT LEG P6B TO SIDE PANEL WITH BOLT H6, WASHER H7 AND NUT
H8.SEE FIGURE 14-15.
11. ATTACH LEG PANEL P7 TO LEG WITH BOLT H9 AND WASHER H10.SEE FIGURE 16.
12. ATTACH LEG LEVELER P12 TO LEG .SEE FIGURE 17.
13. ATTACH DECORATIVE STRIP P8 TO SIDE PANEL WITH SCREW H11.SEE FIGURE 18-19.
18
19
P8
14
16
15
H11
P8
P6A
P6A
P6B
H8
H7
H6
P7
P6B
H10
H9
H8
H7
H6
17
P12
H11

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
9
Assembly Instructions
14. INSERT THE PLAYERS ROD C1-C8 THROUGH BEARING A P13.SEE FIGURE 20-21.
15. INSERT THE PLAYERS ROD C1-C8 THROUGH SIDE PANEL .SEE FIGURE 22-23.
16. ATTACH BEARING A P13 AND BEARING B P14 TO SIDE PANEL .SEE FIGURE 24.
17. ATTACH PLAYERS ROD C1-C8 TO SIDE PANEL WITH WASHER H2, ELASTIC WASHER H4 AND NUT H3.
SEE FIGURE 25.
20
24
21
22
23
25
26
C1
C2
P13
C4
C3
P13
C5
C6
C7
C6
C8
C5
C4
P13
C5
C8
C7
C6
C1
C2
C3
C4
H2
H4
H3
P14
P13

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
10
Assembly Instructions
18. SLIDE THE HANDLES P15 ON THE ENDS OF THE RODS .SEE FIGURE 27.
ATTACH THE HANDLES P15 ON THE ENDS OF THE RODS WITH SCREW H12.SEE FIGURE 28.
19. ATTACH SCORER P16 AND P17 TO END PANEL WITH SCREW H13.SEE FIGURE 30-32.
29
30
31
27
28
P15
32
H13
P17
H13
P17
H13
P16
H12
P16

KICKFoosballTables.com I (866)-844-KICK (5425) I [e-mail]
11
Now that you have completed the assembly
Successfully, you can now enjoy hours of
Endless fun with new
Kick Foosball TABLE
